Goodmans GDVD301R User manual

GDVD301R
DigitalVersatile Disc Recorder
with Remote Control
User Guide
82-178-00110
Goodmans product information helpline
0870-873-0080

2
D
V
D
+
R
/
R
W
R
e
c
o
r
d
e
r
R
W
Getting Started
2
DVD
2-1 DVD Playback ...................................... 35
Basic Playback ......................................... 35
Stopping Playback and Returning to The Menu Screen
(If a Menu Screen is Available on The Disc ........ 36
Stopping Playback .................................... 36
Rapid Advance (Rapid Reverse)...................... 36
Skipping Ahead or Back to Chapters ............... 37
Still Picture (PAUSE).................................. 37
Frame Advance (STEP) ............................... 37
Slow-Motion Playback ................................ 37
2-2 Direct Selection of Scenes .......... 38
Selecting Scenes by Title/Chapter/Time Number
.......................................................... 38
2-3 Repeat Playback ........................... 39
Repeating Viewing ................................... 39
Repeating Sections Between Two Specific Points
(A-B Repeat) ........................................... 39
2-4 Other Functions............................. 40
Displaying the Information of the Scene .......... 40
Displaying the Scene With a Larger and Closer View. 40
Changing Audio Soundtrack Language ............. 40
Clearing/Changing Subtitles ........................ 41
Viewing From Another Angle ........................ 41
Using a DVD Menu .................................... 42
Using the MENU Function ............................ 42
Displaying the Information of the Disc ............ 42
Muting the DVD Recorder ............................43
Playing Kodak Picture CDs and JPEG picture CD. 43
Getting Started
Important Safeguards ....................... 4
Important Notes ................................ 6
Important Safety Instructions .................... 7
Precautions ................................................... 8
About This Manual ...................................... 9
How to Proceed in This Manual ...................... 9
Package Contents ................................ 10
Parts and Controls ................................ 11
Front View ................................................11
Rear View ...............................................11
Remote Control .........................................12
The Remote Control ................................. 13
Connecting External Equipment .............. 14
Connecting to a TV .....................................14
Connecting to a SKY Box ..........................15
Connecting to a TV Using S-Video Cable ..........16
Connecting to a TV Using Component Video Cable ..17
Connecting to an AV Amplifier ..................... 18
Connecting to Other AV Equipment .............. 19
Connecting to a DV .................................. 20
Making Your First Recording .................. 21
Quick Disc Playback .................................. 22
1Recording Functions
1-1 Before recording ........................... 23
Record Quality Setting ............................... 23
Erase/Format Setting ...........................23
Finalise Setting ....................................... 23
1-2 Recording ................................. 24
To Record TV Programs while Watching ..............24
One Touch Recording (OTR)...................24
Video Plus+ Recording .............................. 26
Timer Recording ..................................... 26
To Record From External Source .................. 27
1-3 Editing...........................................28
To Edit a Title While The Title is Playing.......... 28
Insert Chapter .................................. 28
Contents
Contents
(Continue to the next page)
Remove Chapter ..................................29
Hide Chapter .................................. 29
Show Chapter .................................. 30
New Picture .................................. 30
Insert REC Mark .................................. 31
Remove REC mark ..................................31
To Edit a Title While The Title is Not Playing......32
Protect Title .................................. 32
Erase Title .................................. 32
Play Full Title .................................. 33
Edit Title .................................. 33
Insert REC Mark .................................. 34
Remove REC mark ..................................34

3
D
V
D
+
R
/
R
W
R
e
c
o
r
d
e
r
R
W
Getting Started
3
Audio CDs
3-1 Audio CD Playback .......................44
Basic Playback ....................................... 44
Playing MP3 Music Discs.............................. 45
Stopping Playback .................................... 45
Rapid Advance (Rapid Reverse) .................... 45
Skipping Ahead or Back to Tracks .................. 46
Pause Playback ....................................... 46
Programming Audio CD Soundtrack................ 47
Selecting Music by Track............................. 49
Selecting Music by Time..............................49
Random Playback...................................... 50
Repeat Playback ...................................... 50
Displaying the remaining /Elapsed time of the Playing
Disc ...................................................... 51
4
Initial Settings
4 Initial Settings .................................... 52
4-1 Channel Setup .............................. 54
Channel Search Setting .............................. 54
Fine Tune Setting.............................. 55
Programme Swap Setting........................... 55
Erase Programme Setting .............................. 55
4-2 Record / Disc Setup ...................... 56
Record Quality Setting ................................ 56
Auto Chapter Setting .................................... 57
Disc Info. Setting ......................................58
Finalise Setting ......................................... 59
Make Compatible Setting ............................. 59
Protect Disc Setting ................................. 60
Erase/Format Setting .................................. 60
4-3 Video Setup ............................... 61
TV Type Setting ....................................... 61
TV System Setting ....................................... 62
Subtitle Setting ....................................... 62
Video Output Setting................................. 63
4-4 System Setup ................................ 64
RATINGS Setting [DVD]................................ 64
Change PASSWORD Setting [DVD]................... 65
Contents
Factory Reset Setting ................................ 66
Version Setting ................................ 66
4-5 Timer Setup .............................. 67
Video Plus+ Setting .................................... 67
Programme List (Record) Setting .......................68
Date/Time Setting .................................... 69
5For Your Reference
5-1 Troubleshooting ............................ 70
5-2 Disc Handling and Maintenance...72
5-3 Definition of Terms ....................... 73

4
D
V
D
+
R
/
R
W
R
e
c
o
r
d
e
r
R
W
Getting Started
Important Safeguards
For your own safety read following instructions carefully before attempting to connect this
recorder to the mains.
Mains Supply: 230V ~ 50Hz - AC only
This unit is designed to operate on a 230V~50Hz supply only. Connecting it to other power
sources may damage it. Ensure that the supply corresponds to the information on the rating
label at the rear of the recorder.
This component system may be fitted with a non-rewireable plug. If it is necessary to change the fuse
in a non-rewireable plug the fuse cover must be refitted. If the fuse cover becomes
lost or damaged, the plug must not be used until a replacement, available from the
manufacturer, is obtained. It is important that the colour of the replacement fuse cover
corresponds with the colour marking on the base of the plug.
If the plug needs to be changed because it is not suitable for your socket, or becomes damaged,
it should be cut off and an appropriate plug fitted following the wiring instructions below. The
plug must then be disposed of safely, as insertion into a 13A socket is likely to cause an
electrical hazard.
IMPORTANT
The wires in the mains plug should be connected
as shown in the diagram.
The colours of the wires in the mains lead of the unit
may not correspond with the coloured markings
identifying the terminals in your plug. Connect them
as follows:-
The wire which is coloured blue must be connected
to the terminal which is marked with the letter 'N' or
coloured black.
The wire which is coloured brown must be
connected to the terminal which is marked with the
letter 'L' or coloured red.
There should be no connection to the earth terminal of your plug.
If a 13 Amp (BS 1363) Plug is used, a 3 Amp Fuse must be fitted, or if any other type of Plug
is used a 3 Amp or 5 Amp Fuse must be fitted, either in the Plug orAdaptor, or on the Distribution
Board.
BLUE
(NEUTRAL)
OUTER
SLEEVE
CORD GRIP
BROWN
(LIVE)
FUSE
This symbol means that this unit is double insulated. An earth connection is not
required.
DANGER
LASER SAFETY
CAUTION : USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE
OF PROCEDURES OTHER THAN SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.
INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCK FAILED OR
DEFEATED. AVOID DIRECT EXPOSURE TO BEAM
This unit employs a laser. Only a qualified service person should remove
the cover or attempt to service
CAUTION
To prevent electric shock, disconnect from the mains before removing cover.No user
serviceable parts inside. Refer servicing to qualified service personnel.

5
D
V
D
+
R
/
R
W
R
e
c
o
r
d
e
r
R
W
Getting Started
Important Safeguards -continued
To achieve the utmost in enjoyment and performance, please read this manually carefully before
attempting to operate the unit in order to became familiar with its features, and assure you years of
faithful, trouble free performance and listening pleasure.
Keep instructions the safety and operating instructions should be retained for future reference.
Avoid installing the unit in locations described below:
Exposed to direct sunlight or close to heat radiating appliances such as electric heaters.
On top of other stereo equipment that radiate too much heat.
Places lacking ventilation or dusty places.
Places subject to constant vibration.
Humid or moist places.
Make sure not to obstruct the ventilation opening.
Operate turning controls and switches as instructed in the manual.
Before turning on the power for the first time, make certain the power cord is properly installed.
Store your DVDs in a cool area to avoid damage from heat.
Important Notes
For safety reasons, do not remove any covers or attempt to gain access to the inside of the product.
Refer any servicing to qualified personal.
Do not attempt to remove any screws, or open the casing of the unit; there are no user serviceable
parts inside, refer all servicing to qualified service personal.
CAUTIONCAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER(OR
BACK), NO USER SERVICEABLE PARTS INSIDE, REFER SERVICING TO QUALIFIED
SERVICE PERSONAL.
DANGEROUS VOLTAGE
Conductor dangerous voltage, that may be of sufficient magnitude to constitute a risk
of electric shock to persons is present within this product's enclosure.
The owner's manual contains important operating and maintenance instructions, for
your safety, it is necessary to refer to the manual.
ATTENTION
WARNING :TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO
DRIPPING OR SPLASHING.
Note:
This unit will become warm when used for a long period of time. This is normal and does not indicate
a problem with the unit.

6
D
V
D
+
R
/
R
W
R
e
c
o
r
d
e
r
R
W
Getting Started
Important Notes
Hearing is very important to you and to us so please take care when operatingthis
equipment. It is strongly recommended that you follow the listed guidelines in order to
prevent possible damage or loss of hearing.
ESTABLISH A SAFE SOUND LEVEL
Over time yourhearing will adaptto continuous loudsounds and willgive the
impression that thevolume has in fact been reduced.What seems normalto
you may infact that be harmful. To guard against this BEFORE YOUR HEARING
ADAPTS set the volume at a low level.
Slowly increase thelevel until you can hear comfortably and clearly and without
distortion.
Damage to yourhearing is accumulative and is irreversible..
Any ringing ordiscomfort in the ears indicates that the volume is maybe too loud.
Once your have established a comfortable listening level, DO NOT INCREASE THE SOUND
LEVEL FURTHER.
The following list of typical sound levels may assist you in recognising just how loud you have set
the volume level.
.
DECIBEL
Level(dB) Example .
30dB Quiet library ,soft whisper.
40dB Living room , fridge freezer bedroom away from traffic.
50dB Normal conservation, quiet office, light traffic.
60dB Electric sewing machine.
70dB Vacuum cleaner, hair dryer, noisy restaurant.
THE FOLLOWING NOISE CAN BE HARMFUL UNDER CONSTANT EXPOSURE
80dB Average city traffic, alarm clock buzzer at 2 feet, food mixer.
90dB Motorcycle heavy goods vehicle, petrol lawn mower.
100dB Pneumatic drill, chair saw, garbage truck, discotheque/night-club.
120dB Rock band concert, thunderclap fast train passing by.
PERMANENT LOSS OF HEARING
140dB THRESHOLD OF PAIN GUNSHOT 2 feet away, Jet planetaking off.

7
D
V
D
+
R
/
R
W
R
e
c
o
r
d
e
r
R
W
Getting Started
Since it is usual for DVD movies to be released
at different times in different regions of the world,
all players have region codes and disc can have
an optional region code. If you load a disc of a
different region code to your player, you will see
the region code notice on the screen. The disc
will not play, and should be unloaded.
(Possible region codes:)
There are 6 regions (also called “locals”).
Each DVD player and disc will be played in
one region ONLY.
1: Canada, U.S., U.S. Territories
2: Japan, Europe, South Africa, Middle East
(including Egypt)
3: Southeast Asia, East Asia (including Hong
Kong)
4: Australia, New Zealand, Pacific Islands,
Central America, Mexico, South America,
Caribbean
5: Former Soviet Union, Indian Subcontinent,
Africa (also North Korea, Mongolia)
6: China
Never make or change connections with the
power switched on.
CAUTION VISIBLE AND INVISBLE
LASER RADIATION WHEN
OPEN AVOID EXPOS U R E
TO BEAM (WARNING LOCA-
TION: INSIDE ON LASER
COVER SHIELD)
This product incorporates copyright protection
technology that is protected by method claims of
certain U.S. patents and other intellectual prop-
erty rights owned by Macrovision Corporation
and other rights owners. Use of this copyright
protection technology must be authorized by
Macrovision Corporation, and is intended for
home and other limited viewing uses only un-
less otherwise authorized by Macrovision Cor-
poration. Reverse engineering or disassembly
is prohibited.
WARNING: To reduce the risk of fire or electric shock,
do not expose this apparatus to rain or moisture. The
apparatus shall not be exposed to dripping or splashing
and that no objects filled with liquids, such as vases,
shall be placed on the apparatus.
Important Safety Instructions

8
D
V
D
+
R
/
R
W
R
e
c
o
r
d
e
r
R
W
Getting Started
Please read these precautions before operating this unit.
Power cord protection
To avoid any malfunctions of the unit, and to protect against electric shock, fire or personal injury, please
observe the following.
Hold the plug firmly when connecting or disconnecting the AC power cord.
Keep the AC power cord away from heating appliances.
Never put any heavy object on the AC power cord.
Do not attempt to repair or reconstruct the AC power cord in any way.
Placement
Avoid placing the unit in areas of:
direct sunlight or heating radiators, or closed automobiles
high temperature (over 350C) or high humidity (over 90%)
much dust as the internal parts may be seriously damaged.
Non-use periods
When the unit is not being used, turn it off. When left unused for a long period of time, the unit should
be unplugged from the household AC outlet.
No fingers or other objects inside
Touching internal parts of this unit is dangerous, and may cause serious damage to the unit. Do not at-
tempt to disassemble the unit.
Do not put any foreign object on the disc tray.
Keep away from water/magnet
Keep the unit away from flower vases, tubs, sinks, etc. If liquids are spilled into the unit, serious dam-
age could occur.
Never bring a magnet or magnetized object near the unit.
Stacking
Place the unit in a horizontal position, and do not place anything heavy on it.
Condensation
Moisture may form on the lens in the following conditions:
immediately after a heater has been turned on
in a steamy or very humid room
when the unit is suddenly moved from a cold environment to a warm one If moisture forms inside this
unit, it may not operate properly. In this case, turn on the power and wait about one hour for the mois-
ture to evaporate.

If there is noise interference on the TV while a broadcast is being received
Depending on the reception condition of the TV, interference may appear on the TV monitor while you
watch a TV broadcast and the unit is left on. This is not a malfunction of the unit or the TV. To watch a
TV broadcast, turn off the unit.
Precautions

9
D
V
D
+
R
/
R
W
R
e
c
o
r
d
e
r
R
W
Getting Started
About This Manual
Thank you for purchasing this DVD Recorder. We sincerely hope you can enjoy the pleasure of
recording and playing back pictures through this quality unit with only certain simple operations
to follow. Through this DVD Recorder, you can watch DVDs, play audio CDs, or watch TV shows
through external devices. What’s more, you can record programs to DVD+R or DVD+RW discs.
This DVD Recorder supports the following Media Formats:
--Playable disc format
 DVD, DVD+R, DVD+RW, DVD-R, DVD-RW, VCD, SVCD, CD-DA, Mixed CD-DA, MP3,
WMA Audio CD, JPEG file disc and Kodak Picture disc.
--Recordable disc format
 DVD+RW (Application Programme)
 DVD+R
NOTE:
Some discs may encounter problems during playback possibly due to mal production or external
damage. If the discs are self-burn, self-copy or are non-original, we can not guarantee that they
will be playable.
How to Proceed in This Manual
Using the DVD recorder and its features may be confusing at first. Please follow the order below
to help you get through the important stages of getting set up so you can start using your DVD
recorder as soon as possible.
1
Check the contents of the package.
Refer to the section of “PACKAGE CONTENTS” in the manual that was included with this unit.
You should have the items listed in the section.
2
Get acquainted with the recorder.
Refer to the sections of “Parts and Controls” in the manual. It will let you get familiar with the
parts and buttons on the main unit and remote control as you proceed throughout the manual.
3
Make the necessary connections.
Refer to the section of “CONNECTIONS” in the manual. It will guide you how to make the
connections with external audio and video device.
(To continue to the next page)

10
D
V
D
+
R
/
R
W
R
e
c
o
r
d
e
r
R
W
Getting Started
About This Manual -continued
4Set the necessary settings from the initial setup menu.
Before you operate the DVD recorder, refer to the section of Chapter 4:Initial Settings in
the manual. It will provide on-screen menus with different options to let you select the proper
settings corresponding to the system.
5Record a disc.
You can record your favourite shows from local cable TV, or music and picture from an external
audio and video device on both DVD+R and DVD+RW media. Refer to section of Chapter 1-2
Recording in the manual.
6Play back a disc.
After making all the connections and menu setups, you can start to play DVD, DVD+R, DVD+RW,
DVD-R, DVD-RW, JEPG photo CD, Video CD, MP3, or CD discs with the recorder. Refer to section
of Chapter 2-1 : DVD Playback, or Chapter 3-1 : Audio CD Playback.
7Benefit all the available features.
You can obtain all the benefits from advance features given by this recorder. Refer to section of
Chapter 2-4: Other Functions in the manual.
Package Contents
Included in this package should be:
1 x GDVD 301R Recorder
1 x remote control
2 x AAA batteries for the remote control
1 x RCA AV line cable
1 x RF coaxial cable
1 x S-video cable
1 x Scart to scart cable
1 x Component video cable
1 x Blank DVD+RW disc
1 x User guide
1 x Quick reference
1 x Guarantee Card
1 x Warranty card
Should any of these items be missing, please contact the helpline on 0870-873-0080.

11
D
V
D
+
R
/
R
W
R
e
c
o
r
d
e
r
R
W
Getting Started
Front View
Back View
RCA Audio In (Left & Right)
RCA Vide Out
Cr/Y/Cb Out
S-Video Out
Coaxial (Digital Out)
60-178-C0206XA
TV Aerial Input
TV Aerial Out 21-pin Scart In Socket
21-pin Scart Out Socket
Parts and Controls
STANDBY/ON
button
S-VIDEO input
SOURCE button RECORD
button
L
AUDIO
R
input
VIDEO input
STOP button
PLAY button
DV In
Input

12
D
V
D
+
R
/
R
W
R
e
c
o
r
d
e
r
R
W
Getting Started
STAND BY button
CHANNEL button
RECORD/DISC
button
CLEAR button
MUTE button
TIMER button
DISC MENU button
DISPLAY button
REC. QUALITY button
REC/OTR button
PAUSE button
PREV. button
NEXT button
Numbers buttons
SOURCE (AV)
button
AUDIO button
SUBTITLE button
HELP button
EJECT button
SYSTEM button
VIDEO button
PR +/- button
TV  DVDR button
PLAY/ENTER button
Cursor buttons
RETURN button
DISC INFO button
EDIT button
STOP button
SLOW button
F.FWD button
F.BWD button
REPEAT (A-B) button
REPEAT (1-ALL) button
PROGRAM button
GOTO button
TITLE button
ZOOM button
ANGLE button
Remote Control
Parts and Controls - continued
NOTE
If you encounter some difficulties while operating this recorder, press
Help
(Help) button to
obtain some useful tips, such as DISC/MEDIA INFO, IMPORTANT NOTES, USEFUL BUTTONS, and
TROUBLESHOOTING to guide you through for using this recorder.
“Please note that there is No Sky Coding available for this remote control”

13
D
V
D
+
R
/
R
W
R
e
c
o
r
d
e
r
R
W
Getting Started
The Remote Control
Installing the batteries
Locate the remote control, and remove the battery cover.
Insert two AAA size batteries into the compartment.
Note: Refer to the diagram inside the battery compartment for correct installation of batteries.
We recommend the use of Alkaline batteries.
Using The Remote Control
To use the remote control, point it at the front of the DVD player, towards the sensor situated to
the right of the DVD drawer.
The remote control has a range of up to 6 metres from the DVD player and at an angle of up to
60 degrees.
Do not block the path of the beam from the remote control to the DVD player.
Note: Sunlight or very bright light will reduce the remote control sensitivity.

14
D
V
D
+
R
/
R
W
R
e
c
o
r
d
e
r
R
W
Getting Started
Connecting External Equipment
Turn the power off to your TV / Recorder before making any connections.
Connecting to a TV
Note: Only use one of the above mentioned options 1 or 2 to connect the recorder to your
TV otherwise it will cause picture interference.
60-178-C0206XA
VIDEO
INPUT
L
R
IN
Option 1:
RCA Audio
Video cable
(supplied)
TV
301R

Option 2: Scart Cable
(supplied)
21 Pin Scart (DVD) to 21
Pin Scart (TV)
White
Red
Yellow
White
Red
Yellow
Existing
Outdoor Aerial
Aerial Input
RF Loop through
Aerial cable
(supplied)
Scart In

15
D
V
D
+
R
/
R
W
R
e
c
o
r
d
e
r
R
W
Getting Started
Connecting External Equipment
Connecting to a SKY Box
Turn the power off to your TV / Recorder before making any connections.
60-178-C0206 XA
Aerial In
TV
301R
Scart Cable
(supplied)
21-pin Scart (DVD) to 21-pin
Scart (TV)
Aerial Lead
(not supplied)
TV
Aerial
RF Loop through
Aerial Cable
(supplied)
SCART 1
AV1 AV2
SCART 2
SKY Box
RF Loop through
Aerial Cable
Scart Cable
Scart Cable

16
D
V
D
+
R
/
R
W
R
e
c
o
r
d
e
r
R
W
Getting Started
60-178-C0206 XA

Connecting to a TV Using S-Video Cable
If your TV has a S-Video or S-VHS ( super video) Input , connect this DVD Recorder‘s S-Video
socket to your TV‘s S-Video In socket, this will provide a better viewing result on TV. Make sure to set
Video Output Settings to S-Video from VIDEO Setup Screen.
Connecting External Equipment
IN
TV
S-VIDEO
Existing
Outdoor Aerial
S-Video Cable
(supplied)
Aerial Input
RF Loop through
Aerial cable
(supplied)
301R

17
D
V
D
+
R
/
R
W
R
e
c
o
r
d
e
r
R
W
Getting Started
Connecting to a TV Using Component Video Cable
If your TV has Component Video input, connect this DVD Recorder‘s Cr Y Cb sockets to your TV‘s
Cr Y Cb In sockets, this will obtain the best viewing result. Make sure to set Video Output Settings to
RCA Component from VIDEO Setup Screen.
Connecting External Equipment
Cr
301R
Y
Cb
IN
TV
Red
Green
Blue
Existing
Outdoor Aerial
Component Video Cable
(supplied)
RF Loop through
Aerial cable
(supplied)
Aerial Input
60-178-C0206 XA
Red
Green
Blue

18
D
V
D
+
R
/
R
W
R
e
c
o
r
d
e
r
R
W
Getting Started
60-178-C0206 XA
Aerial Input
Connecting to an AV Amplifier
When you’re playing a DVD with digital surround sound tracks, you can either connect this player
to a compatible digital sound decoder or an AV amplifier (for models that support built-in decoding)
if the disc was recorded in Dolby Digital format.
Connecting External Equipment
RF Loop through
Aerial cable
(supplied)
VIDEO
INPUT
Existing
Outdoor Aerial
TV
301R
Coaxial digital output to
coaxial digital input
(supplied)
L
R
AUDIO
INPUT
VIDEO
OUTPUT
AV
AMPLIFIER
VIDEO
INPUT
RCA Audio
Video cable
(supplied)
RCA Video cable
(not supplied)
Red
Yellow
White
Yellow
Red
White
Yellow
Yellow

19
D
V
D
+
R
/
R
W
R
e
c
o
r
d
e
r
R
W
Getting Started
Connecting to Other AV Equipment
You can connect to a VCR or Camcorder, or other AV device using RCA Audio Video cable.
Connecting External Equipment
RCA Audio Video
cable (supplied)
301R
White
Red
Yellow
White
Red
Yellow
Camcorder
VCR
VIDEO
L
R
AV OUT

20
D
V
D
+
R
/
R
W
R
e
c
o
r
d
e
r
R
W
Getting Started
Connecting to a DV
You can use DV connection to copy DV recording onto DVD discs.
Connecting External Equipment
IEEE1394 Output (DV Out) to IEEE
1394 Input (DV In) on DVD
301R
DV
DV OUT
IEEE1394 Cable (not supplied)
