GPS IDF-2 Instruction manual

NOTICE: This product is to be used only as directed. Read entire manual before use. Do not use unless properly installed.
Installation, Operation & Maintenance Manual
www.globalplasmasolutions.com
™
Pre-production release
Data
subject
to
change

Location
• Please read the operation manual before use.
• The IDF-2 shall be installed such that it is at least 7.5' above the floor.
• The IDF-2 is to be mounted on a suspended ceiling system (24” x 24”) that can fully support it's weight (11.5 lbs).
• For non drop ceilings use the ceiling box mount.
• Do not insert hands or materials into the airflow grill or touch the fan when the tile fan is running.
• To avoid the risk of shock, disconnect the electricity before cleaning.
• Installation must be in accordance with local electrical wiring regulations.
• Regularly clean and maintain the fan.
• Handle remote controller with care.
• Do not allow anything to obstruct the fan or airflow grill.
• Installation and maintenance by a trained professional.
• Children should be supervised to ensure that they do not play with the appliance.
Thank you for purchasing an IDF-2™ air ionization system from GPS Air.
What’s Included
Before you start, confirm the contents of your shipment. Each IDF-2™ will consist of the following:
1. IDF-2 air ionization system
2. Installation, Operation & Maintenance Manual
3. Remote Control
Not Included
1. Electrical wiring, junction box, or receptacle to provide power to the IDF-2
As part of the installation process, a Startup Document should be completed. For
the latest version of the document, visit our website or utilize the QR code.
For technical product queries, please reach out to [email protected]

Housing Cover
Motor
Ionizer
Fan Blade
Fan Cap
Bottom Housing
Diffuser
Diffuser Cap
1. Remove the ceiling tile where the IDF-2 will be installed.
Parts List
Installation
1. Review the installation video at our website or scan the QR code opposite.

2. Insert the IDF-2 diagonally through the opening and place gently onto the 2’ x 2’ ceiling frame.
3. Slide the adjacent ceiling tile away to allow easy access to the terminal block.

1
2
3
4
5
BEFORE USE, BE SURE:
• There are no foreign objects inside the circulating fan.
• The power is connected.
• The circulating fan is placed steadily.
REMOTE CONTROL FUNCTIONS:
1. Speed: High
2. Speed: Medium
3. Speed: Low
4. Power: On
5. Power: Off
The fan will begin to spin on every power up. Ensure all
guarding is installed before applying power.
Note: • The remote control can be used to operate a single fan system or multiple fans at the same time.
Cleaning Cycle
The IDF-2 comes with a preset cleaning cycle designed to clean the ionizer emitters twice per day.
Operation
Line/L1
120V - 240V Power Connections
Neutral/L2
Wiring
1. GPS recommends the IDF-2 be connected to a switched power source such as a lighting circuit.
3. If wiring to a non-switched circuit a means of removing power is required.
2. The IDF-2 requires a 120-240 VAC source. Connect the power wires as follows:
4. Remove the terminal block cover with a Philips-head screwdriver.

1. Support the diffuser with one hand while removing the difuser cap (turn counter clockwise). Once removed
use a clean cloth to wipe the diffuser (highlighted in blue).
Cleaning and Maintenance
2. Use a clean cloth to wipe the area highlighted in blue (shown in the figure below).

The bottom housing is held to the fan with a hinge
4. Once the screw and 4 thumbs screws are removed gently allow the bottom housing to rotate downwards.
Use a clean cloth to wipe any visible dust and debris.
5. Re-Assemble in reverse order being careful to not cross thread the thumbscrews.
3. Remove the bottom housing for access to the fan blades.
Use a Philips-head screwdriver and remove the screw located on the side of the fan.
Remove 4 thumb screws located on each corner of the fan by rotating counter clockwise.
1
1
2
2
2
1

Contact GPS representative for additional assistance
Signal receiver malfunction
Fuse motor is cut off Contact GPS representative for additional assistance
Motor malfunction Contact GPS representative for additional assistance
Troubleshooting
The information provided in this manual is up to date at the time of printing. Any
revisions to this document will supersede the content included. For the latest
applicable version of this manual, visit our website or utilize the QR code.
Product Registration
By registering your order, the standard limited warranty on eligible products from
your purchase is automatically extended to 3 years, at no additional cost.
Register your products at www.gpsair.com/product-registration
or scan the QR code.
PROBLEM CHECK SOLUTIONS
Remote controller malfunction
IDF-2 cannot connect with powerRemote does not operate fan
(Fan does not rotate)
Check power and plug
Replace battery
Contact GPS representative for additional assistance
Contact GPS representative for additional assistance
Remote control indicator light does not work
IDF-2 is dirty
Damage to motor bearing
IDF-2 is not stableFan makes unusual noise Stabilize IDF-2
Re-fix the airflow grille
Tighten the fan cap
Clean the IDF-2
Airflow grille has friction with main body
Loose fan cap
Air movement fan does not
operate
Distribution grille does no operate

3101 Yorkmont Road • Suite 400
Charlotte, NC 28208
980-279-5622
www.gpsair.com
GPS-066-11-R20-iDF2 IOM
© 2023 GPS Air
GPS Air is the owner of certain trademarks that appear in our materials. Please visit www.gpsair.com/trademarks for a list of our marks.
