GoPlus HW66420 User manual

THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Metal Garden Bench
HW66420
USER’S MANUAL

Back x 1
Arms x 2
Seat slats x 6
Board Identification
Not actual size
02

Board Identification
Not actual size
03

D12
M6 x 35mm
E4
M6 x 55mm
F16
M6
G1
4 x 4
Hardware List
Actual size
BOLT BOLT
WASHER ALLEN WRENCH
04

1
Attach the seat slat (C) to the arm (B) by bolts (D) with washers
(F) through the pre-drilled holes on the arm into the pre-welded
nuts on the seat slat. Repeat step for the other side arm(B).
IMPORTANT: Do not tighten completely until assembly is
completed.
05

2
Attach the back (A) to the arm (B) by inserting bolts (E) with
washers (F) through the pre-drilled holes on the arm into the
pre-welded nuts on the back. Repeat step for the other side
arm(B).
06

Tighten all the bolts with the allen wrench , and turn the
bench to the upright position. Your bench is now ready for
use, so relax & enjoy!
3
07

250lbs
250lbs
WARNING
This item is only suitable within the specified maximum load-bearing. Heavier
loads than the indicated load capacity may cause instability, resulting in possible
injuries.
Maximum Loads
08
