GPS GPS-1000X Series User manual

User Manual
Super Phosphor Oscilloscope
V 1.1
GPS-1000X/XS series
All Rights Reserved - General Polytronic Systems Ltd., London
www.gpslimited.com

All Rights Reserved - General Polytronic Systems Ltd., London
www.gpslimited.com

User Manual I
Safety Information
General Safety Summary
Carefully read the following safety precautions to avoid any personal injury or
damage to the instrument and any products connected to it. To avoid potential
hazards, please use the instrument as specified.
Use Proper Power Line
Only the power cord designed for the instrument and authorized by local country could be
used.
Ground the Instrument
The instrument is grounded through the protective earth conductor of the power line. To
avoid electric shock, please make sure the instrument is grounded correctly before
connecting its input or output terminals.
Connect the Signal Wire Correctly
The potential of the signal wire is equal to the earth, so do not connect the signal wire to a
high voltage.
Look Over All Terminals’ Ratings
To avoid fire or electric shock, please look over all ratings and sign instruction of the
instrument. Before connecting the instrument, please read the manual carefully to gain
more information about the ratings.
Use Proper Overvoltage Protection
Make sure that no overvoltage (such as that caused by a thunderstorm) can reach the
product, or else the operator might expose to danger of electrical shock.
Electrostatic Prevention
Operate in an electrostatic discharge protective area environment to avoid damages
induced by static discharge. Always ground both the internal and external conductors of
the cable to release static before connecting.
Keep Well Ventilation
Inadequate ventilation may cause increasing of temperature, which will eventually
damage the instrument. So keep well ventilation and inspect the intake and fan regularly.
Avoid Circuit or Components Exposed
Do not touch exposed contacts or components when the power is on.
All Rights Reserved - General Polytronic Systems Ltd., London
www.gpslimited.com

II User Manual
Use proper Fuse
Use only the specified fuse.
Do Not Operate Without Covers
Do not operate the instrument with covers or panels removed.
Do Not Operate With Suspected Failures.
If you suspect damage occurs to the instrument, have it inspected by qualified service
personnel before further operations. Any maintenance, adjustment or replacement
especially to circuits or accessories must be performed by authorized personnel.
Do Not Operate in Wet Conditions.
In order to avoid short circuiting to the interior of the device or electric shock, please do
not operate in a humid environment.
Do Not Operate in an Explosive Atmosphere.
In order to avoid damages to the device or personal injuries, it is important to operate the
device away from an explosive atmosphere.
Keep Product Surfaces Clean and Dry.
To avoid the influence of dust and/or moisture in air, please keep the surface of device
clean and dry.
Handling Safety
Please handle with care during transportation to avoid damages to buttons, knob
interfaces and other parts on the panels.
All Rights Reserved - General Polytronic Systems Ltd., London
www.gpslimited.com

User Manual III
Safety Terms and Symbols
Terms in this Manual. These terms may appear in this manual:
WARNING
Warning statements indicate the conditions or practices that could
result in injury or loss of life.
CAUTION
Caution statements indicate the conditions or practices that could
result in damage to this product or other property.
Terms on the product. These terms may appear on the product:
DANGER Indicates direct injuries or hazards that may happen.
WARNING Indicates potential injuries or hazards that may happen.
CAUTION Indicates potential damages to the instrument or other property that may
happen.
Symbols on the product. These symbols may appear on the product:
Hazardous protective Earth Warning Test Power Switch
Voltage Terminal Ground
All Rights Reserved - General Polytronic Systems Ltd., London
www.gpslimited.com

IV User Manual
Measurement Category
Measurement Categories
The oscilloscopes can make measurements in measurement category I.
WARNING
This oscilloscope can only be used for measurements within its specified
measurement categories.
Measurement Category Definitions
Measurement category I is for measurements performed on circuits not directly connected
to MAINS. Examples are measurements on circuits not derived from MAINS, and
specially protected (internal) MAINS derived circuits. In the latter case, transient stresses
are variable; for that reason, the transient withstand capability of the equipment is made
known to the user.
Measurement category II is for measurements performed on circuits directly connected to
the low voltage installation. Examples are measurements on household appliances,
portable tools and similar equipment.
Measurement category III is for measurements performed in the building installation.
Examples are measurements on distribution boards, circuit-breakers, wiring, including
cables, bus-bars, junction boxes, switches, socket-outlets in the fixed installation, and
equipment for industrial use and some other equipment, for example. Stationary motors
with permanent connection to the fixed installation.
Measurement category IV is for measurements performed at the source of the low-voltage
installation. Examples are electricity meters and measurements on primary over current
protection devices and ripple control units.
All Rights Reserved - General Polytronic Systems Ltd., London
www.gpslimited.com

User Manual V
Working Environment
Temperature
Operating: 10℃ to +40℃
Non-operation:-20℃ to +70℃
Humidity
Under +35℃:≤90% relative humidity
+35℃ to +40℃: ≤60% relative humidity
WARNING
To avoid short circuit inside the instrument or electric shock, please do not
operate in humid environment.
Altitude
Operating: less than 3 Km
Non-operation: less than 15 Km
Installation (overvoltage) Category
This product is powered by mains conforming to installation (overvoltage) category II.
WARNING
Make sure that no overvoltage (such as that caused by thunderbolt) can reach
the product, or else the operator might expose to danger of electric shock.
Installation (overvoltage) Category Definitions
Installation (overvoltage) category I refers to signal level which is applicable to equipment
measurement terminals connected to the source circuit. In these terminals, precautions
are done to limit the transient voltage to the corresponding low level.
Installation (overvoltage) category II refers to the local power distribution level which is
applicable to equipment connected to the AC line (AC power).
All Rights Reserved - General Polytronic Systems Ltd., London
www.gpslimited.com

VI User Manual
Ventilation Requirement
This oscilloscope uses fan to force cooling. Please make sure that the air intake and
exhaust areas are free from obstructions and have free air. When using the oscilloscope
in a bench-top or rack setting, provide at least 10 cm clearance beside, above and behind
the instrument for adequate ventilation.
WARNING
Inadequate ventilation may cause temperature increase which would damage
the instrument. So please keep the instrument well ventilated during operation
and inspect the intake and fan regularly.
All Rights Reserved - General Polytronic Systems Ltd., London
www.gpslimited.com

User Manual VII
General Care and Cleaning
Care
Do not store or leave the instrument in direct sunshine for long periods of time.
WARNING
To avoid damages to the instrument or probe, please do not leave them in fog,
liquid, or solvent.
Cleaning
Please perform the following steps to clean the instrument and probe regularly according
to its operating conditions.
1. Disconnect the instrument from all power sources, and then clean it with a soft wet
cloth.
2. Clean the loose dust on the outside of the instrument and probe with a soft cloth.
When cleaning the LCD, take care to avoid scarifying it.
WARNING
To avoid damages to the surface of the instrument and probe, please do not
use any corrosive liquid or chemical cleanser.
WARNING
Make sure that the instrument is completely dry before restarting it to avoid
short circuits or personal injuries.
All Rights Reserved - General Polytronic Systems Ltd., London
www.gpslimited.com

VIII User Manual
Document Overview
This manual introduces how to use the digital oscilloscope in details.
Quick Start Provide information about preparations before
using the instrument and a brief introduction of
the instrument.
To Set the Vertical System Introduce the functions of the vertical system of
the oscilloscope.
To Set the Horizontal System Introduce the functions of the horizontal system
of the oscilloscope.
To Set the Sample System Introduce the functions of the sample system of
the oscilloscope.
To Trigger the Oscilloscope Introduce the trigger mode, trigger coupling,
trigger hold off, external trigger and various
trigger types of the oscilloscope.
Serial Trigger and Decode Introduce how to trigger and decode the input
signal.
To Save Reference Waveform Introduce how to save and display REF
waveform.
To Make Math Operation Introduce the math operation function of the
oscilloscope.
To Make Cursor Measurements Introduce how to use cursors to make
measurements.
To Make Measurements Introduce how to use measure function to
measure the waveform parameters.
Display Setting Introduce how to set the display of the
oscilloscope.
Save and Recall Introduce how to save and recall the
measurement result and the setting of the
oscilloscope.
System Setting Introduce how to set the system setup.
Arbitrary Waveform Generation Introduce how to use Arbitrary waveform
generation function.
Default Introduce the Default setup of the oscilloscope
Troubleshooting Introduce how to deal with common failures of
the oscilloscope.
Table of Content
Copyright and Declaration .......................................................................... 错误！未定义书签。
All Rights Reserved - General Polytronic Systems Ltd., London
www.gpslimited.com

User Manual IX
Safety Information ........................................................................................................................... I
General Safety Summary ........................................................................................................... I
Safety Terms and Symbols ....................................................................................................... III
Measurement Category .......................................................................................................... IV
Working Environment .............................................................................................................. V
Ventilation Requirement......................................................................................................... VI
General Care and Cleaning ..................................................................................................... VII
Document Overview ................................................................................................................... VIII
Quick Start ....................................................................................................................................... 1
General Inspection .................................................................................................................... 2
Appearance and Dimensions .................................................................................................... 3
To Prepare the Oscilloscope for Use ......................................................................................... 4
To Adjust the Supporting Legs ..................................................................................... 4
To Connect to Power Supply ........................................................................................ 5
Power-on Inspection ...................................................................................................... 6
To Connect the Probe .................................................................................................... 7
Function Inspection ........................................................................................................ 8
Probe Compensation ..................................................................................................... 9
Front Panel Overview .................................................................................................. 10
Rear Panel Overview ................................................................................................... 11
Front Panel Function Overview ............................................................................................... 12
Horizontal ....................................................................................................................... 12
Vertical ........................................................................................................................... 13
Trigger ............................................................................................................................ 14
Run Control ................................................................................................................... 15
Universal Knob.............................................................................................................. 16
Menu ............................................................................................................................... 17
Help ......................................................................................................................................... 18
User Interface.......................................................................................................................... 19
To Use the Security Lock ......................................................................................................... 21
To Set the Vertical System ......................................................................................................... 22
To Enable the Channel ............................................................................................................ 23
To Adjust the Vertical Scale .................................................................................................... 24
To Adjust the Vertical Position ................................................................................................ 24
To Specify Channel Coupling ................................................................................................... 25
To Specify Bandwidth Limit ..................................................................................................... 25
To Specify Probe Attenuation Factor ...................................................................................... 26
To Specify channel Input Impedance ...................................................................................... 26
To Specify Amplitude Unit ...................................................................................................... 27
To Invert a Waveform ............................................................................................................. 27
Set the Horizontal System .......................................................................................................... 28
Adjust the Horizontal Scale ..................................................................................................... 29
Adjust Trigger Delay ................................................................................................................ 30
Set the Roll mode .................................................................................................................... 31
All Rights Reserved - General Polytronic Systems Ltd., London
www.gpslimited.com

X User Manual
Use the Zoom Function ........................................................................................................... 32
To Set the Sample System ......................................................................................................... 33
Run Control ............................................................................................................................. 34
Overview of Sampling ............................................................................................................. 35
Sampling Theory .......................................................................................................... 35
Sample Rate.................................................................................................................. 36
Oscilloscope Bandwidth and Sample Rate .............................................................. 37
Select Memory Depth ............................................................................................................. 38
Select Sampling Mode ............................................................................................................. 39
Select Waveform Interpolation Method ................................................................................. 40
Select Acquisition Mode ......................................................................................................... 42
Normal............................................................................................................................. 42
Peak Detect ..................................................................................................................... 43
Average ........................................................................................................................... 44
High Resolution ............................................................................................................... 45
Change the Horizontal Format ................................................................................................ 46
Use Sequence Mode ............................................................................................................... 47
To Trigger the Oscilloscope ........................................................................................................ 49
Trigger Source ......................................................................................................................... 51
Trigger Mode ........................................................................................................................... 52
Trigger Level ............................................................................................................................ 53
Trigger Coupling ...................................................................................................................... 54
Trigger Holdoff ........................................................................................................................ 55
Noise Rejection ....................................................................................................................... 56
Trigger Type ............................................................................................................................ 58
Edge Trigger.................................................................................................................. 59
Slope Trigger ................................................................................................................. 60
Pulse Trigger ................................................................................................................. 62
Video Trigger ................................................................................................................. 64
Window Trigger ............................................................................................................. 67
Interval Trigger .............................................................................................................. 70
DropOut Trigger ............................................................................................................ 72
Runt Trigger .................................................................................................................. 74
Pattern Trigger .............................................................................................................. 76
Serial trigger and decode ............................................................................................................ 78
IIC Trigger and Serial Decode .................................................................................................. 79
Setup for IIC Signals .................................................................................................... 79
IIC Triggering ................................................................................................................. 80
IIC Serial Decode ......................................................................................................... 83
SPI Triggering and Serial Decode ............................................................................................. 85
Setup for SPI Signals ................................................................................................... 85
SPI Triggering ............................................................................................................... 88
SPI Serial Decode ........................................................................................................ 90
UART/RS232 Triggering and Serial Decode.............................................................................. 92
All Rights Reserved - General Polytronic Systems Ltd., London
www.gpslimited.com

User Manual XI
Setup for UART/RS232 Signals ................................................................................. 92
UART/RS232 Triggering .............................................................................................. 93
UART/RS232 Serial Decode ...................................................................................... 94
To Save Reference Waveform.................................................................................................. 112
To Save REF Waveform to Internal Memory ......................................................................... 113
To Display REF Waveform ...................................................................................................... 113
To Adjust REF Waveform Display ........................................................................................... 114
To Clear REF Waveform Display ............................................................................................. 114
To Make Math Operation ........................................................................................................... 115
Units for Math Waveforms ................................................................................................... 115
Math Operators .................................................................................................................... 116
Addition or Subtraction ................................................................................................. 116
Multiplication and Division ........................................................................................... 117
FFT Operation ................................................................................................................ 118
Math Function Operation...................................................................................................... 121
Differentiate .................................................................................................................. 121
Integrate ........................................................................................................................ 122
Square Root ................................................................................................................... 123
To Make Cursors Measurements ............................................................................................. 124
X Cursors ............................................................................................................................... 124
Y Cursors ............................................................................................................................... 124
To Make Cursor Measurements............................................................................................ 125
To Make Measurements ................................................................................................................ 126
Type of Measurement ........................................................................................................... 127
Voltage Measurements ................................................................................................. 127
Time Measurements ..................................................................................................... 129
Delay Measurements .................................................................................................... 130
To Make Automatic Measurement ........................................................................................ 131
To Clear Measurement Parameters ....................................................................................... 133
To Make All Measurement .................................................................................................... 133
Display Setting ............................................................................................................................... 134
To Set Display Type ................................................................................................................ 135
To Set Color Display ............................................................................................................... 136
To Set and Clear Persistence ................................................................................................. 136
To clear the display ................................................................................................................ 137
To Select Grid Type ............................................................................................................... 138
To Adjust Waveform Intensity ............................................................................................... 138
To Adjust Grid Brightness ...................................................................................................... 140
To Adjust Transparence ......................................................................................................... 140
Save and Recall .............................................................................................................................. 141
Save Type............................................................................................................................... 142
Internal Save and Recall ........................................................................................................ 143
External save and recall ......................................................................................................... 144
Disk Management ................................................................................................................. 147
All Rights Reserved - General Polytronic Systems Ltd., London
www.gpslimited.com

XII User Manual
To Create a New File or Folder ...................................................................................... 148
To delete a file or folder ................................................................................................ 149
To rename a file or a folder ........................................................................................... 149
System Function Setting ................................................................................................................ 150
To View the System Status .................................................................................................... 151
To Do Self Calibration ............................................................................................................ 152
To Enable or Disable the Sound ............................................................................................ 153
To Specify the Language ....................................................................................................... 153
To Do Pass/Fail Test ............................................................................................................... 154
To Set and Perform Pass/Fail Test................................................................................. 155
To Save and Recall Test Mask ........................................................................................ 156
IO Set ..................................................................................................................................... 158
To Set the USB Device ................................................................................................... 158
To Set the LAN ............................................................................................................... 159
To Set Aux Output ......................................................................................................... 160
To Enable Quick-Cal ............................................................................................................... 161
To Update Firmware and Configuration ............................................................................... 162
Do Self Test ............................................................................................................................ 163
Screen Test .................................................................................................................... 163
Keyboard Test ............................................................................................................... 164
LED Test ......................................................................................................................... 165
To specify Screen Saver Time ................................................................................................ 166
Option Management ............................................................................................................. 167
To Use the History Function .......................................................................................................... 169
Arbitrary Waveform Generator .................................................................................................... 171
To Set Wave Type and Parameters ........................................................................................ 172
To Output Arbitrary Waveform............................................................................................. 174
To Set Output Load ................................................................................................................ 175
Recover the Default Values of Wave Gen. ............................................................................. 175
AWG Self Cal .......................................................................................................................... 176
Default Setup ................................................................................................................................ 177
Troubleshooting ............................................................................................................................ 183
Content of Figure
Figure 1 Front View ................................................................................................................... 3
Figure 2 Top View ..................................................................................................................... 3
Figure 3 Adjust the Supporting Legs ......................................................................................... 4
Figure 4 To Connect to Power Supply ....................................................................................... 5
Figure 5 Function Inspection ..................................................................................................... 8
Figure 6 Front Panel Overview ................................................................................................ 10
Figure 7 Rear panel Overview ................................................................................................. 11
Figure 8 Help Message ............................................................................................................ 18
All Rights Reserved - General Polytronic Systems Ltd., London
www.gpslimited.com

User Manual XIII
Figure 9 User Interface ............................................................................................................ 19
Figure 10 To Use the Security Lock ......................................................................................... 21
Figure 11 Display Type Set to Dots .......................................................................................... 40
Figure 12 x Interpolation ......................................................................................................... 41
Figure 13 Sinx Interpolation .................................................................................................... 41
Figure 14 Acquisition System .................................................................................................. 42
Figure 15 Pulse With 0.1% Duty, Normal Mode ..................................................................... 43
Figure 16 Pulse With 0.1% Duty, Peak Detect Mode .............................................................. 43
Figure 17 With Random Noise, Normal Mode........................................................................ 44
Figure 18 With Random Noise, Average Mode ....................................................................... 45
Figure 19 SEQUENCE Function Menu ..................................................................................... 47
Figure 20 HISTORY Function Menu ......................................................................................... 47
Figure 21 Turn off the Noise Reject................................................................................... 56
Figure 22 Turn on the Noise Reject................................................................................... 57
Figure 23 Edge Trigger ............................................................................................................. 59
Figure 24 Slope Trigger............................................................................................................ 61
Figure 25 Pulse Trigger ....................................................................................................... 63
Figure 26 Video Trigger ........................................................................................................... 66
Figure 27 Absolute Window Trigger........................................................................................ 68
Figure 28 Relative Window Trigger ......................................................................................... 69
Figure 29 Interval Trigger ........................................................................................................ 71
Figure 30 Edge DropOut Trigger .............................................................................................. 73
Figure 31 State DropOut Trigger ............................................................................................. 73
Figure 32 Runt Trigger ............................................................................................................. 75
Figure 33 Pattern Trigger ......................................................................................................... 77
Figure 34 IIC SINGAL Menu ..................................................................................................... 79
Figure 35 IIC TRIGGER Menu ................................................................................................... 80
Figure 36 IIC Decode Menu ..................................................................................................... 83
Figure 37 IIC Decode Result .................................................................................................... 83
Figure 38 SPI SINGAL Menu .................................................................................................... 85
Figure 39 SPI Clock Menu ........................................................................................................ 85
Figure 40 MOSI Menu ............................................................................................................. 85
Figure 41 MOSI Menu ............................................................................................................. 86
Figure 42 SPI CS Menu ............................................................................................................ 86
Figure 43 SPI TRIG SET Menu .................................................................................................. 88
Figure 44 SPI Trigger................................................................................................................ 89
Figure 47 SPI Decode function menu ...................................................................................... 90
Figure 46 SPI Decode .............................................................................................................. 90
Figure 47 UART SIGNAL Menu ................................................................................................ 92
Figure 48 BUS CONFIG Menu .................................................................................................. 92
Figure 49 UART TRIG SET Menu .............................................................................................. 93
Figure 50 UART Trigger ............................................................................................................ 93
Figure 51 UART/RE232 DECODE Function Menu .................................................................... 94
Figure 52 UART Decode........................................................................................................... 94
All Rights Reserved - General Polytronic Systems Ltd., London
www.gpslimited.com

XIV User Manual
Figure 53 Reference Waveform ............................................................................................. 114
Figure 54 FFT Waveform In Split Mode ................................................................................. 120
Figure 55 Differential Function Operation ............................................................................ 121
Figure 56 Integral without Offset.......................................................................................... 122
Figure 57 Integral with Offset ............................................................................................... 123
Figure 58 Square Root ........................................................................................................... 123
Figure 59 Measure Pulse Width ............................................................................................ 125
Figure 60 Voltage Measurements ......................................................................................... 127
Figure 61 Overshoot .............................................................................................................. 128
Figure 62 Preshoot ................................................................................................................ 128
Figure 63 Time Measurements ............................................................................................. 129
Figure 64 Select the Measurement Parameter ..................................................................... 131
Figure 65 Added the Measurement ................................................................................... 132
Figure 66 All Parameters Measurement ............................................................................... 133
Figure 67 Vectors Display ...................................................................................................... 135
Figure 68 Dots Display........................................................................................................... 135
Figure 69 Color Temperature ................................................................................................ 136
Figure 70 Persist Set to Infinite ............................................................................................. 137
Figure 71 Intensity Set to 100% ............................................................................................ 139
Figure 72 Intensity Set to 10% .............................................................................................. 139
Figure 73 SAVE/RECALL File System ...................................................................................... 144
Figure 74 Select Save Location .............................................................................................. 145
Figure 75 File Name Dialogue ............................................................................................... 145
Figure 76 Input Keyboard ...................................................................................................... 148
Figure 77 System Status ........................................................................................................ 151
Figure 78 Do Self Cal ............................................................................................................. 152
Figure 79 Pass/Fail Test ......................................................................................................... 154
Figure 80 LAN Setting Interface ............................................................................................ 159
Figure 81 Screen Test ............................................................................................................ 163
Figure 82 Keyboard Test ........................................................................................................ 164
Figure 83 LED Test ................................................................................................................. 165
Figure 84 Screen Saver Interface .......................................................................................... 166
Figure 85 OPTION Function Menu ........................................................................................ 167
Figure 86 LABEL Function Menu ........................................................................................... 167
Figure 87 Option Information ............................................................................................... 168
Figure 88 History ................................................................................................................... 169
Figure 89 Send Wave Dialogue ............................................................................................. 174
Figure 90 Save Waveform Successfully ................................................................................. 174
Figure 91 SETTING Function Menu ....................................................................................... 175
Figure 92 AWG Self Cal .......................................................................................................... 176
All Rights Reserved - General Polytronic Systems Ltd., London
www.gpslimited.com

User Manual 1
Quick Start
This chapter introduces the preparations when using the oscilloscope for the first time, the
front panel, rear panel and user interface of the oscilloscope,
The contents of this chapter:
General Inspection
Appearance and Dimensions
To Prepare the Oscilloscope for Use
Front Panel Overview
Rear Panel Overview
Front Panel Function Overview
Back Panel Function Overview
User Interface
To Use the Security Lock
All Rights Reserved - General Polytronic Systems Ltd., London
www.gpslimited.com

2 User Manual
General Inspection
1. Inspect the shipping container for damage.
Keep the damaged shipping container or cushioning material until the contents of the
shipment have been checked for completeness and the instrument has passed both
electrical and mechanical tests.
The consigner or carrier shall be liable for the damage to instrument resulting from
shipment. The manufacturer would not be responsible for free maintenance/rework or
replacement of the unit.
2. Inspect the instrument.
In case of any damage, or defect, or failure, notify your sales representative.
3. Check the Accessories
Please check the accessories according to the packing lists. If the accessories are
incomplete or damaged, please contact your sales representative.
All Rights Reserved - General Polytronic Systems Ltd., London
www.gpslimited.com

User Manual 3
Appearance and Dimensions
340mm
Figure 1 Front View
Figure 2 Top View
175mm 111mm
All Rights Reserved - General Polytronic Systems Ltd., London
www.gpslimited.com

4 User Manual
To Prepare the Oscilloscope for Use
To Adjust the Supporting Legs
Adjust the supporting legs properly to use them as stands to tilt the oscilloscope upwards
for stable placement of the oscilloscope as well as better operation and observation.
Figure 3 Adjust the Supporting Legs
All Rights Reserved - General Polytronic Systems Ltd., London
www.gpslimited.com
