Instructions
Field Sensitive
Magnetic Proximity
Cycle Switch
For use with MX, MXP & MGO Valve Sections. DC-powered 4-pin FSM proximity switches
are not recommended for use on series divider valves operating at less than 20 cycles per
minute. For professional use only.
Part Nos. 557752, 558938
8000 psi (55.2 MPa, 552 bar) Maximum Working Pressure
Important Safety Instructions
Read all warnings and instructions in
this manual before using the equipment.
Save these instructions.

Warnings
2 313229D
Warnings
The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The
exclamation point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks.
When these symbols appear in the body of this manual or on warning labels, refer back to these Warnings.
Product-specific hazard symbols and warnings not covered in this section may appear throughout the body of this
manual where applicable.
WARNING
ELECTRIC SHOCK HAZARD
This equipment must be grounded. Improper grounding, setup, or usage of the system can cause
electric shock.
• Turn off and disconnect power at main switch before disconnecting any cables and before servicing
or installing equipment.
• Connect only to grounded power source.
• All electrical wiring must be done by a qualified electrician and comply with all local codes and
regulations.

Warnings
313229D 3
EQUIPMENT MISUSE HAZARD
Misuse can cause death or serious injury.
• Do not operate the unit when fatigued or under the influence of drugs or alcohol.
• Do not exceed the maximum working pressure or temperature rating of the lowest rated system
component. See Technical Specifications in all equipment manuals.
• Use fluids and solvents that are compatible with equipment wetted parts. See Technical
Specifications in all equipment manuals. Read fluid and solvent manufacturer’s warnings. For
complete information about your material, request Safety Data Sheets (SDSs) from distributor or
retailer.
• Check equipment daily. Repair or replace worn or damaged parts immediately with genuine
manufacturer’s replacement parts only.
• Do not alter or modify equipment. Alterations or modifications may void agency approvals and
create safety hazards.
• Make sure all equipment is rated and approved for the environment in which you are using it.
• Use equipment only for its intended purpose. Call your distributor for information.
• Route hoses and cables away from traffic areas, sharp edges, moving parts, and hot surfaces.
• Do not kink or over bend hoses or use hoses to pull equipment.
• Keep children and animals away from work area.
• Comply with all applicable safety regulations.
SKIN INJECTION HAZARD
High-pressure fluid from dispensing device, hose leaks, or ruptured components will pierce skin. This
may look like just a cut, but it is a serious injury that can result in amputation. Get immediate surgical
treatment.
• Do not point dispensing device at anyone or at any part of the body.
• Do not put your hand over the fluid outlet.
• Do not stop or deflect leaks with your hand, body, glove, or rag.
• Follow the Pressure Relief Procedure in the pump instruction manual when you stop dispensing and
before cleaning, checking, or servicing equipment.
• Tighten all fluid connections before operating the equipment.
• Check hoses and couplings daily. Replace worn or damaged parts immediately.
WARNING

Valve Assembly Installation
4 313229D
Valve Assembly Installation
Grounding
Assemblies not originally
equipped with cycle pin
indicator pin/switch
1. Determine which valve section and side is the most
convenient location for the switch.
2. Disconnect the electrical system.
3. Relieve pressure. See Pressure Relief Procedure in
the pump instruction manual included with your
operating system.
4. Remove piston plug and discard.
5. Install the appropriate proximity switch into the pis-
ton chamber using the supplied seal/gasket. For
MS and MH valve sections, torque to 6-8 ft-lb (8 -
10.8 N•m) for o-ring seal; 10 ft-lb (13.6 N•m) for
gasket seals. For MX and MGO torque adapter to
25-30 ft-lb (33.9 - 40.7 N•m) and the switch to 6-8
ft-lb (8 - 10.8 N•m).
6. Connect the electrical system.
Assemblies equipped with cycle
pin indicator/electrical
micro-switch
(Two options: Method A or Method B)
Method A: Installation in any piston
chamber not occupied by the cycle pin
indicator
1. Determine which valve section and side is the most
convenient location for the switch.
2. Disconnect the electrical system.
3. Relieve pressure. See Pressure Relief Procedure in
the pump instruction manual included with your
operating system.
4. Remove the piston plug. (Do not discard plug if
removing the cycle indicator pin. It is reinstalled in
step 6e.)
5. Install the appropriate proximity switch into the
piston chamber using the supplied seal/gasket. For
MS and MH valve sections, torque to 6-8 ft-lb (8 -
10.8 N•m) (for o-ring seal; 10 ft-lb (13.6 N•m) for
gasket seals. For MX and MGO torque adapter to
25-30 ft-lb (33.9 - 40.7 N•m) and the switch to 6-8
ft-lb (8 - 10.8 N•m).
6. Either leave the cycle indicator pin installed for
visual indication of cycle or remove as follows:
a. Unscrew cycle indicator body from valve and
discard.
b. Grasp indicator pin and pull pin/piston assem-
bly out of the feeder.
The equipment must be grounded to reduce the risk
of static and electric shock by providing an escape
wire for the electric current due to static build up or in
the event of a short circuit.
NOTICE
Do not over torque. Excessive torque will cause
switch failure.
NOTICE
Do not reuse gasket. If switch is removed for any rea-
son, replace with new gasket.
NOTICE
Do not over torque. Excessive torque will cause
switch failure.
NOTICE
Do not reuse gasket. If switch is removed for any rea-
son, replace with new gasket.

Valve Assembly Installation
313229D 5
c. Remove the indicator pin by sliding it through
the slot on models equipped with this arrange-
ment (MS and late model MX type) or drive out
cross pin using a brass rod (old MX type).
d. Discard the pin.
e. Carefully insert piston back into the bore.
f. Plug the hole with piston plug removed in step
4. Torque to 12 ft-lb (16.3 N•m) for MSP, 35
ft-lb (47.5 N•m) for MX.
7. Make electrical connection.
Method B: Replacing existing cycle
indicator pin/switch
1. Determine which valve section and side is the most
convenient location for the switch.
2. Relieve pressure. See Pressure Relief Procedure in
the pump instruction manual included with your
operating system.
3. Remove the existing cycle indicator pin/switch.
4. Reverse piston so the proximity switch does not
sense slot end of piston.
5. Install the appropriate proximity switch into the pis-
ton chamber using the supplied seal/gasket. For
MS and MH valve sections, torque to 6-8 ft-lb (8 -
10.8 N•m) for o-ring seal; 10 ft-lb (13.6 N•m) for
gasket seals. For MX and MGO torque adapter to
25-30 ft-lb (33.9 - 40.7 N•m) and the switch to 6-8
ft-lb (8 - 10.8 N•m).
Wiring Instructions
In order to make proper electrical connections,
connector cable must be used. The following connector
cables are available:
4-Pin Cable Options for DC Powered
Applications with LED Power/Operation
Lights
5-Pin Cable Options for AC Powered
Applications (No Operational Indicators in
Cables)
NOTICE
Piston is a ground part and all caution must be taken
to avoid nicking, scratching or contaminating this
part or the feeder piston bore.
NOTICE
Do not over torque. Excessive torque will cause
switch failure.
The equipment must be grounded to reduce the risk
of static and electric shock by providing an escape
wire for the electric current due to static build up or in
the event of a short circuit.
Connector Polarity
Cable
Length Part No.
Straight NPN 12 ft. 558968
Straight PNP 12 ft. 558025
90° PNP 12 ft. 558026
Connector
Cable
Length Part No.
Straight 6 ft. 558023
Straight 12 ft. 558024
90° 6 ft. 558965

Valve Assembly Installation
6 313229D
DC Proximity Switch Cables - Connecting
Cable Wiring Code
*With LED Operational Indicators
Connecting Cable Wiring Code
Cable Wires
Color Code
DC Cable Pin Assignments
PNP Cable* NPN Cable*
Black Pin A - N.O.
Brown Pin B - Power
Blue Pin C - Common
White Pin D - Ground
A
B
C
D
USA
Color Code
AC Cable
Pin Assignments
White Pin A - N.O.
Red Pin B - Not Used
Green Pin C - Ground
Orange Pin D - Not Used
Black Pin E - Common
A
B
C
D
E
