GRAND + BENEDICTS 050-SW-HU-2 User manual

A. TOE KICK PANEL - A (X2)
CAMLOCK (X32)
E. SIDE SLATWALL (X2)
B. TOE KICK PANEL - B (X2) C. BOTTOM PANEL (X1)
D. CENTER SLATWALL (X1)
ASSEMBLY INSTRUCTIONS - 050 - SW - HU - 2 - ( 2' SLATWALL H-UNIT )
GRAND + BENEDICTS | 800-547-7005 | www.grand-benedicts.com PAGE: 1 OF 3

2.
STEP 1:
INSERT THE BOLTS OF CAMLOCK IINTO TOE KICK PANEL - A;
CENTER SLATWALL (X1)
SIDE SLATWALL (X2)
2. CONNECT TOE KICK PANEL - A & B BY CAMLOCKS;
1.
CAMLOCK (X8)
TOE KICK PANEL - B (X2)
TOE KICK PANEL - A (X2)
CAMLOCK (X12)
INSERT THE BOLTS OF CAMLOCK IINTO SIDE SLATWALL;1. CONNECT SIDE SLATWALL & CENTER SLATWALL BY CAMLOCKS;
STEP 2:
ASSEMBLY INSTRUCTIONS - 050 - SW - HU - 2 - ( 2' SLATWALL H-UNIT )
GRAND + BENEDICTS | 800-547-7005 | www.grand-benedicts.com PAGE: 2 OF 3

TOE KICK ASSEMBLED (X1)
CAMLOCK (X4)
1.
BOTTOM PANEL (X1)
1.
ATTACH BOTTOM PANEL TO SLATWALL ASSEMBLED BY CAMLOCKS;
CAMLOCK (X8)
STEP 3:
SLATWALL ASSEMBLED (X1)
ATTACH TOE KICK ASSEMBLED BY CAMLOCKS;
STEP 4:
ASSEMBLY INSTRUCTIONS - 050 - SW - HU - 2 - ( 2' SLATWALL H-UNIT )
GRAND + BENEDICTS | 800-547-7005 | www.grand-benedicts.com PAGE: 3 OF 3
