GRAND + BENEDICTS 260-EC-4FVSC User manual

PVC STICKER (X5)
10" SHELF BRACKET (X3) 8" SHELF BRACKET (X3)
STANDARD (X3)
A. BOTTOM PANEL (X1)
ALU. TOP TRACK (X1)
B. TOE KICK (X2)
ALU. BOTTOM CHANNEL (X1)
H. FRONT GLASS (X1)G. 10" GLASS SHELF (X1)
ALU. TOP CHANNEL (X1)
C. SIDE PANEL - LEFT (X1) D. SIDE PANEL - RIGHT (X1) E. TOP GLASS (X1) F. 8" GLASS SHELF (X1) I. DOOR PANEL (X2)
PAN CROSS HEAD SELF
TAPPING SCREW #8X0.75 (X6) HEX NUT M4 (X3)
ASSEMBLY INSTRUCTIONS - 260 - EC - 4FVSC - ( 4' FULL VISION SHOWCASE )
GRAND + BENEDICTS | 800-547-7005 | www.grand-benedicts.com PAGE: 1 OF 6
FLAT HEAD DRILLING SELF
TAPPING SCREW #8X1.5 (X8)
WOOD DOWEL (X16) FLAT HEAD SCREW
M4X14 (X3)
CAMLOCK (X22)

2.
STEP 1: STEP 3:
INSERT ALU. BOTTOM TRACK;
2. ATTACH ALU. TOP TRACK BY SCREW;
3.
CONNECT ONE SIDE PANEL BY CAMLOCKS;
3. CONNECT BOTTOM PANEL BY CAMLOCKS;
2. SCREW THE BOLTS OF CAMLOCK INTO TOE KICK & BOTTOM PANEL;
CAMLOCK (X8)
WOOD DOWEL (X4)
TOE KICK (X2)
BOTTOM PANEL (X1)
1. NSERT WOOD DOWELS INTO BOTTOM PANEL;I
SIDE PANEL - LEFT (X1)
ALU. TOP TRACK (X1)
ALU. TOP CHANNEL (X1)
5.
STEP 2:
ATTACH THE OTHER SIDE PANEL BY CAMLOCKS;
4. INSERT FRONT GLASS;
3.
CAMLOCK (X14)
WOOD DOWEL (X12)
FRONT GLASS (X1)
SIDE PANEL - RIGHT (X1)
FLAT HEAD DRILLING SELF-TAPPING SCREW #8X1.5" (X8)
ALU. BOTTOM TRACK (X1)
INSERT WOOD DOWELS INTO BASE ASSEMBLED;1. SCREW THE BOLTS OF CAMLOCK INTO SIDE PANEL - LEFT & RIGHT;2.
ATTACH ALU. TOP CHANNEL BY SCREW;1.
ATTACH STANDARD ON BASE & TOP CHANNEL BY SCREWS & NUTS;1. ATTACH PVC STICKER ON CABLE HOLE & SCREW HOLES ON BOTH SIDES;
STEP 4:
STANDARD (X3)
PVC STICKER (X5)
PAN CROSS HEAD SELF-TAPPING SCREW #8X0.75" (X6)
FLAT HEAD SCREW M4X14 (X3)
HEX NUT M4 (X3)
ASSEMBLY INSTRUCTIONS - 260 - EC - 4FVSC - ( 4' FULL VISION SHOWCASE )
GRAND + BENEDICTS | 800-547-7005 | www.grand-benedicts.com PAGE: 2 OF 6

ASSEMBLY INSTRUCTIONS - 260 - EC - 4FVSC - ( 4' FULL VISION SHOWCASE )
GRAND + BENEDICTS | 800-547-7005 | www.grand-benedicts.com PAGE: 3 OF 6
STEP 6:
STEP 5:
1.
10" GLASS SHELF (X1)
TOP GLASS ( X1)
1. PLACE 8" & 10" GLASS SHELF ON SHELF BRACKETS;
3. GENTLY SIT TOP GLASS ON TOP FRAME;
2. PLACE 8" & 10" SHELF BRACKETS ON STANDARD WITH PROPER HEIGHT;
8" SHELF BRACKET (X3)
10" SHELF BRACKET (X3)
8" GLASS SHELF (X1)
INSERT DOOR PANELS ON SHOWCASE;
DOOR PANEL (X2)

ASSEMBLY INSTRUCTIONS - 260 - EC - 4FVSC - ( 4' FULL VISION SHOWCASE )
GRAND + BENEDICTS | 800-547-7005 | www.grand-benedicts.com PAGE: 4 OF 6
TUBE BASE (X1)
WITH LED LIGHT OPTION - START FROM STEP 4
STEP 4:
LED LIGHT CIP (X3)
ALU. TUBE (X1)
SCREW M3X6 (X3)
FLAT HEAD CROSS SCREW #8X0.625" (X2) SLOTTED SET SCREW #8-32 X 0.164" (X2) FLAT HEAD CROSS WOOD
POWER SUPPLY W/ POWER PLUG (X1)
LED LIGHT (X1)

ASSEMBLY INSTRUCTIONS - 260 - EC - 4FVSC - ( 4' FULL VISION SHOWCASE )
GRAND + BENEDICTS | 800-547-7005 | www.grand-benedicts.com PAGE: 5 OF 6
2.
STEP 5:
FLAT HEAD WOOD SCREW #8X0.625" (X2)
TUBE BASE (X1)
ALU. TUBE (X1)
2. ATTACH LED LIGHT ON THE CLIPS;
1.
LED LIGHT ( X1)
FLAT HEAD CROSS SCREW M3X6 (X3)
LED LIGHT CLIP (X3)
ATTACH LED LIGHT CLIPS ON ALU. TOP CHANNEL BY SCREW (M3X6);
SLOTTED SET SCREW #8-32X0.164" (X2)
THROUGH THE CABLE TO ALU. TUBE & TUBE BASE;1.
SCREW THE TUBE BASE FROM BOTTOM BY FLAT HEAD WOOD SCREWS;
MOVE THE ALU. TUBE AS TOP AS POSSIBLE, FIX THE ALU.TUBE BY SET SCREWS;
STEP 6:

ASSEMBLY INSTRUCTIONS - 260 - EC - 4FVSC - ( 4' FULL VISION SHOWCASE )
GRAND + BENEDICTS | 800-547-7005 | www.grand-benedicts.com PAGE: 6 OF 6
4.
STEP 7:
TOP GLASS (X1)
1.
POWER SUPPLY W/ POWER PLUG (X1)
CONNECT POWER SUPPLY TO LED LIGHT CABLE;
10" GLASS SHELF (X1)
8" SHELF BRAKET (X3)
10" SHELF BRAKET (X3)
8" GLASS SHELF (X1)
DOOR PANEL (X2)
PLACE 8" & 10" SHELF BRACKETS ON STANDARD WITH PROPER HEIGHT;1. PLACE 8" & 10" GLASS SHELF ON SHELF BRACKETS;2. GENTLY SIT TOP GLASS ON TOP FRAME;3. INSERT DOOR PANELS ON SHOWCASE;
STEP 8:
