GoodHome 5059340213811 User manual

5059340213811
GHCOM50a
Bamia
V10821 BX220IM
213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 1213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 1 18-08-2021 12:23:3218-08-2021 12:23:32

02
EN Contents FR Contenu
PL Zawartość RO Cuprins
Installation 04
FR Installation 04
PL Instalacja 04
RO Instalare 05
Use 16
FR Utilisation 31
PL Użytkowanie 47
RO Utilizare 63
Care and maintenance 79
FR Entretien et maintenance 81
PL Czyszczenie i konserwacja 83
RO Îngrijire şi întreţinere 85
213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 2213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 2 18-08-2021 12:23:3218-08-2021 12:23:32

x ?
[01] x 1 [02] x 1 [03] x 2 [04] x 2
[05] x 1 [06] x 1 [07] x 1 [08] x 1
[09] x 1 [10] x 2 [11] x 2 [12] x 2
EN IMPORTANT - Please read carefully the separate safety guide before use.
FR IMPORTANT - Lire attentivement le guide de sécurité séparé avant utilisation.
PL WAŻNE - Przed użyciem proszę dokładnie zapoznać się z instrukcją bezpieczeństwa.
RO IMPORTANT - Vă rugăm să citiţi cu atenţie ghidul de siguranţă separat înainte de utilizare.
213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 3213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 3 18-08-2021 12:23:3318-08-2021 12:23:33

04
EN Before you start
This appliance must be installed correctly by a qualified person, strictly following the manufacturer’s instructions.
Warning: Danger of electric shock! The power supply must be cut off before the appliance is installed completely.
Only a qualified person in compliance with the instructions provided can install the appliance. The manufacturer
declines all responsibility for improper installation, which may harm persons and animals and cause damage.
Check the package and make sure you have all of the parts listed.
Decide on the appropriate location for the appliance.
This appliance contains glass. Please take care when fitting or handling to prevent personal injury or damage to
the appliance.
The specifications plate is available on this appliance. This plate displays all the necessary identification
information for ordering replacement parts.
If you sell the appliance, give it away, or leave it behind when you move house, make sure you also pass on this
manual so that the new owner can become familiar with the appliance and its safety warnings.
FR Avant de commencer
Cet appareil doit être correctement installé par une personne qualifiée, en suivant rigoureusement les instructions
du fabricant.
Avertissement: Risque de choc électrique ! L’alimentation électrique doit être coupée avant que l’appareil ne soit
installé complètement.
Seule une personne qualifiée peut installer l’appareil, conformément aux instructions fournies. Le fabricant décline
toute responsabilité en cas d’installation incorrecte susceptible de blesser des personnes et des animaux et de
provoquer des dommages.
Vérifier l’emballage et s’assurer qu’il contient toutes les pièces énumérées.
Choisir un emplacement approprié pour l’appareil.
Cet appareil contient du verre. Rester prudent lors du montage ou de la manipulation pour éviter toute blessure ou
tout dommage de l’appareil.
La plaque signalétique est disponible sur cet appareil. Cette plaque affiche toutes les informations d’identification
nécessaires pour commander des pièces de rechange.
Si l’appareil est vendu, donné ou laissé suite à un déménagement, s’assurer de transmettre ce manuel de façon à
ce que le nouveau propriétaire puisse se familiariser avec l’appareil et les avertissements de sécurité.
PL Przed rozpoczęciem użytkowania
To urządzenie musi zostać prawidłowo zamontowane przez wykwalifikowaną osobę, ściśle przestrzegającą
instrukcji producenta.
Ostrzeżenie: Niebezpieczeństwo porażenia prądem elektrycznym! Zasilanie musi być odcięte do momentu
zakończenia montażu urządzenia.
Urządzenie może zamontować wyłącznie wykwalifikowana osoba, postępując zgodnie z dostarczoną instrukcją.
Producent nie ponosi żadnej odpowiedzialności za nieprawidłowy montaż, który może spowodować obrażenia u
ludzi i zwierząt lub uszkodzenia mienia.
Sprawdzić zawartość opakowania i upewnić się, że zawiera części wymienione w specyfikacji.
Wybrać odpowiednie miejsce ustawienia urządzenia.
Urządzenie zawiera elementy szklane. Podczas montażu lub obsługi należy zachować ostrożność, aby uniknąć
obrażeń ciała i uszkodzeń urządzenia.
Na urządzeniu jest umieszczona tabliczka znamionowa. Tabliczka zawiera wszystkie dane identyfikacyjne
niezbędne do zamówienia części zamiennych.
W przypadku sprzedaży urządzenia lub przeprowadzki należy oddać tabliczkę lub pozostawić ją na swoim miejscu.
Należy również przekazać niniejszą instrukcję obsługi nowemu właścicielowi, aby umożliwić mu zaznajomienie się
z urządzeniem i ostrzeżeniami dotyczącymi bezpieczeństwa.
EN Installation FR Installation PL Instalacja
213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 4213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 4 18-08-2021 12:23:3318-08-2021 12:23:33

05
RO Înainte de a începe
Acest aparat trebuie instalat corespunzător de o persoană calificată, urmând cu strictețe instrucțiunile producătorului.
Avertisment: Pericol de electrocutare! Alimentarea trebuie întreruptă înainte de montarea completă a aparatului.
Aparatul trebuie instalat numai o persoană calificată, în conformitate cu instrucțiunile furnizate. Producătorul nu
își asumă nicio responsabilitate pentru instalarea necorespunzătoare, care poate cauza rănirea persoanelor și
a animalelor și poate cauza prejudicii.
Verificați ambalajul și asigurați-vă că aveți toate piesele specificate.
Stabiliți amplasarea corespunzătoare pentru aparat.
Acest aparat conține sticlă. Aveți grijă la montare sau manipulare pentru a preveni vătămările corporale sau
deteriorarea aparatului.
Plăcuța cu specificații este disponibilă pe aparat. Pe plăcuță sunt afișate toate informațiile de identificare necesare
pentru comandarea pieselor de schimb.
Dacă vindeți, donați sau lăsați în urmă aparatul când vă mutați în altă casă, predați și acest manual noului proprietar,
pentru ca acesta să se familiarizeze cu aparatul și cu avertismentele de siguranță.
RO Instalare
01
≤10 mm
595 mm
565 mm
545 mm
20 mm
560 mm
450 mm
454 mm
452 mm
550 mm
20 mm
454 mm
213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 5213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 5 18-08-2021 12:23:3318-08-2021 12:23:33

06
EN Installation of Built-in Ovens
For correct installation, this appliance can be fitted in a tall appliance housing unit only.
Caution! The panels of the adjacent cabinets must be made of heat-resistant material.
In particular, the adhesive that bonds the plastic laminate to the furniture must be able to withstand
temperatures of not less than 120ºC to avoid delamination. The appliance must be housed in
heat-resistant cabinets.
Be sure to observe the minimum installation height of the kitchen unit. Pay attention to the minimum
dimensions of the openings.
Remove the back of the kitchen unit to ensure an adequate current of air circulates around the appliance.
FR Installation de fours intégrables
Pour une installation correcte, cet appareil ne peut être monté que dans un logement d’appareil de
grande taille.
Attention! Les panneaux des éléments de cuisine adjacents doivent être conçus à partir de matériaux
résistants à la chaleur.
La colle permettant de fixer le plastique stratifié aux meubles doit pouvoir résister à une température
minimale de 120ºC afin d’éviter le décollement. L’appareil doit être installé dans des éléments résistants
à la chaleur.
Penser à respecter la hauteur minimale d’installation de l’unité de cuisine. Faire attention aux dimensions
minimales des ouvertures.
Retirer le fond de l’élément de cuisine pour garantir qu’un courant d’air approprié circule autour de l’appareil.
PL Montaż piekarników do zabudowy
Urządzenie może zostać zamontowane jedynie w wysokiej zabudowie na urządzenia AGD.
Uwaga! Płyty sąsiednich szafek muszą być wykonane z materiału odpornego na wysokie temperatury.
Aby uniknąć delaminacji, klej mocujący laminat z tworzywa sztucznego do mebla musi być odporny
na temperaturę co najmniej 120ºC. Urządzenie musi być umieszczone w szafce odpornej na
wysokie temperatury.
Należy zwrócić uwagę na minimalną wysokość montażową zabudowy kuchennej. Zwrócić uwagę na
minimalne wymiary otworów.
Zdjąć tylną płytę zabudowy kuchennej, aby zapewnić odpowiedni obieg powietrza wokół urządzenia.
EN Installation FR Installation
PL Instalacja RO Instalare
45 mm
125 mm
600 mm
125 mm
45 mm
450-452 mm
560-568 mm
560-568 mm
550 mm
460-462 mm
560-568 mm
560-568 mm
50 mm
45 mm
213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 6213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 6 18-08-2021 12:23:3318-08-2021 12:23:33

07
RO Instalarea cuptoarelor încorporate
Pentru instalare corectă, aparatul poate fi montat doar într-o carcasă de cuptor înaltă.
Atenție! Panourile dulapurilor adiacente trebuie să fie fabricate din material termorezistent.
În mod special, pentru a evita exfolierea, adezivul care fixează folia laminată de mobilier trebuie să poată
suporta temperaturi ce depășesc 120ºC. Aparatul trebuie încorporat într-un dulap termorezistent.
Respectați înălțimea minimă de instalare a corpului de bucătărie. Respectați dimensiunile minime ale golurilor.
Îndepărtați partea din spate a corpului de bucătărie pentru a asigura o circulație corespunzătoare
a aerului în jurul aparatului.
EN Important: Do not lift the appliance by the door handle to avoid potential damage to the glass and hinges.
Caution! If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
FR Important: Ne pas soulever l’appareil par la poignée de la porte afin d’éviter tout dommage potentiel au
niveau du verre et des charnières.
Attention ! Si le cordon d’alimentation est endommagé, il doit être remplacé par le fabricant,
son prestataire de service ou une personne qualifiée afin d’éviter tout accident.
PL Ważne: Nie należy unosić urządzenia, trzymając za uchwyt drzwi, aby uniknąć uszkodzenia szyby oraz
zawiasów.
Uwaga! Jeśli dojdzie do uszkodzenia przewodu zasilania, powinien on zostać wymieniony przez
producenta, przedstawiciela serwisowego lub inną osobę o podobnych kwalifikacjach, aby uniknąć
zagrożeń.
RO Important: Nu ridicați aparatul ținând-l de mânerul ușii, pentru a evita posibilele deteriorări ale sticlei și
balamalelor.
Atenție! În cazul în care cablul de alimentare este deteriorat, acesta trebuie înlocuit de producător,
agentul de service sau persoane cu un nivel de calificare similar pentru evita o situație periculoasă.
02
EN Installation FR Installation
PL Instalacja RO Instalare
213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 7213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 7 18-08-2021 12:23:3318-08-2021 12:23:33

08
03
[10] x 2
[11] x 2
[12] x 2
EN Once the oven has been lifted into place inside the appliance housing, locate the two holes in the casing of
the oven and fix it into place using [10], [11] and [12].
Caution: Do not over tighten the screws [10] to avoid damage to the oven or appliance
housing - use a screwdriver only!
FR Une fois le four placé dans le logement prévu à cet effet, repérer les deux trous de l’enveloppe du four et
les fixer à l’aide de [10], [11] et [12].
Attention: Ne pas trop serrer les vis [10] pour éviter d’endommager le four ou le logement de l’appareil.
Utiliser uniquement un tournevis !
PL Po umieszczeniu piekarnika we właściwym miejscu wewnątrz zabudowy zlokalizować dwa otwory
w obudowie piekarnika i zamocować go za pomocą elementów [10], [11] i [12].
Przestroga: Nie dokręcać zbyt mocno śrub [10] aby uniknąć uszkodzenia piekarnika lub
zabudowy - używać wyłącznie wkrętarka!
RO După ce cuptorul a fost ridicat pe poziție în carcasa aparatului, localizați cele două orificii din carcasa
cuptorului și fixați-l pe poziție folosind [10], [11] și [12].
Atenție: Nu strângeți excesiv șuruburile [10] pentru a evita deteriorarea cuptorului sau
a carcasei - folosiți o șurubelniță!
[12] [10]
11
EN Installation FR Installation
PL Instalacja RO Instalare
213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 8213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 8 18-08-2021 12:23:3418-08-2021 12:23:34

09
04
05 [06][05]
[03]
[04]
1
2
3
1
2
3
EN Installation of the ceramic clips and side rails
FR Installation des clips en céramique et des rails latéraux
PL Montaż i zacisków ceramicznych prowadnic bocznych
RO Instalarea clemelor ceramice și a șinelor laterale
[03] x 2
[04] x 2
[05] x 1
[06] x 1
EN Installation FR Installation
PL Instalacja RO Instalare
213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 9213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 9 18-08-2021 12:23:3418-08-2021 12:23:34

10
06
07
EN Left side rail installation [05]
FR Installation du rail latéral gauche [05]
PL Montaż lewej prowadnicy [05]
RO Instalarea șinei laterale stângi [05]
[04]
[05]
[03]
[05]
[03]
[04]
[05] x 1
EN Installation FR Installation
PL Instalacja RO Instalare
213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 10213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 10 18-08-2021 12:23:3518-08-2021 12:23:35

11
08
09
[04]
[05]
[03]
EN Right side rail installation [06]
FR Installation du rail latéral droit [06]
PL Montaż prawej prowadnicy [06]
RO Instalarea șinei laterale drepte [06]
[03]
[04]
[06]
EN Installation FR Installation
PL Instalacja RO Instalare
213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 11213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 11 18-08-2021 12:23:3518-08-2021 12:23:35

12
10
11
[06]
[03] [04]
[06]
[03] [04]
EN Installation FR Installation
PL Instalacja RO Instalare
213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 12213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 12 18-08-2021 12:23:3518-08-2021 12:23:35

13
EN Installation FR Installation
EN Installation
All installation must be carried out by a competent person or qualified electrician. Before connecting the mains
supply ensure that the mains voltage corresponds to the voltage on the rating plate.
Direct Connection
The appliance must be connected directly to the mains using an omnipolar circuit breaker with a minimum opening
of 3mm between the contacts.
The installer must ensure that the correct electrical connection has been made and that it complies with the
wiring diagram.
The cable must not be bent or compressed.
Regularly check the power cord for damage. If the supply cord becomes damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
WARNING: This is a Class I appliance and MUST be earthed.
The appliance is supplied with a 3-core mains cable and must be connected to the electricity supply via a double
pole switch having a 3mm minimum contact gap on each connector.
This appliance should be connected directly to the consumer unit with a 16Amp Residual Current Device (RCD)
protecting its circuit.
The wires in the mains lead are coloured in accordance with the following code:
Brown = L - Live
Blue = N - Neutral
Green and Yellow = - Earth
To avoid the risks that are always present when you use an electrical appliance it is important that this appliance
is installed correctly and that you read the safety instructions carefully to avoid misuse and hazards. Please keep
this instruction booklet for future reference and pass it on to any future owners. After unpacking the appliance
please check that it is not damaged. If in doubt, do not use the appliance but contact Customer Services - see end
of Care & Maintenance section for details.
FR Installation électrique
L’intégralité de l’installation doit être effectuée par une personne compétente ou un électricien qualifié. Avant
de raccorder le câble d’alimentation, s’assurer que la tension de secteur correspond à la tension indiquée sur la
plaque signalétique.
Raccordement direct
L’appareil doit être raccordé directement au secteur à l’aide d’un disjoncteur omnipolaire présentant une
ouverture minimale de 3mm entre les contacts.
L’installateur doit s’assurer que le bon raccordement électrique a été effectué et qu’il respecte le schéma de câblage.
Le câble ne doit pas être plié ou comprimé.
Vérifier régulièrement que le cordon d’alimentation n’est pas endommagé. Si le cordon d’alimentation est
endommagé, il doit être remplacé par le fabricant, son prestataire de service ou une personne qualifiée afin
d’éviter tout accident.
AVERTISSEMENT: Il s’agit d’un appareil de ClasseI. Il DOIT être raccordé à la terre.
L’appareil est livré avec un câble secteur à 3conducteurs principaux. Il doit être relié à l’alimentation électrique via
un interrupteur bipolaire présentant un écart minimal de 3mm entre chaque raccord.
Cet appareil doit être raccordé directement au tableau électrique par l’intermédiaire d’un dispositif différentiel à
courant résiduel (DDR) de 16A protégeant son circuit.
Les fils du cordon d’alimentation secteur présentent le code couleur suivant:
Marron=L-Phase
Bleu=N-Neutre
Vert et jaune= -Terre
213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 13213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 13 18-08-2021 12:23:3518-08-2021 12:23:35

14
FR Installation PL Instalacja
Afin de prévenir les risques toujours présents lors de l’utilisation d’un appareil électrique, il est important d’installer
correctement cet appareil et de lire les instructions de sécurité soigneusement en vue d’empêcher tout danger
ou mauvaise utilisation. Veiller à conserver ce manuel d’instructions pour référence ultérieure et à le transmettre
à tout futur propriétaire. Après avoir déballé l’appareil, vérifier qu’il n’est pas endommagé. En cas de doute, ne pas
utiliser l’appareil et contacter le service client; voir la fin de la section Entretien et maintenance pour plus de détails.
PL Instalacja elektryczna
Montaż musi zostać wykonany przez osobę kompetentną lub wykwalifikowanego elektryka. Przed podłączeniem
zasilania upewnić się, czy napięcie zasilania odpowiada napięciu na tabliczce znamionowej.
Podłączenie bezpośrednie
Urządzenie należy podłączyć bezpośrednio do sieci zasilającej, korzystając z wyłącznika wielobiegunowego
o minimalnym odstępie między stykami wynoszącym 3mm.
Monter powinien upewnić się, czy zostało wykonane odpowiednie połączenie elektryczne oraz czy jest ono
zgodne ze schematem połączeń.
Przewód nie może być zagięty ani przygnieciony.
Należy regularnie sprawdzać przewód zasilania pod kątem uszkodzeń. Jeśli dojdzie do uszkodzenia przewodu
zasilania, powinien on zostać wymieniony przez producenta, przedstawiciela serwisowego lub inną osobę
o podobnych kwalifikacjach, aby uniknąć zagrożeń.
OSTRZEŻENIE: Jest to urządzenie klasy I i MUSI być uziemione.
Urządzenie jest wyposażone w 3-żyłowy przewód zasilania i musi być podłączone do źródła zasilania za pomocą
wyłącznika dwubiegunowego o minimalnym odstępie między stykami wynoszącym 3mm na każdym złączu.
Urządzenie należy podłączyć bezpośrednio do tablicy rozdzielczej poprzez wyłącznik różnicowoprądowy (RCD)
oobciążalności 16 A.
Żyły w przewodzie zasilania są oznaczone następującymi kolorami:
Brązowy = L — faza
Niebieski = N — neutralny
Zielono-żółty = - uziemienie
Aby ograniczyć do minimum ryzyko związane z użytkowaniem urządzenia elektrycznego, niezwykle ważne
jest, aby produkt został prawidłowo zamontowany oraz aby użytkownik dokładnie zapoznał się z instrukcjami
dotyczącymi bezpieczeństwa i unikał nieprawidłowej obsługi oraz związanych z tym zagrożeń. Należy zachować
instrukcję obsługi w celu wykorzystania w przyszłości i przekazania jej kolejnym właścicielom. Po rozpakowaniu
urządzenia upewnić się, że nie jest ono uszkodzone. W przypadku wątpliwości nie używać urządzenia
i skontaktować się z działem obsługi klienta. Więcej szczegółowych informacji znajduje się na końcu części
Czyszczenie i konserwacja.
213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 14213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 14 18-08-2021 12:23:3518-08-2021 12:23:35

15
RO Instalare
RO Conectarea la alimentarea electrică
Instalarea trebuie să fie realizată în totalitate de o persoană competentă sau de un electrician calificat. Înainte
de conectarea la rețeaua electrică, asigurați-vă că tensiunea rețelei corespunde cu tensiunea de pe plăcuța de
identificare.
Conexiune directă
Aparatul trebuie conectat direct la rețea cu ajutorul unui disjunctor omnipolar cu o deschidere minimă între
contacte de 3mm.
Instalatorul trebuie să se asigure că a realizat corect legăturile electrice și că a respectat schema electrică.
Cablul nu trebuie să fie îndoit sau comprimat.
Verificați periodic cablul de alimentare pentru a depista deteriorările. În cazul în care cablul de alimentare se
deteriorează, acesta trebuie înlocuit de producător, agentul de service sau persoane cu un nivel de calificare
similar, pentru evita o situație periculoasă.
AVERTISMENT: Acesta este un aparat Clasa I și TREBUIE împământat.
Aparatul dispune de un cablu de alimentare cu 3fire conductoare și trebuie conectat la sursa de alimentare
printr-un întrerupător bipolar, cu o distanță minimă între contacte de 3mm la fiecare conector.
Aparatul trebuie conectat direct la unitatea consumatoare cu un dispozitiv de protecție la curent rezidual (RCD)
de 16 A care să-i protejeze circuitul.
Firele din cablul de alimentare sunt colorate conform codificării de mai jos:
Maro = L - Fază
Albastru = N - Nul
Verde și galben = - Împământare
Pentru a evita riscurile aferente utilizării unui echipament electric, este important ca acest aparat să fie instalat
corect și să citiți cu atenție instrucțiunile de siguranță, ca să evitați utilizarea greșită și pericolele. Păstrați această
broșură cu instrucțiuni pentru consultare ulterioară și predați-o proprietarilor viitori. După despachetarea
aparatului, verificați să nu fie deteriorat. Dacă aveți îndoieli, nu folosiți aparatul, ci contactați Serviciul de asistență
clienți - a se vedea sfârșitul secțiunii Îngrijire și întreținere pentru detalii.
213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 15213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 15 18-08-2021 12:23:3618-08-2021 12:23:36

16
EN Before you start
WARNING: Read the instructions before using the appliance.
Switch on the appliance at the switched fused connection unit. The appliance will beep once and is ready for use.
Function and setting
6
3
7
9
1
8
2
4
5
1 Control panel
2 Fixing holes (x 2)
3 Oven lamp
4 Fan
5Door
6 Carrying handles (x 2)
7 Side rails (x 2)
8 Mains cable (at rear, not shown)
9 Door handle
Control Panel
19:45
1 2 3
12
4
5
8
6
9
710
11
Thusday, 21 June
Thusday, 21 June
EN Use
213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 16213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 16 18-08-2021 12:23:3618-08-2021 12:23:36

17
1 Master On/Off Key 5 Cooking Mode Key 9 Master Settings Key
2 Left Touch Screen 6 Defrost Mode Key 10 Oven Light Key
3360º Control Knob (Push to eject or hide) 7 Microwave Mode Key 11 Child Lock Key
4 Right Touch Screen 8 Presets Mode Key 12 Time and Date Display
Turning the oven on and off
Touch the Master On/Off Key once to turn on the oven, and once more to turn it off. The oven will beep once to
confirm in each case.
After ten minutes of inactivity, the oven will automatically turn itself off.
Once the oven has started up, both touch screens will be displayed as above.
Using the touch screens
Setting up the oven for first use
From the main menu of the Left Touch Screen, touch the Master Settings Key .
NOTE: It is normal for the Right Touch Screen to dim during various functions such as when Settings are altered.
6
2 5
7
1
3 4
Settings
1 Exit Master Settings Key
2 Clock Key
3 Date Key
4 Language Key
5 Display Brightness Key
6 Master Volume Key
7 Factory Reset Key
Setting the time
1. Touch the Clock Key and the hour and minute digits appear on the Right Touch Screen.
2. Rotate the 360º Control Knob to select the hours from 0-23.
3. Touch the minute display and rotate the 360º Control Knob to select the minutes from 0-59.
4. Touch the Tick twice to store the time.
Setting the date
1. Touch the Date Key and the date, month and year appear on the Right Touch Screen.
2. Swipe up or down in each column to choose the correct date.
3. Touch the Tick twice to store the date.
Setting the language
1. Touch the Language Key and the country options appear on the Right Touch Screen.
2. Swipe up or down to choose the correct language.
3. Touch the Tick twice to store the language.
EN Use
213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 17213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 17 18-08-2021 12:23:3618-08-2021 12:23:36

18
Setting the display brightness
1. Touch the Display Brightness Key and the control appears on the Right Touch Screen.
2. Rotate the 360º Control Knob to select the brightness from 0-9. Default brightness is 8.
3. Touch the Tick twice to store the brightness.
Setting the alert volume
1. Touch the Master Volume Key and the control appears on the Right Touch Screen.
2. Rotate the 360º Control Knob to select the volume from 0-3. Default volume is 3.
3. Touch the Tick twice to store the volume.
Reset to factory default options
1. Touch the Factory Reset Key and the reset message appears on the Right Touch Screen.
2. Touch the Tick or Cross to reset or cancel and return to the Settings menu.
Using your oven
Before first use
• Remove all stickers, surface protection foils and packing materials.
• Remove all accessories and the side racks from the cavity.
• Clean the appliance cavity and all accessories as described in Care and maintenance.
• Turn the oven on, choose Standard mode and set the temperature to 250ºC. Close the door and cook for one
hour to burn off any remaining manufacturing residues. (See the section “Choosing a Cooking Mode” below.)
IMPORTANT: Keep the kitchen well ventilated during this first use to help disperse the odours produced.
Keep kitchen doors closed and ensure children and pets are not present.
Cooking Modes
IMPORTANT: Do not use any metallic accessories or cooking utensils when using a mode that includes microwave
heating and MWO is switched on in the Cooking Mode Control Panel (see Cooking Mode Controls below).
Use the supplied glass shelf in the lowest rack position along with microwave proof accessories. The door must be
fully closed to start cooking.
Choosing a Cooking Mode
• From the Main Menu, choose the Cooking Mode Key to enter the Heating Menu.
• The Cooking Mode options are now shown on the Left Touch Screen.
Heating
• Touch the icon of the required Cooking Mode from the table below and the two displays will now show the
individual controls available in that mode.
TURN AND TOUCH
Quick Tip: From the Main Menu, just turn the 360º Control Knob clockwise or anti-clockwise and you will gain
instant access to the Standard Cooking Mode at its default temperature of 180ºC. Touch the Start Cooking Key
and the oven will start instantly.
EN Use
213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 18213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 18 18-08-2021 12:23:3618-08-2021 12:23:36

19
Icon Mode Temperature Range
(default) Microwave Power (default) Description
Standard 100-235ºC in 5ºC
increments (180ºC) Not applicable
Traditional static heat from upper and
lower heating elements ensures that
the foods remain moist when cooked
for longer periods of time. Ideal for slow
baked cakes and soufflés.
Convection 100-250ºC 5ºC
increments (160ºC)
100/300/500W
(300W)
A heating element around the convection
fan provides an additional source of
heat for convection style cooking. In
convection mode the fan automatically
comes on to improve air circulation within
the oven and creates an even heat for
cooking. This mode is suitable for cakes,
pastry and to roast meat when you want
it well cooked on the outside and tender
in the middle. No pre-heating is required
when using this mode and additional
microwave cooking is also available.
Pizza 100-250ºC in 5ºC
increments (180ºC)
100/300/500W
(300W)
Ideal for pizza and dishes which need
a lot of heat from underneath. The lower
element and circular convection element
are both used and additional microwave
cooking is also available.
Fanned 100-235ºC in 5ºC
increments (160ºC) Not applicable
Combination of the fan and both heating
elements provides more even heat
penetration, saving up to 30-40% of
energy. Dishes are lightly browned on
the outside and still moist on the inside.
Ideal for grilling or roasting large pieces
of meat at a higher temperature.
Grill 100-235ºC in 5ºC
increments (150ºC) Not applicable
Only the upper heating element is
working.
Best results are achieved by using the top
shelf for smaller foods and a lower shelf
for larger foods. Ideal for rapid cooking
and browning.
Grill & Fan 100-250ºC in 5ºC
increments (180ºC)
100/300/500W
(300W)
The inner heating element and the
upper heating element are both working
together with the fan.
Best results are achieved by using the
top shelf for smaller foods and a lower
shelf for larger foods. The fan lessens
the strong heat from the upper heating
element creating more even browning and
heat distribution, without drying out foods.
Ideal for rapid cooking and browning and
additional microwave cooking is also
available.
EN Use
213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 19213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 19 18-08-2021 12:23:3718-08-2021 12:23:37

20
EN Use
Icon Mode Temperature Range
(default) Microwave Power (default) Description
Double grill 100-235ºC in 5ºC
increments (180ºC) Not applicable
The inner heating element and the upper
heating element are both working. Ideal
for grilling flat items and for browning
foods.
Bottom 100-235ºC in 5ºC
increments (150ºC) Not applicable
Only the lower heating element is working.
Ideal for pies or pastries where a crispy
base is desired. Also suitable for slow
cooking of stews and casseroles.
Practical cooking advice
• This appliance offers a wide range of alternatives which allow you to cook any type of food in the best possible
way. With time you will learn to make the best use of this versatile appliance and the following directions are
a guideline which may be varied to suit your personal needs.
• Read the information on the food packaging for guidance on recommended cooking times and temperatures.
Once familiar with the performance of the appliance, the temperatures and times may be varied to adapt them
to your personal tastes.
• Check that frozen food is completely thawed before cooking, unless instructed otherwise.
STANDARD
Food Temperature setting (ºC) Recommended shelf
position from the bottom Cooking time in minutes
Small cakes 175 - 185ºC 4 16 - 19
Sponge cake 180 - 185ºC 2 20 - 25
Pizza 205 - 210ºC 3 18 - 23
Apple yeast cake 185 - 195ºC 4 25 - 50
CONVECTION
Food Temperature setting (ºC) Recommended shelf
position from the bottom Cooking time in minutes
Small cakes
(single layer) 165 - 170ºC 2 20 - 23
Sponge cake 160 - 165ºC 2 30 - 40
Pizza 170 - 175ºC 2 19 - 25
Apple yeast cake
(single layer) 170 - 175ºC 2 60 - 70
Small cakes
(double layer) 165 - 170ºC 2 (deep tray) 20 - 23
4 (shallow tray)
Apple yeast cake
(double layer) 170 - 175ºC 2 (deep tray) 65 - 75
4 (shallow tray)
213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 20213170_s2_s8_5059340213811_GoodHome_A5_IM_Multi_V02.indd 20 18-08-2021 12:23:3718-08-2021 12:23:37
