Great Gazebo CROWN User manual

crown gazebo
assembly instructions
Gazebo Setup
1) Unfold the smaller of the two Bottom Frames into a hexagon.
2) Arrange the larger Bottom Frame around the smaller frame with snaps facing outward.
3) Join the two Bottom Frames together by inserting the pipe attached to the larger
frame into the connector attached to the smaller frame at each of the six locations labeled in
the diagram below.
4) Assemble the Top Frame as show in the digram to the right.
5) Attach the Top Frame to the Bottom Frame by lifting two of the ribs into the frame
sockets labeled . Next, insert two ribs into the sockets labeled . Finally, lift the remaining two
ribs into the frame sockets labeled .
6) Throw the Top Canopy over the assembled Top Frame and snap it to the ribs.
7) Snap the Gazebo Skirt onto the Bottom Frame, starting at one end.
8) Align counters with Velcro and press down firmly.
Please contact The Great Gazebo, Inc. with
any questions regarding the assembly or
care of your Crown Gazebo.
EMAIL » [e-mail]
PHONE » 800.962.2767 or 517.625.2011
CONTACT
Top Frame Setup
Slip top and bottom ribs together ( ),
then insert the ribs into the crown ( ).
Make sure the button comes through the
hole in the bottom rib and on the crown.
top frame
bottom frame

Gazebos are strong, sturdy, and designed to withstand windy
conditions. Stakes and tie downs or sandbags are recommended in
windy conditions. For 30+ MPH winds or wind gusts it is
recommended to remove the vinyl top & skirt.
When setting up on an uneven ground or surface make sure that all
feet are touching firmly.
Avoid setting up on muddy ground. It will stain the bottom of the
Gazebo skirt.
outdoor use
Clean with soap and water. For stronger stains use a mild abrasive
household cleaner such as Clorox Soft Scrub and wipe afterwards
with water.
Do not set items on the under counter shelf that will bulge or spill
on the skirt. Center heavy items over the cross brace. Slide the cross
brace towards the center legs for maximum support.
Counter & Shelf Care
Clean with soap and water. For stronger stains use a mild abrasive
household cleaner such as Clorox Soft Scrub and wipe afterwards
with water. Do not use dry abrasive cleaners. This will scratch the
PVC finish.
Clean any dirt build-up on the inside of the fittings and outside of
the pipe ends. This will make it easier for insertion when
assembling and removal when disassembling.
When storing gazebo frames it is best to rotate the rib sockets
upside down. This prevents dirt and/or water from collecting in
them.
PVC Frame Care
WARNING! Do not apply adhesive tape of any kind to the
surface of printed vinyl. Doing so will damage the printing
and WILL void the warranty.
When storing vinyl, make sure it is completely dry to prevent
mold and mildew.
Carefully roll top and skirt vinyl (do not wad up) to avoid creases
and wrinkles.
Avoid placing heavy items on top of vinyl. Proper care will help the
vinyl look good for years.
Clean the outside of the vinyl with soap & water. Vinyl
preservatives extend the life of the vinyl. Do not scrub printed
custom graphics.
Avoid letting the cloth backing on the vinyl get dirty or stained. If
it gets dirty, clean with warm soap and water and let it dry
thoroughly before storing.
Do not fold the frame while the skirt is still snapped on. If the vinyl
is cold it will be tight when snapping to the frame.
When unsnapping hold near the snap and pull straight. Do not yank
or pull from a distance.
Vinyl care
Store the Gazebo’s
vinyl Top Canopy
and Skirt in the
included bag.
To store the Gazebo Top Canopy: First, fold in half, as shown
below. Next, fold along the seams until you have a triangle the size
of one panel. Finally, roll the Top Canopy from edge to edge.
Storage & transport
Vinyl
Disassemble the
Gazebo Top Frame.
Place the separated
parts into the
included frame bag.
Next, disconnect the
inner and outer Gazebo
Bottom Frames and fold
each separately for
transport or storage as
shown to the right (FIG C).
Storage & transport
Frame
Lay the two included counter cases flat.
Insert the Gazebo counters, distributing
them between the two cases.
Storage & transport
Counters
Thank you for purchasing a Great Gazebo, Inc. product. We have
used the highest quality materials and manufacturing standards.
To ensure that you obtain the best possible results, please read
these instructions thoroughly and save for future reference.
Product care instructions
To store the Gazebo Skirt: While in an indoor location with a
clean, dry floor, roll the skirt on the floor with the vinyl side out
and the cloth side in (FIG. A). Otherwise, to keep the Gazebo Skirt
off of the ground,
simply roll the skirt
with the vinyl side in
as you are unsnapping
the skirt from the
bottom frame (FIG. B).
CAUTION! Do not drag
vinyl on ground. Severe
abrasion will damage
the vinyl and graphics.
FIG. A
FIG. B
FIG. C
x6
x6
x1
