Good Way card reader User manual

USB3.0 SD Card Reader
User’s Manual

Multi Card Reader User’s Manual
Safety Instructions
Always read the safety instructions carefully
Keep this User’s Manual for future reference
Keep this equipment away from humidity
If any of the following situation arises, get the equipment checked by a service technician:
•The equipment has been exposed to moisture.
•The equipment has been dropped and damaged.
•The equipment has obvious sign of breakage.
•The equipment has not been working well or you cannot get it work according to User’s
Manual.
Copyright Statement
No part of this publication may be reproduced in any form by any means without the prior written
permission. Other trademarks or brand names mentioned herein are trademarks or registered
trademarks of their respective companies.
Disclaimer
Information in this document is subject to change without notice. The manufacturer does not make
any representations or warranties (implied or otherwise) regarding the accuracy and completeness
of this document and shall in no event be liable for any loss of profit or any commercial damage,
including but not limited to special, incidental, consequential, or other damage.
i

Table of Contents
Table of Contents
1. Introduction.......................................................................................................3
Features..............................................................................................................3
Package Contents...............................................................................................3
System Requirements.........................................................................................3
LED Status..........................................................................................................3
2 Specifications.....................................................................................................4
3. Regulatory Compliance....................................................................................5
FCC Conditions ..................................................................................................5
CE.......................................................................................................................5
WEEE Information ..............................................................................................5
ii

1. Introduction
1. Introduction
This USB 3.0 SD card reader controller is based upon universal Serial Bus 3.0
specification, which integrates USB3.0 & USB2.0 Transceiver, MCU, SIE regulator and
memory card access units into a single chip. It can link in Super speed, High Speed, or
Full Speed operation and support USB2.0/USB3.0 power saving mode. Beside, this
also supports both the internal MCU program ROM, and external serial flash memory
interface. With the external serial flash memory interface, the firmware could be easily
updated through USB link.
This SD card reader integrate all regulator, clock generation circuitry and MOSFET
components for switching card power, and also dramatically reduce the system cost.
Package Contents
Before installation, please check the items of the package.
SD Card Reader x1
User Manual x1
System Requirements
Support full USB 3.0 speed at Windows®7, Windows Vista®, Windows®XP
3

Multi Card Reader User’s Manual
LED Status
LED Color Description
Power Green On: To confirm a proper connection.
4

2. Specifications
2. Specifications
USB compliance
- Comply with USB3.0
- Comply with USB2.0 rev 2.0
- Comply with USB Mass storage class specification rev 1.0
-Comply with SD part 1 Physical Layer specification Version 3.0
- Comply with Multimedia Card system Specification version 4.4
Memory card support
- Support Secure Digital (SD) Multi Media Card (MMC), Mini SD, Micro SD
(T-Flash), SDHC, SDXC (up to 2TB), RS-MMC, Mobile MMC and
MMC-Micro
Support SD card clock 208MHz (max.) forSDR104 mode.
Support SD card clock 100 MHz (Max.) for SDR50 Model.
Support SD card clock 50MHz (max.) for DDR50 model.
Support Hardware ECC (Error Correction Code)
Support Hardware CRC (Cyclic Redundancy Check) function
USB Bus power operation
Support USB2.0/USB3.0 power saving mode.
Support control, Bulk IN/OUT data pipes.
Integrated Fast 8051 processor.
External serial EEPROM 93C46 interface.
Support Spread Spectrum Clock for SD/MMC to reduce EMI effect.
Storage Temperature: -10 ℃to +60℃
5

Multi Card Reader User’s Manual
3. Regulatory Compliance
FCC Conditions
This equipment has been tested and found to comply with Part 15 of the FCC
Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference
(2) This device must accept any interference received. Including interference that
may cause undesired operation.
CE
This equipment is in compliance with the requirements of the following regulations:
EN 55 022: CLASS B
WEEE Information
For EU (European Union) member users:
According to the WEEE (Waste electrical and electronic equipment) Directive, do not
dispose of this product as household waste or commercial waste. Waste electrical and
electronic equipment should be appropriately collected and recycled as required by
practices established for your country. For information on recycling of this product,
please contact your local authorities, your household waste disposal service or the shop
where you purchased the product.
6
