Grandstream Networks DP755 User manual

Grandstream Networks, Inc.
DP755/DP730/DP722
User Guide

DP755/DP730/DP722 - User Guide
WELCOME
Thank you for purchasing Grandstream DP755 DECT Cordless VoIP Base Station and DP722/DP730 DECT Cordless HD
Handsets.
The DP755 is a powerful Dect VoIP Phone Base station that pairs with up to 10 of Grandstream’s DP series DECT handsets to
offer mobility to business and residential users. It supports a range of up to 400 meters with DP730 and up to 350 meters with
DP722/DP720 outdoors and 50 meters indoors to give users the freedom to move around their work or home space,
delivering efficient flexibility. This DECT VoIP Phone Base Station supports up to 10 handsets and 20 SIP accounts while also
offering 3-way voice conferencing, full HD audio, and integrated PoE. A shared SIP account on all handsets will add seamless
unified features that give users the ability to answer all calls regardless of location in real-time. The DP755 supports a variety
of auto-provisioning methods and TLS/SRTP/HTTPS encryption security. When paired with Grandstream’s DP720, DP722, or
DP730 handsets, the DP755 offers a powerful cordless DECT solution for any business or residential user.
The DP730 is a DECT cordless IP phone that allows users to mobilize their VoIP network throughout any business, warehouse,
retail store, or residential environment. It is supported by Grandstream’s DP750, DP752, and DP755 DECT VoIP base stations
and delivers a combination of mobility and top-notch telephony performance. Up to ten DP730 handsets are supported on
each base station while each DP730 supports a range of up to 400 meters outdoors and 50 meters indoors from the base
station. It touts a suite of robust telephony features including support for up to 10 SIP accounts and 2 concurrent calls per
handset, full HD audio, a 3.5mm headset jack, push-to-talk, a speakerphone, and more. When paired with Grand stream’s
DECT Base Stations, the DP730 offers a powerful cordless DECT solution for any business or residential user.
The DP722 is a DECT cordless IP phone that allows users to mobilize their VoIP network throughout any business, warehouse,
retail store, or residential environment. It is supported by Grandstream’s DP750, DP752, and DP755 DECT VoIP base stations
and delivers a combination of mobility and top-notch telephony performance. Up to ten DP722 handsets are supported on
each base station while each DP722 supports a range of up to 350 meters outdoors and 50 meters indoors from the base
station. It touts a suite of robust telephony features including support for up to 20 SIP accounts and two concurrent calls per
handset, full HD audio, a 3.5mm headset jack, push-to-talk, a speakerphone and more. When paired with Grandstream’s DECT
Base Stations, the DP722 offers a powerful cordless DECT solution for any business or residential user.
PRODUCT OVERVIEW
Feature Highlights
The following tables contain the major features of the DP755 / DP730 / DP722:
DP755
DP755 Features at a Glance
DP730
●10 Handsets.
●20 accounts.
●20 Lines.
●8 Concurrent calls.
●PoE power support.
●Range: Up to 400m with DP730 and up to 350m with
DP722/DP720 outdoor / 50m range indoor.

DP730 Features at a Glance
DP722
DP722 Features at a Glance
DP755 Technical Specifications
The following table resumes all the technical specifications including the protocols/standards supported, voice codecs,
telephony features, languages, and upgrade/provisioning settings for the Base station DP755.
●DECT cordless HD.
●2.4 inch (240x320) color TFT LCD.
●500 hours standby / 40 hours talk time.
●15 languages embedded.
●10 accounts.
●2 concurrent calls.
●5 ring modes.
●DECT cordless HD.
●1.8 inch (128x160) color TFT LCD.
●250 hours standby / 20 hours talk time.
●15 languages embedded.
●10 accounts.
●2 concurrent calls.
●5 ring modes.
Air Interface
Telephony standards: DECT
Frequency bands:
●1880 – 1900 MHz (Europe), 1920 – 1930 MHz (US)
●1910 – 1920 MHz (Brazil), 1786 – 1792 MHz (Korea)
●1893 – 1906 MHz (Japan), 1880 – 1895 MHz (Taiwan)
Number of channels: 10 (Europe), 5 (US, Brazil or Japan), 3 (Korea), 8
(Taiwan)
Range: up to 400 meters outdoor and 50 meters indoor
Peripherals
3 LED indicators: Power, Network, DECT.
Pairing/Paging button.
One 10/100 Mbps auto-sensing Ethernet port with integrated PoE
Protocols/Standards
SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP/RARP,
ICMP, DNS (A record, SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP,
STUN, SIMPLE, LLDP-MED, LDAP, TR-069, 802.1x, TLS, SRTP
Voice Codecs
G.711μ/a-law, G.723.1, G.729A/B, G.726-32, iLBC, G.722, OPUS,
G.722.2/AMR-WB (special order), in-band and out-of-band DTMF (in
audio, RFC2833, SIP INFO), VAD, CNG, PLC, AJB

DP755 Technical Specifications
DP730 Technical Specifications
The following table resumes all the technical specifications including the protocols/standards supported, voice codecs,
telephony features, languages, and upgrade/provisioning settings for the DP730 handsets.
Telephony Features
Hold, transfer, forward, 3-way conference, push to talk, intercom,
downloadable phonebook (XML, LDAP, up to 3000 entries), call
waiting, call log (up to 300 records), auto answer, flexible dial plan,
server redundancy and fail-over
QoS Layer 2 QoS (802.1Q, 802.1p) and Layer 3 QoS (ToS, DiffServ, MPLS)
Security
User and administrator level access control, MD5 and MD5-sess based
authentication, 256-bit AES encrypted configuration file, TLS, SRTP,
HTTPS, 802.1x media access control, DECT authentication &
encryption
Multi-language
Chinese Simple, Chinese Tradition, Czech, Danish, Dutch, English,
Estonian, Finnish, French, German, Hebrew, Hungarian, Japanese,
Korean, Norwegian, Portuguese, Romanian, Spanish, Swedish, Turkish.
Upgrade/ Provisioning Firmware upgrade via HTTP/HTTPS or FTP/FTPS, mass provisioning
using TR-069 or AES encrypted XML configuration file
Multiple SIP Accounts
Up to twenty (20) distinct SIP accounts per system
Each handset may map to any SIP account(s)
Each SIP account may map to any handsets(s)
Ring Group ●Parallel Mode: All phones ring concurrently; after one phone
answers, the remaining available phones can make new calls
Power & Green Energy
Efficiency
Universal Power Supply Input AC 100-240V 50/60Hz; Output 5VDC,
1A; Micro-USB connection;
PoE: IEEE802.3af Class 1, 0.44W–3.84W
Package Content Base unit, Universal Power Supply, Ethernet cable, Quick Installation
Guide, GPL Statement
Dimensions (H x W x D) to be defined.
Weight
Base unit: 140g;
Universal power supply: 50g;
Package: 370g
Temperature and Humidity
Operation: -10º to 50ºC (14 to 122ºF); Storage: -20º to 60ºC (-4 to
140ºF);
Humidity: 10% to 90% non-condensing
Compliance
FCC: FCC Part 15B; FCC Part 15D; SAR (FCC 47 CFR Part2.1093;
IEEE 1528; IEC 62209-2); FCC Part68 HAC; FCC ID
CE：EN 55032; EN 55035; EN 61000-3-2; EN 61000-3-3; EN 60950-
1;EN 301 489-1/-6; EN 301 406; EN 50332-2;
SAR(EN50360;EN50566;EN 50663;EN62209-1; EN62209-2; EN
62479); RED NB Cert
RCM：AS/NZS CISPR32; AS/NZS 60950.1;AS/CA S004;AS/ACIF
S040. ANATEL, EAC, UL(adapter).

Air Interface
Telephony standards: DECT
Frequency bands:
●1880 – 1900 MHz (Europe), 1920 – 1930 MHz (US)
●1910 – 1920 MHz (Brazil), 1786 – 1792 MHz (Korea)
●1893 – 1906 MHz (Japan), 1880 – 1895 MHz (Taiwan)
Number of channels: 10 (Europe), 5 (US, Brazil or Japan), 3 (Korea), 8
(Taiwan)
Range: up to 400 meters outdoor and 50 meters indoor
Peripherals
2.4 inch (240×320) color TFT LCD
27 keys including 3 soft keys, 5 navigation/ menu keys, 4 dedicated
function keys for SEND, POWER/END, SPEAKERPHONE, MUTE, 3
side keys including 2 volume (up and down) and 1 Push-to-Talk key
3-color MWI LED
3.5mm headset jack
Proximity and accelerometer sensors
Backlit keypad
Removable belt clip
Micro-USB port for alternative charging and non-battery operation
Protocols/Standards Hearing Aid Compatibility (HAC) compliant
Voice Codecs
G.722 codec for HD audio and G.726 codec for narrow band audio
(G.711μ/a-law, G.723.1, G.729A/B, iLBC and OPUS are supported via
companion DECT base station DP755), AEC, AGC, Ambient noise
reduction on microphone capturing and advanced noise suppression on
audio playing
Telephony Features
Hold, transfer, forward, 3-way conference, push-to-talk, intercom, call
park, call pickup, downloadable phonebook, call waiting, call log, auto
answer, click-to-dial, flexible dial plan
HD Audio Yes, in both Handsets and Speakerphone modes
Security DECT authentication & encryption
Multi-language
Chinese Simple, Chinese Tradition, Czech, Danish, Dutch, English,
Estonian, Finnish, French, German, Hebrew, Hungarian, Japanese,
Korean, Norwegian, Polish, Portuguese, Romanian, Spanish, Turkish.
Upgrade/ Provisioning Software Upgrade Over-The-Air (SUOTA), handsets provisioning Over-
The-Air
Multiple Line Access Each handset may access up to 10 lines
Power & Green Energy
Efficiency
Universal Power Supply Input AC 100-240V 50/60Hz; Output 5VDC
1A; Micro-USB connection;
Rechargeable Li-ion battery (500 hours of standby time and 40 hours of
talk time)
Package Content Handset unit, universal power supply, charger cradle, belt clip, 1 battery,
Quick Installation Guide
Dimensions (H x W x D) Handset: 168.5 x 52.5 x 21.8mm;
Charger cradle: 76 x 73 x 81mm

DP730 Technical Specifications
DP722 Technical Specifications
The following table resumes all the technical specifications including the protocols/standards supported, voice codecs,
telephony features, languages, and upgrade/provisioning settings for the DP722 handsets.
Weight
Handset: 180g;
Charger cradle: 78g;
Universal power supply: 50g;
Package: 465g
Temperature and Humidity
Operation: -10º to 50ºC (14 to 122ºF); Charging: 0 to 45ºC (32 to 113ºF);
Storage: -20º to 60ºC (-4 to 140ºF); Humidity: 10% to 90% non-
condensing
Compliance
FCC: FCC Part 15B; FCC Part 15D; SAR (FCC 47 CFR Part2.1093;
IEEE 1528; IEC 62209-2); FCC Part68 HAC; FCC ID
CE：EN 55032; EN 55035; EN 61000-3-2; EN 61000-3-3; EN 60950-
1;EN 301 489-1/-6; EN 301 406; EN 50332-2;
SAR(EN50360;EN50566;EN 50663;EN62209-1; EN62209-2; EN
62479); RED NB Cert
RCM：AS/NZS CISPR32; AS/NZS 60950.1;AS/CA S004;AS/ACIF
S040. ANATEL, EAC, UL(adapter).
Air Interface
Telephony standards: DECT
Frequency bands:
●1880 – 1900 MHz (Europe), 1920 – 1930 MHz (US)
●1910 – 1920 MHz (Brazil), 1786 – 1792 MHz (Korea)
●1893 – 1906 MHz (Japan), 1880 – 1895 MHz (Taiwan)
Number of channels: 10 (Europe), 5 (US, Brazil or Japan), 3 (Korea), 8
(Taiwan)
Range: up to 350 meters outdoor and 50 meters indoor
Peripherals
1.8 inch (128×160) color TFT LCD
23 keys including 2 softkeys, 5 navigation / menu keys, 4 dedicated
function keys for SEND, POWER/END, SPEAKERPHONE, MUTE
3-color MWI LED
3.5mm headset jack
Removable belt clip
Micro-USB port for alternative charging and non-battery operation
Protocols/Standards Hearing Aid Compatibility (HAC) compliant
Voice Codecs
G.722 codec for HD audio and G.726 codec for narrow band audio
(G.711μ/a-law, G.723.1, G.729A/B, iLBC and OPUS are supported via
companion DECT base station DP755), AEC, AGC, Ambient noise
reduction on microphone capturing and advanced noise suppression on
audio playing
Telephony Features
Hold, transfer, forward, 3-way conference, push-to-talk, intercom, call
park, call pickup, downloadable phonebook, call waiting, call log, auto
answer, click-to-dial, flexible dial plan
HD Audio Yes, in both Handsets and Speakerphone modes
Security DECT authentication & encryption

DP722 Technical Specifications
GETTING STARTED
This chapter provides basic installation instructions including the list of the packaging contents and also information for
obtaining the best performance with the DP730/DP722 DECT Cordless HD Handsets and the DP755 DECT Cordless VoIP Base
Station.
Equipment Packaging
DP755
Multi-language
Chinese Simple, Chinese Tradition, Czech, Danish, Dutch, English,
Estonian, Finnish, French, German, Hebrew, Hungarian, Japanese,
Korean, Norwegian, Polish, Portuguese, Romanian, Spanish, Turkish.
Upgrade/ Provisioning Software Upgrade Over-The-Air (SUOTA), handsets provisioning Over-
The-Air
Multiple Line Access Each handset may access up to 10 lines
Power & Green Energy
Efficiency
Universal Power Supply Input AC 100-240V 50/60Hz; Output 5VDC
1A; Micro-USB connection;
Rechargeable Li-ion battery (500 hours of standby time and 40 hours of
talk time)
Package Content Handset unit, universal power supply, charger cradle, belt clip, 1 battery,
Quick Installation Guide
Dimensions (H x W x D) Handset: 158 x 50 x 28.1mm;
Charger cradle: 81.15 x 75.89 x 36.36mm
Weight
Handset: 110g;
Charger cradle: 44g;
Universal power supply: 50g;
Package: 328g
Temperature and Humidity
Operation: -10º to 50ºC (14 to 122ºF); Charging: 0 to 45ºC (32 to 113ºF);
Storage: -20º to 60ºC (-4 to 140ºF); Humidity: 10% to 90% non-
condensing
Compliance
FCC: FCC Part 15B; FCC Part 15D; SAR (FCC 47 CFR Part2.1093;
IEEE 1528; IEC 62209-2); FCC Part68 HAC; FCC ID
CE：EN 55032; EN 55035; EN 61000-3-2; EN 61000-3-3; EN 60950-
1;EN 301 489-1/-6; EN 301 406; EN 50332-2;
SAR(EN50360;EN50566;EN 50663;EN62209-1; EN62209-2; EN
62479); RED NB Cert
RCM：AS/NZS CISPR32; AS/NZS 60950.1;AS/CA S004;AS/ACIF
S040. ANATEL, EAC, UL(adapter).
DP755
●1 Base unit
●1 Universal power supply 5V
●1 Bracket
●1 Ethernet cable
●1 Quick Installation Guide

Equipment Packaging – DP755
DP755 Package Content
DP730
Equipment Packaging – DP730
DP730 Package Content
DP722
DP730
●1 Handset unit
●1 Universal power supply 5V
●1 Charging station
●1 Handset Belt
●1 Rechargeable Li-ion battery
●1 Quick Installation Guide
DP722
●1 Handset unit
●1 Universal power supply 5V
●1 Charging station
●1 Handset Belt
●2 Rechargeable batteries
●1 Quick Installation Guide

DP722 Package Content
Connecting DP755
To set up the DP755 DECT Cordless VoIP Base Station, please follow the steps below:
DP755 Back View
You have two options for power and network connection of the base station: AC power or Power over Ethernet (PoE).
Connecting via AC power
1. Connect the micro-USB connector into the related port on the base station and connect the other end of the power
adapter into an electrical power outlet.
2. Connect the supplied Ethernet cable between the Internet port on the base station and the Internet port in your network
or the switch/hub device port.
Connecting via PoE
To connect the base station using PoE, you need to connect the Ethernet cable provided (or 3rd party network cable) between
the Network Socket on the base station to Ethernet port of your PoE switch/hub.
Setting up DP730/DP722 Handsets
Please follow below steps to insert batteries into the Handsets:
Open the battery compartment cover.
For DP730: Inset Li-ion battery with the electrodes in the bottom left corner.
For DP722: Insert AAA batteries with correct polarity (+ / -).
Close the battery compartment cover.
Note
Check the package before installation. If you find anything missing, contact your system administrator.
Note
For better signal range, we recommend installing DP755 with LED side facing toward the usage area. Ceiling mount is
recommended for better coverage.

Setting up the DP730/DP722
Battery Information
DP722 Batteries Specifications DP730 battery specifications
Technology: Nickel Metal Hydride (Ni-MH)
Size: AAA
Voltage: 1.2V
Capacity: 800mAh
Charging time: 12 hours from empty to full
Standby time: up to 250 hours
Talk time: up to 20 hours’ active talk time
Technology: Li-ion
Nominal Voltage: 3.8V
Capacity: 1500mAh
Charging time: 12 hours from empty to full
Standby time: up to 500 hours
Talk time: up to 40 hours’ active talk time
Table 10: DP722/DP730 Battery Specifications
In order to get the best performance of your DP730/DP722 Handsets, we recommend using original batteries provided in the
package or batteries compliant with above specifications.
Setting up the Charge Station
Please refer to the following steps for setting up the charge station and charging the Handsets:
1. Connect the DC plug on the power adapter to the micro-USB connector on the charge station.
2. Connect the other end of the power adapter into an electrical power outlet.
3. After setting up the Handsets and the charge station, place the Handsets in the charge station.
Note
Please charge the batteries fully before using the Handsets for the first time.
Disclaimer
The abovementioned battery specifications can vary and depend on many factors (age of the battery, number of recharge
cycles, real capacity…). The recharge cycles of the battery are limited; thus, it might need to be replaced if the battery
performance is low. The number of charge cycles and battery life are affected by usage and configuration.
Important Note
Be careful when inserting the batteries into your handset to avoid any risk of short-circuit, which lead to damage your batteries
and/or the handset itself. Do not use damaged batteries which can increase the risk of serious harm.

Setting up Charging Stations
DP755 LED Patterns
The DP755 has 3 LED lights on it. Please refer to the following table for the meaning of each light.
DP755 LED Patterns
LED Light Status
Indicates Power ON/OFF.
Indicates status of SIP account registration and network
Solid ON: SIP account registered.
Blinking: SIP account not registered or network error
Indicates status of the DECT handset registration:
Solid ON: Handset registered to base.
Fast Blinking (0.25s ON/0.25s OFF): Paging handset.
Blinking (0.5s ON/0.5s OFF): Pairing mode.
Table 11: DP755 LED Patterns
DP730/DP722 Handsets Description
The LCD screen and the Keypad are the main hardware components of the DP730/DP722.
Key Description
1. Earphone Delivers audio output.
2. LED Indication
Red: Charging. Green: Charge completed.
Blinking: Missed call(s) or Voice Mail received.
3,
5
Left and right
softkeys
Correspond to functions displayed on the LCD. These functions change depending on the
current context.

4. LCD display Shows call information, handset status icons, prompt messages, etc.
6. 4 Arrow key
combination Permits navigation of the cursor through the displayed menu options.
7. Men/Ok key Selects the option chosen by the cursor. (Enters the main menu from the home screen.)
8. Off-hook / Dial key Enters dialing mode, or dials number entered.
9. On-hook / Power
key Terminates calls, or turns the handset on / off.
10
.
Alphanumeric
Keypad
Provides the digits, letters, and special characters in context-sensitive applications. For + sign,
press and hold key 0.
11
.# / Lock key
Locks keypad against unintentional entries when keep pressing #.
Press and hold # key for approximately 2 seconds to lock the keys.
Press Unlock softkey and then # to unlock the keys.
12
.Mute key Activates or deactivates the mute feature.
13
.
Hands-free /
Speaker key Switches between handset and hands-free / speaker modes.
14
.Microphone Picks up audio earpiece and hands-free calls.
Table 12: Keypad Keys Description
Figure 9: DP730 Keys Description
Key Description
1. Proximity sensor The proximity senor can detect and measure gravitational acceleration, tilt,
vibration, altitude changes, and static position.

2. Earphone Delivers audio output.
3,
4Volume up / Down Keys Configure the handset and ringtone volume.
5. PTT Key PTT (Push-to-Talk) button, to initiate PTT call.
6. Hands-free / Speaker key Switches between Handset and Hands-free / Speaker modes.
7. Arrow key combination (Up,
Down, Left, Right) Allows navigation of the cursor through the displayed menu options.
8. Off-hook / Dial key Enters dialing mode, or dials number entered.
9. Alphanumeric Keypad Provides the digits, letters, and special characters in context-sensitive applications.
For + sign, press and hold key 0.
1
0. * / Silent Mode key Activates or deactivates the silent mode (no ringtone heard during incoming call) when keep pressing on * in idle screen.
1
1. LED indicator 1dual-color LED indicator indicating power, call, battery, message waiting…
1
2. 3.5 mm headset jack Phone connector for the headphones/headsets.
1
3. Color LCD Screen 2.4-inch (240×320) TFT color LCD
1
4. Softkeys Correspond to functions displayed on the LCD. These functions change depending on the current context.
1
5. Mute Mute microphone during conversation.
1
6. Menu/OK key Selects the option chosen by the cursor or enters the main menu from the home screen.
1
7. On-hook or Power key Terminates calls or turns the handset on / off.
1
8. # / Lock key
Locks keypad against unintentional entries when keep pressing #.
Press and hold # key for approximately 2 seconds to lock the keys.
Press Unlock softkey and then # to unlock the keys.
1
9. Microphone Picks up audio earpiece and hands-free calls.
Table 13: Keypad Keys Description
DP730/DP722 Icons Description
The following table contains description of each icon that might be displayed on the LCD screen of the DP730/DP722
Handsets.

Battery status
Not equipped with battery
Battery status
Battery empty
Battery status
Battery low
Battery status
Battery normal
Battery status
Battery full
Battery status
Charging
Signal status
Not subscribed
Signal status
Not in range
Signal status
Signal very low
Signal status
Signal low
Signal status
Signal normal
Signal status
Signal good
Signal status
Signal very good
Microphone MUTE Status
OFF – Not muted
ON – Muted

Speaker status
OFF – Speaker is inactivated
ON – Speaker is activated
Headset icon
Missed Call icon
Voicemail icon
Ringtone status
OFF – Ringtone off (Silent mode)
ON – Ringtone on
Keypad Lock status
OFF – Keypad unlock
ON – Keypad locked
DND Status.
OFF – Do Not Disturb disabled
ON – Do Not Disturb enabled
Call forward
Call waiting
Information
Account not registered
Account Registered
Error message
Handset number
Incoming Call notification
Outgoing Call notification
Missed Call notification
Voicemail notification

Contacts
Call History
Registration
Voice Mail
Preferences
Shortcut
Call Features
Status
Settings
DP730/DP722 Icons Description
DP730/DP722 Handsets Menu
The Handsets has an easy-to-use menu structure. Every menu opens a list of options. To open the main menu, press “Menu”
(left softkey) when the Handsets is on and in standby mode. Press Arrow keys to navigate to the menu option you require.
Then press “Select” (left softkey) or OK/Selection key to access further options or confirm the setting displayed. To go to the
previous menu item, press “Back” (right softkey). You can press Power key at any time to cancel and return to standby mode.
If you do not press any key, the Handsets automatically reverts to standby mode after 20 seconds.
Note
Users can navigate by through handset menu by pressing menu number when displayed.

DP730/DP722 Menu Structure
Contacts
●Private: Private contacts include contacts visible in the current Handsets
only.
●Global: Global phonebook contacts are the contacts shared between the
Handsets subscribed to the DP755 base station.
Note: Private/Global Phonebooks will be merged on the handset.
Call History
Display the call history:
1. Missed Calls.
2. Accepted Calls.
3. Outgoing Calls.
4. All Calls.
Note: You can add contacts to Shared Contacts directly from call logs.
Registration
●Register: Register your handset to base station.
●Deregister: Deregister your handset from base station.
●Select Base: Select base station.
Voice Mail
●Play Message: Play voice mail messages received.
●Set Voice Mail: Configure voice mail parameters.
●Set Key 1: Configure Key 1 as VM speed dial for selected account.
Preferences
●Outgoing Default Line: Select account to be use by default for outgoing
calls.
●Auto Answer: Enable/Disable Auto Answer. (Default is Disabled).

●Off-Cradle Pickup: Enable/Disable Off-Cradle Pickup. If enabled, users
can answer the calls by picking up the handset off-cradle. (Default is
Disabled).
●On-Cradle Hangup: Enable/Disable On-Cradle Hangup. If enabled,
users can end the call by placing the handset on-cradle. (Default is
Disabled).
●Mute as DND: Enable/Disable Mute as DND. If enabled, pressing mute
key on idle state will set the phone to DND mode. (Default is Enabled)
●Disable Busy Tone: Enable/Disable Busy Tone. If set to enabled, busy
tone will not be played. (Default is Disabled).
●Disable CW Tone: Enable/Disable CW Tone. If set to enabled, Call
Waiting Tone will not be played. (Default is Disabled).
●Onhook Backlight: Enable/Disable Onhook Backlight. If enabled,
pressing "Hangup" key on idle screen will switch off LCD screen.
(Default is Disabled)
●Cradle Backlight: Enable/Disable/Dim Cradle Backlight. If enabled,
LCD will remain backlit when the handset is placed on-cradle/charging.
If set to “Dim”, LCD brightness will be reduced when the handset is
placed on-cradle/charging. (Default is Disabled)
●SIP Account Display: Select which SIP Account information will be
displayed on the screen.
●Name Only: Display SIP Account Name only. (Default)
●ID Only: Display SIP User ID only.
●None: No account information will be displayed.
●PTT (Push To Talk): Enable/Disable Push To Talk. If set to enabled,
pressing and hold PTT hard/soft key, a PTT call will be initiated.
Pressing the PTT hard/soft key, it will redirect you to the setting to
enable or disable it. (Default is Disabled)
Customizing
keys functions
Customizing keys functions:
●L : Configure Left Softkey function in idle. Function can be set as Menu,
History, Contacts, Line or PTT. Default is Menu.
●R : Configure Right Softkey function. Function can be set as History,
Contacts, Line or PTT Default is Contacts.
●⯅ : Configure Arrow UP Key function. Default is Outgoing Calls (Call
History).
●⯆ : Configure Arrow DOWN key function. Default is Accepted Calls
(Call History).
●⯇ : Configure Arrow LEFT key function. Default is Ringer Volume
Down.
●⯈ : Configure Arrow RIGHT key function. Default is Ringer Volume Up.
Select key and press OK button to configure function. Following functions
are available for arrow keys: 1. Disabled, 2. Missed Calls, 3: Accepted Calls,
4: Outgoing Calls, 5: History, 6: Contacts, 7: Status, 8: Line, 9: Voice Mail,
10: Ringer Volume Up, 11: Ringer Volume Down, 12: Audio Volume Up, 13:
Audio Volume Down, 14: Intercom.
●Speed Dial: Assign contact numbers as speed dial.
Select a key [2], [3], [4], [5], [6], [7], [8] or [9] and press OK button. Select
“Edit” to manually specify the destination number or select “From Contacts”
to select a contact as speed dial destination.
Call Features
●Do Not Disturb: Enable/disable do not disturb mode on the phone.
●Call Forward: Configure call forward feature.
●Call Waiting: Configure call waiting feature.
●Paging: Configures Inter-Handsets paging feature.
Status
●Base Status: Display Base status (Firmware, IP address, Subnet mask,
Gateway, MAC Address)
●Handset Statut: Display Handsets status (Model RF, Firmware, IPEI)
●Line Status: Display Line status (Account name, Status)

DP730/DP722 Menu Structure Definitions
BASIC OPERATIONS
Turning the Handsets ON / OFF
To turn ON the handsets
Long press on Power key until the LCD screen lights up.
To turn OFF the handsets
Long press on Power key again when the handsets is idle until the display turns off.
Settings
●Handset Name: Change the Handset name.
●Phone Language: Select the language to be displayed on the phone’s
LCD. (Default is English.)
●Date/Time: Configure date and time on the Handsets.
●Audio: Specify ringtones for internal/external calls, the volume, advisory
tones (Keypad, Confirmation, Low battery notifications) and Vibration
mode (DP730 only).
●Display: Configure backlight, LCD timeout (Idle/Call), LCD brightness,
Message Waiting Prompt and menu key timeout.
●Gestures (DP730 only): Configure Close-to-Ear Backlight and
Facedown Hangup.
●Network Settings: Configure IP addresses and select DHCP/Static IP
mode.
●SIP Settings: Configure/View SIP accounts settings.
●System Settings: Change Base PIN code, perform factory reset, reboot
base and configure repeater mode.
●Firmware Upgrade: Upgrade the firmware version of the Handsets.
●Factory Functions: Diagnostic Mode (DP722) / Keypad Diagnostic
(DP730)
All LEDs will light up, and the LCD will display a table listing the names of
all keys in red. Press any key to diagnose; the key’s name will display in
blue. After all keys are diagnosed, a prompt message (“PASS”) will display;
press “Back” (right softkey) to exit.
Note: User can long press arrow UP key to exit at any time.
●Audio Loopback: Speak to the phone using speaker/Handsets/headset. If
you can hear your voice, your audio is working fine. Press “Exit”
softkey to exit audio loopback mode.
●LCD ON / OFF: Select this option to turn off LCD. Press any button to
turn on LCD.
●LCD Diagnostic: Select this option to enter LCD Diagnostic mode. Press
“Next” (left softkey) to display white screen. Continue pressing the left
softkey to view all remaining screens (black, blue, red, and green) and
then exit. End the test early by pressing the right softkey.
●LED Diagnostic: Enters this option and press “1” to start LED
Diagnostic (you will notice that the color of the LED will be changing).
Press “2” to quit.
●System Monitoring: Displays RSSI, battery voltage and RPN
information.
●Vibration (DP730 only): Test vibration on DP730.
●Acceleration Sensor (DP730): Displays X, Y, Z coordinates.
●Proximity Sensor (DP730): Test proximity sensor on DP730.

Setup Wizard
Setup wizard shows at first access to DP722/DP730 or factory reset allowing users to configure handsets language and
date/time. Users can quit at any time by pressing “Skip” (left softkey).
Register DP730/DP722 Handsets to DP755 Base Station
1. On DP755 Base station, press and hold the Radio/Page button for 4 seconds until the Radio icon starts
blinking to start Subscription process. Or Access web UI, and press Subscribe icon to Open Subscription.
2. On DP730/DP722, press “Subscribe” softkey if available on the main screen or access Menu 🡪 Registration 🡪
Registerwhile the DP755 Radio icon is blinking.
Note: “Subscribe” softkey appears only if DP730/DP722 is not registered to any DP755 base station.
3. Select BaseX (X=1-4) corresponding to the desired base station DP755, then press Subscribe.
4. The DP730/DP722 will search for nearby base stations and will display the RFPI code and Base station name of the
discovered DP755.
5. Press Subscribe to pair with the displayed DP755.
6. The DP730/DP722 will display Easy Pairing on the LCD and play an audible buzz when successful. Then it will return to
the home screen, displaying the Handsets name and number assigned by the registered base station.
Registration Process
Using DP730/DP722 with Multiple DP755 Base Stations
DP730/DP722 is able to be registered to up four different DP755 base stations.
Registering DP730/DP722 to an additional DP755 base station
Considering DP730/DP722 is previously registered to an initial base station, please follow below steps to register a Handset to
an additional base station:
1. Press Menu (left softkey or the selection key) to bring up operation menu.
2. Use arrow keys to reach Registration and select Register.
3. Navigate to an unsubscribed base using arrow keys, and click on Subscribe.
4. Make sure that the subscription is opened on the new base station.
