GRASS SENSOMATIC User manual

118857 – 06/20 – GRASS Advertising Subject to changes, no liability for typographic or printing errors
GRASS GmbH
Movement Systems
Grass Platz 1
A 6973 Höchst, Austria
Phone [phone]
Fax [phone]
E-mail [email protected]
Technical support
Movement Systems
Michael Orschulik
Tel. [phone]
[e-mail]
Business hours (CET):
Monday - Thursday 8am to 12 noon and 1pm to 4.30pm
Friday 8am - 12 noon
GRASS MOVEMENT-SYSTEMS
SENSOMATIC OPENING SYSTEM
Assembly and operating instructions
SENSOMATIC OPENING SYSTEM
www.grass.eu

21
SENSOMATIC
SENSOMATIC
Assembly and operating instructions
Translation of the original operating instructions

22
SENSOMATIC
Translation of the original operating instructions
1.0 Introduction ..............................................................................................................................23
1.1 Instructions for installers ............................................................................................................................. 23
1.2 Signs and symbols in this instruction manual.............................................................................................. 23
1.3 Designated purpose ..................................................................................................................................... 23
2.0 Safety instructions...................................................................................................................24
2.1 General information ..................................................................................................................................... 24
2.2 Safety instructions for assembly ................................................................................................................. 24
2.3 General safety instructions ......................................................................................................................... 25
2.4 Repairs and modifications .......................................................................................................................... 26
3.0 Functional description.............................................................................................................26
4.0 System overview ......................................................................................................................27
5.0 Initial start up ...........................................................................................................................28
5.1 Synchronisation of drive units by means of a synchronisation cable ......................................................... 28
5.2 Disassembly ................................................................................................................................................ 29
5.3 Disassembly of synchronisation cable ........................................................................................................ 29
6.0 Troubleshooting .......................................................................................................................30
7.0 Maintenance and care instructions .......................................................................................32
7.1 Maintenance ................................................................................................................................................ 32
7.2 Care instructions ........................................................................................................................................ 32
8.0 Exchange/disassembly of the drive unit .............................................................................33
8.1 Dismounting the opening unit...................................................................................................................... 33
8.2 Mounting the opening unit .......................................................................................................................... 34
9.0 Installation dimensions ...........................................................................................................35
9.1 Nova Pro installation dimensions ................................................................................................................ 35
9.2 DWD XP installation dimensions ................................................................................................................. 35
9.3 Dynapro installation dimensions ................................................................................................................. 36
10.0 Adjusting the opening force ...................................................................................................36
11.0 Technical data ..........................................................................................................................37
11.1 Power supply unit for up to 30 opening units ............................................................................................. 37
11.2 Power supply unit for 1 opening unit .......................................................................................................... 37
12.0 Disposal ....................................................................................................................................37
Table of contents

23
English
SENSOMATIC
Translation of the original operating instructions
1.0 Introduction
GRASS Sensomatic compliments furniture‘s clear lines from the inside. The electro-mechanical opening system
translates the outer beauty of furniture into the beauty of movement. Natural elegance is transformed into unique
convenience, tangible in every movement. Combining GRASS Sensomatic with any of the GRASS full-extension
slides means you will have convenient access to the full depth of the drawer. With this system, your furniture indeed
becomes exceptional.
Please read the assembly and operating instructions carefully and act accordingly. Keep these
assembly and operating instructions since you or a subsequent owner may require them later
on.
1.1 Instructions for installers
The following assembly and operating instructions contain important tips, instructions and recommendations for
assembly, initial start up and operation. Please read and adhere to the instructions to ensure safe and flawless ope-
ration of the electrically powered GRASS Sensomatic opening system.
1.2 Signs and symbols in this instruction manual
The signs and symbols in these assembly and operating instructions are intended to ensure quick and safe use of
the manual and the system.
Note
This sign indicates additional information which may be helpful when using a GRASS
Sensomatic system.
Warning of a general danger
This warning sign indicates actions which may for several reasons cause danger or impair
functionality.
Warning of hazardous voltage
This warning sign indicates actions during which you will be exposed to danger due to electric
shock possibly causing fatal injuries.
ÂAction
This symbol indicates a call for an action. This action facilitates correct and safe use of the
system.
3Result
This sign indicates the description of the result of an action.
1.3 Designated purpose
The components of the „GRASS Sensomatic“ electromechanical opening system may only be used for their inten-
ded purpose. This means that they may only be connected and operated as described in the installation and ope-
rating instructions. The Sensomatic must be mounted without connection to the power supply and installed in an
enclosed cabinet. No modifications or additions of any kind to the approved mechanical and electrical functions are
permitted, as these.

24
SENSOMATIC
Translation of the original operating instructions
2.0 Safety instructions
2.1 General information
The electro-mechanical GRASS Sensomatic drawer system is a state-of-the-art system complying with the appli-
cable EU standards and general accident prevention regulations. Certain risks, however, remain in case of non-
compliance with these operating instructions. GRASS GmbH does not accept any liability or claims under warranty
for damage or subsequent damage resulting from noncompliance with these operating instructions.
The Sensomatic drive units are subject to the regulations of the Machinery Directive 2006/42/EC (MD for short).
The Grass Sensomatic is a complete machine - see the Machinery Directive guidelines (edition 2.2.) The requi-
rements of the Machinery Directive are fulfilled by the Grass Declaration of Conformity if the Sensomatic unit is
installed in furniture in compliance with the current Grass specifications (catalogue, operating instructions, assem-
bly instructions). If the furniture deviates from these specifications, the party placing the furniture on the market
must ensure its conformity.
The scope of the Machinery Directive covers distribution within the European Economic Area (EEA), Switzerland,
Turkey and Northern Macedonia. The requirements of other countries are covered by certifications.
2.2 Safety instructions for assembly
GRASS Sensomatic opening systems may only be assembled by trained specialists with the help of these
assembly instructions.
All work must be performed whilst disconnected from the electrical supply.
Adhere to national regulations and standards when assembling Sensomatic system.
GRASS GmbH excludes all liability for unauthorised changes to GRASS Sensomatic opening systems and
any resulting damage.
GRASS GmbH provides a warranty only for the drawer and slide systems Nova Pro, DWD XP and Dynapro.
However GRASS GmbH cannot accept any liability for combinations with products of other manufacturers.
Use only genuine GRASS parts for repairs and maintenance.
The system must be connected to the power supply by a qualified electrician.
When sawing in the vicinity of GRASS Sensomatic systems, ensure that no sawdust gets into the drive unit
or into the guide rails.
It must be possible to isolate the opening system, e.g. using switchable sockets. Prior to changing the power
supply unit or the opening unit, the system must be isolated.
Do not squeeze cables or allow them to come into contact with moving parts.
The power supply unit must be easily accessible.
Ensure that no moisture can enter the power supply unit.
Do not use damaged parts.
When the power supply unit is connected, the extension arm moves to the home position.

25
English
SENSOMATIC
Translation of the original operating instructions
2.3 General safety instructions
It is generally prohibited to reach in behind the rear wall of the drawer.
Check the drawer system for visible damage.
Ensure any damage to the drawer system is repaired by an authorised expert.
Disconnect the drawer system from the power supply during longer periods of absence.
Automatically opening drawers! Risk of injury!
Do not allow children to play within the movement range of drawers.
Persons with a physical, sensory or mental impairment must not use this device.
To secure GRASS Sensomatic systems against unintended opening, isolate the power
supply unit.
Children should never be left unattended in the drawer danger zone.
Do not place any objects in the opening range of the drawers. Maintain a minimum
distance of 500 mm from stationary objects when the drawer is fully open.
Live components! Electric shock!
Disconnect the power supply unit before cleaning the drawers.
Incorrect loading, assembly or overload of drawers!
Drive fault!
Do not overload drawers (for max. loading refer to the product catalogue of the relevant
drawer system).
Do not obstruct the space between the back of the drawer and the rear wall and do not
cover the power supply unit.
Ensure that cables and the opening unit do not come into contact with moving parts.
Cables must be re-centred after processing.
Indoor use only
max.
500

26
SENSOMATIC
Translation of the original operating instructions
2.4 Repairs and modifications
Repairs and structural changes to the „GRASS Sensomatic“ opening system may only be carried out by an
authorised specialist. The declaration of conformity issued by Grass is based on a risk assessment of stan-
dard kitchen units. If furniture is not manufactured in accordance with the Grass catalogue, operating instruc-
tions and assembly instruction specifications, conformity must be certified by the party placing the furniture
on the market. This means that the furniture manufacturer is therefore obliged to prepare a risk assessment
for the installed furniture, to prepare and keep the technical documentation, to fill in and sign a declaration of
conformity, to ensure CE marking on the furniture (fill in and affix the type plate) and to forward a user manu-
al and a copy of the declaration of conformity to the customer in the customer‘s national language.
Live components!
Never open the power supply unit or an opening unit!
3.0 Functional description
A drawer can be opened by tapping or by pulling the handle (if applicable). The opening unit supports opening the
drawer as the opening lever pushes the drawer forward. When leaning against the drawer, it cannot be opened!
GRASS Sensomatic facilities a smooth and gentle action when closing the drawer.
Note: It is not permitted to install the Sensomatic in conjunction with an internal drawer
driver. When installed with an inset drawer, do not use an internal drawer driver.

27
English
SENSOMATIC
Translation of the original operating instructions
4.0 System overview
1. Drive unit 5. Connection cable
2. Opening lever 6. Power supply unit
3. Locking lever 7. Power supply cable
4. Frame cable 8. Spring-loaded front buffers
1
7
2
4
5
6
8
3

28
SENSOMATIC
Translation of the original operating instructions
5.0 Initial start up
1. Plug frame and connection cable into the power supply unit
2. Connect adjacent cabinets with the connection cables
3. Connect power supply unit to sock
5.1 Synchronisation of drive units by means of a synchronisation cable
1. Strip the synchronisation cable
2. Connect the synchronisation cable to the unit
3. Connect the drive units together
4. Connect the power supply unit to the socket
3
1
2
SYNK
1 2 3 4

29
English
SENSOMATIC
Translation of the original operating instructions
5.2 Disassembly
1. Unplug the power supply unit
2. Disconnect secondary cabinets from the connecting cable accordingly
3. Disconnect the cross bar and connection cables from the power supply unit
4. For disassembly of the drive unit see 8.1
5.3 Disassembly of synchronisation cable
1. Disconnect the power supply unit from the socket
2. Disconnect units from one another
3. Disconnect the synchronisation cable from the unit
SYNK
1 2 3
3
1
4
2

30
SENSOMATIC
Translation of the original operating instructions
6.0 Troubleshooting
The drawers can always be opened manually like conventional drawers, even when isolated.
It is often helpful to disconnect the system from the mains. Wait 10 seconds before switching the
system on again.
Fault Cause Remedy
The drawer does
not open - neit-
her by pulling
nor by pushing
The spring-loaded front buffer facilitating the
activation path
Âis missing or defective.
ÂFit the spring-loaded front buffer.Front
height up to 300 mm: 1 per side, front
height > 300 mm: 2 per side
ÂReplace the spring-loaded front buffer
Drawer is blocked, e.g. by stowed items. ÂRemove the blocking item
The drawer back is bent to the rear. ÂStraighten the back of the drawer
The opening unit is temporarily or perma-
nently de-energised or defective.
ÂCheck the LED
✓ Green: Power supply OK
a) Flashing in red:
Opening unit is temporarily out of order
b) Red: Opening unit is defective
c) No indication: Power supply is interrupted
or opening unit is defective
Âa) Wait 3 min
Âb) Switch the system on and off or
replace the opening unit (see chapter
8.0)
Âc) Slightly shift the opening unit and
mount it again, or replace it (see chap-
ter 8.0)
Cross beam cable is not mounted correctly.
The operation indicator on the power supply
unit is lit.
ÂCheck that the frame cable is correctly
fitted into the cross beam and make
any necessary corrections
The operation
indicator on the
power supply
unit is not lit.
The power cable is not correctly connected
to the power supply unit or defective.
ÂCheck that the power cable is seated
firmly, or replace it
There is no voltage present at the power
socket used.
ÂSwitch on the switchable power socket
ÂUse another power socket
The power supply unit is defective. ÂCheck the fuses
ÂReplace the power supply unit
When the drawer
is opened it
slides against
the end stop too
quickly.
Rack is not aligned horizontally. ÂAlign the rack
Switch for the opening force is not set cor-
rectly.
ÂShift the switch to the left (see chapter
10.0)
Drawer does
not open wide
enough.
Rack is not aligned horizontally. ÂAlign the rack
Switch for the opening force is not set cor-
rectly.
ÂShift the switch to the right (see chap-
ter 10.0)
Opening unit is defective. ÂReplace the opening unit (see chapter
8.0)
The drawers of
the entire cabinet
do not open
Connection cable is not plugged in or is
defective
ÂCheck that the power cable is seated
firmly, or have it replaced by an autho-
rised expert

31
English
SENSOMATIC
Translation of the original operating instructions
When contacting an authorised expert,
have the following information ready:
Part number of the power supply unit (see fig. 1 and
fig. 2)
Serial number and part number at the rear side of the
opening unit (see fig. 3)
Conditions under which the problem occurred.
Use the table to make sure that the range of required
tasks can be narrowed down and the required spare part
can be ordered
Part number F121 ...
Fig. 1: Part number
Power supply unit for
up to 30 opening units
Part number 112 ...
Part number F121 ...
Serial number SN ...
GRASS GmbH
Grass Platz 1
A-6973 Höchst
www.grass.eu
SN 91329301000 24 V 10W
F121131975
SENSOMATIC NOVA PRO/DYNAPRO
CAUTION: FOR INDOOR USE ONLY
ATTENTION:
POUR UTILIZATION À L‘INTÉRIEUR SEULEMENT
2020
2021
2022
2023
Fig. 2: Part number
Power supply unit for 1
opening unit
Fig. 3: Serial number and
part number of the opening
unit

32
SENSOMATIC
Translation of the original operating instructions
7.0 Maintenance and care instructions
7.1 Maintenance
The GRASS Sensomatic drawer system does not require maintenance.
7.2 Care instructions
Live components! Electric shock!
Defect of the opening unit
Disconnect the drawer system from the mains before cleaning the drawers!
Liquids or other substances in the power supply unit! Electric shock!
Defect in the drive
Do not pour liquids or other substances over or into the power supply unit!
If liquids or other substances penetrate the rack, immediately disconnect the
drawer system from the mains!
Liquid-free cleaning
Use a dry cloth, dry feather duster or vacuum cleaner for cleaning

33
English
SENSOMATIC
Translation of the original operating instructions
8.0 Exchange/disassembly of the drive unit
8.1 Dismounting the opening unit
Live components! Electric shock!
Disconnect the power supply unit from the mains before opening the locking lever!
12
3

34
SENSOMATIC
Translation of the original operating instructions
8.2 Mounting the opening unit
12
3 4
2. right-hand side:
clip on)
1. left-hand side: attach

35
English
SENSOMATIC
Translation of the original operating instructions
9.0 Installation dimensions
9.1 Nova Pro installation dimensions
10
52*
4-10 10
Inside cabinet height
Length of frame side= Inside cabinet height- 31
min. 50
Inside cabinet width (min. 262)
200
Ø 10
52
10
96
160
Ø 5/ 5 min.
Minimum installation depth
Depth of hole pattern
1/2 1/2
Inside cabinet width
Cable routing
9.2 DWD XP installation dimensions
Inside cabinet height
Length of frame side= Inside cabinet height- 31
Inside cabinet width (min. 262)
min. 55
5-10 10 10
min. 49
200
Ø 10
52
10
96
160
Ø 5/ 5 min.
1/2 1/2
Minimum installation depth
Depth of hole pattern
Inside cabinet width
Cable routing

36
SENSOMATIC
Translation of the original operating instructions
9.3 Dynapro installation dimensions
min. 37 15 15 15
min. 64
Length of frame side= Inside cabinet height- 31
Inside cabinet height
Inside cabinet width (min. 312)
200
(min. 88) (min. 88)
Ø 10
52
10
96
160
Ø 5/ 5 min.
1/2 1/2
Minimum installation depth
Depth of hole pattern
Inside cabinet width
Cable routing
10.0 Adjusting the opening force
Low
Medium
High

37
English
SENSOMATIC
Translation of the original operating instructions
11.0 Technical data
11.1 Power supply unit for up to 30 opening units
Scope of application Movement Systems Nova Pro, Dynapro, DWD XP
Range of application Only in dry indoor environments
Power supply unit Power supply 100 to 240 V
Mains frequency 50 to 60 Hz
Max. power output 230 W
Drive unit Supply voltage 24 V
Operating conditions Temperature
Relative humidity
0 to 50
15 to 90 %
non-condensing
11.2 Power supply unit for 1 opening unit
Scope of application Movement Systems Nova Pro, Dynapro, DWD XP
Range of application nur in trockenen, geschlossenen Räumen
Power supply unit Power supply 100 to 240 V
Mains frequency 50 to 60 Hz
Max. continuous power
rating
16 W
Drive unit Supply voltage 24 V
Operating conditions Temperature
Relative humidity
0 to 50
15 to 90 %
non-condensing
12.0 Disposal
All national and local regulations must be observed when disposing of or recycling the product
or its components! If you have any questions regarding the disposal of the product, please ask
an authorised expert.
Observe disassembly instructions for disposal.

38
SENSOMATIC
Translation of the original operating instructions
