Grandbeing N363 User manual

Version:V1.0.1
UserManual
N363&N373&N383
H.264encoderanddecoder
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn

ImportantSafetyInstructions
Note:
Incaseofanycontentchange,wearesorryfornofurthernotice.
Warning:
Toreducetheriskoffire,electricshockorproductdamage:
1.Donotexposethisapparatus
torain,moisture,drippingor
splashingandthatnoobjects
filledwithliquids,suchasvases,
shallbeplacedontheapparatus.
6. Cleanthisapparatus
onlywithdrycloth.
2.Donotinstallorplacethisunit
inabookcase,built-incabinetor
inanotherconfinedspace.
Ensuretheunitiswellventilated.
3.Topreventriskofelectric
shockorfirehazarddueto
overheating,donotobstruct
theunitsventilationopenings
withnewspapers,tablecloths,
curtains,andsimilaritems.
4.Donotinstallnearanyheat
sourcessuchasradiators,heat
registers,stoves,orother
apparatus(includingamplifiers)
thatproduceheat.
5.Donotplacesourcesofnaked
flames,suchaslightedcandles,
ontheunit.
7. Unplugthisapparatus
duringlightningstormsor
whenunusedforlong
periodsoftime.
8. Protectthepowercord
frombeingwalkedonor
pinchedparticularlyat
plugs.
9. Onlyuseattachments/
accessoriesspecifiedby
themanufacturer.
10. Referallservicingto
qualifiedservice
personnel.
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn

1
TableofContents
Introduction......................................................................................................................3
Overview....................................................................................................................3
N363...................................................................................................................3
N373...................................................................................................................3
N383...................................................................................................................4
Features..................................................................................................................... 4
N363...................................................................................................................4
N373...................................................................................................................5
N383...................................................................................................................6
PackageContents................................................................................................... 8
N363...................................................................................................................8
N373...................................................................................................................8
N383...................................................................................................................8
Specifications............................................................................................................9
N363...................................................................................................................9
N373/N383......................................................................................................11
Panel.........................................................................................................................13
N363.................................................................................................................13
N373/N383......................................................................................................14
TypicalApplication.................................................................................................15
OneEncodertoOneDecoder....................................................................15
OneEncodertoMultipleDecoders...........................................................16
MultipleEncoderstoMultipleDecoders..................................................16
VideoWallFunction......................................................................................17
ViewingMultiplePicturesinaDisplay......................................................17
HardwareInstallation.................................................................................................19
OperatingwithControlSoftware........................................................................... 21
BeforeUsingtheControlSoftware....................................................................21
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn

2
SettingaStaticIPonYourComputer.......................................................21
ConfiguringYourOperatingSystemFirewall..........................................23
ControlSoftwareInstructions..............................................................................24
SearchingDevices........................................................................................24
DeviceParameterSettings.........................................................................26
DeviceSettingsWindowIntroduction.......................................................27
MatrixSettingIntroduction..........................................................................29
CreatingtheSceneWindow.......................................................................31
SceneAreaWindowInstruction.................................................................31
SettingaMatrix..............................................................................................33
ConfigurationFilesManagement.............................................................. 38
Logs..................................................................................................................40
UpgradingtheDevices.................................................................................41
Troubleshooting...........................................................................................................47
ProductService............................................................................................................49
Maintenance........................................................................................................... 49
ProvidedService....................................................................................................49
Mail-InService........................................................................................................49
Warranty.................................................................................................................. 50
WarrantyLimitsandExclusions.........................................................................50
Glossary..........................................................................................................................52
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn

3
Introduction
Overview
N363
N363,ahighperformanceliveH.264streamingmediaencoderwithHDMI
signalsinput,deliversmediaoverIPnetworks.N363canbeusedwith
decodersN373andN383toprovidecompleteend-to-endstreamingmedia
system.ItfeaturesoneHDMIinput,oneHDMIoutputandoneVGAoutput.
N363adoptsstandardH.264/MPEG-4AVCencodingandoutputstwoIP
streams,a1080p@60streamanda480p@60stream.N363outputs
resolutionsfrom480pto1920x1200scaledbasedonthesinkEDID.High
performancesignalprocessingscalesandoptimizesvideoinputsignalsto
obtaintheintendedviewingeffects.Encodingcontrolscanalsoadjustbitrate
andquality.N363expandsAudio/VideosystemcapabilitybyextendingHDMI
signalsoverIPnetworks.
N373
N373isahighperformanceliveH.264decoderusedwithN363encoderto
providecompleteend-to-endstreaming-mediatransmissionsystem.N373
supportsvideowallfunction.Inaddition,itsupportsstreamingresolutions
[e-mail]efrom480p
to1920x1200scaledbasedonthesinkEDID.Withthecomputercontrol
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn

4
software,thiscompactdecoderoffersmultipleintegratedfeatures,suchas
RS232,IRforflexiblecontrolandmanagementoptions.
N383
N383isahighperformanceliveH.264decoderusedwithN363encoderto
providecompleteend-to-endstreaming-mediatransmissionsystem.N383
candecodeupto16IPstreams.WhenN383receivesasingleIPstream,it
hasthesamedecodingfeaturesasN373's,suchassupportingstreaming
resolutionsandrefreshratesupto1080p@60andoutputresolutionsfrom
480pto1920x1200scaledbasedonthesinkEDID.Whenreceivingtwoor
moreIPstreams(upto16IPstreams),itsupportsstreamingresolutionsand
refreshratesupto480p60andoutputresolutionsfrom480pupto
1920x1200scaledbasedonthesinkEDID.Withthecomputercontrol
software,thiscompactdecoderoffersmultipleintegratedfeatures,suchas
RS232,IRforflexiblecontrolandmanagementoptions.
Features
N363
lStreamsHDMIsignalsoverIPnetworks
lSupportsH.264/MPEG-4AVCcompressionstandard.
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn

5
lUsewithH.264decoderN373toprovidefeatures,suchasextending
HDMIsignalsoverIPnetworksandmatrixswitchingcontroloverLANby
thecontrolsoftware.
lUsewithH.264decoderN383toprovidemulti-pictureviewingeffects(up
to16pictures)inasinglescreeninadditiontothesamefeaturesas
N373.
lSupportstheinputresolutions,480i,480p,576i,576p,720p,1080i,
1080p.
lSupportsoutputresolutionsfrom480pto1920x1200scaledbasedonthe
sinkEDID.
lScalesandoptimizesvideoinputsignalsfortheintendedviewingeffects.
lAutoinputformatdetectiontoprovidetheappropriatedecodingand
signalprocessing.
lEncodingbitrateisselectablefrom1K~40Mbps.
lSupportsTCP/IP,Telnet,UDP,IGMPandH.264
lSupportsAutoIPconfiguration.
lAutomaticallydetectedbythecontrolsoftware.
lUseswiththeIPcontrolboxTK-N006-000formatrixcontroland
managementviaLAN.
N373
lSupportsliveIPvideostreamdecoding.
lUseswithencoderN363toprovideacompleteend-to-endstream
transmissionsystem,supportingseamlessswitching.
lSupportsstreamingresolutionsandrefreshratesupto1080p@60.
lSupportsoutputresolutionsfrom480pupto1920x1200basedonthe
sinkEDID.
lSupportsvideowallfunction
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn

6
lIRpass-throughcontrolfordisplaysorsourcesoverIPnetworks.
lRS232fordebugortocontrolaRS232device.
lAutomaticaspectratiofilling,followingandfittingmanagement.
lSupportTCP/IP,Telnet,UDP,IGMPandH.264
lSupportsPoE
lSupportsAutoIPconfiguration.
lAutomaticallydetectedbycontrolsoftware.
lUseswiththeIPcontrolboxTK-N006-000formatrixcontroland
managementviaLAN.
N383
lSupportsliveIPvideostreamdecoding
lUseswithencoderN363toprovidecompletestreamtransmission
system,supportingseamlessswitching.
lSupportsstreamingresolutionsandrefreshratesupto480p@60.
lSupportsoutputresolutionsfrom480pupto1920x1200basedonthe
sinkEDID.
lSupportsmulti-pictureviewingeffectsinasinglescreenbyautomatically
dividingthescreeninto1,4,9or16completepicturesbasedonthe
numberofIPstreams.
lIRpass-throughcontrolfordisplaysorsourcesoverIPnetworks.
lRS232fordebugortocontrolaRS232device.
lAutomaticaspectratiofilling,followingandfittingmanagement.
lSupportTCP/IP,Telnet,UDP,IGMPandH.264
lSupportsPoE
lSupportsAutoIPconfiguration.
lAutomaticallydetectedbycontrolsoftware.
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn

7
lUseswiththeIPcontrolboxTK-N006-000formatrixcontroland
managementviaLAN.
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn

8
PackageContents
N363
1xN363
1xPowercable
1xPhoenixmaleconnector(3.5mm3pins)
2xMountingear
N373
1xN373
1xPowercable
1xPoweradapter
1xPhoenixmaleconnector(3.5mm3pins)
1xPhoenixmaleconnector(3.5mm5pins)
2xMountingear
N383
1xN383
1xPowercable
1xPoweradapter
1xPhoenixmaleconnector(3.5mm3pins)
1xPhoenixmaleconnector(3.5mm5pins)
2xMountingear
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn

9
Specifications
N363
Technical
I/OConnections
1×HDMIIN
1×HDMIOUT
1xVGAOUT
1×RJ45
2×RS232(3.5mmphoenix)
PowerSupply AC100~240V50/60Hz
PowerConsumption 6.3Watts
InputVideoSignal 1.2voltsp-p
InputDDCSignal 5voltsp-p(TTL)
DataRate 1K~40Mbps,configurable
MaximumDistance 100meters
Video Format
Supported
Input:
HDMI:480i,480p,576i,576p,720p,1080i,1080p
Output:
HDMI&VGA:Followthesink'sEDID.
Ethernet:1080p@60,480p@60
OutputVideo HDMI1.3
ControlMethod RS232
LAN
ESDProtection
Humanbodymodel:
±8kV(air-gapdischarge)
±4kV(contactdischarge)
SurgeProtection Voltage: ±1kV
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn

10
Technical
Operating
Temperature
32°Fto95°F(0°Cto35°C)
10%to90%,non-condensing
StorageTemperature -4°Fto140°F(-20°Cto70°C)
10%to90%,non-condensing
SystemRequirements
lHDMIequippedsourcedevices.
lHDMIequippeddisplaysorVGAequipped
displays.
lIndustrystandardCAT5e/6cablesorabove.
lHDMIcablesandVGAcables.
lA10/100Base-TEthernetswitchorabove.
General
CaseDimensions
(WxHxD)
l525mmx122mmx327mm
l20.7''x4.8''x12.9''
DeviceDimensions
(WxHxD)
l440mmx44mmx211mm
l17.3''x1.7''x8.3''
Mass(Mainunit) 2.62kg
Certification CE,FCC,RoHS
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn

11
N373/N383
Technical
I/OConnections
1×RJ45
1×AUDIOOUT(3.5mmphoenix)
1×HDMIOUT
2×RS232(3.5mmphoenix)
1×IRTX(3.5mmphoenix)
2×IO/IN(3.5mmphoenix)
2×RELAY(3.5mmphoenix)
PowerSupply 12V2ADC,5.5mm
PowerConsumption 4.56Watts
InputVideoSignal 1.2voltsp-p
InputDDCSignal 5voltsp-p(TTL)
MaximumDistance 100meters
Video Format
Supported
Input:
Ethernet:1080p@60forN373,480p@60for
N383
Output:
HDMI:Followthesink'sEDID.
OutputVideo HDMI1.3
OutputAudio Stereo(reserved)
ControlMethod RS232
LAN
ESDProtection HumanBodyModel: ±8kV(air-gapdischarge)
±4kV(contactdischarge)
SurgeProtection Voltage: ±1kV
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn

12
Technical
OperatingTemperature 32°Fto95°F(0°Cto35°C)
10%to90%,non-condensing
StorageTemperature -4°Fto140°F(-20°Cto70°C)
10%to90%,non-condensing
SystemRequirements
lHDMIequippedsourcedevices.
lHDMIequippeddisplaysandaudio
receivers.
lIndustrystandardCAT5e/6cablesor
above.
lHDMIcables.
lA10/100Base-TEthernetswitchorabove.
General
CaseDimensions
(WxHxD)
l390mmx92mmx220mm
l15.4''x3.6''x8.7''
DeviceDimensions
(WxHxD)
l269mmx24mmx110mm
l10.6''x0.9''x4.3''
Mass(Mainunit) 0.78kg
Certification CE,FCC,RoHS
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn

13
Panel
N363
FrontPanel
1
ID Name Description
1Power
indicator
On: N363ispoweredon.
Off: N363ispoweredoff.
RearPanel
1 2 83 4 5 6 7
ID Name Description
1HDMIIN ConnectstoasourcedeviceviaanHDMIcable.
2HDMIOUT ConnectstoasinkviaanHDMIcable.
3VGAOUT ConnectstoasinkviaaVGAcable.
4LANport Connectstoa10/100Base-TEthernetswitchwitha
CAT5e/6cable.
5RS232-1 Usedfordebug.
6RS232-2 ConnectstoaRS232device.
7Power ConnectstotheACpowersupplyviaapowercable.
8GND Grounding.
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn

14
N373/N383
N373andN383havethesameappearance.
FrontPanel
1 2
ID Name Description
1Power
indicator On: N373/N383ispoweredon.
Off: N373/N383ispoweredoff.
2Link
indicator SteadyOn: N363andN373/N383arelinkedtoeach other.
Flashing: N363andN373/N383arenotlinkedtoeach
other.
RearPanel
1 2 8 93 4 5 6 7
ID Name Description
1GND Grounding
2Power Connectstoa12V/2ADCpowersupplyviaapower
adapter.
3LAN Connectstoa10/100Base-TEthernetswitchwitha
CAT5e/6cable.
4AUDIOOUT Reservedport.
5 HDMIOUT ConnectstoasinkviaanHDMIcable.
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn

15
ID Name Description
6RS232 RS2321:
Usedfordebug.
RS2322:
ConnectstoaRS232device.
7IRTX ConnectstoanIRemittercable.
8 IO/IN Reservedports.
9Relay Reservedports.
TypicalApplication
OneEncodertoOneDecoder
IfanencoderN363andadecoderN373/N383areused,youcanenjoythe
full-screenviewingeffectsinthedisplaydeviceconnectedtotheN373/N383.
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn

16
OneEncodertoMultipleDecoders
IfanencoderN363andmultipledecodersN373/N383areused,youcan
enjoythefull-screenviewingeffectsinthedisplaydeviceconnectedtothe
N373/N383.
MultipleEncoderstoMultipleDecoders
IfmultipleencodersN363anddecodersN373/N383areused,youcan:
lEnjoythefull-screenviewingeffectsinthedisplaydeviceconnectedto
theN373/N383ifaN363islinked.
lEnjoymulti-pictureviewingeffectsinthedisplaydeviceconnectedtothe
N383ifmultipleN363sarelinked.
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn

17
VideoWallFunction
N373supportsvideowallfunction.Thediagramisshownbelowforyour
reference.
ViewingMultiplePicturesinaDisplay
BasedonthenumberofIPstreamsfromthesources,asinglescreencanbe
dividedinto1,4,9or16partswitheachpartdisplaysacompletepicture.
Fordetails,seethefollowingtable.
Decoder NumberofN363linked Viewingeffectsonthescreen
N383
11completepicturefillingtheentire
screen.
2~4 4completepicturesfillingtheentire
screen
5~9 9completepicturesfillingtheentire
screen.
10~16 16completepicturesfillingthe
entirescreen.
Note:
WhenthenumberofN363linkedtoN383isfrom2~3,5~8,or10~15,the
unoccupiedpartsofthescreenshownopicture.Forexample,N383
belowislinkedtooneortwoN363s,thedisplaysconnectedtoN383s
showoneortwocompletepictures.
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn

18
OneN363Linked
TwoN363sLinked
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn
