Graco 260110 Operation manual

Instructions - Parts List
APEX
On-Demand Pump
For pumping non-flammable fluids including motor oils, hydraulic fluid, and
antifreeze. Do not use to pump water.
Model 260110, 2.3 gpm (9 lpm), 115 VAC
370 psi (2.59 MPa, 25.9 bar) Maximum Working Pressure
Model 260111, 3.0 gpm (11 lpm), 115 VAC
550 psi (3.85 MPa, 38.5 bar) Maximum Working Pressure
Model 260113, 4.0 gpm (16 lpm), 115 VAC
470 psi (3.29 MPa, 32.9 bar) Maximum Working Pressure
Model 260114, 4.0 gpm (16 lpm), 115 VAC
650 psi (4.55 MPa, 45.5 bar) Maximum Working Pressure
Model 260112, 3.0 gpm (11 lpm), 12 VDC
400 psi (2.8 MPa, 28 bar) Maximum Working Pressure
Important Safety Instructions
Read all warnings and instructions in this
manual. Save these instructions. See
Table of Contents on page 2.
311307E
EN

Graco Information 16Warnings
2311307E
Contents
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
System Plumbing . . . . . . . . . . . . . . . . . . . . . . . . 4
Mounting Pump on Tank . . . . . . . . . . . . . . . . . . . 5
Connection Hose . . . . . . . . . . . . . . . . . . . . . . . . 5
Electrical Installation . . . . . . . . . . . . . . . . . . . . . . 5
Priming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Performance Chart . . . . . . . . . . . . . . . . . . . . . . 14
Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Graco Standard Warranty . . . . . . . . . . . . . . . . . . . 16
Graco Information 16Warnings
The following general warnings are for the setup, use, grounding, maintenance, and repair of this
equipment. Additional, more specific warnings may be found throughout the body of this manual
where applicable. Symbols appearing in the body of the manual refer to these general warnings.
When these symbols appear throughout the manual, refer back to these pages for a description
of the specific hazard.
WARNING
FIRE AND EXPLOSION HAZARD
When flammable fluids are present in the work area, such as gasoline and windshield
wiper fluid, be aware that flammable fumes can ignite or explode. To help prevent fire
and explosion:
• Use equipment only in well ventilated area.
• Eliminate all ignition sources, such as cigarettes and portable electric lamps.
• Keep work area free of debris, including rags and spilled or open containers of sol-
vent and gasoline.
• Do not plug or unplug power cords or turn lights on or off when flammable fumes
are present.
• Ground all equipment in the work area.
• Use only grounded hoses.
• If there is static sparking or you feel a shock, stop operation immediately. Do not
use equipment until you identify and correct the problem.
• Keep a fire extinguisher in the work area.
ELECTRIC SHOCK HAZARD
Improper grounding, setup, or usage of the system can cause electric shock.
• Turn off and disconnect power at main switch before disconnecting any cables and
before servicing equipment.
• Connect only to grounded power source.
• All electrical wiring must be done by a qualified electrician and comply with all local
codes and regulations.

Graco Information 16Warnings
311307E 3
PERSONAL PROTECTIVE EQUIPMENT
You must wear appropriate protective equipment when operating, servicing, or when in
the operating area of the equipment to help protect you from serious injury, including
eye injury, inhalation of toxic fumes, burns, and hearing loss. This equipment includes
but is not limited to:
• Protective eyewear
• Clothing and respirator as recommended by the fluid and solvent manufacturer
•Gloves
• Hearing protection
PRESSURIZED EQUIPMENT HAZARD
Fluid from the gun/dispense valve, leaks, or ruptured components can splash in the
eyes or on skin and cause serious injury.
•FollowPressure Relief Procedure in this manual, when you stop dispensing and
before cleaning, checking, or servicing equipment.
• Tighten all fluid connections before operating the equipment.
• Check hoses, tubes, and couplings daily. Replace worn or damaged parts immedi-
ately.
EQUIPMENT MISUSE HAZARD
Misuse can cause death or serious injury.
• Do not operate the unit when fatigued or under the influence of drugs or alcohol.
• Do not exceed the maximum working pressure or temperature rating of the lowest
rated system component. See Technical Data in all equipment manuals.
• Use fluids and solvents that are compatible with equipment wetted parts. See Tech-
nical Data in all equipment manuals. Read fluid and solvent manufacturer’s warn-
ings. For complete information about your material, request MSDS forms from
distributor or retailer.
• Check equipment daily. Repair or replace worn or damaged parts immediately with
genuine Graco replacement parts only.
• Do not alter or modify equipment.
• Use equipment only for its intended purpose. Call your Graco distributor for informa-
tion.
• Route hoses and cables away from traffic areas, sharp edges, moving parts, and
hot surfaces.
• Do not kink or over bend hoses or use hoses to pull equipment.
• Keep children and animals away from work area.
• Comply with all applicable safety regulations.
BURN HAZARD
Equipment surfaces and fluid that’s heated can become very hot during operation. To
avoid severe burns, do not touch hot fluid or equipment. Wait until equipment/fluid has
cooled completely.
WARNING

Installation
4311307E
Installation
These On-Demand dispensing pumps are
positive displacement gear pumps. The motors
are totally enclosed 115 VAC or 12 VDC units,
with sealed bearings, and require minimal
maintenance.
When unpacking, check for shipping damage.
Report any shipping damage to delivering car-
rier immediately. See Parts, page 10.
System Plumbing
The On-Demand pumps deliver a constant
output flow even with a varying load. It is
important the system plumbing be of adequate
size to handle the rated pump flow at a pres-
sure drop that is less than maximum rated
pressure for the pump model used. All plumb-
ing and hoses used in the installation should
have a pressure rating compatible with the
pump selected.
Flow and pressure switch settings
If the system pressure drop at the rated pump
flow is greater than the pressure switch setting,
the motor will cycle on and off when the hose
valve is opened to dispense fluid. If this hap-
pens, reduce system pressure by using a
larger diameter hose or using a less restrictive
valve.
Model No.
Pressure Switch
Setting
Output
Flow Rate
260110 370 psi (2.59
MPa, 25.9 bar)
2.3 gpm
(8.9 lpm)
260111 550 psi (3.85
MPa, 38.5 bar)
3.0 gpm
(11.4 lpm)
260113 470 psi (3.29
MPa, 32.9 bar)
4.0 gpm
(15.5 lpm)
260114 650 psi (4.55
MPa,45.5 bar)
4.0 gpm
(15.5 lpm)
260112 400 psi (2.8 MPa,
28 bar)
3.0 gpm
(11.4 lpm)

Installation
311307E 5
Mounting Pump on Tank
1. Install supplied bung adapter fitting (12)
into the tank bung port and tighten.
2. Use a 3/4 in. (19 mm) steel or PVC pipe
with 3/4 npt pipe threads on one end as a
suction tube.
3. Measure the length from the top of the
bung adapter to the bottom of the tank. Cut
the suction tube length to 1/2 in. (13 mm)
less than this measurement.
4. Apply pipe thread sealant to suction tube
threads and install pipe into pump inlet.
5. Insert suction tube assembly through bung
adapter and lower pump onto the bung
adapter.
6. Position the pump so that the outlet port is
in the desired position. Tighten the swivel
nut on the pump to the bung adapter.
Connection Hose
A flexible hose must be used to connect the
pump outlet to solid plumbing. The pump outlet
port is 1/2 NPT female.
Electrical Installation
115 VAC models
Models 260110, 260111, 260113, and 260114,
use a 115 VAC, single phase, 60 Hz motor.
The electrical circuit supplying the motor must
be on a circuit breaker and be rated to carry a
minimum current greater than the motor full
load current.
Motor current ratings:
260110: 10.6 amps full load
260111: 13.6 amps full load
260113: 18.0 amps full load
260114: 21.0 amps full load
1. Turn power switch OFF.
2. Remove conduit box cover by removing
screws in the opposite corner of cover. A
1/2 in. (13 mm) conduit opening is provided
on the right side of the conduit box just
below the pressure switch.
3. Connect the 115 VAC to the black wire in
the conduit box.
4. Connect the neutral supply wire to the two
white wires in the conduit box. Make sure
both white wires are connected. The small
diameter wire is the pressure switch.
5. Connect ground wire to the motor housing
using the green screw in the motor housing
inside the conduit box.
6. Replace conduit cover, making sure gasket
is in place.
7. Finish wiring the electrical circuit to the
breaker box.

Installation
6311307E
12 VDC model 260112
Motor current rating: 62 amps full load. Use 8
AWG or larger for supply wires.
1. Turn power switch OFF.
2. Use an appropriate size ring terminal to
attach the black (negative) supply wire to
the negative post near the back of the
motor. Ensure the existing small black wire
remains on the post.
3. Use an appropriate size ring terminal to
connect the red (positive) supply wire to the
relay post (16) at the front of the motor.
This post is the one closest to the pump
inlet and outlet. Do not connect the positive
supply wire directly to the positive post of
the motor or the motor will run continuously.
Ensure the small red wire remains on the
front post.
Priming
1. Attach the connection hose to the outlet of
the pump. Insert the opposite end of the
hose into the tank through the fill opening.
2. Turn power switch ON. The pump should
prime in a few seconds. If priming does not
start, see steps 4-6.
3. When pumps starts to prime, turn power
switch OFF. Go to step 7.
4. If priming does not start, remove the outlet
fitting (18) by disconnecting the small diam-
eter sensing hose (17) from the outlet fitting
and remove the fitting.
5. Fill the outlet port of the pump to within 1/2
in. (13 mm) of the top.
6. Replace the outlet fitting and reconnect the
sensing hose. Repeat step 2. Once the
pump is primed the inlet check valve will
prevent loss of prime.
7. Attach the connection hose to the system
plumbing.

Operation
311307E 7
Operation
The on-demand dispensing pumps sense the
pump outlet pressure and turn the pump on or
off depending on the pressure. When a dis-
pensing valve is opened, the pressure in the
system drops and the pump will start pumping
fluid. When the dispensing valve is closed, the
pressure increases and the pump will stop.
1. To start the pump, turn power switch ON.
Power switch is located on the back side of
the motor.
2. Place the outlet of the dispensing valve into
the fill tube of the vehicle.
3. Open the dispensing valve to the full open
position until the desired amount of fluid
has been dispensed.
4. To stop dispensing, close the dispensing
valve.
When system is not in use, always turn power
switch OFF. Failure to do so can result in a
spill if a hose ruptures or a leak occurs in the
system plumbing. If a leak occurs, pressure
will drop in the system signaling the pump to
turn on.
See Parts, page 10 for reference numbers.

Troubleshooting
8311307E
Troubleshooting
Problem Cause Solution
Motor runs but pump will not
prime.
Motor rotation wrong. Check wiring instructions for
possible problems (260112
only).
Dirt under pressure relief valve
or seal.
Remove pressure relief valve
and inspect, clean, or replace if
damaged.
Oil depth too high to prime. See Priming Pump, page 6.
Worn or damaged gears. Remove cover and inspect
gears. Replace if worn or
damaged.
Oil level low. Refill tank.
Cover seal damaged. Replace if worn or damaged.
Air leak in suction tube. Inspect all joints in suction
tube, make sure all joints have
sealant applied.
Air lock in system. This may occur if filter or meter
or automatic shut-off nozzle is
used. If this occurs, fill pump
and meter with fluid through
top of pump.
Motor does not run at proper
speed.
Check electric connections.
Ensure supply voltage is at the
proper level.
Oil leaking in motor mount. Faulty or damaged motor shaft
seal.
Replace shaft seal (4).
Motor shaft worn. Replace motor (5) if shaft has
groove worn in seal area.
Unit pumps but output flow is
low.
Air leak in suction tube. Check to make sure all joints in
suction tube are sealed.
Suction tube too close to tank
bottom.
Suction tube must have a 2 in.
(51 mm) minimum clearance.
Tank empty. Refill tank.
Tank not vented. Tank must be vented to atmo-
sphere.
Worn or damaged gears. Remove cover and inspect
gears (3). Replace if worn or
damaged.
Damaged motor. Replace motor (5).
Clogged hose or nozzle. Inspect and clean.

Troubleshooting
311307E 9
Motor stalls when nozzle is
closed.
Bypass relief valve is stuck. Inspect relief valve, making
sure ball is free. Replace if
damaged.
Low supply voltage. Check supply voltage.
Gears damaged and binding. Inspect gears. Gears should
turn freely. Replace if dam-
aged.
Faulty pressure switch. Replace pressure switch (20).
Motor overheating. Gears binding. Check to make sure gears turn
freely on shaft.
Clogged hose or nozzle. Inspect and clean if required.
Operating pump more than 30
minutes continuous duty.
Limit operation to 30 minutes
per hour.
Switch will not turn pump on. Blown fuse or tripped breaker. Replace fuse or reset breaker.
Electrical problem. Check that supply voltage is
proper and getting to pump.
Defective pressure switch (20). Check and replace if defective.
Damaged or defective motor. Check motor (5), replace if
damaged or defective.
Outlet pressure above pres-
sure switch limit.
Open dispense valve to relieve
pressure.
Problem Cause Solution

Parts
10 311307E
Parts
Models 260110, 260111, 260113, and 260114
Model 260112
5
16
11108
1
18
22
21
5
9
19
6
17
12
7
3
4
13
14
15
20
2

Parts
311307E 11
▲Replacement Danger and Warning labels,
tags, and cards are available at no cost.
Kits
Ref. No. Description Qty.
1a PUMP BODY 1
1b PUMP BODY, high flow 1
2 ADAPTER, pump motor 1
3a GEAR, pump 2
3b GEAR, pump, high flow 2
4 SEAL, shaft 1
5a MOTOR, 115 VAC, 3/4 HP 1
5b MOTOR, 115 VAC, 1 HP 1
5c MOTOR, 115 VAC, 1.5 HP 1
5d MOTOR, 115 VAC, 2 HP 1
5e MOTOR, 12 VDC, 3/4 HP 1
6 POWER CORD (models 260110
and 260111 only)
1
7 O-RING, -144 nitrile (Buna N) 1
8 BALL, relief valve 1
9 GUIDE, spring 1
10 SPRING, relief valve 1
11 HOUSING, relief valve 1
12 ADAPTER, bung 1
13 STRAIN RELIEF (not included in
model 260112)
1
14 NUT, wire (not included in model
260112)
2
15 RELAY, AC (for models with AC
motors)
1
16 RELAY, DC (for model 260112) 1
17 HOSE, 1/4 in. x 12 in. 1
18 CHECK VALVE, outlet 1
19 CHECK VALVE, inlet 1
20a PRESSURE SWITCH, 370 psi 1
20b PRESSURE SWITCH, 550 psi 1
20c PRESSURE SWITCH, 470 psi 1
20d PRESSURE SWITCH, 650 psi 1
20e PRESSURE SWITCH, 400 psi 1
21 SCREW, cap, 5/16-18 x 1 in. 4
22 SCREW, cap, 3/8-16 x 1 in. 4
23▲LABEL, warning (not shown)
Part no. 15G901
1
Ref. No. Description Qty.
Kit Number Description Includes Items
260061 ADAPTER, bung 12
260120 KIT, fluid (models 260110, 260111, 260112) 1a, 2, 3a, 4, 7, 8, 9, 10, 11, 17,
21, 22
260121 KIT, fluid, high flow (models 260113, 260114) 1b, 2, 3b, 4, 7, 8, 9, 10, 11,17,
21, 22
260276 KIT, AC relay 15
260284 KIT, DC relay (includes switching and power relays) 16
260292 KIT, packing 4, 7
260293 KIT, gear, high flow (models 260113, 260114) 3b, 4, 7
260294 KIT, gear (models 260110, 260111, 260112) 3a, 4, 7
260296 KIT, pressure relief 8, 9, 10, 11
260501 KIT, inlet check valve assembly 19
260502 KIT, outlet check valve assembly 18
260503 KIT, 370 psi pressure switch 20a
260504 KIT, 550 psi pressure switch 20b
260505 KIT, 470 psi pressure switch 20c
260506 KIT, 650 psi pressure switch 20d
260507 KIT, 400 psi pressure switch 20e
260508 KIT, motor, 115 VAC ¾ HP (model 260110) 5a, 6, 13, 14, 15, 23
260509 KIT, motor, 115 VAC 1 HP (model 260111) 5b, 6, 13, 14, 15, 23
260510 KIT, motor, 115 VAC 1.5 HP (model 260113) 5c, 13, 14, 15, 23
260511 KIT, motor, 115 VAC 2 HP (model 260114) 5d, 13, 14, 15, 23
260512 KIT, motor, 12 VDC ¾ HP (model 260112) 5e, 16, 23

Technical Data
12 311307E
Technical Data
Maximum Working Pressure Model 260110: 370 psi (2.59 MPa, 25.9 bar)
Model 260111: 550 psi (3.85 MPa, 38.5 bar)
Model 260113: 470 psi (3.29 MPa, 32.9 bar)
Model 260114: 650 psi (4.55 MPa, 45.5 bar)
Model 260112: 400 psi (2.8 MPa, 28 bar)
Output Flow Model 260110: 2.3 gpm (9 lpm)
Model 260111: 3.0 gpm (11 lpm)
Model 260113: 4.0 gpm (16 lpm)
Model 260114: 4.0 gpm (16 lpm)
Model 260112: 3.0 gpm (11 lpm)
Inlet Size 3/4 in. npt
Outlet Size 1/2 NPT female
Horsepower Model 260110: 3/4 hp
Model 260111: 1 hp
Model 260113: 1-1/2 hp
Model 260114: 2 hp
Model 260112: 3/4 hp
Max Current Model 260110: 10.6 amps
Model 260111: 13.6 amps
Model 260113: 18.0 amps
Model 260114: 21.0 amps
Model 260112: 62.0 amps
Wetted parts carbon steel with zinc plating, stainless steel, galvanized
steel, aluminum, nitrile, rubber, PVC, PVC cement
Dimensions See page 13

Technical Data
311307E 13
Dimensions
Models Length (A) Height (B) Width (C)
Inches mm Inches mm Inches mm
260110 14 355.6 8 203.2 7.75 196.8
260111 14.75 374.6 9 228.6 8.5 215.9
260113 14.5 368.3 9 228.6 8.5 215.9
260114 17 431.8 9 228.6 9.75 247.6
260112 15 381 10.5 266.7 7.75 196.8
A
B
C

Technical Data
14 311307E
Performance Chart
&,5)$/54,%402%3352%PSIBAR-0A
&,/72!4%
















GPM
LPM      
0!24.5-"%23
,%'%.$
!
"
# 
$
% 
0RESSURESWITCHOPENS
!
"
#
$
%

Notes
311307E 15
Notes

All written and visual data contained in this document reflects the latest product information available at the time of publication.
Graco reserves the right to make changes at any time without notice.
For patent information, see www.graco.com/patents.
Original instructions. This manual contains English. MM 311307
Graco Headquarters: Minneapolis
International Offices: Belgium, China, Japan, Korea
GRACO INC. AND SUBSIDIARIES • P.O. BOX 1441 • MINNEAPOLIS MN 55440-1441 • USA
Copyright 2005, Graco Inc. All Graco manufacturing locations are registered to ISO 9001.
www.graco.com
Revised August 2012
Graco Standard Warranty
Graco warrants all equipment referenced in this document which is manufactured by Graco and bearing its name to be free from defects in
material and workmanship on the date of sale to the original purchaser for use. With the exception of any special, extended, or limited warranty
published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by
Graco to be defective. This warranty applies only when the equipment is installed, operated and maintained in accordance with Graco’s written
recommendations.
This warranty does not cover, and Graco shall not be liable for general wear and tear, or any malfunction, damage or wear caused by faulty
installation, misapplication, abrasion, corrosion, inadequate or improper maintenance, negligence, accident, tampering, or substitution of
non-Graco component parts. Nor shall Graco be liable for malfunction, damage or wear caused by the incompatibility of Graco equipment with
structures, accessories, equipment or materials not supplied by Graco, or the improper design, manufacture, installation, operation or
maintenance of structures, accessories, equipment or materials not supplied by Graco.
This warranty is conditioned upon the prepaid return of the equipment claimed to be defective to an authorized Graco distributor for verification of
the claimed defect. If the claimed defect is verified, Graco will repair or replace free of charge any defective parts. The equipment will be returned
to the original purchaser transportation prepaid. If inspection of the equipment does not disclose any defect in material or workmanship, repairs will
be made at a reasonable charge, which charges may include the costs of parts, labor, and transportation.
THIS WARRANTY IS EXCLUSIVE, AND IS IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED
TO WARRANTY OF MERCHANTABILITY OR WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE.
Graco’s sole obligation and buyer’s sole remedy for any breach of warranty shall be as set forth above. The buyer agrees that no other remedy
(including, but not limited to, incidental or consequential damages for lost profits, lost sales, injury to person or property, or any other incidental or
consequential loss) shall be available. Any action for breach of warranty must be brought within two (2) years of the date of sale.
GRACO MAKES NO WARRANTY, AND DISCLAIMS ALL IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, IN CONNECTION WITH ACCESSORIES, EQUIPMENT, MATERIALS OR COMPONENTS SOLD BUT NOT
MANUFACTURED BY GRACO. These items sold, but not manufactured by Graco (such as electric motors, switches, hose, etc.), are subject to
the warranty, if any, of their manufacturer. Graco will provide purchaser with reasonable assistance in making any claim for breach of these
warranties.
In no event will Graco be liable for indirect, incidental, special or consequential damages resulting from Graco supplying equipment hereunder, or
the furnishing, performance, or use of any products or other goods sold hereto, whether due to a breach of contract, breach of warranty, the
negligence of Graco, or otherwise.
FOR GRACO CANADA CUSTOMERS
The Parties acknowledge that they have required that the present document, as well as all documents, notices and legal proceedings entered into,
given or instituted pursuant hereto or relating directly or indirectly hereto, be drawn up in English. Les parties reconnaissent avoir convenu que la
rédaction du présente document sera en Anglais, ainsi que tous documents, avis et procédures judiciaires exécutés, donnés ou intentés, à la suite
de ou en rapport, directement ou indirectement, avec les procédures concernées.
Graco Information
For the latest information about Graco products, visit www.graco.com.
TO PLACE AN ORDER, contact your Graco distributor or call to identify the nearest distributor.
Phone: [phone] or Toll Free: 1-800-533-9655, Fax: [phone]
