Greater Goods GBF-1719-B/0383 User manual

version:1.0
User Manual
Body Fat Analyzer GBF-1719-B/0383
Please do read the user manual carefully and thoroughly so as to ensure
the safe usage of this product, and keep the manual well for further
reference in case you have problems.
Thank you very much for purchasing the DMD Body Fat Analyzer
GBF-1719-B/0383.
TEL:[phone] Website: http://greatergoods.com
Greater Goods, LLC
4427 Chouteau Ave.St.Louis,Missouri,63110,Unite States

1
Table of Contents
Table of Contents
Safety Information
Safety and Usage Information
Tips
Overview
Device Components
List
LCD Display
Initial Start-Up
Insert the Batteries
Select Measurement Unit
Initialising Your Scale
Start Measuring
Daily Measurement
Troubleshooting
Error Prompt
When Data Transmitting...
When Measuring...
Specifications
Maintenance
Maintenance
Warranty
FCC Regulations
Appendix
Health Tips – About Body Fat
Health Tips – About Body Water
Health Tips – About Muscle Mass
Health Tips – About Bone Mass
Health Tips – About BMI
Warning
2
3
4
4
5
6
6
7
9
10
10
11
12
13
13
14
15
15
15
16
16
17
...........................................................................................................................................
...............................................................................................
.................................................................................................................
..........................................................................................................................................
.................................................................................................................
.................................................................................................................
.................................................................................................................
.............................................................................................................................
....................................................................................................................
.....................................................................................................................
...............................................................................................................................
................................................................................................
.............................................................................................................
...................................................................................................
..............................................................................................................................
.................................................................................................
..............................................................................................
...................................................................................................................
................................................................................................
................................................................................................
...................................................................................................
..............................................................................................................................

2 3
Safety InformationSafety Information
INDICATIONS FOR USE
The warning signs and symbols are essential to ensure your correct and safe use of
this product and protect you and others from injury. Please kindly find the meanings of the
warning signs and symbols, which you may encounter in the label and user manual, as
follows:
Safety and Usage Information
CAUTION
Greater Goods’ Body Fat Analyzer GBF-1719-B/0383 offers you a seamless way to manage your health.
Please be aware that this device is designed for healthy population over 10 years old self-measuring
and self-monitoring body compositions. Any information provided by this device is in no way meant to
treat, cure or prevent any disease or illness from happening. If in doubt, contact your physician.
This device is contraindicated for any female subject who may be suspected of, or is pregnant.
Otherwise, the effects of this device on the fetus are unknown.
This device is contraindicated for any person who is connected to a wearable or implantable electronic
device or instrument such as a pacemaker or defibrillator.
This device should not be used for anyone who is acutely or chronically ill because of suffering from a
disease or taking medications that affect your water levels. The accuracy of readings for these patients
has not been verified. Specific medical advice should be obtained from a physician.
GBF-1719-B/0383 is equipped with data transmission function. It may emit electromagnetic energy
so as to perform its intended function. Nearby portable and mobile RF communications equipment can
affect the performance of GBF-1719-B/0383 And the device can interfere vicinity electrical equipment.
Manufacturer will make available on request circuit diagrams, component parts list,etc.
WARNING:No modifications of this equipment is allowed. This may result in increased EMISSIONS
or decreased IMMUNITY of GBF-1719-B/0383.
Please use the device according to the user manual. Any misuse can cause electric shock,burns, fire
and other unexpected hazards.
Please use and storage the device under the environment which was provided in the user manual.
Don’t expose the device to extreme temperatures, direct sunlight, moist or corrosive environment.
Do not step on the scale when your body or feet are wet, especially after bathing or showering to
prevent slipping.
Please keep the device out of reach of infants, children or pets, since inhalation or swallowing of small
parts is dangerous or even fatal.
Please don't use the device out of lifetime any more because degraded sensors and electrodes, or
loosened electrodes can degrade performance or cause other problems.
If you have an allergy to stainless steel，please avoid to contact to the electrodes of the device.
The patient is an intended operator. The patient can measure, transmit data and charge battery under
normal circumstances and maintain the device and its accessories according to the user manual.
Tips
To ensure the accuracy of measurement, please follow below instructions when
you start measurement.
Place the scale on a flat, hard surface. Soft surface such as carpet will affect the
performance of the scale.
Step onto the platform with bare feet. Stand still and keep full contact with the electrodes
until the measurement is complete.
Start measurement at least two hours after Getting up or Dinning.
Avoid measurement immediately after strenuous exercise, sauna or bath, drinking, and
dinning.
Always start measurement in the same time slot and on the same scale located on the
same flat, hard surface.
For maximum accuracy and repeatability , it is recommended that you should use the
device in the same time of the day and on the same location.
Body fat percentage estimates will vary with the amount of water in the body, and can
be affected by dehydration or over-hydration due to such factors as alcohol consumption,
menstruation, illness, intense exercise, etc.
The condition of the skin on the bottom of your feet can affect the reading. The natural
effects of aging or activity can make this skin hard. Take the reading with clean, slightly
damp feet for best accuracy. If you are having a problem on operating this scale please
contact customer service.
The Greater Goods` Body Fat Analyzer measures weight and uses bio-electrical impedance analysis
(BIA) technology to estimate calorie, BMI, body fat, total body water percentage, bone mass and
muscle mass in generally healthy children 10-17 years old and healthy adults.
It is intended for use in the domestic setting only.
Symbol for “THE OPERATION
GUIDE MUST BE READ”
Symbol for “ENVIRONMENT
PROTECTION – Waste electrical
products should not be disposed of with
household waste. Please recycle where
facilities exist. Check with your local
authority or retailer for recycling advice”
The Bluetooth Combination Mark
Symbol for “SERIAL NUMBER”
Symbol for “DIRECT CURRENT”
Symbol for “TYPE BF APPLIED
PARTS”

4
OverviewOverview
5
LCD Display
List
1. Body Fat Analyzer GBF-1719-B/0383
2. Four AAA-size Batteries (1.5V per each)
3. User Manual
Device Components
Battery Compartment
Sensor
Kilogram
Data pending to transmit to
smartphone
Pound
LCD display
Electrode
Electrode
Successful Bluetooth Connection
UNIT Button

7
Initial Start-UpInitial Start-Up
6
Insert the Batteries
Open the battery door in the back of the scale.
Remove insulating strip from beneath the battery (if
fitted) or insert batteries (3 x 1.5V AAA) observing the
polarity signs (+ and -) inside the battery compartment.
* All the digits will be shown on the LCD.
Close the battery door and wait until the digits
“0.0lb” are shown on the LCD.
CAUTION
When the symbol “Lo” appears, the device will power off in three seconds. Then you shall replace with a
new set of batteries. Please replace all three batteries at the same time. Do NOT mix the old batteries with
the new one.
Worn batteries are hazardous waste. Do NOT dispose of them together with the household garbage.
Please refer to the local ordinances and recycling instructions regarding disposal of the worn batteries.
Select Measurement Unit
With batteries correctly installed, press UNIT button in the back of the scale to select
measurement unit. The default measurement unit is “lb”. You may press UNIT button
to choose between pound and kilogram.
Install App and Pair-Up
With the advanced Bluetooth 4.0 technology applied, the mobile or portable equipments,
which are equipped with Bluetooth function in line with BLE Technical Specifications as
well as BLP Protocol established by global organization Bluetooth SIG, are capable to
receive your personal health data.
Before you use the smartphone which supports Bluetooth 4.0 technology, please turn
on the Bluetooth.
Register an account and set your personal information. Then you can pair up your scale
with your smartphone through the following steps:
A. the mobile phone is connected to the network and the bluetooth is turned on.
B. Then open the customer APP.
C. In the "TES AFP" page, click "SCAN", and then click "CET DATA" to enter the
production connection bluetooth.
D. If the device is connected by bluetooth of other mobile phones, the device needs to be
disconnected from other mobile phones to be successful in the search binding.

9
8
With original SENSE ON patent technology, the scale
will automatically switch on as you step on the platform
barefooted.
When your scale is successfully connected to your smartphone and the Bluetooth is ON,
it will process data transmission automatically.
(Please refer to Data Transmission for more details.)
Daily Measurement
Stand still and keep full contact with the scale, the weight data on the LCD will blink
twice, then the weight is locked.
Start Measuring
The symbol will disappear after successful data
transmission, and you may check your personal
health data stored in your smartphone.
If the data transmission fails, the symbol will
remain. The pending measurement data will be
temporarily kept in the scale and transmitted to your
smartphone when next measurement is complete.
Data ready to transmit to
the App:
-If SUCCEED, the symbol
disappears;
-If FAIL, the symbol
remains.
Data Transmission
Data Management
Once the Body Scale GBF-1719-B/0383 is successfully connected to your smartphone,
please open the App and turn on your Bluetooth. Keep smartphone and scale
in transmission distance. Step on the scale and take a measurement. Once the
measurement is finished the data is automatically transferred to the app.
Successful Bluetooth
Connection
CAUTION
Interference may occur in the vicinity of equipment marked with the following symbol . And
the Analyzer may interfere vicinity electrical equipment.
To enable the data transmission function, this product should be paired to a Bluetooth 4.0 end.
How to mitigate possible interference?
1. The range between the Analyzer and the Bluetooth end should be reasonably close, from 1
meter to 10 meters. Please ensure no obstacles between the Analyzer and the Bluetooth end
so as to obtain quality connection.
2. To avoid interference, other electronic devices (particularly those with Bluetooth transmission
/ Transmitter) should be kept at least 1 meter away from the Analyzer.
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN
INCORRECT TYPE DISPOSE OF USED BATTERIES
ACCORDING TO THE INSTRUCTIONS.

10 11
Stand still and keep full contact with the electrodes until the LED displays
the weight and stops blinking the unit.
Troubleshooting
Troubleshooting
Error Prompt
Error Description Solution
Overload. The device will
power off.
Stop using this scale for
measurement.
Replace all four batteries at the
same time. Please purchase the
authorized batteries for
replacement.
Stand on the scale,and
measure again.
Measurement error.
Make sure the bluetooth
connection is successful.
Data transmission failed.
Low Battery. When the
symbol “Lo” appears three
times in a row, the device will
power off in about 3s for the
fourth time.
The pending measurement
data will be temporarily kept in
the scale and transmitted to
your smartphone when the
scale is connected to the
bluetooth successfully.
Problem Root Cause Solution
Bluetooth is OFF.
Data transmission
failed.
Turn ON the Bluetooth via
Settings.
App is OFF. Press the icon to turn ON your
app.
Place your smartphone closer
to the scale.
Out of range of Bluetooth
transmission.
When Data Transmitting ...
Problem Root Cause Solution
Incorrect posture
Abnormal
measuring results:
- Too high; OR
- Too low; OR
- Huge difference
between two recent
measurement.
Please step on the platform
barefooted and stand still.
The device is located on
the soft ground such as a
carpet OR on a rugged
surface.
Please place the device on a
flat, hard surface.
Your feet are too dry.
Abnormal
measuring results:
- Too high; OR
- Too low; OR
- Huge difference
between two recent
measurement.
No display on
LCD when the
device powers on.
The device
powers off.
Wipe your feet with a damp
cloth, keeping them slightly damp
when starting measurement.
Batteries not yet installed.
Worn batteries.
Low battery.
Install the batteries.
(Please refer to Insert the
Batteries)
Replace all three batteries at the
same time. Please purchase the
authorized batteries for
replacement.
Replace all three batteries at the
same time. Please purchase the
authorized batteries for
replacement.
When Measuring ...

13
12
Specifications Maintenance
Specifications
About the Accuracy of This Product
This product passes strict inspection before delivery and therefore its accuracy is guaranteed by the manufacturer.
Please refer to the above table for the descriptions on accuracy.
This product is specially designed for body fat analysis as well as weight measurement. It should NOT be used by
anyone during the process of transaction for verification of goods’ weight.
When carrying out usual maintenance, please ensure practice of the following Do’s and
Don’ts:
Maintenance
DO use a dry soft cloth to wipe the dust.
DO use a wet soft cloth, dipped into water and wrung out, to wipe the dirt. Then use a
dry soft cloth to dry up the device.
DON’T wash the device with water or immerse it in water.
DON’T use propellant, abrasive or other chemicals to wipe the dirt in avoidance of
discolor or malfunction.
DON’T disassemble this device. If you have any problems, please contact DMD. (Please
refer to Warranty for contact information)
Do not dispose of batteries in fire. Batteries may explode or leak. Remove the batteries if
the scale will not be used for a long period.
DMD warrants its products free of defects in materials and workmanship in normal use
for a period of TWO years from the date of retail purchase.
This warranty does NOT cover damages caused by misuse or abuse, including but not
limited to:
Failure caused by unauthorized repairs or modifications;
Damage caused by shock or drop during transportation;
Failure caused by improper operation inconsistent with the instructions stated in this user
manual;
Malfunction or damage from failure to provide the recommended maintenance;
Damage caused by improper use of power supply.
Should this device require maintenance (or replacement at our option) under warranty,
please deliver the original package to Greater Goods, LLC prepaid.
Please return the store receipt (with the retail purchase date) and a note with reasons to
return on it as well.
Warranty
Greater Goods, LLC
Tel: [phone]
Website: http://greatergoods.com
4427 Chouteau Ave.St.Louis,Missouri,63110,Unite States
Body Fat Analyzer (GBF-1719-B/0383)
0.1kg / 0.1 Ib
6V (Four AAA-size Batteries)
Product Name
Dimension
Net Weight
Display Digital LCD
Measurement Unit Kilogram / Pound
Measurement Range 180kg / 397Ib
Division
Accuracy 50kg: ±0.3kg;
150kg: ±0.5kg;
Working Environment
Storage Environment
Power Source
Auto-ON SENSE ON technology
Auto-OFF The scale will turn off after about 15s if there is no operation.
Accessories 1. Four AAA Size Batteries
2. User Manual
100kg: ±0.4kg;
Mode of Operation Continuous Operation
Temperature: 5℃to 40℃
Temperature: -20℃to 60℃Relative Humidity: ≤90% RH
Atmospheric pressure: 86kPa to 106kPa
Atmospheric pressure: 50kPa to 106kPa
Relative Humidity: ≤90% RH
Scale: 300x300x23.9mm (Approximately)
Approximately 1.6kg ( Including the dry cells)
BT Frequency Range 2402MHz to 2480MHz
BT Output Power Less than 5dBm
Bluetooth Module No
BT Supply Voltage
LS8261
1.8-3.6V

15
14
Health Tips - About Body Fat
Human body is made up of, amongst other things, a percentage of fat. Body fat is vital
for a healthy, functioning body, protects vital organs, helps regulate body temperature,
stores vitamins and helps the body sustain itself when food is scarce. However, too much
body fat or indeed too little body fat will damage to your health. It is difficult to gauge how
much body fat we have in our bodies simply by looking at ourselves in the mirror.
This is why it is important to measure and monitor your body fat percentage. Body fat
percentage gives you a better measure of fitness than weight alone–the composition of
your weight loss could mean you are losing muscle mass rather than fat-you could still
have a high percentage of fat even when a scale indicates‘normal weight’.
Health Tips - About Body Water
Body water is the single most important component of body weight. It represents over
half of your total weight and almost two thirds of your lean body mass (predominantly
muscle). Water performs a number of important roles in the body:
All the cells in the body, whether in the skin, glands, muscles, brain or anywhere else,
can only function properly if they have enough water. Water also plays a vital part in
regulating the body’s temperature balance, particularly through perspiration.
The combination of your weight and fat measurement could appear to be ‘normal’ but
your body hydration level could be insufficient for healthy living.
Health Tips - About Muscle Mass
According to the American College of Sports Medicine (ACSM), lean muscle mass may
decrease by nearly 50 percent between the age of 20 and 90. If you do nothing with it
you’re losing muscle and increasing fat. It is also important to know your muscle mass %
during weight reduction. At rest, the body burns approximately 110 additional calories for
each kilo of muscle gained. Benifits of gaining muscle mass include:
• Reversing the decline in strength, bone density and muscle mass with aging
• Maintenance of flexible joints
• Guide weight reduction when combined with a healthy diet.
Appendix
FCC Regulations
FCC User Guide Information
Radio Frequency Interface Requirements - FCC
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna;
Increase the separation between the equipment and receiver;
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected;
Consult the dealer or an experienced radio / TV technician for help.
Radio Transmitters (Part 15)
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
FCC RF Exposure Guidelines
Safety Information
Reducing RF Exposure - Use Properly
Only operate the device in accordance with the instructions supplied.
This device complies with FCC radiation exposure limits set forth for an uncontrolled
environment.
FCC Regulations
This device complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1)this device may not cause harmful interference, and
(2)this device must accept any interference received,
including interference that may cause undesired operation.

17
16
Appendix
Health Tips - About BMI
Maintaining proper weight is essential to healthy living. Obesity has been linked to a
higher risk of heart disease, diabetes and some forms of cancer. The Body Mass Index
(BMI) is the most widely accepted measurement of weight according to health
professionals. The Analyzer will calculate your BMI on your height and weight.
Health Tips - About Bone Mass
Regular exercise and a balanced diet can help maintain healthy bones. Like muscle,
bone is a living tissue that can respond to exercise by becoming stronger. For most
people, bone mass peaks in their thirties. Then people begin to lose bone. Regular
exercise can help prevent that loss.
Calcium and vitamin D, good sources of which are dairy products, green leafy
vegetables and fish, contribute to healthy bones.
The bone mass readings given by this product are anestimation of the amount of bone in
your body. Those with osteoporosis or low bone densities may not get accurate
estimations. If you have any concern regarding your bones please consult your doctor
timely.
Warning
Appendix
• Don’t near active HF SURGICAL EQUIPMENT and the RF shielded room of an ME
SYSTEM for magnetic resonance imaging, where the intensity of EM DISTURBANCES is
high.
• Use of this equipment adjacent to or stacked with other equipment should be avoided
because it could result in improper operation. If such use is necessary, this equipment and
the other equipment should be observed to verify that they are operating normally.
• Use of accessories, transducers and cables other than those specified or provided by
the manufacturer of this equipment could result in increased electromagnetic emissions or
decreased electromagnetic immunity of this equipment and result in improper operation.
• Portable RF communications equipment (including peripherals such as antenna
cables and external antennas) should be used no closer than 30 cm (12 inches) to any
part of the model GBF-1719-B, including cables specified by the manufacturer. Otherwise,
degradation of the performance of this equipment could result.
Guidance and manufacturer’s declaration - electromagnetic emissions
RF emissions
CISPR 11 Group 1
Class B
Not application
Not application
Compliance
Harmonic emissions
IEC 61000-3-2
Voltage fluctuations/
flicker emissions IEC
61000-3-3
RF emissions
CISPR 11
Emissions test
Table 1
Guidance and manufacturer’s declaration-electromagnetic
emissions and Immunity

19
18
Appendix Appendix
Guidance and manufacturer’s declaration – electromagnetic immunity
IMMUNITY test
±8 kV contact
±2 kV, ±4 kV, ±8 kV, ±15 kV air
±8 kV contact
±2 kV, ±4 kV, ±8 kV, ±15 kV air
Not application
30 A/m
50Hz/60Hz
NOTE UT is the a.c. mains voltage prior to application of the test level.
Table 2
IEC 60601-1-2 test level
Electrostatic
discharge (ESD)
IEC 61000-4-2
Power frequency
magnetic field
IEC 61000-4-8
Voltage dips,
short interruptions
and voltage
variations on
power supply
input lines
IEC 61000-4-11
Electrical fast
transient/burst
IEC 61000-4-4
Surge IEC
61000-4-5
Not application
Not applicationNot application
Not applicationNot application
30 A/m
50Hz/60Hz
Table 3
Guidance and manufacturer’s declaration - electromagnetic Immunity
Compliance level
Conduced RF
IEC61000-4-6
Radiated RF
IEC61000-4-3
Not applicationNot application
10 V/m
80 MHz – 2,7 GHz
80 % AM at 1 kHz
10 V/m
80 MHz – 2,7 GHz
80 % AM at 1 kHz
Radiated RF
IEC61000-4-3
(Test specifications
for ENCLOSURE
PORT IMMUNITY
to RF wireless
communications
equipment)
Test
Frequency
(MHz)
Band
(MHz)
Modulation
(W)
Service Distance
(m)
IMMUNITY
TEST LEVEL
(V/m)
Modulation
385 380
-390
TETRA
400
Pulse
modulation
18 Hz
1,8 0.3 27
450 380
-390
GMRS 460,
FRS 460
FM
± 5 kHz
deviation
1 kHz sine
20.3 28
710
704
-787
LTE Band
13,17
Pulse
modulation
217 Hz
0.2 0.3 9
745
780
800
-960
GSM 800/
900,TETRA
800,iDEN
820,CDMA
850,LTE
Band 5
Pulse
modulation
18 Hz
20.3 28
810
870
930
1700
-1990
GSM 1800;
CDMA1900;
GSM 1900;
DECT;
LTE Band
1, 3,4, 25;
UMTS
Pulse
modulation
217 Hz
20.3 28
1720
1845
1970
2400
-2570
Bluetooth,
WLAN,
802.11
b/g/n,RFID
2450,LTE
Band 7
Pulse
modulation
217 Hz
20.3 28
2450
5100
-5800
WLAN
802.11 a/n
Pulse
modulation
217 Hz
0.2 0.3 9
5240
5240
5785
