GoodHome bamia GHCOM50 User manual

bamia
V10519
GHCOM50
3663602434412

EN Contents FR Table des matières
PL Spis treści RO Cuprins
FR Installation 05
PL Montaż 05
RO Instalare 05
Installation 05
FR Entretien et maintenance 67
PL Czyszczenie i konserwacja 68
RO Îngrijire și întreținere 70
Care and
Maintenance 66
FR Préparation 03
PL Czynności wstępne 03
RO Pregătire 03
Preparation 03
FR Utilisation 27
PL Użytkowanie 40
RO Utilizare 53
Use 15

x 2
EN IMPORTANT - Please read
carefully the separate
safety guide before use.
FR IMPORTANT: veiller à lire
attentivement le guide de
sécurité avant utilisation.
PL WAŻNE — przed
użyciem należy się
uważnie zapoznać z
dołączonymi oddzielnie
informacjami dotyczącymi
bezpieczeństwa.
RO IMPORTANT - Citiți cu
atenție ghidul separat
privind siguranța înainte de
utilizarea produsului.
[02] x 1[01] x 1 [05] x 1
[06] x 1 [07] x 1 [08] x 1 [09] x 1
[03] x 2 [04] x 2
[10] x 2 [11] x 2 [12] x 2

04
EN Installation FR Installation
PL Montaż RO Instalare
EN This appliance must be installed correctly by a qualified person, strictly following the manufacturer’s instructions.
Warning: Danger of electric shock! The power supply must be cut off before the appliance is installed completely.
Only a qualified person in compliance with the instructions provided can install the appliance. The manufacturer
declines all responsibility for improper installation, which may harm persons and animals and cause damage.
Check the package and make sure you have all of the parts listed.
Decide on the appropriate location for the appliance.
This appliance contains glass. Please take care when fitting or handling to prevent personal injury or damage to
the appliance.
The specifications plate is available on this appliance. This plate displays all the necessary identification
information for ordering replacement parts.
If you sell the appliance, give it away, or leave it behind when you move house, make sure you also pass on this
manual so that the new owner can become familiar with the appliance and its safety warnings.
FR Cet appareil doit être correctement installé par une personne qualifiée, en suivant rigoureusement les
instructions du fabricant.
Avertissement: risque de choc électrique! L’alimentation électrique doit être coupée avant que l’appareil ne soit
installé complètement.
Seule une personne qualifiée peut installer l’appareil, conformément aux instructions fournies. Le fabricant
décline toute responsabilité en cas d’installation incorrecte susceptible de blesser des personnes et des
animaux et de provoquer des dommages.
Vérifier l’emballage et s’assurer qu’il contient toutes les pièces énumérées.
Choisir un emplacement approprié pour l’appareil.
Cet appareil contient du verre. Rester prudent lors du montage ou de la manipulation pour éviter toute blessure
ou tout dommage de l’appareil.
La plaque signalétique est disponible sur cet appareil. Cette plaque affiche toutes les informations
d’identification nécessaires pour commander des pièces de rechange.
Si l’appareil est vendu, donné ou laissé suite à un déménagement, s’assurer de transmettre ce manuel de façon à
ce que le nouveau propriétaire puisse se familiariser avec l’appareil et les avertissements de sécurité.
PL To urządzenie musi zostać prawidłowo zamontowane przez wykwalifikowaną osobę, ściśle przestrzegającą
instrukcji producenta.
Ostrzeżenie: Niebezpieczeństwo porażenia prądem elektrycznym! Zasilanie musi być odcięte do momentu
zakończenia montażu urządzenia.
Urządzenie może zamontować wyłącznie wykwalifikowana osoba, postępując zgodnie z dostarczoną instrukcją.
Producent nie ponosi żadnej odpowiedzialności za nieprawidłowy montaż, który może spowodować obrażenia u
ludzi i zwierząt lub uszkodzenia mienia.
Sprawdzić zawartość opakowania i upewnić się, że zawiera części wymienione w specyfikacji.
Wybrać odpowiednie miejsce ustawienia urządzenia.
Urządzenie zawiera elementy szklane. Podczas montażu lub obsługi należy zachować ostrożność, aby uniknąć
obrażeń ciała i uszkodzeń urządzenia.
Na urządzeniu jest umieszczona tabliczka znamionowa. Tabliczka zawiera wszystkie dane identyfikacyjne
niezbędne do zamówienia części zamiennych.
W przypadku sprzedaży urządzenia lub przeprowadzki należy oddać tabliczkę lub pozostawić ją na swoim
miejscu. Należy również przekazać niniejszą instrukcję obsługi nowemu właścicielowi, aby umożliwić mu
zaznajomienie się z urządzeniem i ostrzeżeniami dotyczącymi bezpieczeństwa.
RO IMPORTANT - Citiți cu atenție ghidul separat privind siguranța înainte de utilizarea produsului.
Acest aparat trebuie instalat corespunzător de o persoană calificată, urmând cu strictețe instrucțiunile
producătorului.
Avertisment: Pericol de electrocutare! Alimentarea trebuie întreruptă înainte de montarea completă a aparatului.
Aparatul trebuie instalat numai o persoană calificată, în conformitate cu instrucțiunile furnizate. Producătorul nu
își asumă nicio responsabilitate pentru instalarea necorespunzătoare, care poate cauza rănirea persoanelor și a
animalelor și poate cauza prejudicii.
Verificați ambalajul și asigurați-vă că aveți toate piesele specificate.
Stabiliți amplasarea corespunzătoare pentru aparat.
Acest aparat conține sticlă. Aveți grijă la montare sau manipulare pentru a preveni vătămările corporale sau
deteriorarea aparatului.
Plăcuța cu specificații este disponibilă pe aparat. Pe plăcuță sunt afișate toate informațiile de identificare
necesare pentru comandarea pieselor de schimb.
Dacă vindeți, donați sau lăsați în urmă aparatul când vă mutați în altă casă, predați și acest manual noului
proprietar, pentru ca acesta să se familiarizeze cu aparatul și cu avertismentele de siguranță.

05
EN Installation FR Installation
PL Montaż RO Instalare
01
595 mm
565 mm
545 mm
20 mm
560 mm
452 mm
450 mm
10 mm
550 mm
20 mm
454 mm
454 mm
560-568 mm
600mm
45 mm
125 mm
125 mm
550
mm
45 mm
450-452 mm
560-568 mm
560-568 mm
50mm
560-568 mm
45 mm
mm
264
-
064

EN Installation of Built-in Ovens
For correct installation, this appliance can be fitted in a tall appliance housing unit only.
Caution! The panels of the adjacent cabinets must be made of heat-resistant material.
In particular, the adhesive that bonds the plastic laminate to the furniture must be able to withstand temperatures
of not less than 120°C to avoid delamination. The appliance must be housed in heat-resistant cabinets.
Be sure to observe the minimum installation height of the kitchen unit. Pay attention to the minimum dimensions
of the openings.
Remove the back of the kitchen unit to ensure an adequate current of air circulates around the appliance.
FR Installation de fours intégrables
Pour une installation correcte, cet appareil ne peut être monté que dans un logement d’appareil de grande taille.
Attention! Les panneaux des éléments de cuisine adjacents doivent être conçus à partir de matériaux résistants
à la chaleur.
La colle permettant de fixer le plastique stratifié aux meubles doit pouvoir résister à une température minimale
de 120°C afin d’éviter le décollement. L’appareil doit être installé dans des éléments résistants à la chaleur.
Penser à respecter la hauteur minimale d’installation de l’unité de cuisine. Faire attention aux dimensions
minimales des ouvertures.
Retirer le fond de l’élément de cuisine pour garantir qu’un courant d’air approprié circule autour de l’appareil.
PL Montaż piekarników do zabudowy
Urządzenie może zostać zamontowane jedynie w wysokiej zabudowie na urządzenia AGD.
Uwaga! Płyty sąsiednich szafek muszą być wykonane z materiału odpornego na wysokie temperatury.
Aby uniknąć delaminacji, klej mocujący laminat z tworzywa sztucznego do mebla musi być odporny na
temperaturę co najmniej 120°C. Urządzenie musi być umieszczone w szafce odpornej na wysokie temperatury.
Należy zwrócić uwagę na minimalną wysokość montażową zabudowy kuchennej. Zwrócić uwagę na minimalne
wymiary otworów.
Zdjąć tylną płytę zabudowy kuchennej, aby zapewnić odpowiedni obieg powietrza wokół urządzenia.
RO Instalarea cuptoarelor încorporate
Pentru instalare corectă, aparatul poate fi montat doar într-o carcasă de cuptor înaltă.
Atenție! Panourile dulapurilor adiacente trebuie să fie fabricate din material termorezistent.
În mod special, pentru a evita exfolierea, adezivul care fixează folia laminată de mobilier trebuie să poată suporta
temperaturi ce depășesc 120°C. Aparatul trebuie încorporat într-un dulap termorezistent.
Respectați înălțimea minimă de instalare a corpului de bucătărie. Respectați dimensiunile minime ale golurilor.
Îndepărtați partea din spate a corpului de bucătărie pentru a asigura o circulație corespunzătoare a aerului în
jurul aparatului.
06
EN Installation FR Installation
PL Montaż RO Instalare
02

07
EN Installation FR Installation
PL Montaż RO Instalare
EN Important: Do not lift the appliance by the door handle to avoid potential damage to the glass and hinges.
Caution! If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
FR Important: ne pas soulever l’appareil par la poignée de la porte afin d’éviter tout dommage potentiel au niveau du
verre et des charnières.
Attention! Si le cordon d’alimentation est endommagé, il doit être remplacé par le fabricant, son prestataire de
service ou une personne qualifiée afin d’éviter tout accident.
PL Ważne: Nie należy unosić urządzenia, trzymając za uchwyt drzwi, aby uniknąć uszkodzenia szyby oraz zawiasów.
Uwaga! Jeśli dojdzie do uszkodzenia przewodu zasilania, powinien on zostać wymieniony przez producenta,
przedstawiciela serwisowego lub inną osobę o podobnych kwalifikacjach, aby uniknąć zagrożeń.
RO Important: Nu ridicați aparatul ținând-l de mânerul ușii, pentru a evita posibilele deteriorări ale sticlei și balamalelor.
Atenție! În cazul în care cablul de alimentare este deteriorat, acesta trebuie înlocuit de producător, agentul de
service sau persoane cu un nivel de calificare similar pentru evita o situație periculoasă.
EN Once the oven has been lifted into place inside the appliance housing, locate the two holes in the casing of the
oven and fix it into place using [10], [11] and [12].
Caution: Do not over tighten the screws [10] to avoid damage to the oven or appliance housing - use a
screwdriver only!
FR Une fois le four placé dans le logement prévu à cet effet, repérer les deux trous de l’enveloppe du four et les fixer
à l’aide de [10], [11] et [12].
Attention: ne pas trop serrer les vis [10] pour éviter d’endommager le four ou le logement de l’appareil. Utiliser
uniquement un tournevis!
PL Po umieszczeniu piekarnika we właściwym miejscu wewnątrz zabudowy zlokalizować dwa otwory w obudowie
piekarnika i zamocować go za pomocą elementów [10], [11] i [12].
Przestroga: Nie dokręcać zbyt mocno śrub [10] aby uniknąć uszkodzenia piekarnika lub zabudowy — używać
wyłącznie wkrętarka!
RO După ce cuptorul a fost ridicat pe poziție în carcasa aparatului, localizați cele două orificii din carcasa cuptorului și
fixați-l pe poziție folosind [10], [11] și [12].
Atenție: Nu strângeți excesiv șuruburile [10] pentru a evita deteriorarea cuptorului sau a carcasei - folosiți o
șurubelniță!
03 [12]
[11]
[10]
[10] x 2
[11] x 2
[12] x 2

04
08
EN Installation FR Installation
PL Montaż RO Instalare
EN Installation of the ceramic clips and side rails
FR Installation des clips en céramique et des rails latéraux
PL Montaż i zacisków ceramicznych prowadnic bocznych
RO Instalarea clemelor ceramice și a șinelor laterale
05
[05] x 1
[06] x 1
1
1
2
2
3
3
[04]
[03]
[
04
]
x
2
[
03] x
2
[05] [06]

09
EN Installation FR Installation
PL Montaż RO Instalare
06 A
06 B
EN Left side rail installation [05]
FR Installation du rail latéral gauche [05]
PL Montaż lewej prowadnicy [05]
RO Instalarea șinei laterale stângi [05]
[05] x 1
[05]
[03]
[04]
[04] [03]
[05]

10
EN Installation FR Installation
PL Montaż RO Instalare
06 C
07 A EN Right side rail installation [06]
FR Installation du rail latéral droit [06]
PL Montaż prawej prowadnicy [06]
RO Instalarea șinei laterale drepte [06]
[05] [03]
[04]
[03]
[04]
[06]

11
EN Installation FR Installation
PL Montaż RO Instalare
07 B
07 C
[04][03] [06]
[06] [04]
[03]

12
EN Installation FR Installation
PL Montaż RO Instalare
EN Electrical Installation
All installation must be carried out by a competent person or qualified electrician. Before connecting the mains supply
ensure that the mains voltage corresponds to the voltage on the rating plate.
Direct Connection
The appliance must be connected directly to the mains using an omnipolar circuit breaker with a minimum opening of
3mm between the contacts.
The installer must ensure that the correct electrical connection has been made and that it complies with the
wiring diagram.
The cable must not be bent or compressed.
Regularly check the power cord for damage. If the supply cord becomes damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
WARNING: This is a Class I appliance and MUST be earthed.
The appliance is supplied with a 3-core mains cable and must be connected to the electricity supply via a double pole
switch having a 3 mm minimum contact gap on each connector.
The Residual Current Device (RCD) must be rated at 16 Amps.
The wires in the mains lead are coloured in accordance with the following code:
Brown = L - Live
Blue = N - Neutral
Green and Yellow = - Earth
EUR UK
N
L
N
L
FUSE ON
DOUBLE POLE SWITCHED
FUSED SPUR OUTLET
USE A 16AMP FUSE
N (Blue)
L (Brown)
(Green/Yellow)
To avoid the risks that are always present when you use an electrical appliance it is important that this appliance is
installed correctly and that you read the safety instructions carefully to avoid misuse and hazards. Please keep this
instruction booklet for future reference and pass it on to any future owners. After unpacking the appliance please
check that it is not damaged. If in doubt, do not use the appliance but contact Customer Services - see end of Care &
Maintenance section for details.
FR Installation électrique
L’intégralité de l’installation doit être effectuée par une personne compétente ou un électricien qualifié. Avant de
raccorder le câble d’alimentation, s’assurer que la tension de secteur correspond à la tension indiquée sur la
plaque signalétique.
Raccordement direct
L’appareil doit être raccordé directement au secteur à l’aide d’un disjoncteur omnipolaire présentant une ouverture
minimale de 3mm entre les contacts.
L’installateur doit s’assurer que le bon raccordement électrique a été effectué et qu’il respecte le schéma
de câblage.
Le câble ne doit pas être plié ou comprimé.
Vérifier régulièrement que le cordon d’alimentation n’est pas endommagé. Si le cordon d’alimentation est endommagé,
il doit être remplacé par le fabricant, son prestataire de service ou une personne qualifiée afin d’éviter tout accident.
AVERTISSEMENT: il s’agit d’un appareil de ClasseI. Il DOIT être raccordé à la terre.
L’appareil est livré avec un câble secteur à 3conducteurs principaux. Il doit être relié à l’alimentation électrique via un
interrupteur bipolaire présentant un écart minimal de 3mm entre chaque raccord.
Le dispositif à courant résiduel (RCD) doit être de 16ampères.
Les fils du cordon d’alimentation secteur présentent le code couleur suivant:
Marron=L-Phase
Bleu=N-Neutre
Vert et jaune= -Terre

EUR UK
N
L
N
L
FUSE ON
BOÎTIER DE DÉRIVATION AVEC FUSIBLES
ET INTERRUPTEUR BIPOLAIRE
UTILISER UN FUSIBLE DE 16A
N (bleu)
L (marron)
(vert/jaune)
Afin de prévenir les risques toujours présents lors de l’utilisation d’un appareil électrique, il est important d’installer
correctement cet appareil et de lire les instructions de sécurité soigneusement en vue d’empêcher tout danger ou
mauvaise utilisation. Veiller à conserver ce manuel d’instructions pour référence ultérieure et à le transmettre à tout
futur propriétaire. Après avoir déballé l’appareil, vérifier qu’il n’est pas endommagé. En cas de doute, ne pas utiliser
l’appareil et contacter le service client; voir la fin de la section Entretien et maintenance pour plus de détails.
PL Instalacja elektryczna
Montaż musi zostać wykonany przez osobę kompetentną lub wykwalifikowanego elektryka. Przed podłączeniem
zasilania upewnić się, czy napięcie zasilania odpowiada napięciu na tabliczce znamionowej.
Podłączenie bezpośrednie
Urządzenie należy podłączyć bezpośrednio do sieci zasilającej, korzystając z wyłącznika wielobiegunowego o
minimalnym odstępie między stykami wynoszącym 3mm.
Monter powinien upewnić się, czy zostało wykonane odpowiednie połączenie elektryczne oraz czy jest ono zgodne ze
schematem połączeń.
Przewód nie może być zagięty ani przygnieciony.
Należy regularnie sprawdzać przewód zasilania pod kątem uszkodzeń. Jeśli dojdzie do uszkodzenia przewodu zasilania,
powinien on zostać wymieniony przez producenta, przedstawiciela serwisowego lub inną osobę o podobnych
kwalifikacjach, aby uniknąć zagrożeń.
OSTRZEŻENIE: Jest to urządzenie klasy I i MUSI być uziemione.
Urządzenie jest wyposażone w 3-żyłowy przewód zasilania i musi być podłączone do źródła zasilania za pomocą
wyłącznika dwubiegunowego o minimalnym odstępie między stykami wynoszącym 3mm na każdym złączu.
Wyłącznik różnicowoprądowy (RCD) musi mieć wartość znamionową 16A.
Żyły w przewodzie zasilania są oznaczone następującymi kolorami:
Brązowy = L — faza
Niebieski = N — neutralny
Zielono-żółty = — uziemienie
EUR UK
N
L
N
L
FUSE ON
PUSZKA PRZYŁĄCZENIOWA Z
BEZPIECZNIKIEM I WYŁĄCZNIKIEM
DWUBIEGUNOWYM
UŻYĆ BEZPIECZNIKA 16A
N (niebieski)
L (brązowy)
(zielony/żółty)
Aby ograniczyć do minimum ryzyko związane z użytkowaniem urządzenia elektrycznego, niezwykle ważne jest, aby
produkt został prawidłowo zamontowany oraz aby użytkownik dokładnie zapoznał się z instrukcjami dotyczącymi
bezpieczeństwa i unikał nieprawidłowej obsługi oraz związanych z tym zagrożeń. Należy zachować instrukcję obsługi w
celu wykorzystania w przyszłości i przekazania jej kolejnym właścicielom. Po rozpakowaniu urządzenia upewnić się, że
nie jest ono uszkodzone. W przypadku wątpliwości nie używać urządzenia i skontaktować się z działem obsługi klienta.
Więcej szczegółowych informacji znajduje się na końcu części Czyszczenie i konserwacja.
13
EN Installation FR Installation
PL Montaż RO Instalare

14
EN Installation FR Installation
PL Montaż RO Instalare
RO Conectarea la alimentarea electrică
Instalarea trebuie să fie realizată în totalitate de o persoană competentă sau de un electrician calificat. Înainte
de conectarea la rețeaua electrică, asigurați-vă că tensiunea rețelei corespunde cu tensiunea de pe plăcuța
de identificare.
Conexiune directă
Aparatul trebuie conectat direct la rețea cu ajutorul unui disjunctor omnipolar cu o deschidere minimă între contacte
de 3 mm.
Instalatorul trebuie să se asigure că a realizat corect legăturile electrice și că a respectat schema electrică.
Cablul nu trebuie să fie îndoit sau comprimat.
Verificați periodic cablul de alimentare pentru a depista deteriorările. În cazul în care cablul de alimentare se
deteriorează, acesta trebuie înlocuit de producător, agentul de service sau persoane cu un nivel de calificare similar,
pentru evita o situație periculoasă.
AVERTISMENT: Acesta este un aparat Clasa I și TREBUIE împământat.
Aparatul dispune de un cablu de alimentare cu 3 fire conductoare și trebuie conectat la sursa de alimentare printr-un
întrerupător bipolar, cu o distanță minimă între contacte de 3 mm la fiecare conector.
Dispozitivul de protecție la curent rezidual (RCD) trebuie să aibă 16 Amperi.
Firele din cablul de alimentare sunt colorate conform codificării de mai jos:
Maro = L - Fază
Albastru = N - Nul
Verde și galben = - Împământare
EUR UK
N
L
N
L
FUSE ON
PRIZĂ CU ÎNTRERUPĂTOR
BIPOLAR CU SIGURANȚĂ
UTILIZAȚI O SIGURANȚĂ DE 16 AMPERI
N (Albastru)
F (Maro)
(Verde / galben)
Pentru a evita riscurile aferente utilizării unui echipament electric, este important ca acest aparat să fie instalat corect
și să citiți cu atenție instrucțiunile de siguranță, ca să evitați utilizarea greșită și pericolele. Păstrați această broșură cu
instrucțiuni pentru consultare ulterioară și predați-o proprietarilor viitori. După despachetarea aparatului, verificați să
nu fie deteriorat. Dacă aveți îndoieli, nu folosiți aparatul, ci contactați Serviciul de asistență clienți - a se vedea sfârșitul
secțiunii Îngrijire și întreținere pentru detalii.

15
EN Use FR Utilisation
PL Użytkowanie RO Utilizare
EN Before you start
WARNING: Read the instructions before using the appliance.
Switch on the appliance at the switched fused connection unit. The appliance will beep once and is ready for use.
EN Function and setting
1
8
6
3
7
9
4
5
2
1Control panel
2 Fixing holes (x 2)
3Oven lamp
4Fan
5Door
6Carrying handles (x 2)
7 Side rails (x 2)
8 Mains cable (at rear, not shown)
9Door handle
EN Control Panel
19:45
34 34
12
Thursday, 21 June
12
11
10
Thursday, 21 June
7
1Master On/Off Key 5Cooking Mode Key 9Master Settings Key
2 Left Touch Screen 6 Defrost Mode Key 10 Oven Light Key
3 360° Control Knob (Push to eject or hide) 7 Microwave Mode Key 11 Child Lock Key
4 Right Touch Screen 8 Presets Mode Key 12 Time and Date Display

EN Turning the oven on and off
Touch the Master On/Off Key once to turn on the oven, and once more to turn it off. The oven will beep once to
confirm in each case.
After ten minutes of inactivity, the oven will automatically turn itself off.
Once the oven has started up, both touch screens will be displayed as above.
EN Using the touch screens
Setting up the oven for first use
From the main menu of the Left Touch Screen, touch the Master Settings Key .
NOTE: It is normal for the Right Touch Screen to dim during various functions such as when Settings are altered.
Settings
6
2 5
7
1
3 4
1 Exit Master Settings Key
2Clock Key
3Date Key
4Language Key
5 Display Brightness Key
6Master Volume Key
7 Factory Reset Key
Setting the time
1. Touch the Clock Key and the hour and minute digits appear on the Right Touch Screen.
2. Rotate the 360° Control Knob to select the hours from 0-23.
3. Touch the minute display and rotate the 360° Control Knob to select the minutes from 0-59.
4. Touch the Tick twice to store the time.
Setting the date
1. Touch the Date Key and the date, month and year appear on the Right Touch Screen.
2. Swipe up or down in each column to choose the correct date.
3. Touch the Tick twice to store the date.
Setting the language
1. Touch the Language Key and the country options appear on the Right Touch Screen.
2. Swipe up or down to choose the correct language.
3. Touch the Tick twice to store the language.
Setting the display brightness
1. Touch the Display Brightness Key and the control appears on the Right Touch Screen.
2. Rotate the 360° Control Knob to select the brightness from 0-9. Default brightness is 8.
3. Touch the Tick twice to store the brightness.
Setting the alert volume
1. Touch the Master Volume Key and the control appears on the Right Touch Screen.
2. Rotate the 360° Control Knob to select the volume from 0-3. Default volume is 3.
3. Touch the Tick twice to store the volume.
Reset to factory default options
1. Touch the Factory Reset Key and the reset message appears on the Right Touch Screen.
2. Touch the Tick or Cross to reset or cancel and return to the Settings menu.
16
EN Use FR Utilisation
PL Użytkowanie RO Utilizare

EN Using your oven
Before first use
• Remove all stickers, surface protection foils and packing materials.
• Remove all accessories and the side racks from the cavity.
• Clean the appliance cavity and all accessories as described in Care and maintenance.
• Turn the oven on, choose Standard mode and set the temperature to 250°C. Close the door and cook for one hour to
burn off any remaining manufacturing residues. (See the section “Choosing a Cooking Mode” below.)
IMPORTANT: Keep the kitchen well ventilated during this first use to help disperse the odours produced. Keep kitchen
doors closed and ensure children and pets are not present.
Cooking Modes
IMPORTANT: Do not use any metallic accessories or cooking utensils when using a mode that includes microwave
heating and MWO is switched on in the Cooking Mode Control Panel (see Cooking Mode Controls below).
Use the supplied glass shelf in the lowest rack position along with microwave proof accessories. The door must be fully
closed to start cooking.
Choosing a Cooking Mode
• From the Main Menu, choose the Cooking Mode Key to enter the Heating Menu.
• The Cooking Mode options are now shown on the Left Touch Screen
Heating
• Touch the icon of the required Cooking Mode from the table below and the two displays will now show the individual
controls available in that mode.
TURN AND TOUCH
Quick Tip: From the Main Menu, just turn the 360° Control Knob clockwise or anti-clockwise and you will gain instant
access to the Standard Cooking Mode at its default temperature of 180°C. Touch the Start Cooking Key and the oven
will start instantly.
Icon Mode Temperature
Range (default) Microwave Power (default) Description
Standard 100-235°C in 5°C increments
(180°C) Not applicable
Traditional static heat from upper and lower heating
elements ensures that the foods remain moist when
cooked for longer periods of time. Ideal for slow baked
cakes and soufflés.
Convection 100-250°C 5°C increments
(160°C)
100/300/500W
(300W)
A heating element around the convection fan provides
an additional source of heat for convection style
cooking. In convection mode the fan automatically
comes on to improve air circulation within the oven and
creates an even heat for cooking. This mode is suitable
for cakes, pastry and to roast meat when you want it
well cooked on the outside and tender in the middle.
No pre-heating is required when using this mode and
additional microwave cooking is also available.
Pizza 100-250°C in 5°C increments
(180°C)
100/300/500W
(300W)
Ideal for pizza and dishes which need a lot of heat from
underneath. The lower element and circular convection
element are both used and additional microwave
cooking is also available.
Fanned 100-235°C in 5°C increments
(160°C) Not applicable
Combination of the fan and both heating elements
provides more even heat penetration, saving up to
30-40% of energy. Dishes are lightly browned on the
outside and still moist on the inside. Ideal for grilling or
roasting large pieces of meat at a higher temperature.
17
EN Use FR Utilisation
PL Użytkowanie RO Utilizare

Icon Mode Temperature
Range (default) Microwave Power (default) Description
Grill 100-235°C in 5°C increments
(150°C) Not applicable
Only the upper heating element is working.
Best results are achieved by using the top shelf for
smaller foods and a lower shelf for larger foods. Ideal
for rapid cooking and browning.
Grill & Fan 100-250°C in 5°C increments
(180°C)
100/300/500W
(300W)
The inner heating element and the upper heating
element are both working together with the fan.
Best results are achieved by using the top shelf for
smaller foods and a lower shelf for larger foods. The
fan lessens the strong heat from the upper heating
element creating more even browning and heat
distribution, without drying out foods. Ideal for rapid
cooking and browning and additional microwave
cooking is also available.
Double grill 100-235°C in 5°C increments
(180°C) Not applicable The inner heating element and the upper heating
element are both working. Ideal for grilling flat items
and for browning foods.
Bottom 100-235°C in 5°C increments
(150°C) Not applicable Only the lower heating element is working. Ideal for
pies or pastries where a crispy base is desired. Also
suitable for slow cooking of stews and casseroles.
Practical cooking advice
• This appliance offers a wide range of alternatives which allow you to cook any type of food in the best possible way.
With time you will learn to make the best use of this versatile appliance and the following directions are a guideline
which may be varied to suit your personal needs.
• Read the information on the food packaging for guidance on recommended cooking times and temperatures. Once
familiar with the performance of the appliance, the temperatures and times may be varied to adapt them to your
personal tastes.
• Check that frozen food is completely thawed before cooking, unless instructed otherwise.
STANDARD
Food Temperature setting (ºC) Recommended shelf position
from the bottom Cooking time in minutes
Small cakes 175 - 185°C 4 16 - 19
Sponge cake 180 - 185°C 2 20 - 25
Pizza 205 - 210°C 3 18 - 23
Apple yeast cake 185 - 195°C 4 25 - 50
CONVECTION
Food Temperature setting (ºC) Recommended shelf position
from the bottom Cooking time in minutes
Small cakes (single
layer) 165 - 170°C 2 20 - 23
Sponge cake 160 - 165°C 2 30 - 40
Pizza 170 - 175 °C 2 19 - 25
Apple yeast cake
(single layer) 170 - 175°C 2 60 - 70
Small cakes (double
layer) 165 - 170°C 2 (deep tray) 20 - 23
4 (shallow tray)
Apple yeast cake
(double layer) 170 - 175°C 2 (deep tray) 65 - 75
4 (shallow tray)
18
EN Use FR Utilisation
PL Użytkowanie RO Utilizare

GRILL
Food Temperature setting (ºC) Recommended shelf position
from the bottom Cooking time in minutes
Toast 240°C 34-5
Beef steak 240°C 215+
GRILL & FAN
Food Temperature setting (ºC) Recommended shelf position
from the bottom Cooking time in minutes
Chicken 210°C 2 55 - 65
Goose 210 °C 2 75 - 88
Roasted joint of pork 210 °C 1 135 - 150
DOUBLE GRILL
Food Temperature setting (ºC) Recommended shelf position
from the bottom Cooking time in minutes
Toast 240 °C 4 6 - 8
Cooking Mode Controls
Left Touch Screen Right Touch Screen
Boost Control (if applicable) Temperature Dial Timer Dial
Standard
Convection
Temperature TemperatureTimer Timer
Boost
MWO
Boost
1 Exit Key 7 Current time
2Current Cooking Mode 8 Timer Dial
3 Boost Key (if applicable) 9 Child Lock Key
4 Main Menu Key 10 Stop Cooking Key
5 Oven Light Key (orange when on) 11 Start Cooking Key
6Temperature Dial 12 Microwave Key (where applicable)
13 Microwave Power Options
Adjusting the temperature
Eject the 360° Control knob (if necessary) and rotate it to set the desired temperature on the Right Touch Screen.
19
EN Use FR Utilisation
PL Użytkowanie RO Utilizare

Adjusting the timer (optional)
• If required, touch the Timer Dial and rotate the 360° Control Key to set the timer from 1 minute to 4 hours in
combination oven mode. When using a microwave only cooking mode, the time can be set from 1 second to
90minutes using power levels 100-700W, and from 1 second to 30 minutes using power level 900W. The default
microwave time is 1 minute.
• When the selected time has elapsed, the oven will continue to beep until the “Timer complete” tick is touched on
the screen.
Setting the Boost
Touch the Boost Key to activate this function and the oven will heat up faster to the selected temperature by switching
on all elements for a short period until the operating temperature is reached. The oven will then switch off those
elements not used in the selected Cooking Mode.
Note: This function is not available in every Cooking Mode.
Selecting Combination Microwave Cooking
Note: Additional microwave cooking is also available in three modes and three power levels.
Refer to the Cooking Modes table above.
Start cooking
Touch the Start Cooking Key to commence cooking. The Right Touch Screen will change to the following display,
and the Timer will start its countdown, if this was selected.
The Oven Light Key will turn orange when the oven is illuminated. If you wish to alter the temperature after cooking
has started, just touch the Temperature Dial and adjust as required.
After three seconds the new temperature is set automatically.
Note: If you do not commence cooking at this point, the oven will revert to the Main Menu after five minutes.
Standard
Temperature
Current
Timer
1 Oven Light Key (orange when on)
2Current time
3Timer
When set: Shows remaining time
When not set: Shows current cooking time
4 Child Lock Key
5Stop Cooking Key
6Internal oven temperature
7
Pause Cooking Key
The large Pause icon will show in the centre of the display and both screens will be locked; touch the icon again
to resume cooking.
8 Selected cooking temperature
Pause cooking
• You can touch the Pause Key to temporarily stop and touch the large Pause icon to recommence again.
Stop cooking
Touch the Stop Cooking Key at any time to turn the oven off and cancel the timer.
20
EN Use FR Utilisation
PL Użytkowanie RO Utilizare
