Graco G3 Series User manual

3A6319A
EN
Instructions
G3 Standard Automatic
Lubrication Pump
For dispensing of NLGI Grades #000 to #2 greases. For Professional Use Only.
Not approved for use in explosive atmospheres or hazardous locations.
5100 psi (35.1 MPa, 351.6 bar) Maximum Pump Output Pressure
5000 psi (34.4 MPA, 344.7 bar) Maximum Fill Inlet Pressure
Important Safety Instructions
Read all warnings and instructions in this
manual before using this equipment. Save
these instructions.
Conforms to ANSI/UL 73
Certified to CAN/CSA
Std. 22.2 No 68-09
3132066
24V and 110-240VAC Pumps ONLY

Part / Model Numbers
23A6319A
Part / Model Numbers
The Part Number is a six-digit unique number that is only used to order the G3 Pump. Directly related to this six digit
Part Number is the configured Graco Model Number. This configured number identifies the distinct features of a spe-
cific G3 Pump. To help you understand each component that makes up the Model Number see Understanding Your
Model Number, page 3. The tables below shows the relationship between each Part Number and its related Model
Number.
8 Liter Models
12 Liter Models
16 Liter Models
20 Liter Models
Part Model Numbers
96G500 G3-G-24NC-8LTA00-0D00L000
Part Model Numbers
96G501 G3-G-24NC-12TA00-0D00L000
Part Model Numbers
96G502 G3-G-24NC-16TA00-0D00L000
Part Model Numbers
96G503 G3-G-24NC-20TA00-0D00L000

Part / Model Numbers
3A6319A 3
Understanding the Model Number
Use the Code Sample provided below to identify each component’s location in the Model Number. The options for
each component that make up the code are provided on the lists below.
NOTE: Some pump configurations are not available. Contact Graco Customer Service or your local Graco distributor
for assistance.
G3 - G = Identifies pump as being a G3; G = Grease
G3 - A = Identifies pump as being a G3; A = Oil
Code aa: Power Source
• 24 = 24 Volts DC
Code bb: Operation Control
• NC = No Controller
Code cc: Reservoir Capacity (Liters)
• 8L = 8 Liters
• 12 = 12 Liters
• 16 = 16 Liters
• 20 = 20 Liters
Code d: Follower Plate Installed
• T = Follower Plate Installed; Tie Rods
Code e: Low Level Option
• A = Low Level No Controller
Code ff: Options
• 00 = No Options
Code g, h, i, j, k, m, n, p
NOTE: Codes g - p relate to a specific location on the
G3 pump. See FIG. 1 for these locations.
•D=DIN
• 0 = Not populated
• L = Low Level
G3 -G- NC
Code Sample: a a b b - c c d e f f - g h i j k m n p
FIG. 1
k
h

Warnings
43A6319A
Warnings
The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclama-
tion point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When
these symbols appear in the body of this manual or on warning labels, refer back to these Warnings. Product-specific
hazard symbols and warnings not covered in this section may appear throughout the body of this manual where
applicable.
WARNING
SKIN INJECTION HAZARD
High-pressure fluid from dispensing device, hose leaks, or ruptured components will pierce skin. This
may look like just a cut, but it is a serious injury that can result in amputation. Get immediate surgical
treatment.
• Do not point dispensing device at anyone or at any part of the body.
• Do not put your hand over the fluid outlet.
• Do not stop or deflect leaks with your hand, body, glove, or rag.
• Follow the Pressure Relief Procedure when you stop dispensing and before cleaning, checking, or
servicing equipment.
• Tighten all fluid connections before operating the equipment.
• Check hoses and couplings daily. Replace worn or damaged parts immediately.
PRESSURIZED EQUIPMENT HAZARD
Over-pressurization can result in equipment rupture.
• A pressure relief valve is required at each pump outlet.
• Follow the Pressure Relief Procedure in this manual before servicing.

Warnings
3A6319A 5
WARNING
EQUIPMENT MISUSE HAZARD
Misuse can cause death or serious injury.
• Do not operate the unit when fatigued or under the influence of drugs or alcohol.
• Do not exceed the maximum working pressure or temperature rating of the lowest rated system
component. See Technical Specifications in all equipment manuals.
• Use fluids and solvents that are compatible with equipment wetted parts. See Technical
Specifications in all equipment manuals. Read fluid and solvent manufacturer’s warnings. For
complete information about your material, request Safety Data Sheets (SDSs) from distributor or
retailer.
• Turn off all equipment and follow the Pressure Relief Procedure when equipment is not in use.
• Check equipment daily. Repair or replace worn or damaged parts immediately with genuine
manufacturer’s replacement parts only.
• Do not alter or modify equipment. Alterations or modifications may void agency approvals and create
safety hazards.
• Make sure all equipment is rated and approved for the environment in which you are using it.
• Use equipment only for its intended purpose. Call your distributor for information.
• Route hoses and cables away from traffic areas, sharp edges, moving parts, and hot surfaces.
• Do not kink or over bend hoses or use hoses to pull equipment.
• Keep children and animals away from work area.
• Comply with all applicable safety regulations.
PLASTIC PARTS CLEANING SOLVENT HAZARD
Many cleaning solvents can degrade plastic parts and cause them to fail, which could cause serious
injury or property damage.
• Use only compatible solvents to clean plastic structural or pressure-containing parts.
•SeeTechnical Specifications in all equipment manuals for materials of construction. Consult the
solvent manufacturer for information and recommendations about compatibility.
MOVING PARTS HAZARD
Moving parts can pinch, cut or amputate fingers and other body parts.
• Keep clear of moving parts.
• Do not operate equipment with protective guards or covers removed.
• Equipment can start without warning. Before checking, moving, or servicing equipment, follow the
Pressure Relief Procedure and disconnect all power sources.
PERSONAL PROTECTIVE EQUIPMENT
Wear appropriate protective equipment when in the work area to help prevent serious injury, including
eye injury, hearing loss, inhalation of toxic fumes, and burns. Protective equipment includes but is not
limited to:
• Protective eyewear, and hearing protection.
• Respirators, protective clothing, and gloves as recommended by the fluid and solvent manufacturer.

Installation
63A6319A
Installation
Component Identification - 8 Liter Model Shown
See Parts, page 17 for expanded view.
Key:
AReservoir
B Pump Element (1 included. Can accommodate 3 total)
C Pressure Relief Valve (Not shown. Not included / required for
each outlet - Available from Graco. See Parts, page 18.)
D Zerk Inlet Fill Fitting (1 included / grease models only)
E Pump Outlet Plug (2 included)
F Volume Control Spacers (2 included. More spacers = less
output volume per stroke) (also see FIG. 9, page 12)
G Fuse (DC models only - Not included, not shown. Available
from Graco. See Parts, page 18.)
HCover
J Top Mounting Bracket
K Bottom Mounting Bracket
L Part Number / Model Number example only shown, (see
pages 3, Understanding the Model Number, for details)
M Follower Plate
N Vent Hole for Follower Plate
FIG. 2
A
B
DE
F
H
J
K
L
M
N

Installation
3A6319A 7
Typical Installation
Series Progressive Divider Valve
Key
A Connected to fused power source
B Pressure relief valve (Not included; required for each out-
let - user supplied)
C Supply Hose (user supplied)
D Series progressive divider valves
E To lube points
F Proximity Switch
FIG. 3
A
B
D
E
F
C

Installation
83A6319A
Injector Installations
Key
A Connected to fused power source
B Pressure relief valve (Not included; required for each out-
let - user supplied)
C Supply Hose (user supplied)
DInjectors
E To lube points
F Pressure switch
G Vent valve (Not included / available from Graco)
H Return to reservoir
FIG. 4
A
B
D
E
F
H
G
C

Installation
3A6319A 9
Unpacking
The pump module was carefully packaged for shipment
by Graco. When the package arrives, perform the follow-
ing procedure to unpack the units:
1. Inspect the shipping box carefully for shipping
damage. Contact the carrier promptly if damage is
discovered.
2. Unseal the box and inspect the contents carefully.
There should not be any damaged parts.
3. Compare the packing slip against all items included
in the box. Any shortages or other inspection
problems should be reported immediately.
Choosing an Installation
Location
- Select a location that will adequately support
the weight of the G3 Pump and lubricant, as
well as all plumbing and electrical connections.
- Refer to the mounting hole layouts provided in
the Mounting Bracket Dimensions section of this
manual, page 21. No other installation configu-
ration should be used.
- Use designated mounting holes and provided
configurations only.
- Use the five fasteners (included) to secure the
G3 to the mounting surface. 3 fasteners are
used for the bottom bracket and 2 fasteners are
used for the top bracket.
- Adjust top mounting bracket, if necessary to
align the bracket with the mounting surface (FIG.
5).
- Insert (user supplied) spacers if there is still a
gap after adjusting the bracket.
System Wiring
Fuses
Fuse Kits are available from Graco. The following Table
identifies the correct fuse to use for your input voltage
and the corresponding Graco Kit number.
Recommendations for Using Pump in
Harsh Environments
• If using a DIN style power or alarm harness with a
right angle mating connector, make sure the con-
nector does not exit the unit in the UP direction.
• Use a corrosion preventative electrical grease on all
contacts.
NOTICE
Observe precautions for handling electrostatic sensi-
tive devices. Touch ground before handling pump.
AUTOMATIC SYSTEM ACTIVATION HAZARD
If the system is equipped with has an automatic timer
(user supplied) that activates the pump lubrication
system when power is connected or when exiting the
programming function, unexpected activation of the
system could result in serious injury, including skin
injection and amputation.
Before you install or remove the lubrication pump
from the system, disconnect and isolate all power
supplies and relieve all pressure.
FIG. 5
NOTICE
Fuses (user supplied) are required on all DC mod-
els. To avoid equipment damage:
• Never operate G3 Pump DC models without a
fuse installed.
• A fuse of the correct voltage must be installed in
line with the power entry to the system.
Input Voltage Fuse Value Graco Kit No.
24 VDC 4 A 571040

Installation
10 3A6319A
Wiring and Installation Diagrams
The following Table identifies the wiring and installation
diagrams for the cable included with the pump provided
in this manual.
Power DIN DC - 15 foot
Pin and Related Wire Color (FIG. 6)
Low Level Outputs
See Low Level Output Option, page 14 for functional
description. See Technical Specifications, page 20 for
ratings.
Pins (FIG. 7)
Pin Pin Name Color
1-VDC Black
2+VDC White
3 Not Used Not Used
4Not Used Green
FIG. 6
Pin Pin Name
1 LL N.O.
2 Not Used
3LLCOM
4 Not Used
FIG. 7

Setup
3A6319A 11
Setup
Pressure Relief
Follow the Pressure Relief Procedure whenever
you see this symbol.
Relieve pressure in system using two wrenches work-
ing in opposite directions on pump element and pump
element fitting to slowly loosen fitting only until fitting
is loose and no more lubricant or air is leaking from fit-
ting.
NOTE: When loosening pump element fitting, do NOT
loosen pump element. Loosening pump element will
change the output volume.
Connecting to Auxiliary Fittings
Pressure Relief Valves
NOTE: A pressure relief valve can be purchased from
Graco.
This equipment stays pressurized until pressure is
manually relieved. To help prevent serious injury from
pressurized fluid, such as skin injection, splashing
fluid and moving parts, follow the Pressure Relief
Procedure when you stop dispensing and before
cleaning, checking, or servicing the equipment.
FIG. 8
NOTICE
Do not attach unsupported equipment to auxiliary fit-
tings such as fill ports and pump element. Attaching
unsupported equipment to these fitting can result in
irreparable housing damage.
• Always use two wrenches working in opposite
directions when connecting anything to pump ele-
ment or auxiliary fittings. See FIG. 8 for an exam-
ple.
• Torque pump element fittings to 50 in. lbs (5.6
N•m).
• When connecting pump element into housing
torque to 50 in. lbs (5.6 N•m).
To prevent over-pressurization, which can result in
equipment rupture and serious injury, a pressure
relief valve appropriate for the lubrication system
must be installed close to every pump outlet to allevi-
ate unintended pressure rises in the system and pro-
tect the G3 pump from damage.
• Only use a pressure relief valve that is rated for
no more than the working pressure of any com-
ponent installed in the system.
• Install a pressure relief valve close to every pump
outlet; before any auxiliary fitting.

Setup
12 3A6319A
Setting Pump Outlet Volume
NOTE:
• Before making any adjustments to pump volume,
Relieve Pressure following procedure on page 11.
• Only use Graco supplied spacers to control output
volume.
• It may be necessary to repeat this outlet volume
setup procedure after the pump is operating to
re-adjust the volume of dispensed fluids.
1. Use a wrench to turn pump element counter-clock-
wise to loosen. Do not remove entire pump element.
Only back pump element out enough to allow
spacer to be slid on or off (FIG. 9).
2. If needed, remove or insert spacers to achieve
required pump output volume. A tool may be
needed to facilitate removal.
Pump volume control is set using either no (0) spac-
ers, 1 or 2 spacers (FIG. 9).
Do not use more than 2 spacers to adjust output vol-
ume.
3. Tighten pump element fitting. Torque fitting to 50 in.
lbs (5.6 N•m).
• The amount of dispensed volume can vary depend-
ing on external conditions such as lubricant tem-
perature and back pressure from downstream
connections.
• Use of these volume adjustment in conjunction with
setting the ON time of the pump will allow for control
of the output volume.
• Use these volume adjustments as a starting point
and adjust as necessary to ensure desired lubrica-
tion dispense.
Loading Grease
To ensure optimal performance from the G3:
• Only use NLGI #000 - #2 greases appropriate for
your application, automatic dispensing, and the tem-
perature. Consult with machine and lube manufac-
turer for details.
• The reservoir can be filled using a hand operated
pump, pneumatic pump or electric transfer pump.
• Do not overfill.
• Do not operate G3 without reservoir attached.
1. Connect fill hose to inlet fitting.
2. For higher viscosity fluids, start pump to rotate stir-
ring paddle during fill to prevent air pockets from
forming in grease. Do not exceed 30 minutes run
time.
For models using an external controller, start pump
operation per your controller specifications.
FIG. 9
No. Spacers
Output Volume / Minute
cubic inches cubic cm
20.122
10.183
00.254
NOTICE
• Always clean inlet fitting with a clean dry cloth
prior to filling reservoir. Dirt and/or debris can
damage pump and/or lubrication system.
• Care must be used when filling the reservoir
using a pneumatic or electric transfer pump to
not pressurize and break the reservoir.

Setup
3A6319A 13
3. Fill reservoir with grease until seal of follower plate
breaches the vent hole (FIG. 10) and the majority of
air is expelled from the reservoir.
NOTE: Vent port, located in rear of reservoir, should not
be used as an overfill port/indicator.
4. Remove fill hose.
Priming
NOTE: It is not necessary to prime pump every time
pump is filled with lubricant.
Pump only requires priming the first time it is used or if it
is allowed to run dry.
1. Loosen pump element fitting (FIG. 11).
NOTE: When loosening pump element fitting, do NOT
loosen pump element. Loosening pump element will
change the output volume
2. Only run pump until air-free lubricant is dispensed
out of element fitting (FIG. 12).
3. Tighten pump element fitting using two wrenches
working in opposite directions (FIG. 11).
FIG. 10
vent hole
FIG. 11
FIG. 12

Pump Operation
14 3A6319A
Pump Operation
The G3 Pump can be controlled using an external, user
supplied, power source and controller.
Refer to the Typical Installation diagrams starting on
page 7 for correct location of the required fuses.
NOTE:
• When using an external power source and control-
ler, Pump ON (Run) Time should be set for no lon-
ger than 30 minutes.
• In most cases, Pump OFF (Rest) Time should be
twice as long as Pump ON (Run) time. If alternative
ON / OFF times are required, contact Graco Cus-
tomer Service for assistance.
Low Level Output Option
Some G3 pumps without controllers include a Low Level
Output Option. The low level signal is monitored across
PINS 3 and 4. For PIN 3 and 4 locations and wiring
information the Low Level Outputs diagram, page 10.
NOTE: A low level warning is triggered when the con-
troller detects PINS 3 and 4 have momentarily closed.
When the grease level has reached a low warning level,
PINS 3 and 4 momentarily close (1 time per paddle rev-
olution) sending the signal that the fluid has reached a
low level to the controller.
To ensure that a low level condition has been met, 3 or
more low level triggers must be detected within 1 minute
or less.
See FIG. 13 for an illustration of a typical Low Level Out-
put response to low grease level.
Typical Low Level Output Response with Low Level Fluids
FIG. 13
200 ms
Open
Contact
Position
Closed
3 s

Troubleshooting
3A6319A 15
Troubleshooting
Problem Cause Solution
Unit does not power on Incorrect/loose wiring Refer to Installation instructions,
page 6.
Unit does not power on (DC models
only)
Tripped external fuse due to internal
component failure Contact Graco Customer Service.
Tripped external fuse due to pumping
non-cold weather lubricant in cold
weather -13°F (-25°C)
Replace lubricant with pumpable
lubricant, rated for environmental
conditions and application.
Replace fuse.
Lubricant leaks past seal located on
the bottom of the reservoir
Reservoir retaining tabs are cracked
or broken
Replace reservoir.
Reservoir is being pressurized during
filling
Ensure vent hole is not plugged.
If problem persists, contact Graco
Customer Service or your local
Graco distributor for assistance.
Unit not pumping during ON cycle,
but controller lights and functions
Failed motor Replace unit.
Follower plate is not going down
Air is trapped in the reservoir
between the follower plate and lubri-
cant
Add grease following Loading Grease
instructions, page 12. Ensure air is
purged.
Pump takes several minutes before it
begins pumping at the highest pump
volume setting (no stroke adjust
spacers installed)
Pumping non-cold weather lubricant
in cold weather -13°F (-25°C)
Add 1 stroke adjust spacer and
adjust lube cycle time to accommo-
date the difference in pump volume
per stroke.
After wiring and installing equipment
pump is not working
Pump wired backwards Rewire pump. See wiring and instal-
lation diagrams, page 10.

Maintenance
16 3A6319A
Maintenance
Cleaning the Reservoir
Only use water or solvents compatible with polycarbon-
ate to clean reservoir.
Most solvents will degrade the polycarbonate reservoir
and cause it to fail.
Frequency Component Required Maintenance
Daily and at refill Zerk Fittings Keep all fittings clean using a clean
dry cloth. Dirt and/or debris can dam-
age pump and/or lubrication system.
Daily G3 Pump Unit and Reservoir Keep pump unit and reservoir clean
using a clean dry cloth.
Monthly External Wiring Harness Verify external harnesses are secure.

Parts
3A6319A 17
Parts
43
36
6
44
30
31
16
10
11
22
40
42
24
5
5
27
26
25
41
29
1
3
21
20
23
32
4
2
42
34
33
45
8 Liter Model Reservoir for 12 Liter and
Larger Models
20
21
12
10
(See 8 Liter Model for all other parts)

Parts
18 3A6319A
Parts
Replacement Danger and Warning labels, tags and
cards are available at no cost.
Fuses
Ref Part Description Qty
1 BASE, three pump housing 1
2 SCREW, cap, hex head 4
3 RING, snap 1
4 COVER 1
5 17S695 SEAL, reservoir 2
6 BRACKET, top 1
10
RESERVOIR, 8 L 1
RESERVOIR, 12 L 1
RESERVOIR, 16 L 1
RESERVOIR, 20 L 1
11 WASHER, flat, sst 3/8 inch 1
12 SLEEVE (12 L and larger only) 1
16
ROD, support, 8 L 4
ROD, support, 12 L 4
ROD, support, 16 L 4
ROD, support, 20 L 4
20
ROD, guide, 8 L 1
ROD, guide, 12 L 1
ROD, guide, 16 L 1
ROD, guide, 20 L 1
21
SPRING, compression, 8 L 1
SPRING, compression, 12 L and
larger models (Install springs as
shown in Parts, page 17, Reservoir
for 12 Liter and Larger Models)
2
22 123026 SEAL, grease, 10 mm id 1
23 NUT 1
24 PLATE, follower 1
25 BEARING, sleeve 1
26 PLATE, wiper arm 1
27 ADAPTER, base, reservoir 1
29 BRACKET, bottom 1
30 COVER, vent 1
31 GASKET, vent cover 1
32 SEAL, top, foam 1
33 SCREW, SHC, 10 x 0.62, sst 2
34 WASHER, flat 2
36 WASHER, flat 2
38 SPACER, pump shim (not shown) 2
39 PARTS, bracket mounting (bagged) 1
40 SCREW, cap, hex head 2
41 NUT, jam, Ny-loc 6
42 WASHER, plain 6
43 SCREW, M8, 35 mm 2
44 NUT, M8 2
45 571041 KIT, pump element 1
46 16U790 CABLE, DIN, bare) 1
47LABEL, safety 1
Part Description Qty
571040 FUSE, 24 volt DC 1
Ref Part Description Qty

Parts
3A6319A 19
Pressure Relief Valves
Important Information regarding Pressure Relief
Valve 16C807.
Pressure Relief Valve 16C807 can only be used on
the G3 Pump. It is not intended for use with any other
products.
The pressure relief valve uses a
pressure adjustment screw (a) to
set the pressure release point. It
is not intended as a way to
relieve pressure during normal
operation, but as a protective
measure in the event there is an
unintended pressure increase in
the system. Do not use this pres-
sure relief valve a means of
relieving pressure in day-to-day,
normal cycle operation.
The pressure adjustment screw
will require periodic adjustments.
Whenever the valve is set/adjusted (after the set point is
found) it is important to ensure that the valve is not bot-
tomed out and there is at least 1/2 turn of adjustment
remaining. This is determined by turning the screw (a)
1/2 turn and then back turning it out again.
NOTE: Turning adjustment screw (a) clockwise
increases pressure.
Installation and Repair Kits
Part Description Qty
16C807
VALVE, pressure relief, 500-3500 psi (3.44
MPa, 34.4 bar - 24.1 MPa, 241 bar), Set pres-
sure 3000 psi + 10% (20.68 MPa, 206.8 bar +
10%) Included in Kit 571028
1
563156 VALVE, pressure relief, 750 psi (5.17 MPa,
51.71 bar) 1
563157 VALVE, pressure relief, 1000 psi (6.89 MPa,
68.95 bar) 1
563158 VALVE, pressure relief, 1500 psi (10.34 MPa,
103.42 bar) 1
563159 VALVE, pressure relief, 2000 psi (13.78 MPa,
137.89 bar) 1
563160 VALVE, pressure relief, 2500 psi (17.23 MPa,
172.36 bar) 1
563161 VALVE, pressure relief, 3000 psi (20.68 MPa,
206.84 bar) 1
563190 VALVE, pressure relief, 5500 psi (37.92 MPa,
379.21 bar) 1
a
ti15644
b
a = adjustment screw
b = locking nut
Kit No. Description
Manual
Number
571026 KIT, output union, 3 pump 3A0523
571063 KIT, output union, 2 pump
571028 KIT, return to reservoir NPT, includes pres-
sure relief valve 16C807 3A0525
571071 KIT, return to reservoir BSPP, includes pres-
sure relief valve 16C807
571058 KIT, output adapter, NPT 3A0522
571070 KIT, output, adapter, BSPP
571060 KIT, fill, zerk, leakproof NA
25E455 KIT, repair, reservoir 8 liter
3A6385
25E456 KIT, repair, reservoir, 12 liter
25E457 KIT, repair, reservoir 16 liter
25E458 KIT, repair, reservoir, 20 liter
25E485 KIT, mounting hardware NA

Technical Specifications
20 3A6319A
Technical Specifications
Dimensions
G3 Standard Automatic Lubrication Pump US Metric
Pump Output Pressure 5100 psi 35.1 MPa, 351.6 bar
Fill Inlet Pressure 5000 psi 34.4 MPa, 344.7 bar
Power
24 VDC 18 - 32 VDC; 2.5 A current, 60 W, inrush/locked rotor 6 A
Outputs - Low Level (Dry Contact)
Contact Rating 10 Watts Maximum
Switch Rating 200 VDC Maximum
Switching Current 0.5 A Maximum
Carry Current 1.2 A Maximum
Fluid Grease NLGI 000 - #2
Pumps Up to 3
Pump Output
2 spacers per outlet 0.12 in.3/minute 2 cm3/ minute
1 spacer per outlet 0.18 in.3/ minute 3 cm3/ minute
0 spacers per outlet 0.25 in.3/ minute 4 cm3/ minute
Pump Outlet 1/4-18 NPSF. Mates with 1/4-18 NPT male fittings
Weight
8 Liter Models 23 lb. 10.43 kg.
12 Liter Models 25 lb. 11.34 kg.
16 Liter Models 26 lb. 11.79 kg.
20 Liter Models 27 lb. 12.25 kg.
Model Height Width Depth
Inches cm Inches cm Inches cm
8L 22.36 56.79 8.94 22.70 10.37 26.34
12L 26.30 66.80 8.94 22.70 10.37 26.34
16L 30.23 76.78 8.94 22.70 10.37 26.34
20L 34.17 86.79 8.94 22.70 10.37 26.34
