GRAND RESORT 10x12 Add-A-Room Gazebo with Netting User manual

Date of purchase: _____/ _____/ _____
Product Code: D71 M45965
KSN: 0-08402015-5
UPC Code: 749241316913
10x12 Add-A-Room Gazebo with Netting

Thank you for your purchase
Thank you for your purchase!
We are pleased that you have chosen Sears for your outdoor furniture purchase.
We hope that you enjoy the unmatched quality, comfort, and style of your new patio
set. Every piece is meticulously considered all the way down to the smallest details,
exclusively for you, by our world class design team. We know you have a choice when
it comes to your patio furniture needs, so from our team to yours, thank you for letting
us be a part of your outdoors.
Table of contents
Table of Contents ....................................................................................2
Safety Information ..................................................................................3
Set Up your Shelter Properly ................................................................3
Examine your Shelter ............................................................................3
Warranty ..................................................................................................3
Excluded ................................................................................................3
Service Center .......................................................................................3
Care and Maintenance ............................................................................4
Pre-Assembly ...........................................................................................5
Hardware Included ................................................................................5
Package Contents ..................................................................................6
Assembly Instructions .............................................................................9
Customer Service ....................................................................................35
2

Safety Information
SET UP YOUR SHELTER PROPERLY
Please read and understand this entire manual before attempt to assemble, operate, or
install the product.
If any part is missing or damaged. Do not attempt to assemble the product.
Two to four people are needed for assembly.
In order to avoid damage to the gazebo and its components please use appropriate tools.
Do not use the structure as support.
Check all bolts on a regular basis to maintain the solidity of the structure.
Keep instructions for future use.
Approximate time: 2 – 3 hours
.
EXAMINE YOUR SHELTER
Examine occasionally to ensure there are no loose parts. If loose parts are found, they
should be retightened immediately.
3
Warranty
1 YEAR WARRANTY FOR FRAME, NET AND POLY CARBONATE
Limited warranty is applicable on parts only. Warranty extends solely to the original
purchaser who must offer original sales receipt for record.
WHAT IS COVERED
Limited warranty is applicable on parts only. We warranty to the original purchase for
one year limited from the date of purchase that the frame, net and poly carbonate
will be free from manufacturing defects.
SERVICE CENTER
The purchaser must contact our customer service center directly if this product is
found to be defect in material or workmanship. The manufacturer, as its option, will
repair or replace the defectives parts.
Please contact us via 1-800-961-9838, 9AM-5PM, Pacific Time Zone, Monday-Friday,
or [email protected]
.
WHAT IS NOT COVERED
Product used for commercial, contract, or other non-residential purposes, or damage
due to acts of nature, vandalism, misuse, or improper assembly is not covered.
Corrosion or rusting of hardware is not covered. Warranty is to the original purchase
and is non-transferable. Any replacement of warranted items will be in the original style
and color, or a similar style and color if the original is unavailable or has been
discontinued.

Care and Maintenance
4
For cleaning, use a mild detergent solution, rinse with water, and allow to air dry.
Do not use acetone, abrasive, or other special detergents as they would be harmful to
the product’s finish.
Due to the nature of steel, surface oxidation (rusting) will occur if this protective coating
is scratched. This is a natural process. To minimize this condition, it is recommended
that care be taken when assembling and handling the product in order to prevent the
paint from being scratched.
Warning
WARING: KEEP ALL FLAME AND HEAT SOURCES AWAY FROM THIS
TENT FABRIC.
The tent meets the flammability requirements of CPAI-84. The fabric may burn if left in
continuous contact with any flame source. The application of any foreign substance to the
tent fabric may render the flame-resistant properties ineffective.
SNOW LOAD CAPACITY - CAN HOLD UP TO 1170LBS (MAX).
If high winds, heavy rains or snow occurs, remove mosquito net, clear snow load from
the roof immediately, and check for damage before continued use.

5
Pre-Assembly
PLANNING ASSEMBLY
To prevent damage, place all parts on a soft surface during assembly.
Tools required for assembly (not included): Allen wrench (included), a screwdriver,
stepladder (min. 5ft.) and other safety items such as gloves, safety eyewear, and hardhat.
To avoid injury from exposed sharp edges, it may be necessary to use the above safety
equipment.
Do not leave it unattended if not fully assembled even if bolted to the ground.
HARDWARE INCLUDED
NOTED: Hardware not shown
to actual size.
AA DD
CC
BB
FF
EE GG HH
LL
II JJ KK
Part Description Size QTY.
AA
BB
CC
DD
BOLT
BOLT
BOLT
SPANNER
( )
6 x 15mm
( )
6 x 30mm
( )
6 x 35mm
( )
6 x 60mm
60
20
8
4
EE
FF
BOLT
ALLEN WRENCH
6
12
GG
HH
II
JJ
KK
LL
BOLT
BOLT
WASHER
BOLT NUT
BOLT CAP
PLASTIC CAP
( )
6 x 65mm
( )
6 x 95mm
4
4
4
20
1
1

6
Pre-Assembly (continued)
Package Contents

7
Pre-Assembly (continued)
Package Contents
POST
DESCRIPTIONITEM QTY. ILLUSTRATION
POST
BASE FLANGE
CROSSBAR
CROSSBAR
CROSSBAR
CROSSBAR
CROSSBAR
CROSSBAR
WALL MOUNT
CROSSBAR
CROSSBAR
SHORT ROOF TUBE
LONG ROOF TUBE
ROOF TUBE
ROOF TUBE
ROOF TUBE
POST
BASE FLANGE

8
Pre-Assembly (continued)
Package Contents
ROOF TUBE
DESCRIPTIONITEM QTY. ILLUSTRATION
ROOF PANEL
EAVE TUBE
CORNER CONNECTOR
CORNER CONNECTOR
STACK
MOSQUITO NET
ROOF SUPPORT TUBE
ROOF SUPPORT TUBE
ROOF SUPPORT TUBE
EAVE TUBE
CENTER CONNECTOR

9
Assembly Instructions
1. Insert the Base Flange (D) into the bottom of the Post (A). Align the holes and insert
two Bolts (AA), tighten with the Allen Wrench.
Repeat this step for Post (B).
A x 1
B x 1
D x 2 AA x 4

10
Assembly Instructions
1. Insert the Base Flange (E) into the bottom of the Post (C). Align the holes and insert
two Bolts (AA), tighten with the Allen Wrench.
Repeat this step for remaining Post (C).
AA x 4
E x 2
C x 2

11
Assembly Instructions
1. Insert Crossbar (G) into Crossbar (F), then align the holes and insert two Bolts (CC)
through Washer (JJ) and Crossbar (F) into Crossbar (G) and Washer (JJ), secure with
Nuts (GG) using Allen Wrench and Spanner .
Finally cover Nuts (GG) by Bolt Cap (HH).
F x 1
G x 1
CC x 2
GG x 2
HH x 2
JJ x 4
JJ
JJ JJ
JJ

12
Assembly Instructions
1. Insert Crossbar (J) into Crossbar (K), then align the holes and insert two Bolts (CC)
through Washer (JJ) and Crossbar (K) into Crossbar (J) and Washer (JJ), secure with
Nuts (GG) using Allen Wrench and Spanner.
Finally cover Nuts (GG) by Bolt Cap (HH).
J x 1
K x 1
CC x 2
GG x 2
HH x 2
JJ x 4
JJ
JJ
JJ
JJ

13
Assembly Instructions
1. Insert Crossbar (I) into Crossbar (H). Secure the connection with Bolt (AA) using the
Allen Wrench.
I x 1
H x 1 AA x 4

14
Assembly Instructions
1. Insert Crossbar (M) into Crossbar (N). Secure the connection with Bolt (AA) using
Allen Wrench.
N x 1 AA x 4
M x 1

15
Assembly Instructions
1. Insert Roof Tube (R) into Roof Tube (Q), then secure with bolt (AA).
Repeat this step for remaining Roof Tube (Q & R).
Q x 2
AA x 4
R x 2

16
Assembly Instructions
1. Insert Roof Tube (T) into Roof Tube (S), then secure with bolt (AA), tighten with
Allen Wrench.
Repeat this step for remaining Roof Tube (Q & R).
T x 1
S x 1
AA x 4

17
Assembly Instructions
1. Attach one side of crossbar set (G, F) to Post (A). Align the holes and insert two bolts (BB).
Tighten with the Allen Wrench, but do not over tighten.
Repeat the procedure for the other side of crossbar set (G, F) and Post (C) by using
four bolts (BB).
Ensure the preassembled rods on the crossbars face the inside of the gazebo.
Warning: Two people are required to complete this step.
BB x 6

18
Assembly Instructions
1. Attach one side of crossbar set (J, K) to Post (B). Align the holes and insert two bolts (BB).
Tighten with the Allen Wrench, but do not over tighten.
Repeat the procedure for the other side of crossbar set (J, K) and Post (C) by using
four bolts (BB).
Ensure the preassembled rods on the crossbars face the inside of the gazebo.
Warning: Two people are required to complete this step.
BB x 6

19
Assembly Instructions
1. Assign the hole of the Crossbar (M) to the Post (C) by inserting bolts (BB). Tighten
with the Allen Wrench, but do not over tighten.
Repeat the procedure for the other Crossbar (N) to the other Post (C).
2. Assign the hole of the Crossbar (I) to the Post (B) using bolts (FF) and tighten with the
Allen Wrench.
Inserting Bolts (EE) through the top of Crossbar (I) and into Post (B). Tighten with the
Allen wrench.
Repeat the procedure for the other Crossbar (H) and Post (A).
BB x 8 FFx 4 EE x 2
FF
FF

20
Assembly Instructions
1. Assign the hole of the Roof Tube (S) to the assembled crossbar set (F, G) by using two
bolts (AA), tighten with Allen Wrench.
Repeat the procedure for Roof Tube (T) and the other assembled crossbar set (J, K).
2. Assign the hole of the Roof Tube (Q) to the assembled crossbar set (F, G) by using two
bolts (AA). Tighten with Allen Wrench.
Repeat the procedure for Roof Tube (R) and the other assembled crossbar set (J K).
3. Repeat the procedure 2 on the rest assembled roof tube set (Q, R).
AA x 12
