Gorenje DP7C User manual

STEP 1: READ THE LABELS ON THE LAUNDRY
•*See Pg. 4 for laundry labels.
STEP 2: PREPARING THE DRYING PROCESS (Switching the Drying Machine On)
•Press the (1) ON/OFF/RESET BUTTON to turn the drying machine on, off, and reset the program.
STEP 3: CHOOSING THE WASHING PROGRAM (Program Selector Knob)
•Choose the program by rotating the (2) PROGRAM SELECTOR KNOB to the left or to the right. (SEE PROGRAM
TABLE Pg. 3).
STEP 4: CHOOSING THE DRYING MODE AND EXTRA FUNCTIONS
•Adjust the settings by pressing the relevant function button (before pressing the (3) START/PAUSE BUTTON).
•Functions that can be changed or adjusted with the selected drying programs are partly lit (dimmed).
•Certain settings cannot be selected with some programs. Such settings will not be lit, and the button will flash
when pressed (SEE FUNCTION TABLE Pg. 4)
Description of lighting of functions for the selected drying program.
•Lit (Basic/preset setting)
•Dimmed (Functions that can be adjusted)
•Unlit (Functions that cannot be selected)
DRYING MODES –(4)
EXTRA DRY (4a)
•Press on the (4a) EXTRA DRY position to adjust the dryness level –the dryer the laundry, the longer the drying
cycle. This setting can be adjusted before the start of the drying process.
•The signal light will light up to confirm the selection of the relevant extra function.
GENTLE CARE (LOWER TEMPERATURE) –(4b)
•For delicate laundry. The lower temperature depends on the program for which the function was selected. This
setting can be adjusted for the start of the drying process.
•The signal light will light up to confirm the selection of the relevant extra function.
START DELAY -(5)
•Desired time when the drying program should start can be set in advance, which allows for more flexibility.
•Press the position (5) START DELAY to choose between 2h, 4h, 6h, and 8h (5a) Start Delay.
•The selected time is displayed when you press the (3) START/PAUSE Button.
•When the set delay time expires, the selected drying program will start automatically.
•To deactivate the Start Delay, press the position (5) START DELAY and hold for 3 seconds.
ANTI-CREASE
•If you do not intend or cannot remove the laundry from the dryer immediately after the completion of the drying cycle, we
recommend using the (8) ANTI CREASE function, which has to be selected before the start of the drying process.
•Press on the position (8) ANTI CREASE to choose between 1h, and 2h (8a).
•Once you open the door after the completion of the drying program, the function is automatically deactivated.
CHILD LOCK –(4) + (8)
•To activate or deactivate the child lock, press the positions (4) MODE (DRYING MODE) and (8) ANTI CREASE simultaneously
and hold them for at least 3 seconds until the symbol (7) lights up or goes off, respectively.
•If the child lock is activated, the program or additional functions cannot be changed.
•The child lock remains active after the dryer is switched off. Therefore, it must be deactivated before a new program can be
selected.
•It can also be switched off during the drying process.
STEP 5: STARTING THE DRYING PROGRAM
•To Start a drying program, Press the button (3) START/PAUSE.
STEP 6: END OF THE DRYING PROGRAM
•At the end of the drying program, a red indicator light will light up, and the (3) START/PAUSE Button light and ANTI CREASE
(8a) time indicator, if activated or selected, will flash.
*ADDITIONAL NOTES
Interrupting the program process
•Press the (3) START/PAUSE button to pause/resume a program.
•To stop and cancel the drying program, press the (3) START/PAUSE button and hold it for 3 seconds. The selected program
will stop, and the dryer will start to cool down. Cooling down time depends on the selected program.
Changing the program/functions
•Switch off the dryer by pressing the button (1) ON/OFF: then, switch it on again by pressing (1) ON/OFF and rotate the (2)
program selector knob to the desired program or choose extra functions.
•Select another program/function and press the (3) START/PAUSE button again.
Adding laundry after the start of the program,
•Open the door and press the (3) START/PAUSE button. Insert the laundry and press the button (3) START/PAUSE.
*Some functions are not available and cannot be selected with certain programs: an acoustic signal and a flashing light will
indicate such cases (SEE EXTRA FUNCTION TABLE –Pg. 4)
*After
GORENJE DP7C DRYING PROCESS –QUICK REFERENCE STEP BY STEP (1-6)

Q: Why does a drying cycle take longer
than I’m used to?
Condensation dryers, versus the almost obsolete
and previous technology of vented dryers, use
energy-efficient low wattage heating elements and
natural rotational force combined with cool fan-
forced air to delicately dry your clothes. This
mimics an outdoor clothesline, as opposed to
baking them dry like a toaster. The air runs through
easy to clean filters that catch residual lint or
clothing particulate from leaving the machine
which allows the Dryer’s air to enter the laundry
room, as opposed to venting hot and particulate
filled air out into the atmosphere, which is a
leading cause of the escalating greenhouse effect in
our world. Make no mistake; this dryer is helping
preserve our delicate world one laundry load at a
time.
Q: What cycle should I Use?
Normal is your go-to everyday mode. The machine will
sense residual moisture and stop the drying cycle
when clothes are deemed to be ready for standard
closet storage. This mode is the sweet spot between
wrinkled and not wrinkled, dry without being forceful
on the clothes, and still have minimal residual
moisture content. Choose Iron mode for slightly damp
clothes, which will make ironing out wrinkles very
easy. Choose Extra dry to make sure clothes are over-
dried and ready to be folded and put away.
If you have a specified time instead, choose the
minutes between 30/60/90 and the machine will run
at full drying capacity for that duration. This is often
best for a very small load and overrides factory or
sensor settings.
Additional Information
With a 5-year manufacturing warranty to
back these machines up, they are designed
to be a long-term and reliable partner in
your home.
Finding the specific settings that meet your
unique needs early on in the product life
cycle will yield you years of easy-to-use
laundry.
For general use of the standard wash and
dry features, you should budget for about
an hour and a half per wash or dry load,
which is convenient for when it comes time
to change your laundry loads over.
For any further questions, we encourage
you to contact either of our showrooms in
Ontario or BC.
Q: How big of a load can I do?
No bigger than your wash load. Tumble dryers
need extra space in the drum to allow clothes to
tumble around and dry.
Q: How can I choose how damp or dry I
want my clothes?
This might take a bit of trial and error to find the
exact cycle that works perfectly for your specific
needs, but personal experience in the machine I
use in my own home is that ‘Iron Dry’ is my
favourite setting. Clothes come out dry enough,
reduce the ‘pilling’ effect, and let the machine use
its sensors to tell me when it thinks the clothes are
ready and has a slight residual moisture content
that is perfect for ironing my work shirts. If desired
to have a clothes dryer, then go up to ‘Normal’. If
you have towels or anything heavier that does not
need any post-laundry maintenance, ‘Extra-Dry’
will make sure there is no residual moisture
allowing for immediate storage.
*Note also that there is an ‘anti-crease’ function.
Select this if you think you will be back to check on
laundry after the projected drying cycle is done.
This will make the machine do a few rotations
every few minutes to prevent clothes from resting
too long and directly helps to prevent wrinkles.
GORENJE DRYING –FAQ’S

PROGRAM TABLE GUIDE
PRORGAM MAX LOAD PROGRAM DESCRIPTION
Cotton
Storage (Cupboard Dry) 7 kg Use this program for thicker non-sensitive cotton laundry. After drying, it will be dry and ready to be stored in the cupboard.
Normal *7 kg Use this program for thicker non-sensitive cotton laundry of approximately the same thickness. After drying, it will be dry.
Iron (Moist for ironing) 7 kg Use this program for non-sensitive cotton laundry. After drying, it will be ready for ironing.
Mix (Mixed laundry/Synthetics)
Storage 3.5 kg The program is used for drying mixed laundry made of cotton and synthetic fibers.
Iron 3.5 kg The program is used for drying delicate laundry made of synthetics fibers.
Wool 2 kg This short program is intended for softening or fluffing clothes made of wool and silk, which have to be dried thoroughly according to the manufacturer s
instructions.
Sensitive 1 kg Use this program to dry highly delicate laundry made of synthetic fibers, which may be slightly moist after the drying process.We recommend using aspecial-
purpose laundry bag.
Air refresh 2 kg In this program, the heater is switched off. The program is suitable for refreshing your laundry.
Down wear 1.5 kg Use this program to dry textiles stuffed or padded with down (pillows, duvets, jackets, etc.). Dry large items separately and use the EXTRADRY function or the Time
Program if necessary.
Baby
(Baby clothes)
4kg Use this program to dry baby clothes. Clothes dried with this program are usually normally dry.
Sports (Sportswear) 3 kg Use this program for clothing with amembrane, and for sportswear made of mixed materials, and breathable fabrics.
Shirts 2 kg Use this program to dry shirts and blouses. Adjusted drum rotation prevents the laundry from creasing.
Time
(Timed drying program)
90´
60´
30´
4 kg Use this program for non-sensitive laundry that is still slightly moist and has to be thoroughly dried. In the time program, remaining moisture is not detected
automatically. If the laundry is still damp after the
program is complete, repeat the program; if it is too dry and therefore creased and rough to touch, the drying time you selected was too long.
Bedding 5 kg Use this program for larger items. When the program is complete, they will be dry. Adjusted drum rotation prevents the laundry from tangling.
If your laundry is not dried to the desired dryness level, use extra functions or use amore suitable program.
GORENJE DRYING –PROGRAMS

FUNCTION TABLE GUIDE LABELS ON THE LAUNDRY GUIDE
Normal wash;
Sensitive laundry
Max. washing
temperature
EXTRA HOT
Max. washing
temperature
HOT
Max. washing
temperature
WARM
Hand wash
only
COLD
Do not
wash
Bleaching Bleaching in cool water
c1
Bleaching not allowed
Dry cleaning Dry cleaning
with all agents
A
Petroleum
solvent
R11, R113
P
Dry cleaning in
kerosene, pure
alcohol, and in
R113
F
Dry cleaning not
allowed
Ironing Hot ironing,
max.HIGH
temperature
Hot ironing,
max.
MEDIUM
temperature
Hot ironing,
max. LOW
temperature
Ironing not allowed
Drying Dry flat (place
on aflat
surface)
Drip dry
Line dry
High temperature
Low temperature
Do not tumble dry
Programmes
GENTLE
CARE
(LOWER TEMPERATURE)
EXTRA
DRY
START
DELAY
ANTI
CREASE
Cotton
Storage (Cupboard dry) • • • •
Normal • • • •
Iron (Moist for ironing) • • • •
Mix (Mixed laundry/Synthetics)
Storage • • • •
Iron • • • •
Wool
Sensitive • • •
Air refresh
Down wear • • • •
Baby (Baby clothes) • • • •
Sports (Sportswear) • • •
Shirts • • • •
Time
(Timed drying program)
90´ • •
60´ • •
30´ • •
Bedding • • • •
•Extra functions can be used
If your laundry is not dried to the desired dryness level, use extra functions or use amore suitable
program.
GORENJE DRYER –FUNCTION & LABELS

WARRANTY INFORMATION
Gorenje Appliances are designed and manufactured to the highest standards. Each appliance is
covered by comprehensive 2-year parts and labor warranty.
Refer to the product warranty policy for complete terms and conditions.
FOR PARTS &SERVICE
Euro-Parts &Service
39822 Belgrave Road, Belgrave, ON. N0G 1E0 1866 722
2262 www.euro-parts.ca •[e-mail] •
[e-mail]
Gorenje appliances are imported and distributed in North America by Euro-Line Appliances Inc.
For more information, please visit one of our showrooms or www.ela.ca /www.elawest.ca
101-1014 Homer Street, Vancouver, BC V6B
2W9 Canada
604 235 3980
1855 ELA WEST (352 9378)
[e-mail]
871 Cranberry Court, Oakville, ON L6L 6J7
Canada
905 829 3980
1 800 421 6332
[email protected]
SEE ADDITIONAL DOCUMENTS
Gorenje DP7C Specification Sheet
Gorenje DP7C User Manual
GORENJE DRYER –TYPICAL CONSUMPTION TABLE
SPO
Load
Spinning [rpm]
Electric energy consumption [kWh]
Drying
time
[min]
Programme 15,4 lb (7 kg)
Cotton Standard Total 1000 3,98 105
Partial 1400 2,40 70
Low 1000 2,19 61
Low 1400 1,60 55
Cotton moist for ironing Total 1000 2,70 80
Partial 1400 2,15 59
Low 1400 1,20 45
Mixed laundry/Synthetics
(*Iron) Partial 1000 1,15 40
measured by standard EN 61121
Standard programmes for cotton laundry in compliance with the currently effective regulation
EU 392/2012
Programme Amount of laundry
Max./half load
lb [kg]
Programme
duration
[min]
Electric energy
consumption
[kWh]
Cotton Standard 15,4/7,7 (7/3,5) 105/61 3,98/2,19
The Cotton Standard programme ,is intended for drying of normally wet cotton laundry. It is the
most efficient programme for drying cotton laundry in terms of power consumption.
Due to deviations in terms of type and amount of laundry, power supply oscillation, and
environment temperature and humidity, the values measured at the end user may differ from the
one stated in the table.
