GRASS VALLEY UCP-3901 User manual

User Manual
13-03084-010-M00 AB
2020-10-27
UCP-3901
UNIFIED COMPUTE PROCESSOR FOR DENSITÉ

2
Notices
FCC Compliance
In order to comply with FCC/CFR47: Part 15 regulations, it is necessary to use high-quality,
triple-screened Media or Monitor cable assemblies with integrated ferrite suppression at
both ends.
Patent Information
This product may be protected by one or more patents.
For further information, please visit: www.grassvalley.com/patents/
Copyright and Trademark Notice
Grass Valley®, GV® and the Grass Valley logo and/or any of the Grass Valley products listed
in this document are trademarks or registered trademarks of GVBB Holdings SARL, Grass
Valley USA, LLC, or one of its affiliates or subsidiaries. All other intellectual property rights
are owned by GVBB Holdings SARL, Grass Valley USA, LLC, or one of its affiliates or
subsidiaries. All third party intellectual property rights (including logos or icons) remain the
property of their respective owners.
Copyright © 2020 - 2020 GVBB Holdings SARL and Grass Valley USA, LLC. All rights reserved.
Specifications are subject to change without notice.
Terms and Conditions
Please read the following terms and conditions carefully. By using UCP-3901
documentation, you agree to the following terms and conditions.
Grass Valley hereby grants permission and license to owners of UCP-3901 to use their
product manuals for their own internal business use. Manuals for Grass Valley products may
not be reproduced or transmitted in any form or by any means, electronic or mechanical,
including photocopying and recording, for any purpose unless specifically authorized in
writing by Grass Valley.
A Grass Valley manual may have been revised to reflect changes made to the product
during its manufacturing life. Thus, different versions of a manual may exist for any given
product. Care should be taken to ensure that one obtains the proper manual version for a
specific product serial number.
Information in this document is subject to change without notice and does not represent a
commitment on the part of Grass Valley.
Warranty information is available from the Legal Terms and Conditions section of Grass
Valley’s website (www.grassvalley.com).
Title UCP-3901 User Manual
Part Number 13-03084-010-M00 AB
Revision 2020-10-27, 12:18

3
UCP-3901
User Manual
Document History
See the Release Notes for more information about the features added to this product.
Electrostatic Discharge (ESD) Protection
Electrostatic discharge occurs when electronic components are improperly
handled and can result in intermittent failure or complete damage adversely
affecting an electrical circuit. When you remove and replace any card from a frame
always follow ESD-prevention procedures:
• Ensure that the frame is electrically connected to earth ground through the power cord
or any other means if available.
• Wear an ESD wrist strap ensuring that it makes good skin contact. Connect the
grounding clip to an unpainted surface of the chassis frame to safely ground unwanted
ESD voltages. If no wrist strap is available, ground yourself by touching the unpainted
metal part of the chassis.
• For safety, periodically check the resistance value of the antistatic strap, which should
be between 1 and 10 megohms.
• When temporarily storing a card make sure it is placed in an ESD bag.
• Cards in an earth grounded metal frame or casing do not require any special ESD
protection.
Protection contre les décharges électrostatiques (DES)
Une décharge électrostatique peut se produire lorsque des composants
électroniques ne sont pas manipulés de manière adéquate, ce qui peut entraîner
des défaillances intermittentes ou endommager irrémédiablement un circuit
électrique. Au moment de remplacer une carte dans un châssis, prenez toujours les
mesures de protection antistatique appropriées :
• Assurez-vous que le châssis est relié électriquement à la terre par le cordon
d'alimentation ou tout autre moyen disponible.
• Portez un bracelet antistatique et assurez-vous qu'il est bien en contact avec la peau.
Connectez la pince de masse à une surface non peinte du châssis pour détourner à la
terre toute tension électrostatique indésirable. En l’absence de bracelet antistatique,
déchargez l’électricité statique de votre corps en touchant une surface métallique non
peinte du châssis.
• Pour plus de sécurité, vérifiez périodiquement la valeur de résistance du bracelet
antistatique. Elle doit se situer entre 1 et 10 mégohms.
• Si vous devez mettre une carte de côté, assurez-vous de la ranger dans un sac
protecteur antistatique.
• Les cartes qui sont reliées à un châssis ou boîtier métallique mis à la terre ne
nécessitent pas de protection antistatique spéciale.
Document Number Publication Date Notes
13-03084-010-M00 AA 2020-07-08 Initial release.
13-03084-010-M00 AB 2020-10-27 Update to use Havent core version 16.0 code base. Added 50Gbps.

4
Notices
Environmental Information
European (CE) WEEE directive.
This symbol on the product(s) means that at the end of life disposal it should not be mixed
with general waste.
Visit www.grassvalley.com for recycling information.
Grass Valley believes this environmental information to be correct but cannot guarantee its
completeness or accuracy since it is based on data received from sources outside our
company. All specifications are subject to change without notice.
If you have questions about Grass Valley environmental and social involvement (WEEE,
RoHS, REACH, etc.), please contact us at [e-mail].
Laser Safety - Fiber Output SFP and QSFP Modules Warning
LASER SAFETY
The average optical output power does not exceed 0 dBm (1mW) under normal operating
conditions. Unused optical outputs should be covered to prevent direct exposure to the
laser beam.
Even though the power of these lasers is low, the beam should be treated with caution
and common sense because it is intense and concentrated. Laser radiation can cause
irreversible and permanent damage of eyesight. Please read the following guidelines
carefully:
• Make sure that a fiber is connected to the board's fiber outputs before power is
applied. If a fiber cable (e.g. patchcord) is already connected to an output, make sure
that the cable's other end is connected, too, before powering up the board.
•Do not look in the end of a fiber to see if light is coming out. The laser wavelengths
being used are totally invisible to the human eye and can cause permanent damage.
Always use optical instrumentation, such as an optical power meter, to verify light
output.

5
UCP-3901
User Manual
Safety and EMC Standards
This equipment complies with the following standards:
Safety Standards
Information Technology Equipment - Safety Part 1
EN60950-1: 2006
Safety of Information Technology Equipment Including Electrical Business Equipment.
UL1419 (4th Edition)
Standard for Safety – Professional Video and Audio equipment (UL file number E193966)
EMC Standards
This unit conforms to the following standards:
EN55032:2015 (Class A)
Electromagnetic Compatibility of multimedia equipment - Emission requirements
EN61000-3-2:2014 (Class A)
Electromagnetic Compatibility - Limits for harmonic current emissions
EN61000-3-3:2013
Electromagnetic Compatibility - Limits of voltage changes, voltage fluctuations and flicker
EN55103-2:2009 (Environment E2)
Electromagnetic Compatibility, Product family standard for audio, video, audio-visual and
entertainment lighting control apparatus for professional use. Part 2. Immunity
FCC / CFR 47:Part 15 (Class A)
Federal Communications Commission Rules Part 15, Subpart B
Caution to the user that changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
WARNING
This equipment is compliant with Class A of CISPR 32. In a residential
environment this equipment may cause radio interference.

6
Notices
EMC Performance of Cables and Connectors
Grass Valley products are designed to meet or exceed the requirements of the appropriate
European EMC standards. In order to achieve this performance in real installations it is
essential to use cables and connectors with good EMC characteristics.
All signal connections (including remote control connections) shall be made with screened
cables terminated in connectors having a metal shell. The cable screen shall have a large-
area contact with the metal shell.
SIGNAL/DATA PORTS
For unconnected signal/data ports on the unit, fit shielding covers. For example, fit EMI
blanking covers to SFP+ type ports; and fit 75 Ω RF terminators to BNC type ports.
COAXIAL CABLES
Coaxial cables connections (particularly serial digital video connections) shall be made with
high-quality double-screened coaxial cables such as Belden 8281 or BBC type PSF1/2M,
Belden 1694A (for 3Gbps), and Belden 4794A (for 12Gbps).
Note: This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is
operated in a commercial environment.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to
radio communications.
Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be
required to correct the interference at his own expense.

7
toc
Table of Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Essence Processing (EP) SDC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Multiviewer (MV) SDC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Related Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
UCP-3901 with Essence Processing SDC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
UCP-3901 Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Available Upgrade Licenses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Supported SFP28 Cartridges. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Supported Multiviewer Media Network Input Capacity . . . . . . . . . . . . . . . . . . . . 17
2 UCP-3901 Card Installation and Operation . . . . . . . . . . . . . . 19
Front Card-edge Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
SFP Socket Status Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Fiber Optic Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Getting Organized / Unpacking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Required Tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Required Material . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Installation of the Rear Connector Panel and Card. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Installation of the Optical Interface (option). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Rear Panel and Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Images of Rear Panel Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Summary of Rear Panel Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Details of rear panel connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
User Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Control options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Local control using the Densité frame control panel to set the Card’s IP Addresses . 29
Remote control using RollCall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
3 Connections and Cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Cabling Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Cabling to Support SMPTE ST 2022-7 with a UCP-3901 . . . . . . . . . . . . . . . . . . . . . . . . 34
4 Connecting to the Card’s Configuration Interface. . . . . . . . 37
Installing RollCall. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
IP Address and Network Port Usage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Connecting to the UCP-3901 Card with RollCall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
First Time Connection to the UCP-3901 Card with RollCall . . . . . . . . . . . . . . . . . . . . . 37

8
Table of Contents
Connecting to the Multiviewer SDC with RollCall. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Firmware Upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Terminology Used with RollCall. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Navigating Pages in the RollCall Template . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Setting Values in RollCall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
5 Essence Processing SDC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Feature Summary - UCP-3901 with Essence Processing SDC . . . . . . . . . . . . . . . . . . . . . . . 45
General Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Essence Processing Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Template Pages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Information Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Selecting the Information to Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Time Sync Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Interface Status Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Histogram Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Visible Clocks Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Sender TPG (Test Pattern Generator). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Receiver TPG (Test Pattern Generator) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Counters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
FEC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
NMOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Label Patterns . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Defining a Label Pattern. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Ethernet Pages 1 and 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Ethernet 1 and 2 RTP Sender. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Ethernet 1 and 2 RTP Receiver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Ethernet RTP Receiver Video Stats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Ethernet RTP Receiver Audio Stats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Ethernet RTP Receiver Meta Stats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Link Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Configuring the Streams for use with 4K UHD Two-Sample Interleave Division . 72
Configuring the Streams for use with 4K UHD SQD . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
HDR Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Destination Timing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Audio V Fade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Audio Type Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Input Loss Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Spigot Pages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Input Spigots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Output Spigots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Logging - Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Logging Pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Logging - SDI Info . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Logging - System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Logging - Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Logging - Network - 1G. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Logging - SFP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .101

9
UCP-3901
User Manual
Logging - FPGA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .105
Logging - Spigot 1 to n . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .106
Logging - NMOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .108
Logging - Card Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .110
RollTrack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .112
Loopback Router. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .114
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .115
Ethernet Gb. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .117
Interop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .119
SFP Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .121
6 Getting Started with the Multiviewer . . . . . . . . . . . . . . . . . . 123
Multiviewer SDC Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .123
Architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .123
Multiviewer Input Scaling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .123
Grass Valley Orbit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .123
Third Party Devices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .124
Reference Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .124
Video Wall Design. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .124
Orbit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .125
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .125
Orbit Projects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .125
Project Names . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .125
Opening an Orbit Multiviewer Project . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .125
Multiviewer Projects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .125
Getting Started Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .126
Getting Started Procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .126
Assumptions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .126
Default Multiviewer SDC Video Wall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .127
STEP 1: Preliminary Multiviewer SDC Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .127
STEP 1.1: Preliminaries - UCP-3901 Templates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .127
STEP 1.2: Preliminaries - Multiviewer SDC Templates . . . . . . . . . . . . . . . . . . . . . . . . .128
STEP 2: UCP-3901 Media Interface(s) Setup (Video IP Streams) . . . . . . . . . . . . . . . . . . . .129
Manual Configuration of the Media Interfaces. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .130
STEP 3: Make a Change to the Video Wall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .131
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .131
Assumptions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .131
Get Orbit Multiviewer Project from the Multiviewer SDC. . . . . . . . . . . . . . . . . . . . . .131
Quick Edit of Project . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .134
Push a Project from Orbit to a Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .137
Pull a Project into Orbit from a Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .139
Multiviewer Video Wall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .141
Basic Video Wall. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .141
TSL Support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .142
TSL Protocol Tally Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .142
Specifying Multiviewer TSL Tally Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .142
Specifying Index Parameters for each UMD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .143
UMD Properties - TSL Protocol Version 3.1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .143
UMD Properties - TSL Protocol Version 5.0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .144

10
Table of Contents
Terminology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .147
Multiviewer Terminology. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .147
IP Routing Terminology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .148
7 Multiviewer SDC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
Feature Summary - UCP-3901 with Multiviewer SDC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .151
General Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .151
Multiviewer SDC Configuration Interfaces. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .152
RollCall Templates - UCP-3901 Card Configuration on IP port 2050. . . . . . . . . . . . . . . .152
UCP-3901 Card Information Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .154
Selecting the Information to Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .154
Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .155
Time Sync Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .158
Multiviewer Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .159
Sender TPG (Test Pattern Generator). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .160
Counters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .161
FEC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .162
NMOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .162
Ethernet Pages 1 and 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .162
Ethernet 1 and 2 RTP Sender. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .163
Ethernet 1 and 2 RTP Receiver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .163
Ethernet RTP Receiver Video Stats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .163
Ethernet RTP Receiver Audio Stats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .163
Ethernet RTP Receiver Meta Stats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .163
Link Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .164
Destination Timing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .165
Audio V Fade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .165
Input Loss Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .166
Spigot Pages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .166
Spigot 1 to 4 (Multiviewer Head Outputs) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .166
Spigot 5 to 16 (Multiviewer Inputs) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .166
Logging - Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .167
Logging - SDI Info . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .167
Logging - System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .167
Logging - Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .167
Logging - Network 1G . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .167
Logging - SFP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .167
Logging - FPGA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .167
Logging - Spigot 1 to 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .168
Logging - NMOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .168
Logging - Card Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .168
RollTrack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .168
Loopback Router. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .168
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .169
Ethernet Gb. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .169
Interop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .169
SFP Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .169
HDR Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .170
RollCall Templates - Multiviewer SDC Configuration on IP port 2051 . . . . . . . . . . . . . .171

11
UCP-3901
User Manual
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .171
RollCall templates for the Multiviewer SDC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .171
Multiviewer SDC System Information Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .172
System - Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .173
Carrying Out a System Reset. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .175
About the RollCall Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .175
About the RollCall Domain ID. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .175
Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .176
TSL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .179
Timer Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .181
Timer Request Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .182
8 Maintenance & Troubleshooting . . . . . . . . . . . . . . . . . . . . . . 183
Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .183
Saving and Restoring an UCP-3901’s Configuration . . . . . . . . . . . . . . . . . . . . . . . . . .183
Upgrading the UCP-3901’s SDC Application. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .183
Installing a License into an UCP-3901 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .188
Loading (Selecting) Software Version on the UCP-3901 . . . . . . . . . . . . . . . . . . . . . . .189
Field Repairs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .192
Field Replaceable Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .192
Replacing Cards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .192
Replacing a rear panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .192
Removing a card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .193
Installing a Card. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .193
Cooling Fan Operational Assessment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .193
Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .193
Critical Temperature Alarm Corrective Actions . . . . . . . . . . . . . . . . . . . . . . . . . . .194
Fan Noise. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .194
Fan Alarm and Fan Noise Corrective Actions . . . . . . . . . . . . . . . . . . . . . . . . . . . . .194
Replacing the UCP-3901’s Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .195
Fan Replacement Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .195
Required Tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .195
Cooling Fan Replacement Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .195
To remove a fan. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .195
To install the new fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .197
Replacing the Micro-SD Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .197
Tools Required. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .198
Replacing the UCP-3901’s Micro-SD Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .198
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .198
Testing if Network Redundancy (SMPTE ST 2022-7) is Working. . . . . . . . . . . . . . . .200
Keep Fiber Connections Clean . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .200
9 Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 203
Essence Processing (EP) Inputs/Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .203
EP SDC Signal Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .203
EP SDC Signal Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .203
Multiviewer (MV) Inputs/Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .204
Multiviewer SDC IP Video Inputs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .204

12
Table of Contents
Multiviewer SDC Multiviewer IP Head Display Outputs . . . . . . . . . . . . . . . . . . .204
Multiviewer SDC Multiviewer SDI Head Display Outputs. . . . . . . . . . . . . . . . . .204
Ethernet Management Port. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .204
Essence Processing (EP) Ethernet Media Ports SFP1 & SFP2 . . . . . . . . . . . . . . . . . . . . . . .205
Multiviewer (MV) Ethernet Media Ports SFP1 & SFP2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .205
RollCall Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .206
Communication. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .206
Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .206
Power Consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .206
Appendix A Installing the SFP Ethernet Module . . . . . . . . . . . 207
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .207
Installing an SFP module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .207
Connecting the fiber optic cables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .208
Removing the fiber optic cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .208
Removing the SFP module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .208
Contact Us . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 210

13
1
Introduction
The UCP-3901 provides a hardware platform which can offer different functionality
depending on the software option loaded. These options are known as Software-Defined
Cores (SDCs), and can be purchased through a licensing mechanism and loaded as
operational needs demand.
UCP-3901 modules are also fully compatible with Grass Valley’s broadcast-centric IP routing
and network management solution, designed to migrate broadcasters from a traditional
baseband routing and control environment to new Hybrid SDI and IP work-flows.
The UCP-3901 currently supports on 25G or 50G networks:
• The Essence Processing (EP) SDC.
• The Multiviewer (MV) SDC.
• NMOS IS-04 discovery and registration with group hint tag support.
• NMOS IS-05 device connection management.
• In-band or out-of-band control of NMOS.
Essence Processing (EP) SDC
For SDI to IP gateway type applications. See Essence Processing SDC on page 45 for
information on how to configure this option.
• SDI IP Encapsulation and De-encapsulation:
• For 12G.
• SMPTE ST 2022-6, ST 2022-7, AES67 & ST 2110-20/30/40.
• Frame synchronizer.
• Audio sample rate conversion, shuffling & delay.
• Audio embedding and de-embedding.
Multiviewer (MV) SDC
The multiviewer comprises an advanced multiviewer for monitoring applications. It has 12
video inputs and up to 4 multiviewer head display outputs. Multiviewer video wall layouts
are designed using the Grass Valley Orbit software tool. The multiviewer SDC requires the
multiviewer license.
• Flexible configurations – 12 x 1 UHD (quad link) or 12 x 4 (3G).
• IP inputs.
• IP outputs and SDI HD-BNC copy outputs.
• Audio metering support.
• UMD and Tally support.

14
Introduction
Related Documentation
• Clocks and Timers.
See Multiviewer SDC on page 151 for information on how to configure this option.
Fig. 1-1: UCP-3901 Card and Multiviewer SDC
Related Documentation
The following related documentation is available. You can obtain the latest product
documentation from the Documentation Library section of Grass Valley’s website.
UCP-3901 Card with MV SDC + Rear
Document Number
Software Defined Core
TitleMultiviewer
Essence
Processing
3084-2927-001 AA   UCP-3901 User Manual (this document)
3084-2928-001 AA   UCP-3901 Release Notes
-  RollCall V4 Suite & RollCall Lite Installation Guide
-  RollCall Control Panel User Manual
-  RollMechanic Operator’s Manual
13-03082-030 GV Orbit Client Quick Start Guide: A general introduction to GV
Orbit and its applications.
-Orbit for Multiviewers: Describes multiviewer-specific details of
Orbit.
-Orbit for IP Routing: Describes the IP Routing configuration with
Orbit.

15
UCP-3901
User Manual
Block Diagram
These are the features supported in the initial release and do not necessarily represent all
hardware connectors available.
UCP-3901 with Essence Processing SDC
Figure 1 - 2: UCP-3901 Universal Compute Processor Functional Block Diagram
UCP-3901 Ordering Information
Available Upgrade Licenses
The following Software-Defined Core license is available.
Order Code
Selection Description
Cards:
UCP-3901-25G Unified Compute Processor with a 25 GB/s network interface.
UCP-3901-50G Unified Compute Processor with a 50 GB/s network interface.
Rear Panels:
UCP-3901-3+DRP Double rear panel for Densité 3+ with HD-BNC.
See Rear Panel and Connectors on page 24.

16
Introduction
Supported SFP28 Cartridges
See Installing a License into an UCP-3901 on page 188 to install a license.
Supported SFP28 Cartridges
Up to four SFP28 cartridges are required (extra). These are shipped as a separate order. To
support 50G bandwidth requires 4 × 25G SFPs.
Software
Upgrade
Selection
For use with
card Description
UCP-3901-25G-EP UCP-3901-25G Essence Processing Software-Defined Core license
with 25G network support.
UCP-3901-50G-EP UCP-3901-50G Essence Processing Software-Defined Core license
with 50G network support.
UCP-3901-25G-
MW
UCP-3901-25G 12 × 4 multiviewer license with 25G network
support.
UCP-3901-50G-
MW
UCP-3901-50G 12 × 4 multiviewer license with 50G network
support.
SFP Model
Selection Description
SFP-ETH10G-RT-
M85-LC
Short range optical 10GBase Ethernet SFP cartridge with LC/PC fiber
connector:
• <300m link with OM3 MMF.
• <82m link with OM2 MMF.
• <33m link with OM1 MMF.
850 nm multi-mode optical transceiver that supports signals up to
10.5 Gb/s for bidirectional serial data communications such as
10GBASE-SR and 10GBASE-SW.
SFP-ETH10G-RT-
S13-LC
Long range optical 10GBase Ethernet SFP cartridge with LC/PC fiber
connector (<10 000m):
1310 nm single mode optical transceiver that supports signals up to
10.5 Gb/s for bidirectional serial data communications such as
10GBASE-LR and 10GBASE-LW.
SFP-25-SR Short range SFP28 25GBASE Optical Transceiver MMF cartridge
(<300m).
SFP-25-LR Long range SFP28 25GBASE Optical Transceiver SMF cartridge
(<10 000m).

17
UCP-3901
User Manual
Supported Multiviewer Media Network Input Capacity
The number of supported input streams to a multiviewer depends on SFP cartridge
capacity, the resolution of the input streams, and whether redundancy is required.
Video Input
Resolution
Number of Multiviewer Video IP Inputs
on Media Network Connection
No network redundancy Network redundancy
1x 25G 2x 25G 2x 50G 25G + 25G 50G + 50G
1080i50/59.94 12 12 12 12 12
720p50/59.94 12 12 12 12 12
1080p50/59.94 8 12 12 8 8

18
Introduction
Supported SFP28 Cartridges

19
2
UCP-3901 Card Installation and Operation
Front Card-edge Interface
Figure 2 - 1: Front card-edge layout
Status LEDs are located on the front card-edge of the UCP-3901 Card. The Densité LED is
visible through the front access door of the Densité frame. The remaining LEDs are unlit
until the SELECT button is pressed. These multi-color LEDs indicate the status of the
UCP-3901 Card by color, and by flashing/steady illumination.
Ejector Tab
SELECT Button
USB (unused)
Densité LED
UCP-3901 Card Right SideUCP-3901 Card Left Side
DIAG
SDI IN 9 SDI IN 1
SDI IN 10 SDI IN 2
SDI IN 11 SDI IN 3
SDI IN 12 SDI IN 4
BOARD
SDI IN 13 SDI IN 5
PTP
SDI IN 14 SDI IN 6
CPU
SDI IN 15 SDI IN 7
REF
SDI IN 16 SDI IN 8
STATUS LEDs
SFP 4
SFP 3
SFP 2
SFP 1
STATUS
LEDs
STATUS
LEDs
Ident Button
Reset Button

20
UCP-3901 Card Installation and Operation
Front Card-edge Interface
Item Description
Ident Button Push to:
• Make the card’s SDI IN LEDs flash.
• Activate the Configuration > Location > Where Am I checkbox in
RollCall.
This works bi-directionally between the card and the RollCall setting.
See also Configuration, on page 48 for more information about the
Where Am I checkbox.
Ejector Tab Lift the bottom edge of the ejector tab to lever and remove the card
out of the frame. See Installation of the Rear Connector Panel and
Card, on page 23.
SDI IN 1 to SDI IN
16 status LEDs
As an input, this shows the following port status:
•Green: Signal is detected.
•Yellow: Test pattern generator has been activated.
•Red: Signal loss.
• Off: Input/Spigot not in use.
As an output, this shows the following port status:
•Green: Valid flow is detected.
•Yellow: Test pattern generator has been activated.
•Red: Flow is not found or invalid.
• Off: Output/Spigot not in use.
See also Spigot Pages, on page 80 and Logging - SDI Info, on page 89
for more information.
SFP 1 to SFP 4
status LEDs
Shows the SFP 1, 2, 3, and 4 link status:
•Blue: Link OK (25G/50G/100G SFP).
•Blue flashing: SFP detected, link down (fiber not connected,
different FEC selection from host).
•Unlit: SFP not detected.
See also Ethernet Pages 1 and 2, on page 62 and Logging - Network,
on page 96 for more information.
DIAG status LED Shows the following states:
•Green: PTP-LOCK OK.
•Off: PTP-LOCK Fail.
See also Time Sync Configuration, on page 50 and Logging - System,
on page 91 for more information.
BOARD status LED Shows the following states:
•Green: PTP-SYNC OK. PTP being used and clocks are within the
accepted range.
•Off: PTP-SYNC Fail. PTP being used but clocks haven't
synchronized within +/- 1mS.
PTP status LED Future use.
