200 Watt Off-Grid Charging Kit
(GS-200-KIT)
Quick Connect Guide
IMPORTANT: Please read GS-PWM-COMET-40 charge
controller owner’s manual and GS-STAR-100W connection
guide (included with products) before assembling kit.
For additional information about Grape Solar products:
email [e-mail], or
call 1-877-264-1014 for live telephone support.
GS-200-KIT PHOTOVOLTAIC
POWER GENERATION SYSTEM
QUICK CONNECT GUIDE Rev. 190316
1Check your order to make sure that all parts are included:
 GS-PWM-Comet 40 Charge Controller
 2x 10-Amp MC4 In-Line Fuse
 MC4 Branch Connector Set
 5-Foot Ring-lug Cable, Red
 5-Foot Ring-lug Cable, Black
 15-foot MC4 Cable
 2x GS- STAR-100W Solar Panel
Additional tools and equipment you will need:
◦Screwdriver– Philips Head ◦Wire Stripper/Cutter
◦12-Volt Deep-Cycle Battery Bank ◦Voltmeter (for Troubleshooting)

x2

[diagrams not to scale]


x2
To estimate how much average monthly
power this system should produce in your
area, please use the PV Watts Calculator
found at:
https://pvwatts.nrel.gov/
This System Size= 0.2 kW DC
(only applicable for zip codes in the U.S.A.)


www.GrapeSolar.com
Tel. [phone] (toll free), 1-541-349-9000
Document Version 20190316
©Copyright 2019, Grape Solar, Inc. All Rights Reserved
GS-200-KIT PHOTOVOLTAIC
POWER GENERATION SYSTEM
QUICK CONNECT GUIDE Rev. 190316
4Using wire cutters, snip the 10-gauge, 15ft.
MC4 extension cable  into two equal halves
(7.5ft each.) On the cut ends, strip off ¼-inch of
insulation, revealing bare wire.
Connect the single-input side of each Branch Con-
nector  to the compatible MC4 ends of the halved
cable . On the branch connector of the “female”
MC4 ends, connect both MC4 In-line Fuses .
5

Mount the 100-watt solar panels  so that they are facing due South at approximately the same angle as your
latitude. The ideal area has full sun and no shading. If the following connections are made during daylight, cover
the panels with cardboard, cloth, or a similar opaque material so that the panel does not output power.
Connect the bare wire end of the red battery cable  to
the “+ BATTERY” terminal on the bottom of the
Comet40 charge controller . Connect the bare wire
end of the 5-foot black cable  to the “- BATTERY”
terminal. A Phillips head screwdriver can be used to
loosen and tighten the screw clamps onto the wires.
Attach the ring lug end of the red cable  to the positive
terminal of a 12V deep cycle battery. Attach the ring lug
end of the black cables  to the negative terminal of the
battery.
The charge controller  display screen will be visible if
the battery has sufficient charge. If the display screen is
not visible, the battery must be charged from an another
source. The charge controller, which regulates solar
power flow to the battery, is powered by the battery.
2
3
 

*12V deep cycle battery
is not included with kit

 
“male” cable end
“female” cable end


6
GS-200-KIT PHOTOVOLTAIC
POWER GENERATION SYSTEM
QUICK CONNECT GUIDE Rev. 190316
www.GrapeSolar.com
Tel. [phone] (toll free), 1-541-349-9000
Document Version 20190316
©Copyright 2019, Grape Solar, Inc. All Rights Reserved
Connect the positive panel cables  to the “female” fuse ends  from the previous connections. (TIP: to help
distinguish the two bare wire ends, place a piece of tape on this bare wire end  deriving from this positive solar
output.)
Connect the negative panel cables  to the “male” branch connector ends  of the other MC4 cable half .
Connect the positive bare wire end  to the “+” PV input of the charge controller .
Connect the negative bare wire end  to the “-” PV input of the charge controller .
Remove the panel covering. In good sunlight, the
charge controller’s  ”BAT %” should increase to
100%. When the controller is set to “LOAD ON,”
the system will provide power through the load
control output or through the USB port.
7
8







*12V load device
is not included
with kit

