Goodmans GCE-302 User manual

Service Manual - GCE-302
GCE-302
Service Manual - GCE-302

NO ITEM CODE DESCRIPTION QTY SYMBOL
1 001-0000S-B90 P.C.B FILTER BOX 1
2 001-3900S-100 P.C.B CD-3900RDS/MP3 MAIM BOARD 1 50153110
3 002-01140-A00 I.C LA1140 1 IC201
4 002-03370-A09 I.C LA3370 1 IC301
5 002-07035-T00 I.C KIA7035 1 Q30
6 002-08802-S00 I.C RS8802-004 1 IC401
7 002-1558Q-A05 I.C TDA1558Q 1 IC8
8 002-1923F-H07 I.C BU1923 1 IC403
9 002-7313D-B06 I.C TDA7313D 1 IC601
10 002-75823-H00 I.C LC75823 1 IC501
11 002-78L05-F00 I.C KIA78L05 1 Q29
12 002-9256P-G02 I.C KIC9256P 1 IC402
13 003-01368-C00 TRANSISTOR KTB1368 1Q23
14 003-0966Y-A02 TRANSISTOR 2SA966Y 1 Q11
15 003-0C111-D00 TRANSISTOR C111 2 Q6.26
16 003-1267Y-A00 TRANSISTOR KTA1267Y 1Q13
17 003-1271Y-A03 TRANSISTOR KTA1271Y 2Q14.5
18 003-3199Y-D03 TRANSISTOR KTC3199Y 16
Q1.3.4.7-10.12.28.
Q
16.18-20.24.25.33
19 003-3203Y-D00 TRANSISTOR STC3203Y 2Q15.27
20 003-9018G-D00 TRANSISTOR 9018G 1 Q2
21 004-04001-000 RECTIFIER DIODE IN4001 2 FILTER BOX :1 R40
22 004-04148-000 DIODE IN4148 22
D1-4.6.7.10.11.13.14.16.17.21.23-28.30-
32
23 005-00039-A00 ZENER DIODE 1/2W 3.9V 1 ZD1
24 005-00051-A00 ZENER DIODE 1/2W 5.1V 1 ZD2
25 005-00056-A00 ZENER DIODE 1/2W 5.6V 1 ZD4
26 005-00075-A00 ZENER DIODE 1/2W 7.5V 1 ZD6
27 005-00100-A00 ZENER DIODE 1/2W 10V 2 ZD5.3
28 006-04330-000 CRYSTAL HC-49U 4.33MHZ 1 XT2
29 006-07200-000 CRYSTAL HC-49U 7.2MHZ 1 XT1
30 007-05046-7GY I.F.T 7x7mm K5046 GRAY 1 T1
31 008-05155-C00 LCD DISPLAY 47PIN TTD-5155 1 LCD1 COLOUR

NO ITEM CODE DESCRIPTION QTY SYMBOL
32 009-0201V-A02 TUNER (FM) CCT-201V 1
33 010-A0222-000 CHOCK COIL 22mH 1 L1
34 011-A010F-200 RES .1/2W ±5% 1 OHM 2R61.39
35 011-A100D-200 RES. 1/4W ±5% 10 OHM 2R163.164
36 011-A100A-200 RES .1/16W ±5% 10 OHM 2R77.98
37 011-A102A-200 RES .1/16W ±5% 1K OHM 10
R26.38.55.81.95.*32.D2.
R143.152.153
38 011-A103A-200 RES .1/16W ±5% 10K OHM 10 R33.70.90.99-101. 149-150.115.4
39 011-A104A-200 RES .1/16W ±5% 100K OHM 5R88.106.107.161.21
40 011-A105A-200 RES .1/16W ±5% 1M OHM 3R87.155.?
41 011-A151A-200 RES. 1/16W +-5% 150 OHM 1 R80
42 011-A152A-200 RES .1/16W ±5% 1.5K OHM 2R79.91
43 011-A153A-200 RES .1/16W ±5% 15K OHM 3R11.12.10
44 011-A181A-200 RES. 1/16W +-5% 180 OHM 2 R53.126.162
45 011-A182A-200 RES. 1/16W +-5% 1.8K OHM 1 R3
46 011-A184A-200 RES. 1/16W +-5% 180K OHM 1 R34
47 011-A220A-200 RES.1/16W +-5% 22 OHM 2 R72.68
48 011-A221A-200 RES.1/16W +-5% 220 OHM 1 R93
49 011-A222A-200 RES.1/16W +-5% 2.2K OHM 2 R59.54
50 011-A223A-200 RES .1/16W ±5% 22K OHM 16
R8.9.15.16.19.20.24.30.104.
R31.37.63.96.112.114.140
51 011-A224A-200 RES .1/16W ±5% 220K OHM 2R102.18
52 011-A272A-200 RES .1/16W ±5% 2.7K OHM 1R22
53 011-A330A-200 RES .1/16W ±5% 33 OHM 3R17.28.6
54 011-A331A-200 RES .1/16W ±5% 330 OHM 3R7.1.5
55 011-A332A-200 RES. 1/16W +-5% 3.3K OHM 2 R25.29
56 011-A333A-200 RES .1/16W ±5% 33K OHM 1R20
57 011-A334A-200 RES. 1/16W ±5% 330K OHM 3R57.58.23
58 011-A471A-200 RES. 1/16W +-5% 470 OHM 4 R71.84.13.94
59 011-A472A-200 RES .1/16W ±5% 4.7K OHM 9R97.103.113.50.64. 148.129.154.9
60 011-A473A-200 RES .1/16W ±5% 47K OHM 7R13.14.27.105.142
61 011-A474A-200 RES .1/16W ±5% 470K OHM 2R51.43
62 011-A513A-200 RES .1/16W +-5% 51K OHM 1 R60
63 011-A561A-200 RES .1/16W ±5% 560 OHM 2R49.45
64 011-A562A-200 RES .1/16W ±5% 5.6K OHM 10 R35.36.156.157.44.52.108-111
65 011-A821A-200 RES .1/16W ±5% 820 OHM 2R67.62
66 012-B474F-300 ELEC CAP 0.47uF 50V 4x7mm 1 C50
67 012-C105F-300 ELEC CAP 1uF 50V 5x11mm 5 C13.15.21.23.42
68 012-C106C-300 ELEC CAP 10uF 16V 5x11mm 3 C9.63.18

NO ITEM CODE DESCRIPTION QTY SYMBOL
69 012-C107C-300 ELEC CAP 100uF 16V 5x11mm 5 C98.74.99.57.55
012-C107B-300 ELEC CAP 100uF 10V 5x11mm 1 C202
70 012-C224F-300 ELEC CAP 0.22uF 50V 5x11mm 5 C79.93.94.95.96
71 012-C225F-300 ELEC CAP 2.2uF 50V 5x11mm 1 C24
72 012-C335F-300 ELEC CAP 3.3uF 50V 5x11mm 3 C27.22.104
73 012-C336C-300 ELEC CAP 33uF 16V 5x11mm 1 C91
74 012-C474F-300 ELEC CAP 0.47uF 50V 5x11mm 1 C53
75 012-C475F-300 ELEC CAP 4.7uF 50V 5x11mm 12 C28.29.31-34.47.48.51.54.56.64
76 012-C476C-300 ELEC CAP 47uF 16V 5x11mm 4 C70.35.86.87
77 012-F108B-300 ELEC CAP 1000uF 10V 8x12mm 2 C92.103
78 012-L108C-300 ELEC CAP 1000uF 16V 10x18mm 1 C90
79 012-P108D-300 ELEC CAP 1000uF 25V 13x20mm 1 FILTER BOX
80 013-A223A-400 MYLAR CAP +-10% 0.022uF 2 C25.26
81 013-A224A-400 MYLAR CAP ±10% 0.22uF 1C8
82 013-A272A-400 MYLAR CAP ±10% 0.0027uF 2C30.36
83 013-A332A-400 MYLAR CAP ±10% 0.0033uF 1C78
84 013-B102A-300 POLY CAP 1000PF 50V 1 C20
85 014-A101C-400 CER.CAP ±5% 100PF 2C11.16
86 014-A102C-600 CER.CAP ±20% 0.001uF 50V 5C66.97.100-102
87 014-A103C-600 CER.CAP+-20% 0.01uF 50V 5 C19.40.60.105.107
88 014-A104C-600 CER.CAP ±20% 0.1uF 50V 15 C2.59.65.69.71.37.38.112.88.89.43-46.?
89 014-A150C-400 CER.CAP ±5% 15PF 50V 2C10.77
90 014-A200C-400 CER.CAP ±5% 20PF 50V 1C39
91 014-A222C-400 CER.CAP ±5% 0.0022uF 50V 3C14.108.109
92 014-A223C-400 CER.CAP ±5% 0.022uF 50V 9C5.7.12.84.85.3.61.?.201
93 014-A271C-400 CER.CAP +-5% 270P 50V 1 C17
94 014-A300C-400 CER.CAP ±5% 30PF 50V 4C73.72.82.1
95 014-A473C-400 CER.CAP ±5% 0.047uF 50V 1C6
96 014-A561C-400 CER.CAP ±5% 560PF 50V 1C68
97 014-A681C-400 CER.CAP +-5% 680PF 50V 1 C58
98 015-H0103-E00 SEMI-FIXED 10KB SC-065 1 VR3
99 015-H0104-E00 SEMI-FIXED 100KB SC-065 1 VR1
100 015-H0203-E00 SEMI-FIXED 20KB SC-065 1 VR2
101 016-C0300-600 TRIMMER CAP 30PF 6mm 1 C83
102 017-B0107-400 CER FILTER 10.7MJA 2 CF2.1
103 022-C7000-100 FUSE 7A 1
104 023-A0030-RD0 LED RED 3mm 1

NO ITEM CODE DESCRIPTION QTY SYMBOL
105 029-B0000-000 ANTENNA JACK D.SCREW 1
106 032-E0700-025 RAINBOW WIRE #26 2Pin 70mm 1 5-70-5 A-A.front to amp pcb
107 033-S1000-BN0 1P SHIELD WIRE #28 100mm 1 ANT WIRE
108 033-S1200-BK0 1P SHIELD WIRE #28 120mm 1 FMOSC WIRE
109 034-A1612-005 ISO 16P W/WIRE 12P H/P 1
110 035-B0400-BK1 JUMPER WIRE #20 40mm BLACK 1
111 035-E0500-RD1 JUMPER WIRE #26 50mm RED 1 ANT SOCKET TO FM TUNER
112 035-E0700-BL1 JUMPER WIRE #26 70mm BLK 1 A-A.front to amp pcb
113 035-E0900-BN1 JUMPER WIRE #26 90mm BRN 1 B-B
114 036-A0250-030 3P WAFER P2.5mm ST 1 LINE OUT
115 036-D0250-130 13PIN SOCKET PITCH 2.5mm 1
116 037-G5300-2B1 3P H'ING P2.5mm 2xSH 300mm 1 GREY LINE OUT
117 042-30010-000 FUSE HOLDER 2
118 201-EI240-000 CHOKE TRANS EI-24 1
119 221-S0040-040 BARE WIRE D=0.4x40mm 70
120 230-100BK-100 PLASTICTIE L=100mm 1 BLACK
121 316-WE838-214 LCD FILTER 83.8x21.4mm "WHITE" 2 NEXAN FILM (3900 COM)
FRONT PCB
122 001-3908S-830 P.C.B CD-3908 FRONT BOARD 1
123 011-A102A-200 RES 1/16W +-5% 1K OHM 2 R533.521
124 011-A152A-200 RES 1/16W +-5% 1.5K OHM 2 R534.520
125 011-A181A-200 RES 1/16W +-5% 180 OHM 2 R526.528
126 011-A183A-200 RES 1/16W +-5% 18K OHM 2 R539.1
127 011-A221A-200 RES 1/16W +-5% 220 OHM 2 R529.525
128 011-A222A-200 RES 1/16W +-5% 2.2K OHM 2 R535.519
129 011-A331A-200 RES 1/16W +-5% 330 OHM 2 R524.530
130 011-A332A-200 RES 1/16W +-5% 3.3K OHM 2 R518.536
131 011-A471A-200 RES 1/16W +-5% 470 OHM 2 R523.531
132 011-A472A-200 RES 1/16W +-5% 4.7K OHM 2 R517.537
133 011-A681A-200 RES 1/16W +-5% 680 OHM 2 R522.532
134 011-A822A-200 RES 1/16W +-5% 8.2K OHM 2 R516.538
135 024-40140-300 PILOT LAMP 14V 40mA 3mm 2
136 024-40063-260 PILOT LAMP 6.3V 40mA 2.6mm 4
137 024-40063-300 PILOT LAMP 6.3V 40mA 3.0mm 8
138 025-TA020-500 TACT SW 5mm 2P 15
139 025-TA020-800 TACT SW 8mm 2P 6 M1-6
140 025-TA060-580 PUSH S/W 5.8x5.8 2216N 1 K1

NO ITEM CODE DESCRIPTION QTY SYMBOL
141 035-F1000-BE1 JUMPER WIRE #28 100mm Blue 1 FRONT PCB
142 035-F1000-BK1 JUMPER WIRE #28 100mm Black 1 KEY2 - MAIN PCB KEY2
143 035-F1000-RD1 JUMPER WIRE #28 100mm RED 1 FRONT PCB
144 035-F1000-YW1 JUMPER WIRE #28 100mm Yellow 1 A-MAIN PCB KEY1
145 035-F1600-BE1 JUMPER WIRE #28 160mm Blue 1 D-D
146 035-F1600-VT1 JUMPER WIRE #28 160mm Violet 1 RESET MAIN PCB
147 035-F1800-BK1 JUMPER WIRE #28 180mm Black 1 F-F
148 035-F1800-GY1 JUMPER WIRE #28 180mm GRAY 2 C-C . H-H
149 035-F1800-PK1 JUMPER WIRE #28 180mm PINK 1 E-E
150 035-F1800-RD1 JUMPER WIRE #28 180mm RED 1 A-A
151 035-F1800-WE1 JUMPER WIRE #28 180mm White 1 KEY MAIN PCB
152 035-F1800-YW1 JUMPER WIRE #28 180mm Yellow 1 B-B
153 040-GN030-A00 LAMP CAP 3mm GREEN 1
154 040-GN026-A00 LAMP CAP 2.6mm GREEN 10
CDP BOARD ASSEMBLE
155 MP-3 SUB PCB ASS'Y 1
156 031-0150U-131 13P FFC Flexible Cable P=1.25mm L=150mm 1
157 032-E1000-031 RAINBOW WIRE 3P 100mm 3+100+3 1
158 203-8008S-C2E CD DECK CDM-211 1
159 209-11000-N00 LOCK SPRING 1 SUS T0.4 (1100 COM) 71100501
160 209-30010-K00 RELEASE SPRING 2 SUS T0.35 (3001 COM) 70038037 HOOK 1
161 209-11860-K00 RELEASE SPRING 1 SUS TO.3 FOR REL 1
162 212-52090-140 SPRING WASHER (Ф5.2) 3 SET:1 ACC:2
163 212-52100-05P PLATE WASHER (Ф5.2) 3 SET:1 ACC:2
164 214-18880-C00 MAIN FIBER 1 FIBER T0.5 (1888 CON)
165 216-3888A-C00 HEAT SINK 1 AC DIECASTING (3888 CON)
166 217-1001E-E12 MOUNTING STRIP 1 EGI T1.2 (1001 COM) 70028046
167 218-3003E-E10 IC BRACKET 1 EGI T1.0 (3003 COM) 82047010
168 218-3888C-E10 DECK BRACKET 1 EGI T1.0 (3888 COM)
169 218-3888L-E10 DECK BRACKET "L" 1 EGI T1.0 (3888 COM)
170 218-3888R-E10 DECK BRACKET "R" 1 EGI T1.0 (3888 COM)
171 222-1001S-E06 SLEEVE CASE 1 EGI T1.0 (1001 COM) 70028039
172 222-3501B-H06 BOTTOM COVER A/R 1 EGI T0.6 (3510 COM) 73500350
173 222-3888L-E10 SIDE CHASSIS "L" 1 EGI T1.0 (3888 COM) 241388802030
174 222-3888R-E10 SIDE CHASSIS "R" 1 EGI T1.0 (3888 COM)
175 222-3888T-E06 TOP COVER 1 EGI T0.6 (3888 COM)

NO ITEM CODE DESCRIPTION QTY SYMBOL
176 223-1888A-E06 SIDE BRACKET 2 RGI T0.6 (1888 COM) 71888380
177 225-09007-400 CUSHION BOTTOM 5 81100304
178 227-30010-EA5 CASE CUSHION 2 SPONGE T15mm (3001 COM)
179 227-30050-E60 CASE CUSHION "B" 2 SPONGE (3001 COM) 93005028
180 227-39080-L50 LEFT SPONGE 1 SOFT SPONGE WHITE T=5.0mm
181 227-39080-R50 RIGHT SPONGE 1 SOFT SPONGE WHITE T=5.0mm
182 227-39080-M30 MIDDLE SPONGE 1 SOFT SPONGE WHITE T=3.0mm
183 228-3888A-000 CD FELT 1 CLOTH BLACK (3888 COM)
233-N030W-H00 HEX NUT: M3 1
184 234-HEX50-220 HEX BOLT: 5x22mm 1 SET:1
185 234-MS030-050 SCREW: MS 3x5 (5.5x1x5) 4 BASE PANEL:4
187 234-PA020-05B SCREW: TS 2x5 PA BLACK 13
F/PCB:7 LAMP PCB:2 L/CAP:2
REF
(
REAR
)
R:1 L:1
188 234-PA020-06B SCREW: TS 2x6 PA BLACK 6 N/BACK:6
189 234-PA050-160 SCREW: TS 5x16 PA 1 ACC:1
190 234-PM030-080 SCREW: TS 3x8 PM 1 IC:1
191 234-PM030-130 SCREW: MS 3x13 PM 2 IC:2
192 234-BMT20-040 SCREW: TTP 2x4 BM TAP TYPE 4 SUB PCB:4
193 234-PT026-040 SCREW: TS 2.6x4 TAP TYPE 5 DECK BRT:5
194 234-PT030-050 SCREW: TS 3x5 TAP TYPE 細牙 10
195 234-PTT30-050 SCREW: TS 3x5 TAP TYPE 粗牙 8
196 234-PTT30-080 SCREW: TS 3x8 TAP TYPE 粗牙 2 CORD CLAMPER:2
197 235-10080-H12 SET KEY 1 EGI T1.2 (1008 COM) 71008375
198 236-38501-H10 CORD CLAMER "B" 1 EGI T1.0 (LINE OUT) 6522COM 76522420
199 301-0C025-060 POLY BAG 1 OPEN 2.5"x6"XT0.04
200 301-0C070-105 POLY BAG 1 OPEN 7"x10.5"XT0.05
201 301-0C110-140 POLY BAG 1 OPEN 11"x14"XTo.04
202 303-00000-000 POLYFOAM BOX 2
203 304-00000-000 GIFT BOX 1
204 305-00000-000 INSTRUCTION MANUAL 1
205 306-00000-000 CARTON BOX 1/6 1
206 313-38880-A00 P.V.C CD GUIDE SHEET BLACK 1 T1.0 (3888 COM)
207 313-39000-S00 PVC SHEET 1 PVC BLACK T=0.3
208 313-39080-5CR MEMORY KNOB PLECE 1 PVC T=0.3 CLEAR
209 314-0000A-000 AZIMUTH LABEL 1
210 314-0000T-000 TOP LABEL 1
211 314-0000W-000 WARRANTY LABEL 1
212 314-3900K-A00 GOLD LABEL 55x55mm 1 屏幕用

NO ITEM CODE DESCRIPTION QTY SYMBOL
213 319-00000-010 SILICA GEL 1 PACK IGM
214 402-3906A-1BK BASE PANEL 1 PC BLACK
215 402-3908B-1BK NOSE PIECE 1 ABS BLACK
216 402-3908C-3BK NOSE PIECE BACK 1 PC BLACK
217 402-3003S-4BK NOSE PIECE CASE 1 P.P BLACK
218 413-3908A-2CR LCD WINDOW 1 PMMA (CLEAR)
219 414-3900A-2WE CD GUIDE REFLECTOR 1 PMMA (MILK WHITE) CD-3900COM
220 414-3908D-2BE REFLECTOR RING 1 PMMA ( BLUE)
221 414-3908L-2WE FRONT REFLECTOR 1 PMMA ( MILK WHITE)
222 414-3908B-2WE LEFT REFLECTOR REAR 1 PMMA (MILK WHITE)
223 414-3908C-2WE RIGHT REFLECTOR REAR 1 PMMA (MILK WHITE)
224 414-3908Y-2WE MIDDLE REFLECTOR REAR 1 PMMA (MILK WHITE)
225 423-3908A-1NL BAND KNOB 1 ABS (NATVRAL)
226 424-39081-1NL MEMORY KNOB "1" 1 ABS (NATVRAL)
227 424-39082-1NL MEMORY KNOB "2" 1 ABS (NATVRAL)
228 424-39083-1NL MEMORY KNOB "3" 1 ABS (NATVRAL)
229 424-39084-1NL MEMORY KNOB "4" 1 ABS (NATVRAL)
230 424-39085-1NL MEMORY KNOB "5" 1 ABS (NATVRAL)
231 424-39086-1NL MEMORY KNOB "6" 1 ABS (NATVRAL)
232 424-3908A-1NL ST KNOB 1 ABS (NATVRAL)
233 426-3902A-1BK PULL KNOB 1 ABS (BLACKL)
234 427-3908A-1NL POWER KNOB 1 ABS (NATVRAL)
235 428-3908C-1NL VOLUME KNOB 1 ABS (NATVRAL)
236 430-3908A-1NL EJECT KNOB 1 ABS (NATVRAL)
237 429-3908D-1NL TUNE TRK " " 1 ABS (NATVRAL)
238 429-3908E-1NL TUNE TRK " "1ABS (NATVRAL)
239 432-3908A-1NL SEL KNOB 1 ABS (NATVRAL)
240 437-3908A-1NL DISP KNOB 1 ABD (NATVRAL)
241 439-3908A-1NL RELEASE KNOB 1 ABS (BLACK)
242 440-3900A-3BK HOOK 1 PC BLACK CD-3900COM
243 441-1888A-3BK TRIM COVER 1 PC BLACK 1888COM
244 441-3900C-3WE LCD CAP 1 PC WHITE CD-3900COM
245 445-3908A-1NL MODE KNOB 1 ABS (NATVRAL)
246 446-3908A-INL AF KNOB 1 ABS (NATVRAL)
247 446-3908D-1NL TA KNOB 1 ABS (NATVRAL)
248 446-3908H-1NL PTY KNOB 1 ABS (NATVRAL)
249 447-3099A-1BK PUSH KNOB 1 ABS (BLACK) CRE-3099COM

NO ITEM CODE DESCRIPTION QTY SYMBOL
250 463-0000C-4BK TILTER & FUSE BOX 1 P.P BLACK
251 483-3908A-1BK ORNAMENT RING 1 ABS (BLACK)
