Operating Instructions
Grandbeing®
HDMI Switch
Model No. GB07SW0201
Operating Instructions（P/N of this Instructions is INSGB07SW0201）
Dear customer
Thank you for purchasing this product. For optimum performance and safety,
please read these instructions carefully before connecting, operating or adjusting
this product. Please keep this manual for future reference.
FEATURES
zCompact size: only of 6.7cm by 8.8cm.
zNo need of outside power supply. (The power input is optional)
zNo need of setting.
zSelection: Auto selecting any active input signal of the two to the output.
zSignaling rates up to 2.25Gbits in support of 1080P display.
z8dB receiver equalization to compensate for 5m HDMI cable losses.
z3dB driver pre-emphasis to compensate for PCB losses.
GRANDBEING®
１

Operating Instructions
zEach port supports HDMI or DVI inputs.
zHDCP compliant.
NOTICE
Grandbeing Inc. reserves the right to make changes in the hardware, packaging
and any accompanying documentation without prior written notice.
TABLE OF CONTENTS
Introduction
Package Contents
Panel Descriptions
Connecting and Operating
Specifications
Typical Application
Maintenance
Product Service
Warranty
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PRODUCT
DAMAGE:
1) DO NOT EXPOSE THIS APPARATUS TO RAIN, MOISTURE, DRIPPING
OR SPLASHING AND THAT NO OBJECTS FILLED WITH LIQUIDS, SUCH
AS VASES, SHALL BE PLACED ON THE APPARATUS.
2) DO NOT INSTALL OR PLACE THIS UNIT IN A BOOKCASE, BUILT-IN
CABINET OR IN ANOTHER CONFINED SPACE. ENSURE THE UNIT IS
WELL VENTILATED.
3) TO PREVENT RISK OF ELECTRIC SHOCK OR FIRE HAZARD DUE TO
OVERHEATING, DO NOT OBSTRUCT THE UNIT’S VENTILATION
OPENINGS WITH NEWSPAPERS, TABLECLOTHS, CURTAINS, AND
SIMILAR ITEMS.
4) DO NOT INSTALL NEAR ANY HEAT SOURCES SUCH AS RADIATORS,
HEAT REGISTERS, STOVES, OR OTHER APPARATUS (INCLUDING
AMPLIFIERS) THAT PRODUCE HEAT.
5) DO NOT PLACE SOURCES OF NAKED FLAMES, SUCH AS LIGHTED
CANDLES, ON THE UNIT.
6) CLEAN THIS APPARATUS ONLY WITH DRY CLOTH.
7) UNPLUG THIS APPARATUS DURING LIGHTNING STORMS OR WHEN
UNUSED FOR LONG PERIODS OF TIME.
8) PROTECT THE POWER CORD FROM BEING WALKED ON OR PINCHED
PARTICULARLY AT PLUGS.
9) ONLY USE ATTACHMENTS/ACCESSORIES SPECIFIED BY THE
MANUFACTURER.
10) REFER ALL SERVICING TO QUALIFIED SERVICE PERSONNEL.
GRANDBEING®
２

Operating Instructions
INTRODUCTION
Grandbeing’s GB07SW0201 is a two-input HDMI switch. It switches the two HDMI
inputs to the output. These two inputs are auto switching.(Smart function)
GB07SW0201 has the ability of equalization and amplification to ensure HDMI
signal’s transmission through long cable without quality loss.
GB07SW0201 offers solutions for residential consumers, HDTV retail and show
site, HDTV, STB, DVD and Projector factories, noise, space and security
concerns, data center control, information distribution, conference room
presentation, school and corporate training environments.
PACKAGE CONTENTS
1) Main unit. P/N_GB07SW0201
2) 5VDC Power Supply.P/N_VDC0501(Optional)
3) Operating Instructions. P/N_INSGB07SW0201
*PART NUMBER (Abbreviation as P/N)
PANEL DESCRIPTIONS
GRANDBEING®
３

Operating Instructions
1) HDMI input NO.1
2) HDMI input NO.2
3) Power input (Optional)
4) HDMI output
CONNECT AND OPERATE
1) Connect the HDMI input sources（such as：HD-DVD、PS3、STB etc.）into
GB07SW0201.
2) Connect the HDMI output( such as : HD-LCD、HD-DLP）into GB07SW0201.
3) Power on the input source you want to show. (Keep the unused input power
off, otherwise it may interfere the normal display.)
4) Power on the display.
（Remark：The power adapter is needed when the signal source has no sufficient power
driving ability.）
* Smart function：Using two HDMI signal sources（such as HDDVD etc）, connecting one
HDMI display. If only the source 1 is on, input 1 would be selected. If only the source 2 is on,
the input 2 would be chosen. When the two sources are all on, only input 1 is selected.
Attention: Insert / Extract cable gently.
SPECIFICATIONS
Operating temperature range……………….…………… -5 to +35℃(-41 to +95℉)
Operating humidity range………………………… 5 to 90 % RH (no condensation)
Signalling rates............….............................................................….2.25Gbits x 3
Input Video Signal........................…............................................. 0.5-1.0 volts p-p
Input DDC Signal.........................…............................................ 5 volts p-p (TTL)
Video format supported：…DTV/HDTV：1080P/1080i/720P/576P/480P/576i/480i
Output Video…………………………………………………………………..HDMI1.3
Maximum transmission distance…..<15m（If needed，HDMI extender is optional）
GRANDBEING®
４

Operating Instructions
Power Consumption.....................…......................................... 120 mWatts (max.)
Dimensions..................................…........................ 67mmW x 88mmH x 28mmD
Mass.......................................…..………….................................................. 25 gs
Note: Specifications are subject to change without notice. Mass and dimensions are
approximate.
TYPICAL APPLICATION
MAINTENANCE
HDMI Signal
Source1（Such
as HD-DVD）
HDMI Signal
Source2（Such
as PS3）
DC5V
Input1 Output
GB07SW0201
Input2
Display ：Such as
HDMI LCD TV
Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner or benzine to
clean this unit.
PRODUCT SERVICE
1) Damage requiring service: The unit should be serviced by qualified service
personnel if:
(a) The DC power supply cord or AC adaptor has been damaged;
(b) Objects or liquids have gotten into the unit;
(c) The unit has been exposed to rain;
(d) The unit does not operate normally or exhibits a marked change in
performance;
(e) The unit has been dropped or the cabinet damaged.
2) Servicing Personnel: Do not attempt to service the unit beyond that
described in these operating instructions. Refer all other servicing to
authorized servicing personnel.
3) Replacement parts: When parts need replacing ensure the servicer uses
parts specified by the manufacturer or parts that have the same
characteristics as the original parts. Unauthorized substitutes may result in
fire, electric shock, or other hazards.
4) Safety check: After repairs or service, ask the servicer to perform safety
checks to confirm that the unit is in proper working condition.
WARRANTY
GRANDBEING®
５

Operating Instructions
If your product does not work properly because of a defect in materials or
workmanship, Grandbeing Company (referred to as “the warrantor”) will, for the
length of the period indicated as below, （Parts (1) Year，Labor(90) Days）which
starts with the date of original purchase (“Limited Warranty period”), at its option
either (a) repair your product with new or refurbished parts, or (b) replace it with a
new or a refurbished product. The decision to repair or replace will be made by
the warrantor.
During the “Labor” Limited Warranty period there will be no charge for labor.
During the “Parts” warranty period, there will be no charge for parts. You must
mail-in your product during the warranty period. This Limited Warranty is
extended only to the original purchaser and only covers product purchased as
new. A purchase receipt or other proof of original purchase date is required for
Limited Warranty service.
Mail-In Service
When shipping the unit carefully pack and send it prepaid, adequately insured and
preferably in the original carton. Include a letter detailing the complaint and
provide a day time phone and/or email address where you can be reached.
IF REPAIR IS NEEDED DURING THE LIMITED WARRANTY PERIOD THE
PURCHASER WILL BE REQUIRED TO FURNISH A SALES RECEIPT/PROOF
OF PURCHASE INDICATING DATE OF PURCHASE, AMOUNT PAID AND
PLACE OF PURCHASE. CUSTOMER WILL BE CHARGED FOR THE REPAIR
OF ANY UNIT RECEIVED WITHOUT SUCH PROOF OF PURCHASE.
LIMITED WARRANTY LIMITS AND EXCLUSIONS
1) This Limited Warranty ONLY COVERS failures due to defects in materials or
workmanship, and DOES NOT COVER normal wear and tear or cosmetic
damage. The Limited Warranty ALSO DOES NOT COVER damages which
occurred in shipment, or failures which are caused by products not supplied
by the warrantor, or failures which result from accidents, misuse, abuse,
neglect, mishandling, misapplication, alteration, faulty installation, set-up
adjustments, misadjustment of consumer controls, improper maintenance,
power line surge, lightning damage, modification, or service by anyone other
than a Factory Servicenter or other Authorized Servicer, or damage that is
attributable to acts of God.
2) THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER
“LIMITED WARRANTY COVERAGE”. THE WARRANTOR IS NOT LIABLE
FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM
THE USE OF THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF
THIS WARRANTY. (As examples, this excludes damages for lost time, cost
of having someone remove or re-install an installed unit if applicable, travel to
and from the servicer, loss of or damage to media or images, data or other
recorded content. The items listed are not exclusive, but are for illustration
only.)
GRANDBEING®
６

Operating Instructions
3) PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED
WARRANTY, ARE YOUR RESPONSIBILITY.
Customer Services Directory
Grandbeing Technology Co., Ltd
Address: 6C, Jialitai Building, No. 6 Yanshan Road, Nanshan District
Shenzhen , P.R. China
Post Code:518067
Tel:[phone]
Fax:[phone]
Email:[email protected], [email protected], [email protected]
Website:http://www.grandbeing.com
