Gree GWC09AB-D3DNA2D User manual

Change for Life
Split Air Conditioner
Installation Manual
Residential Air Conditioners
Thank you for choosing Residential Air Conditioners,please read this owner’s
manual carefully before operation and retain it for future reference.
MODEL: GWC09AB-D3DNA2D GWH09AB-D3DNA2D
GWC12AB-D3DNA2DGWH12AB-D3DNA2D
GWC18AC-D3DNA2DGWH18AC-D3DNA2D
GWC24AC-D3DNA2DGWH24AC-D3DNA2D

■ .............................................3
■ ...............................................................4
■ ........................................................1
■ ..............................9
Do not dispose this product as unsorted municipal waste.
Collection of such waste separately for special treatment
is necessary.
CONTENTS
Notices for installation
Installation dimension diagram
Install indoor unit
Test operation and check after installation
■.......................10
Installation and Maintenance of Healthy Filter
Never attempt. Be sure to follow this instruction
The physical product may differ from the drawing in this manual for different display.
If there are some differences between them, please refer to the physical product as
the standard.
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
Children should be supervised to ensure they are away from the appliance.
■ .............................................................7
Install outdoor unit

1
Notices for installation
4.Warning:Before obtaining access to terminals, all supply circuits must be disconnected.
5.For appliances with type Y attachment, the instructions shall contain the substance of
the following. If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
6.The appliance must be positioned so that the plug is accessible.
7.The temperature of refrigerant line will be high; please keep the interconnection cable
away from the copper tube.
8. The instructions shall state the substance of the following:
This appliance is not intended for use by persons(including children)with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible
for their safety.
Children should be supervised to ensure that they do not play with the appliance.
Caution
Installation Site Instructions
The unit should be installed only by authorized service center according to local or
government regulations and in compliance with this manual.
Before installing, please contact with local authorized maintenance center. If the unit is
not installed by the authorized service center, the malfunction may not be solved
due to incovenient contact between the user and the service personnel.
When removing the unit to the other place, please firstly contact with the local authorized
service center.
●
●
●
●
●
●
Proper installation site is vital for correct and efficient operation of the unit. Avoid the
following sites where:
strong heat sources, vapours, flammable gas or volatile liquids are emitted.
high-frequency electro-magnetic waves are generated by radio equipment,
welders and medical equipment.
salt-laden air prevails (such as close to coastal areas).
the air is contaminated with industrial vapours and oils.
the air contains sulphures gas such as in hot spring zones.
corrosion or poor air quality exists.
1.
2.
3.
Installation Site of Indoor Unit
Select a site where the condensate can be easily drained out, and where it is
easily connected to outdoor unit.
Select a place where the wall is strong enough to withstand the full weight and vibration
of the unit.
Select a place where it is out of reach of children.
The air inlet and outlet should be away from the obstructions. Ensure the air can be
blown through the whole room.
Be sure to leave enough space to allow access for routine maintenance. The installation
site should be 98 3/7 inch or more above the floor．
5.
4.
1.
2.
3.

2
Notices for installation
Note:
Safety Precautions for Electric Appliances
Installation Site of Outdoor Unit
1.Select a site where noise and outflow air emitted by the unit will not annoy neighbors.
Select a site where there is sufficient ventilation.
Select a site where there is no obstruction blocking the inlet and outlet.
The site should be able to withstand the full weight and vibration.
Select a dry place, but do not expose the unit to direct sunlight or strong wind.
Make sure that the outdoor unit is installed in accordance with the installation instructions,
and is convenient for maintenance and repair.
The height difference between indoor and outdoor units is within16.4ft, and the length of
the connecting tubing does not exceed 32.8ft.
Select a place where it is out of reach of children.
Select a place where the unit does not have negative impact on pedestrians or on the city.
5. The minimum distance between the unit and combustive surface is 4.9ft.
1. A dedicated power supply circuit should be used in accordance with local electrical
safety regulations.
2. Don't drag the power cord with excessive force.
3.
The appliance shall be installed in accordance with national wiring regulations.
An all-pole disconnection switch with a contact separation of at least 9.8ft in all poles
should be connected in fixed wiring.
The unit should be reliably earthed and connected to an exclusive earth device by the
professionals.
4. The air switch must have the functions of magnetic tripping and heat tripping to prevent
short circuit and overload.
Make sure the live wire, neutral wire and earth wire in the family power socket are properly
connected. There should be reliable circuit in the diagram.
Inadequate or incorrect electrical connections may cause electric shock or fire.
●
●
6.
7.
2.
3.
4.
5.
6.
7.
8.
9.
Make sure that the indoor unit is installed in accordance with installation dimension
Select a place about 3.3ft or more away from TV set or any other electric appliance.
Select a place where the filter can be easily taken out.
instructions.
6.
7.
8.
9. Do not use the unit in the laundry or by swimming pool etc.
Earthing Requirements
①②③
④
1. Air conditioner is type I electric appliance. Please ensure that the unit is reliably earthed.
2. The yellow-green wire in air conditioner is the earthing wire which can not be used
for other purposes. Improper earthing may cause electric shock.
3. The earth resistance should accord to the national criterion.
4. The power must have reliable earthing terminal. Please do not connect the earthing
wire with the following:
W epipsaGepipreta Contamination pipe
Other place that professional personnel consider is unreliable
5. The model and rated values of fuses should accord with the silk print on fuse cover or
related
PCB.

3
Installation dimension diagram
Space to the ceiling
Space to the wall
Space to the wall
Air outlet side Space to the floor
Above Above
6inch Above 6inch
Above
Above
118
inch 98
6inch
Air inlet side
Air outlet side
Space to the wall
Space to the obstruction
Space to the wall
20inch above
20inch above
12inch above
12inch above
79inch above
Installation dimension diagram
● Indoor unit
● Outdoor unit
inch

Drill Piping Hole
1.Slant the piping hole (Ф2 1/6 or Ф2 3/4) on the wall slightly downward
to the outdoor side.
2.Insert the piping-hole sleeve into the hole to prevent the connection piping
and wiring from being damaged when passing through the hole.
Indoor Outdoor
Wall pipe Seal pad
4
Installation of Indoor Unit
Installation of Mounting Plate
1. Mounting plate should be installed horizontally. As the water tray's outlet for the indoor unit is two-way
type, during installation, the indoor unit should slightly slant to water tray's outlet for smooth drainage of
condensate.
2.Fix the mounting plate on the wall with screws.
3.Be sure that the mounting plate has been fixed firmly enough to withstand about 132.3 lb. Meanwhile, the
weight should be evenly shared by each screw.
Fig.5
09K、
12K UNIT:
(Rear piping hole)(Rear piping hole)
Left Right
the wall
6inch
above
Space to
the wall
6inch
above
Wall Wall
18K UNIT:
24K UNIT:
Ф2 1/6
or
Ф2 3/4
3 4/7
6 1/6
1
11 1/7
23 5/6 3 3/4
1/3
33 3/4
1 1/9
4 2/7
Unit: inch
4 1/3 27 1/3 5 3/5
2 3/4
1
Ø2 1/6
3 1/7
1 1/6
Ø2 1/6
11 4/5
1/3
37 1/4
46
6 8/9 27 8 1/5
13
1 4/7
3
1 1/4
7
Ø2 3/4
Ø2 3/4
6 2/5
Ø2 1/6
Ø2 1/6

Connecting Indoor and Outdoor Electric Wires
5
Installation of Indoor Unit
Note: The insulating tube should be connected reliably with
the sleeve outside the outlet pipe. The drain hose should be
slanted downward slightly, without distortion, bulge or
fluctuation. Do not put the outlet in the water.
bulge distortion
Flooded
●
●
●
After tightening the screws, pull the wire slightly to confirm whether it's firm or not.
●
●Make sure that all wiring connections are secure and the cover plates are reinstalled
NOTE:
All wires between indoor and outdoor units must be connected by the qualified electric
contractor.
Electric wires must be connected correctly. Improper connection may cause malfunction.
Tighten the terminal screws securely.
Make sure that the electric connections are earthed properly to prevent electric shock.
properly. Poor installation may cause fire or electric shock.
yellow-
green
brown
Fig.6
1.Open the front panel.
2.Remove the wiring cover as shown in Fig 6.
3.Make the power connection cord and pass through the hole at the back of indoor unit.
4.Reinstall the cord anchorage and wiring cover.
5.Reinstall the front panel.
Wiring cover
outdoor unit connection
1.
2.
3.
Installation of Drain Hose
Connect the drain hose to the outlet pipe of the indoor unit.
Bind the joint with rubber belt.
Put the drain hose into insulating tube.
Wrap the insulating tube with wide rubber belt to prevent
the shift of insulating tube. Slant the drain hose downward
slightly for smooth drainage of condensate.
outlet pipe of
indoor unit
insulating tube
connected
insulating tube
drain hose
outlet pipe of
indoor unit
drain hose
outlet pipe of
indoor unit
outlet pipe of
indoor unit
rubber belt
rubber belt
rubber belt

6
右后
4.
2.
3.
●
1.
⑴
⑵
1.
2.
Installation of Indoor Unit
The piping can be output from right, right rear, left
or left rear.
When routing the piping and wiring from the left
or right side of indoor unit, cut off the tailings
from the chassis when necessary(As shown in Fig.7)
Cut off tailing 1 when routing the wiring only;
Cut off tailing 1 and tailing 2 when routing
both the wiring and piping.
Take out the piping from body case;wrap the piping,
power cords, drain hose with the tape and then make
them pass through the piping hole. (As shown in Fig.8)
Hang the mounting slots of the indoor unit on the
upper hooks of the mounting plate and check if it is
firm enough. (As shown in Fig.9)
The installation site should be 98 3/7 inch or more
above the floor
.
Installation of Connection Pipe
Align the center of the pipe flare with the related valve.
Screw in the flare nut by hand and then tighten the
nut with spanner and torque wrench by referring to the
following:
NOTE: Connect the connection pipe to indoor unit at first and then to outdoor unit. Handle pi-
ping bending with care. Do not damage the connection pipe. Ensure that the joint nut
is tightened firmly, otherwise, it may cause leakage.
Spanner Torque
wrench
Piping
Taper nut
Indoor unit piping
Fig.9
Mounting
plate
Fixing hook Mounting
plate
Right
Right rear Fig.8
Left rear
Left
Fig.7
Tailing 1
Tailing 2
Finally wrap it
with tape
Gas side piping
insulation
Water drainage pipe
Liquid side
Piping insulation
Gas side pipingExternal connection
electric wire
Liquid side piping
(N·m)
Ф6.35(1/4”)
Ф9.52(3/8”)
Ф12.7(1/2”)
Ф15.88(5/8”)
34～42N·m(340-420kgf.cm)
14～18N·m(140-180kgf.cm)
49～61N·m(490-610kgf.cm)
68～82N·m(680-820kgf.cm)
Tube diameter Tightening torque,approximate
Installation of Indoor Unit

7
3.
4.
5.
1.
2.
Remove the handle on the right side plate of outdoor unit.
Take off wire cord anchorage. Connect and fix power cord
to the terminal board. Wiring should fit that of indoor unit.
Fix the power cord with wire clamps and then connect the
the corresponding connector.
Confirm if the wire has been fixed properly.
Reinstall the handle.
●
●
Installation of Outdoor Unit
Electric Wiring
NOTE:
Incorrect wiring may cause malfunction of spare part.
After the wire has been fixed, ensure there is free
space between the connection and fixing places
on the lead wire.
real product for authentic information.
Wire hole
Sketch map of power connection wire:
Power connection wire Power cord
Cable-cross board
for 9k、12k unit
for 18K、24K unit
Indoor unit
connection
N(1)
2 3 L1
L1
L2
L2
G
blue black brown
POWER
yellow-
green
blue
brown
yellow-
green
Schematic diagram being reference only, please refer to
● Use vacuum pump
1. Connect the charging hose of manifold valve to charging
port of low-pressure valve. Both high-pressure valve and
low-pressure valve must be tighten up).
2. Connect joint of charging hose to vacuum pump.
3. Fully open Lo （low pressure ）handle of manifold valve
and start the vacuum pump for vacuum pumping.
4. Usually the vacuum pumping time of 2600W AC is about
15min. The vacuum pumping time of 5000W AC is about
20min. The vacuum pumping time of 7200W AC is about
30min. Make sure the pressure is -1.0X105pa (-76cmHg).
When vacuum pumping is finished, close Lo （low pressure ）
handle of manifold valve completely to stop the vacuum pump.
(Note: R410A refrigerant special vacuum pump should be
applied for R410A unit.)
Liquid
valve
Gas valve
Manifold valve
Multimeter
Piezometer
Hi handle
Lo handle
Charging hose Charging hose
Vacuum pump
Length of connection pipeAir purging method
Use vacuum pump
Nameplate value
Refrigerant charging amount
Not longer than 24.6ft
24.6~65.6ft
● Air purging method:
-76cm Hg
Nameplate value +20g/m (for 9k、12k、18k heat pump unit）
Nameplate value +15g/m (for 18k、24k cool only unit）
Nameplate value +50g/m (for 24k heat pump unit ）
add 15g/20g/50g of refrigerant for additional 1m of pippe length
Air purging
