Goodmans GDVD750R User manual

GB 1
GB
SAFETY
To ensure proper use of this product, please read this owner manual carefully
and retain for future reference. Should the unit require maintenance, con-
tact an authorized service location.

GB 2
IMPORTANT SAFEGUARDS
PREFITTED MAINS PLUGS
For your convenience a mains plug has been fitted to this appliance. For your safety please observe the
following information.
1. Should the fuse in the plug fail remove the plug from the wall socket and replace the fuse with a 3 Amp
ASTA approved to BS 1362 fuse.
2. Never use the plug without the fuse cover fitted. Replacement fuse covers are available from your
dealer or most electrical retail outlets.
3. If the mains plug is cut off the cable, rewire the replacement plug in accordance with instruction give in
this manual.
4. CAUTION: Under no circumstances should the discarded plug be inserted into the mains socket. To
prevent a shock hazard carefully dispose of the discarded plug. Do not leave the plug lying around
where children might see it.
WARNING: To prevent fire or shock hazard do not expose this unit to rain or moisture.
CAUTION: DANGEROUS VOLTAGES EXIST INSIDE THIS UNIT. DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL. DISCONNECT FROM MAINS SUPPLY WHEN NOT IN USE.
This wires in this mains lead are coloured in
accordance with the following wiring codes:
Blue…….......…….…...............………Neutral
Brown……………………......................…Live
This wires in this mains lead must be
connected to the terminals in the plug as
follows:
Blue Wire……………..……..………N or Black
Brown Wire…………..….....…………L or Red
Only a 3 Amp fuse should be fitted in the
plug or a 5 Amp fuse at the distribution
board.
WARNING: UNDER NO CIRCUMSTANCES MUST THE LIVE OR NEUTRAL WIRES BE CONNECTED TO
THE EARTH TERMINAL IN A 3-PIN MAINS PLUG.
This symbol means that this unit is double insulated.
An earth connection is not required.
HELPLINE PHONE NUMBER 08708-730080

GB 3
GB
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: RETAIN THIS BOOKLET FOR FUTURE REFERENCE.
This set has been designed and manufactured to assure personal safety. Improper use can result in electric
shock or fire hazard. The safeguards incorporated in this unit will protect you if you observe the following
procedures for installation, use and servicing. This unit does not contain any parts that can be repaired by the
user.
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near
water.
• Clean only with dry cloth.
• Do not block any ventilation
openings. Install in accordance
with the manufacturer’s
instructions.
• Do not install near any heat
sources such as radiators, heat
registers, stoves, or other
apparatus (including amplifiers)
that produce heat.
• Protect the power cord from
being walked on or pinched
particularly at plugs, convenience
receptacles and the point where
they exit from the apparatus.
• Only use attachments/
accessories specified by the
manufacturer.
• Unplug this apparatus during
lightning storms or when unused
for long periods of time.
• Refer all servicing to qualified
service personnel. Servicing is
required when the apparatus has
been damaged in any way, such as
when the power supply cord or
plug is damaged, liquid has been
spilled or objects have fallen into
the apparatus, the apparatus has
been exposed to rain or moisture,
does not operate normally, or has
been dropped.
• Apparatus shall not be exposed
to dripping or splashing and that
no objects filled with liquids, such
as vases, shall be placed on the
apparatus.
•Disc Tray
Keep your fingers well clear of the
disc tray as it is closing. It may
cause serious personal injury.
•Burden
Do not place a heavy object on, or
step on the product. The object
may fall, causing serious personal
injury and serious damage to the
product.
•Disc
Do not use a cracked, deformed,
or repaired disc. These discs are
easily broken and may cause
serious personal injury and
product malfunction.
•Damage Requiring Service
Unplug this product from the wall
outlet and refer servicing to
qualified service personnel under
the following conditions:
a) When the power-supply cord or
plug is damaged.
b) If liquid has been spilled, or ob-
jects have fallen into the product.
c) If the product has been exposed
to rain or water.
d) If the product does not operate
normally by following the operat-
ing instructions. Adjust only those
controls that are covered by the
operating instructions. Improper
adjustment of other controls may
result in damage and will often
require extensive work by a quali-
fied technician to restore the prod-
uct to its normal operation.
e) If the product has been dropped
or damaged in any way.
f) When the product exhibits a dis-
tinct change in performance - this
indicates a need for service.
•Servicing
Do not attempt to service this
product yourself as opening or
removing covers may expose you
to dangerous voltage or other
hazards. Refer all servicing to
qualified service personnel.
•Replacement Parts
When replacement parts are
required, be sure the service
technician has used replacement
parts specified by the
manufacturer or have the same
characteristics as the original
part. Unauthorized substitutions
may result in fire, electric shock,
or other hazards.
•Safety Check
Upon completion of any service or
repairs to this product, ask the
service technician to perform
safety checks to determine that
the product is in proper operating
condition.
• European versions comply with CE
requirements.

GB 4
Examine the contents of the box for your DVD Receiver.
There should be the following:
• DVD Receiver with attached power cord
• Remote Control with 2 batteries
• Instruction Book
• Scart Cable
• MW loop aerial and FM aerial
• Subwoofer with connection cable
• 2 front speakers with wire
• Centre speaker with wire
• Surround back speaker with wire
• 2 rear speakers with wire
Packing
Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are
trademarks of Dolby Laboratories.
Apparatus Claims of U.S. Patent Nos. 4,631,603, 4,577,216, 4,819,098, and 4,907,093 licensed
for limited viewing uses only.
Software Licence and Copyright Notice
All software that is supplied as part of this equipment is protected by copyright laws and
international copyright treaties, as well as other intellectual property laws and treaties. This
software is licensed, not sold and is intended for use on this device only.
All title and copyrights in and to the software (including but not limited to any images,
photographs, animations, video, audio, music, text, instructions, code and "applets"
incorporated into the software) are owned by Orient Power Video Manufacturing Ltd. or its
suppliers.
You may not reverse engineer, decompile, or disassemble this software for any purpose.
No part of this software may be copied, reproduced, loaned, rented, leased or
transmitted in any form or by any means electronic or mechanical, without the express
written permission of Orient Power Video Manufacturing Ltd.
Consumers should note that not all high definition television sets are fully compatible with this product
and may cause artifacts to be displayed in the picture. In case of 525 or 625 progressive scan picture
problems, it is recommended that the user switch the connection to the “standard definition” output. If
there are questions regarding our TV set compatibility with this model 525p and 625p DVD player,
please contact our customer service centre.
This product incorporates copyright protection technology that is protected by method claims of certain
U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights
owners. Use of this copyright protection technology must be authorized by Macrovision Corporation,
and is intended for home and other limited viewing uses only unless otherwise authorized by
Macrovision Corporation. Reverse engineering or disassembly is prohibited.
Contents
Introduction
Safety ................................................................................................................... GB 1
Important Safeguards .............................................................................................. GB 2
Important Safety Instructions ................................................................................... GB 3
Contents, Packing ................................................................................................... GB 4
Player Zones, Anti-copy Disc Protection, Installation ..................................................... GB 5
DVD Discs & Cleaning DVD Discs ............................................................................. GB 5
Remote Control ...................................................................................................... GB 6
Front Panel ............................................................................................................ GB 7
Rear Panel ............................................................................................................. GB 8
Connections
Setup and Installation - Video Connections ................................................................... GB10
Audio Connections, Speaker Connections .................................................................... GB11
Loudspeaker Placement ........................................................................................... GB13
Switch on for the first time, Special on screen message ................................................ GB13
Function Setup
Basic Operations .................................................................................................... GB14
Play, Play Mode, Lock ............................................................................................... GB15
Display ................................................................................................................. GB16
Sound ................................................................................................................... GB17
Language .............................................................................................................. GB19
Basic Playback
General Operation ................................................................................................... GB 20
Surround Sound & Surround Effects ........................................................................... GB 21
Radio .................................................................................................................... GB 22
Sleep .................................................................................................................... GB 24
Playing DVD Discs .................................................................................................. GB 25
When DVD is playing ............................................................................................... GB 25
When DVD Disc is stopped ....................................................................................... GB 26
Playing Music CD .................................................................................................... GB 28
When Music CD is playing ........................................................................................ GB 29
When CD Disc is stopped ......................................................................................... GB 30
Playing VCD Discs .................................................................................................. GB 32
When VCD is playing ................................................................................................ GB 32
Playing MP3/WMA/JPEG Discs ................................................................................. GB 33
MP3/WMA files alone .............................................................................................. GB 33
JPEG files alone ..................................................................................................... GB 33
MP3 files along with JPEG files ................................................................................. GB 34
Selections and play logic ........................................................................................... GB 34
When disc is playing ................................................................................................ GB 34
When disc is stopped .............................................................................................. GB 35
Problems
Disc you can play .................................................................................................... GB 38
Problems? ............................................................................................................. GB 39

GB 5
GB
Player Zones
Anti-copy Disc Protection
Installation
DVD Discs
For the purpose of distribution of DVD Discs, the world has been separated into 6
zones. The zone your unit is intended for is indicated on the Zone Label. This should
be the same as the label on discs available in your region. If you have any difficulties in
playing a disc, make sure that the disc is for the same zone as your player.
Some DVD discs have anti-copying devices.
With these discs the playback on a Television will give the highest quality picture, however you will not be able to
record this signal on a VCR.
Install your unit on a stable flat surface. There must be sufficient room in front of the unit for the drawer to be
opened and the unit should be positioned so that it can see the remote control.
Do not expose your unit to extremes of temperature or humidity. Avoid standing it on a hot surface such as on
top of other hot running equipment and ensure that there is adequate ventilation to the unit.
* Caution : Do not install this equipment in confined space such as a book case or similar unit!
There are several types of DVD Disc.
Single sided discs. They play for approximately 2 HOURS
Single sided two layer discs. They play for approximately 4 HOURS
Double sided discs. They play for approximately 4 HOURS
Double sided with 2 layers on both sides. They play for approximately 8 HOURS
DVD discs have Titles and Chapters. There can be several Titles on one disc and each Title can contain several
Chapters. Titles and Chapters are numbered, e.g. Title 1, Title 2 etc. & Chapter 1,2,3 etc.
Usually Title one will show the disc publisher and studio
logos. The next Title will be the film. Other Titles
contain trailers for other films, production notes, or
alternative endings for the film. There are many
possibilities with Digital Versatile Disc. Chapters within
the main Title allow you to search quickly for a specific
point on the disc. Many discs have a Chapter Menu
sometimes called Scene Index or Scene Menu that
displays the first shot from each Chapter, which allows
you to select a shot and play the disc from that point
onwards. DVD discs can be PAL or NTSC. This player
can play both types (if the player zone is correct).
DVD discs allow up to 8 Languages and 32 subtitles on a single disc. You can select and change the language
and subtitle to suit yourself and play the whole disc or just part of it and view it from different angles.
Picture freezing & sound skipping or repeating can occur if the disc inside the player is dirty.
• When a disc becomes dirty, clean it with a cleaning cloth. Wipe the disc from the centre out.
• Do not wipe in a circular motion. Circular scratches can cause picture distortion or render the disc
unplayable.
CAUTION - Do not use solvents, commercially viable cleaners, or
antistatic spray intended for analogue discs.
Cleaning DVD Discs
Region 2

GB 6
Remote Control
1. turns unit on/off.
2. sets the sleep (auto-off) timer function.
3. V.SELECT toggles between progressive scan
and switches different video output modes.
4. AV SEL selects external AV inputs (press
repeatedly).
5. DVD selects DVD/CD/VCD mode.
6. TUNER selects Tuner mode, switches between
MW and FM bands.
7. TITLE (ROTATE) 1) displays the Title Menu if
present on disc (DVD mode only), 2) rotates
pictures when playing Picture CDs.
8. MENU 1) enters Disc Contents Menu in DVD
mode, 2) enters System Setup for SPEAKER
settings in all other modes.
9. skips backward/forward to the
previous or next chapter/track.
10. (Active Navigation keys) advance
in indicated directions for making
selections in menus, Active
Navigation mode and tuner
settings.
11. 1) stops playing, 2) selects Mono / Stereo in
Tuner mode.
12. starts playing.
13. freezes picture and sound during play.
14. ZOOM selects zooming options when playing
DVD by pressing repeatedly.
CLEAR delete the last selection.
15. OK 1) enters or selects in menu and setup
navigation, 2) in Tuner mode, enters preset
programming mode or confirms a preset.
16. increases or decreases the volume.
17. starts reverse or forward search.
18. INFO enters or exits Active Navigation mode.
19. EXIT exits menus and Active Navigation mode.
20. EFFECT selects surround modes or soundfield
modes.
21. EQ selects EQ modes.
22. 0 - 9 (Numeric keys) used for direct selections
of title, chapter, track, tuner channel and time
input.
23. mutes and unmutes sound output.
24. opens or closes the disc tray.
1
2
3
4
5
6
7
8
9

GB 7
GB
Front Panel
1
23 4 8
57
610
9
13
1. Standby On / Off
2. Disc Tray
3. Opens or closes the disc loading tray
4. SKIP 1) skips to previous chapter/track
in DVD/VCD/CD mode, 2) tunes down
frequency in tuner mode. When the preset
function applied, you can search downwards
to select the channel you want or start the
preset programming mode.
5. SKIP 1) skips to next chapter/track in
DVD/VCD/CD mode, 2) tunes up frequency in
tuner mode. When the preset function
applied, you can search upwards to select
the channel you want or start the preset
programming mode.
6. Stops playing
7. Pauses playing in DVD/VCD/CD mode
8. Starts playing in DVD/VCD/CD mode.
9. VOLUME Adjusts the master volume. Turn
clockwise to increase the volume and
anti-clockwise to decrease
10. DVD Selects DVD/VCD/CD as the input
source
11. TUNER Selects tuner as the input source.
Also switches between MW and FM bands.
12. Selects AV2 as the input source
13. Selects AV1 as the input source
14. Headphone socket
15. Infra-Red Receiver Window
16. VFD Display Area

GB 8
Rear Panel
1
2
IMPORTANT!
Connect the AC cord only after the speakers, aerial and all optional equipment have been
connected.
Never make or change any connections with the power switched on.
1. FM Aerial Input Connections
For FM reception, connect the FM aerial to the FM socket. Move the aerial in various directions until the
clearest signal is received.
MW Loop Aerial Connections
For MW reception, connect the MW loop aerial to the MW socket. Position the loop aerial to receive the
clearest sound.
Fully insert the stripped portion of the aerial into the terminal as shown above.
Note: Position the aerial as far away as possible from a TV, VCR or other radiation source.
2. Audio Inputs
For connecting audio (Left / Right) input signals from auxiliary sources such as VCR, TV or Satellite
Receiver and playing them through this Home Theater System. These connections are labelled AUX1 and
AUX2 and are selected by the AUX1 and AUX2 buttons on the front panel.
3. Video Inputs
For connecting video signals from the corresponding video out sockets on the axillary items, e.g. TV, VCR
or satellite receiver.
4. Audio Outputs - VCR
For connecting audio (Left / Right) signals to external recording devices such as VCR or Tape Recorder.
5. Video Output - VCR
For connecting VCR or other recording device (Most DVDs cannot be recorded, however you can use this
connection to record from the auxiliary inputs, e.g. satellite receiver, as well).
6. Component Video & Progressive Outputs
For connecting TV with component video input (using component video cable, not provided).
1
23
4 8
7
6
911
5
17 10
12
18
19
15
16
13
14

GB 9
GB
Rear Panel
7. Digital Coaxial Input
For connecting external equipment that has a digital coaxial output socket.
8. Digital Coaxial Output
For connecting an external equipment that has digital audio input socket, such as a CDR recorder.
9. S - Video Output
For connecting the S-VIDEO IN socket on the TV using an optional S-Video cable. This type of connection
will provide superior picture quality. However, your TV must be equipped with an S-Video input socket.
10. Composite Video Output - TV
For connecting to TVs (Most TVs have this type of connections. If your TV has Component Video or S-Video,
you will get a better picture by using them instead).
11. Digital Optical Input
For connecting an external equipment that has a digital optical output socket.
12. SCART TV
For connecting TV using SCART cable.
13. Subwoofer Speaker (Included)
Connect the included subwoofer with coloured wire to “+” and black wire to “-”.
14.Centre Speaker
For connecting the centre speaker to “C” terminals. Connect the coloured wire to “+” and black wire to “-
”.
15. Surround Speaker (Left & Right)
For connecting the left surround speaker to “SL” terminals and right surround speaker to “SR” terminals.
Connect the coloured wire to “+” and black wire to “-” .
16. Front Speaker (Left & Right)
For connecting the left front speaker to “FL” terminals and right front speaker to “FR” terminals.
Connect the coloured wire to “+” and black wire to “-”.
17. Surround Back Speaker
For connecting the surround back speaker to “SB” terminal. Connect the colorued wire to “+” and black
wire to “-” .
18. Active Subwoofer Out
For connecting an external powered subwoofer. (Not supplied)
19. Power Cord

GB 10
Setup and Installation
The following setup and installation diagrams show the different video and audio connections to TV, VCR or CD
Recorder.
Important
Connect the AC cord only after the speakers, aerials, and all optional equipment have been
connected.
(1) Video Connections
For good picture quality, use RCA VIDEO CABLE
For best picture quality, use SCART CABLE
(included) or COMPONENT VIDEO CABLE
(not included)
NOTE: When in AV1 or AV2 mode, only TV Out and SCART TV will have video output signal, therefore, connect
only TV Out or SCART TV to your TV set.

GB 11
GB
(3) Speaker connections
Before Connecting
This DVD Receiver is designed to reproduce optimum sound quality when the supplied speakers are used.
Maintain correct polarity when connecting speakers (coloured wire for positive and black wire for negative).
To prevent damage to circuits, never short-circuit the positive and negative speaker output terminals.
(2) Audio Connections
Example: CD RECORDER
(OPTIONAL)
VCR
AUDIO IN
IN
VCR
AUDIO OUT
TV AUDIO OUT
COAXIAL OUT
TV AUDIO OUT / IN
IN
SUBWOOFER
(Can be placed
anywhere in the room)
in
5
SURROUND
RIGHT SPEAKER (Rear)
5
(Rear)
1
FRONT LEFT
SPEAKER
1
3
CENTRE
SPEAKER (Front)
3
(Front)
4
SURROUND
LEFT SPEAKER (Rear)
4
2
FRONT RIGHT
SPEAKER
2

GB 12
Connection of all speakers are the same.
Notes
• Do not remove
excessive amount of
insulation on the wire
cords, to avoid the
stripped portion from
touching each other. The
optimal length for the
stripped part should be
around 1/3 inch (or
1cm).
• Do not push the
stripped part too far
into the speaker
connectors.
Press the button down & insert the wire, then release the button.
The above connections are connected according to colour codes show in the below table:
FRONT LEFT FRONT RIGHT CENTRE SURROUND
RIGHT (REAR)
SURROUND
LEFT (REAR)
SPEAKERS
Speakers
Terminals
Use Wires
Note: always connect coloured wire to coloured speaker terminal (+).
always connect black wire to black speaker terminal (-).
Unit
Terminals L+
White
L -
Black
White Black
R+
Red
R -
Black
Red Black
C+
Green
C -
Black
Green Black
SL+
Blue
SL -
Black
Blue
SR+
Grey
SR -
Black
Grey Black
PASSIVE
SUBWOOFER
+-
Black
Black
Purple
PurpleBlack
BACK
SURROUND
SB+ SB-
Black
Black
Brown
Brown
Black Wire
Colored Wire

GB 13
GB
Special On Screen Message
This symbol when displayed, means that the key you have pressed is not available at this time, or
that this action is not allowed by the disc at this time.
Loudspeaker Placement
Switch on for the First Time
• You have connected up the Home Theater System as shown in the preceding pages.
• Connect Power to the DVD Player.
• The DVD Player should have the Standby Light illuminated.
• Press the Power on key (either on the panel or the remote control), the player will be in AV 1 mode.
• Press DVD (either on the panel or the remote control), the DVD Player will switch on in DVD mode. After
a few seconds the panel will show “NO DISC”.
• Switch on your TV and select the AV input that the DVD Player is connected to. You should see the DVD
Screen and a message “Insert a disc”.
• Press the open key (on the panel or the remote control). The drawer will open. Place a DVD in the drawer,
and press close (same as open). The player will read the disc and start playing it. Before the movie starts
to play, a menu will be shown. You will need to select ‘PLAY MOVIE’ and press [OK] before the movie will
start.
• Although you can watch a movie immediately, to get the best result from your Home Theater, you should
now press ‘STOP’ and proceed to do the system setup options on the next page. This will set up all the
functions on your theater. You only need to do this when you first install your Home Theater.
• If you choose to watch the movie you can find out about DVD options and navigation of the DVD disc in the
section “Playing a DVD disc” and onward.
Placement of speakers play an important role in the reproduction of surround sound. Particular attention
should be taken when designing the speaker layout. For the best surround effects, all speakers should be
installed.
A typical room layout will have the left, centre, and right speakers placed across the front and the left surround
and right surround speakers placed along the sides towards the rear and the back surround speaker placed
right behind the listener as shown in the above left picture. The centre speaker can be positioned above or
below the video screen or TV. A subwoofer can be installed for powerful bass sounds and can be positioned
anywhere in the room.
The ‘speaker to listener dimensions’ shown in the above right picture is used for proper setup of the surround
system ( Please refer to Speaker Setup on P.16 ).
Note:
•Do not connect more than one speaker to any one pair of +/- speaker terminals.
• Do not connect speakers with an impedance lower than the speakers supplied.
TV
Front
speaker
(left)
Front
speaker
( right )
VIEWING AREA
Subwoofer
Center Speaker
Rear speaker
( right surround )
Rear speaker
( left surround )
TV
Front
speaker
(left)
Front
speaker
( right )
DIM L
Subwoofer
Center Speaker
Rear speaker
( right surround )
Rear speaker
( left surround )
DIM C
DIM R
DIM RS
DIM LS
Surround back speaker Surround back speaker
DIM SB

GB 14
Proper setup of the unit will let you enjoy better sound and picture quality as well as many useful features. The
selections are the preferred options that will be chosen, provided they are available on the disc. NOTE: If the
disc loaded does not have the preferred option then the disc’s own preference should be used.
BASIC OPERATIONS
To access the setup menu the unit must be in STOP mode.
Function Setup
Disc Menus
Player Menus
Subtitles
English
English
English
English
Audio
Play Mode
Lock
Display
Sound
Languages
Play
A parent menu exists,
press or EXIT
To make selections within a menu, press
and then OK
A root menu exists,
press or OK.
Use the Active Navigation keys to browse and make selections in the menus.
Play Mode
Lock
Display
Sound
Languages
Insert a disc
Play
Example shows how to select “French” as “Disc menus” language in the “Languages” menu.
Select “Disc Menus”
Open
“Languages”
Select
“Languages” x5
Player Menus
Audio
Subtitles
English
English
English
English
Disc Menus
Play Mode
Lock
Display
Sound
Languages
Play
Disc Menus
Audio
Subtitles
English
English
English
English
Player Menus
Play Mode
Lock
Display
Sound
Languages
Play
Play Mode
Lock
Display
Sound
Insert a disc
Play
Languages
Select “French” Open “Disc Menus”Confirm “French”
Player Menus
Audio
Subtitles
English
French
English
English
Disc Menus
Play Mode
Lock
Display
Sound
Languages
Play
Audio
Player Menus
Subtitles
Disc Menus
Spanish
German
Portuguese
English
Italian
Swedish
French
Audio
Player Menus
Subtitles
Disc Menus
Spanish
German
Portuguese
English
Italian
Swedish
French

GB 15
GB
PLAY
PLAY MODE
LOCK
Play Mode
No menu available without disc loaded. (See under “When DVD is stopped”
or “When CD is stopped”)
Play Mode
Lock Player
Create your password here using the numeric keys. The player is delivered
without a password. When you set the rating limits (see under “Rated
Titles”) for the first time, you are required to enter your own password (e.g.
1,2,3,4). This becomes the password for the unit. You must memorize this
password in order to change it in future.
Change Password
Change your existing password to a new one using the numeric keys to
replace the existing one.
Rated Titles
DVD discs have parental levels assigned to them. The range of parental
controls are from 1 to 8.
The player can be set in a similar way by pressing . If the
unit’s rating limit is set to 8, it will play all discs. If the player’s rating limit is
set below 8, only discs with a lower or equal parental level will play.
For example if the player is set to 5, only discs with parental control ratings
of 5,4,3,2, & 1 will play. To play a higher rated disc you must change the
unit’s rating to a higher number.
Enter New Password
OK
When alternative scenes with lower rating are included, the player will play the highest rated scene that the
parental setting allows. For example, consider a disc which is generally suitable for most audiences, and is
rated as level 2 for most part. However, in the middle there are also scenes rated at 5 & 7 (not suitable for
children).
The Disc
Enter New Password
OK
Play
Play
No menu is available without disc loaded. (See under “When DVD is stopped”
or “When CD is stopped”)

GB 16
PAL/NTSC
Press OK to select between PAL or NTSC output to match your TV or other
equipment.
Parental Level Set
to 5 or 6
Parental Level Set
to 7 or 8
The Unit
The unit’s behavior depends on the setting in the parental menu.
Parental Level Set
between 2 & 4
A section of the disc can have several different sequences which vary in parental control level. In the above
example of a disc with parental control, the player will show a different section depending on the parental
control level set in the player menu.
In this way, parents can control the content of films and there is no indication that any censorship has occured.
The meaning of the levels 1 to 8 varies depending upon the country and the type of content of the disc.
Some films do not have parental control assigned and will play irrespective of the player setting.
DISPLAY
TV Image
Three options available: 1) 4x3 Letter Box, 2) 4x3 Standard & 3) 16x9 Wide
Screen. Press OK to select a suitable one.
Select TV Image according to your TV type.
If you have a wide-screen (16:9) TV, select “16x9 Widescreen”
- for 16:9 movie, you will have full screen viewing.
- for 4:3 movie, black bars show on left and right sides of screen.
For conventional 4:3 TV,
- if you select 4x3 Letter Box for 16:9 movie, black bars show on top and
bottom of screen.
- if you select 4x3 Standard for 16:9 movie, left and right edges of the
screen are hidden.
- if you select either 4x3 Letter Box or 4x3 Standard for 4:3 movie, you will
have full screen viewing.
4 x 3 Letterbox
4 x 3 Standard
16x9Widescreen
Display
TV Image
PAL/NTSC
Progressive Scan
Progressive Scan
4x3 Letterbox
PAL
Off
Video
Component

GB 17
GB
SOUND
DRC
Press OK to turn on/off. This controls the Dynamic Range Compression
(DRC) for night time listening. DRC reduces the difference between normal
voices and sounds such as like explosion to avoid waking your neighbours.
The amount of range control available depends on the disc.
Digital Output
Press OK to check the box if you have connected the unit’s digital audio
output to a receiver with Dolby Digital or DTS.
Speaker Setup
Three options are available to adjust your speakers setting to
best fit your listening environment.
Speakers
You can indicate the presence and size of speakers you have
connected to your system within this menu. Options available are
as below. Press OK to confirm your selections.
Sound
Digital Output
Speaker Setup
PL II Mode
DRC
PL II Control
Music
Off
On
The setting will change to Progressive Scan ON.
Incorrect setting of this item can distort the picture or no video
can be observed after proceeding this step. To retrieve correct
video output, you can press V.SELECT key several times.
Do you want to continue?
No, switch to Component output.
Yes, switch to Progressive Scan output.
Does your TV support Progressive Scan mode? and
Have you connected the Component Video Output cable to your TV
and your TV has set up accordingly?
Yes
No
Center
Subwoofer
Surround
Front Speaker Size
Surround Back
Front
Component
SCART
S-Video
Progressive Scan
By displaying all the lines of a picture simultaneous (instead of displaying odd
and even lines alternatively such as a conventional TV), Progressive Scan greatly
enhances picture resolution while minimizing distortion and flickering. To use
this feature, your TV must be Progressive Scan compatible with
Component Video input sockets connected to the DVD unit.
1. Set your unit to PAL output mode.
2. Select the Progressive Scan option and press OK (or V.Select on the
remote control) to activate.
3. A caution message will display. Press OK to continue.
Caution: If you see distorted or no picture after pressing OK, then check the
following:
i) Your TV may not be Progressive Scan compatible. Wait a few seconds
and the unit will return to the previous setting before it was changed.
ii) Make sure your TV is connected with Component Video output from the
DVD unit and is now switched to view such input through which Progressive
Scan signals are transmitted . There will be no video signal from AV output,
in case you have both Component Video and AV connections.
4. A message requesting for confirmation will appear on screen. Select
Yes (confirm) or No (return to previous setting) by
and press OK to confirm.
Video Output
Press OK to select among Component Output, SCART Output and S-Video
output to match the video output of your DVD unit.

GB 18
Pro Logic II Mode
The additional flexibility of Pro Logic II allows it to be tailored for specific
applications. Five standard modes are available:
Pro Logic - it offers users the robust surround processing of the original
Pro Logic.
Virtual - it’s usually used when Pro Logic II is connected to a virtual
process for speaker use.
Music - it’s recommended as the standard mode for autosound music
systems (without video), and is optional for A/V systems.
Movie - It can be called simply “Pro Logic II”. It has stereo surround
channels and no surround filter, unlike Pro Logic which has a
mono surround channels and a 7KHz surround filter. Movie
mode is the standard required for all A/V systems.
Matrix - It the same as the Music mode except that the directional
enhancement logic is turned off. It may be used to enhance
mono signals by making them seem “larger”.
Pro Logic II Control
PL II Control lets you to customize the Pro Logic II Music Mode Sound
Effect. The option is available only when the player is in Music Mode.
Dimension
A simple control that alters the ratio of L+R to L-R for the two-
channel input signals. It allows the user to gradually adjust the
soundfield either towards the front or towards the rear. If a
recording is too spacious or strong from the surrounds, it can be
adjusted “forward” to get a better balance. Likewise, if a stereo
recording is somewhat too “mono” or “narrow” sounding, it can be
adjusted toward the rear to get a more enveloping, immersing
result.
Pro Logic
Matrix
Movie
Music
Virtual
Center Width
Dimension
Panorama
Off
Off
Off
Dimension
OFF
2
1
-3
-1
-2
3
Front Speaker Size - Small
Centre Speaker Size - None, Small
Subwoofer Speaker - None or Yes
Surround Speaker Size - None, Small
Back Surround Speaker size - None, Small
Note: Absent speakers are shown with dotted outline.
Distance
You can specify the distance (changing the sound delay) between
speakers (front, centre and surround speakers) and the listener for
optimal stereo sound.
The default distance is 10 feet for front and centre speakers and 5
feet for surround speakers. Change the distance from 1 to 30 feet
according to your actual listening environment by pressing
and then OK.
Volume
You can make fine adjustment to the loudness of each speaker from -
10 to +10 dB. When this option is selected, a test noise will
generate automatically from each speaker, one by one. To go to the
next speaker manually, press .
Adjust loudness by pressing and press OK to
confirm setting and exit the menu.
Distance
Speakers
Volume
dB
0
Center Speaker
Center
Surround
Front
Front Speaker Distance
10 feet
Surround Back

GB 19
GB
Panorama
Extends the front stereo image to include the surround
speakers for an exciting “wraparound” effect with side-wall
imaging.
Centre Width Control
With Pro Logic decoding, dominant centre signals can come
only from the centre speaker. If no centre speaker is present,
the decoder splits the centre signals equally to the left and
right speakers to create a “phantom” centre image. The
Centre Width control allows variable adjustment of the
centre image so it may be heard only from the centre
speaker; only from the left/right speakers as a phantom
image; or from all three front speakers to varying degrees.
It’s recommended to set the control to use the position 3
values for the Music mode. This will also help distinguish the
Music mode from the Movie mode, which automatically
presets the Centre-width control to position 0.
Panorama
OFF
ON
Center Width
OFF
5
Soft
1
3
2
6
7
LANGUAGES
Player Menus
Select among the 7 languages as default language for player menus. Press
OK to confirm selection.
Disc Menus
Select among the 7 languages (if available on disc) as default language for
disc menus. Press OK to confirm selection.
Audio
Select amongst the 7 languages (if available on disc) as the default audio
language. Press OK to confirm selection.
Subtitle
Select among the 7 languages (if available on disc) as the default subtitle
language. Press OK to confirm selection.
French
Spanish
German
English
French
Spanish
German
English
French
Spanish
German
English

GB 20
Selecting the source
Press one of the input selector buttons (on the front panel or remote control) to select the below input source:
- AV SEL (press AV1/ AV2 or AV SEL)
- TUNER
- DVD/CD/VCD
General Operation
Adjusting the Master Volume
The master volume adjusts all channels at the same time: Press on the remote control, OR rotate
the master volume knob on the front panel.
Muting the Sound
Press MUTE to mute the speaker output. The Speaker Indicator will disappear on the display and the MUTE
icon appears. Press MUTE or the volume button on the remote or volume knob on the front panel to restore
the speakers output.
- OPTICAL/ANALOG/COAXIAL/SCART INPUT SELECTIONS
1. In AV1 / AV2 or TUNER, press MENU button.
2. Press until Input Mode is selected.
3. Press OK, select AV1 or AV2, and press OK again. Then use to choose amongst OPTICAL,
ANALOG, COAXIAL and SCART TV inputs (AV1 only)
4. Press OK to save.
NOTE: Analog is set as the default input. Ensure your input selection matches your AV1 or AV2 audio
connection. Mis-matching input selection will result in no audio signal.
HzM
