Gree GDN10BF-K5EBA2A User manual

Change for life
Dehumidifier
Thank you for choosing our product.
Please read this Owner’s Manual carefully before operation and
retain it for future reference.
If youhave lost theOwner's Manual, please contact thelocalagent
or visit www.gree.comor send an email to [email protected] for
theelectronic version.
Owner's Manual
Original Instructions

GDN10BF-K5EBA2A
GDN12BF-K5EBA2A
GDN16BF-K5EBA2A

Content
Operation Notices
● Safety Precautions..................................................................................2
● The Refrigerant.......................................................................................1
● Operation Area........................................................................................3
● Parts Name.............................................................................................4
Operation Instructions
● Operation Method...................................................................................5
●Drainage Method
Maintenance
● Clean and Maintenance........................................................................10
Malfunction
●Troubleshooting....................................................................................12
●Specialist’s Manual ..............................................................................16
●Malfunction Codes................................................................................14
Note:
Graphics in this manual are only for reference. Please refer to actual
products for specific details.
....................................................................................8
This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
This marking indicates that this product should not be disposed with other household wastes
throughout the EU. To prevent possible harm to the environment or human health from un-
controlled waste disposal, recycle it responsibly to promote the sustainable reuse of mate-
rial resources.To return your used device, please use the return and collection systems or
contact the retailer where the product was purchased. They can take this product for envi-
ronmental safe recycling.
●Electric schematic diagram ..................................................................15
R290: 3

Explanation of Symbols
1.Damage the product due to improper use or misuse of the product;
2.Alter, change, maintain or use the product with other equipment without abiding
by the instruction manual of manufacturer;
4.
5.
6.
After verification, the defect of product is directly caused by corrosive gas;
After verification, defects are due to improper operation during transportation of
product;
Operate, repair, maintain the unit without abiding by instruction manual or related
regulations;
After verification, the problem or dispute is caused by the quality specification or
performance of parts and components that produced by other manufacturers;
The damage is caused by natural calamities, bad using environment or force
majeure.
7.
3.
Exception Clauses
Manufacturer will bear no responsibilities when personal injury or
property loss is caused by the following reasons.
Indicates a hazardous situation that, if not avoided, will
result in death or serious injury.
Indicates a hazardous situation that, if not avoided, could
result in death or serious injury.
Indicates a hazardous situation that, if not avoided, may
result in minor or moderate injury.
Indicates important but not hazard-related information,
used to indicate risk of property damage.
Indicates a hazard that would be assigned a signal word
WARNING or CAUTION.
DANGER
WARNING
CAUTION
N OTIC E
If it needs to maintain the appliance , please contact dealer or local service
center to conduct it at first. The appliance must be maintained by appointed
unit. Otherwise, it may cause serious damage or personal injury or death.
When refrigerant leaks or requires discharge during installation, maintenance,
or disassembly, it should be handled by certified professionals or otherwise in
compliance with local laws and regulations.

1
Appliance filled with flammable gas R290.
Before install and use the appliance, read the owner’s manual first.
Before install the appliance, read the installation manual first.
Before repair the appliance, read the service manual first.
The Refrigerant
To realize the function of the unit, a special refrigerant circulates in the system.
The used refrigerant is the fluoride R290, which is specially cleaned.
The
refrigerant is flammable and inodorous. Furthermore, it can lead to explosion
under
certain conditions.
Compared to common refrigerants, R290 is a nonpolluting refrigerant with no harm
to the ozonosphere. The influence upon the greenhouse effect is also lower. R290
has got very good thermodynamic features which lead to a really high energy
efficiency. The units therefore need a less filling.
WARNING
Appliance filled with flammable gas R290.
Appliance shall be installed, operated and stored in a room with a floor area larger
than 4 m
2
.
The appliance shall be stored in a room without continuously operating ignition sources.
(for example: open flames, an operating gas appliance or an operating electric heater.)
The appliance shall be stored in a well-ventilated area where the room size corresponds
to the room area as specified for operation.
The appliance shall be stored so as to prevent mechanical damage from occurring.
Ducts connected to an appliance shall not contain an ignition source.
Keep any required ventilation openings clear of obstruction.
Do not pierce or burn.
Be aware that refrigerants may not contain an odour.
Do not use means to accelerate the defrosting process or to clean, other than those
recommended by the manufacturer.
Servicing shall be performed only as recommended by the manufacturer.
Should repair be necessary, contact your nearest authorized Service Centre.
Any repairs carried out by unqualified personnel may be dangerous.
Compliance with national gas regulations shall be observed.
Read specialist’s manual.

●
●
Prohibit operating the unit in the bathroom or laundry room.
●
●
Children shall not play with the appliance.
●
Cleaning and user maintenance shall not be made by children
without supervision.
Before cleaning, please turn it off and unplug the dehumidifier.●
●
Before operation, please check the power cord if it complies with
the requirement indicated on the nameplate.
●
Make sure the power cord is not pressed by any hard object.
Do not remove the power plug or move unit by pulling the power cord.
●
●Do not remove the power plug in wet hands.
●
Do not use any heating application near the dehumidifier.
cted and not damaged.
Please use grounded power cord and make sure it's well conne-
●
idifier without supervision.
●
Children and disabled people are not allowed to use the dehum-
●
Keep children from playing or climbing on the dehumidifier.
●
Do not place the dehumidifier under dripping objects.
●Do not repair or disassemble the unit by yourself.
●
Memory function is included in this dehumidifier. When nobody
is taking care of the unit, please turn it off and remove the power
plug or disconnect power.
●
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in
order to avoid a hazard.
If abnormal condition occurs (e.g. burned smell), please discon-
nect power at once and then contact local dealer.
●
posal or information service center about what to do.
●Do not use an extension cord.
Dehumidifier can not be disposed of everywhere. If you want to
get rid of this dehumidifier, please check with local handling dis-
●The appliance shall be installed in accordance with national
wiring regulations.
Safety Precautions
2
This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the app-
liance in a safe way and understand the hazards involved.

3
Operation Area
not be used for commercial or industrial applications.
enclosed area, such as a closet.
temperature will not below 5°C or
above 32°C.
●Allow at least 30 cm of air space on all sides of the unit.
● Close all doors, windows and other outside openings of the room to improve
the working effect.
● Please keep the air inlet/outlet clean and not blocked.
●Avoid direct sunlight.
Note:
from the bucket or
Note:
at least 30 cm
Correct
Above
Wrong
Below
at least 30 cm

Parts Name
Front Side
Back Side
4
Castors
Control Panel
Panel
Air-out Grille
Water Bucket
Power Plug
Air-in Filter
Rear Case
Drain Cover

Notes:
Basic Functions of the Buttons
1
Power Button
●
●
●
5
Do not remove the bucket while unit is in operation.
If you want to use drain hose to drain water away, please install the hose acc-
ording to section "Drainage method".
Each time pressing the effective button on the control panel will give out a
"beep" sound.
Operation Method
2Humidity Button
Bucket full light indicates
bucket needs to be emptied
or it is not in the proper place
As for setting the humidify, after each pressing of humidify button, the set
humidity will increase 5% in the range of 30%-80% circularly; Hold the
humidify button can adjust the humidity quickly.
Humidity
Standby indicator
Display
WiFi indicator
Low fan speedHigh fan speed
Running indicatorUV indicator
WiFi Button
UV Button
Fan Button Power Button
Humidity Button
WiFi UV
UV ONLY CHILD LOCK
High Low
(3S) (3S)
Fan Full
Humidity

6
3Fan Button
4UV Button
WiFi Button
6Display
5
Other Instructions
1.
2. Auto Stop
Alarm Warning
If bucket is full or not locked into place for over 3min, buzzer will beep for 10s
to remind you to empty bucket or put it back into the correct place.
When bucket is full, removed or not placed correctly or the humidity is 5%lower
than the set humidity, unit will automatically stop.
Press this button can freely switch from high fan speed to low fan speed.
When you need fast dehumidification, select high fan speed; when you need
the unit to work quietly, select low fan speed.
Hold this button for 3S to enter or exit child lock status. When the unit enters
child lock status, the display window will flash “LC” 3 times; at this time,
pressing other buttons will be invalid and “LC” will be displayed.
Whether the unit is turned on or turned off, press WiFi button can turn on or
turn off WiFi function;
Whether the unit or WiFi is turned on or turned off, hold WiFi button for 5s
can reset WiFi. At the same time, WiFi function will be turned on.
Under on status, hold combination button (uv button + fan button) for 3s can
turn on or turn off the nixie tube.
The humidity display window is defaulted to display current environment hu-
midity. If press humidity button to adjust the humidity, it will display the set
humidity. 5s later, it will turn back to display the ambient humidity.
Under dehumidification mode, it’s defaulted that UV function is turned on.
Press this button once only to turn off or turn on the UV function. Hold this
button for 3S to enter or exit single UV mode. Under single UV mode, the
dehumidification function will be off, and the display window will display “- -”.
Fan
UV
FanUV
WiFi
7Combination button +

7
Memory Function3.
4. Bucket full light
If power is lost, all of the control settings are remembered. So when power is
restored, the unit will start back up in the settings it was in when power was
lost.
This indicates that bucket is full or removed or not placed correctly.

Drainage Method
Option 1 Emptying Manually
Notes:
Do not remove the bucket when unit is in operation or has just stopped.
1.
2.
Do not use the hose if using water bucket to collect water. When the hose is
connected, water will be drained out through it instead of into the bucket.
arrow direction. (Attention: Pull out the bucket carefully in case the water may
Hold the handles on bottom side of the water bucket and pull it out following the
Empty the bucket by grasping the handle on the bottom of bucket with one hand
and grasping the bottom of bucket with the other hand.
8

Option 2 Gravity Drain Hose
1.
2.
3.
4.
Hose is not provided, so user shall prepare it in advance.
[Size: The hose should have an inner diameter of 14mm]
Unscrew the drain cover, and pull out the rubber plug from the unit as
instructed.
Take out the adaptor and connect it firmly to the continuous drainage port.
Thread the drain hose onto the adaptor and make sure it's securely locked.
5.
Note: When you want to take off the drain hose, prepare a receptacle to collect
water from the nozzle.
9
Replace the bucket. Make sure the drain hose goes through the bucket's drain
the hole with a lid. Note that drain hose should not be pressed, otherwise
water can not be drained out.

1
Clean and Maintenance
Warning:
.
may lead to electric shock.
1.
Otherwise it will damage unit's appearance.
2.
replacing it.
To remove: Press the “PUSH” above the filter with
Filter
The filter should be checked and cleaned at
least every 250 hours of operation or more often
if necessary.
Grille and Case
To clean the case:
When there is dust on the case, use soft towel
to dust it off; When the case is very dirty(greasy),
use mild detergent to clean it.
To clean the grille:Use a dust catcher or brush.
●
Warning:
●
two hands simultaneously, then the filter
can be removed.
Don’t use dust catcher or brush to clean the filter. Otherwise the filter may be
destroyed
Otherwise the evaporator will catch dust and
affect unit's performance.
Do not dry the filter with fire or electric hair dryer. Otherwise the filter may be
unshaped or caught on fire.

● Check whether air outlet is blocked.
● Check whether power plug and power socket are in good condition.
● Check whether drain hose is damaged.
Check Before Use-season
● Disconnect power.
● Empty the water bucket.
Care After Use-season
Long-time Storage
11
steps below in order to maintain the unit in good condition.
● Make sure the bucket is clear of water and drain hose is removed.
● Clean the unit and wrap it well to prevent the gathering of dust.

Troubleshooting
● Not all the following problems are malfunctions.
● Problem of Water Leakage.
Problem Possible Causes
Controls can not be set.
● Unit is operating in an area where temperature
is higher than 32°C or lower than 5°C.
● Bucket is full.
Noise suddenly rises during
operation.
● Noise will rise if compressor has just started.
● Power supply problem.
Humidity does not drop.
●
● Doors are open.
● There might be some device producing vapor in
the room.
Little or no effect in
dehumidifying
● Room temperature is too low.
● Humidity level may be improperly set.
● If unit is operating in a room where temperature
is from 5 to 15 °C, it will start to defrost automati-
cally. Compressor will stop for a brief period of
time(fan will operate in high fan speed).
normal operation.
emitted has musty-odor.
● Due to temperature rising of heat exchanger, the
air may have some strange smell at the beginning.
Unit has noise. ●
There might be some noise if unit is operating on
Swooshing sound is heard. ●
Problem Possible Causes Solution
When using drain
hose, there is water
in the bucket.
● Examine the drainage joint. ● Connect the drainage joint
well.
● Clear the obstacle from the
drain hose.
● Drain hose is not correctly
installed. ●
Remove the drain hose and
replace it. Be sure that the
hose is correctly installed.
12

Bad dehumidifying
performance
● Check whether there is
any obstacle around the
unit.
● Make sure there is no curtain,
shutter or furniture that blocks
blocked.
● Doors and windows are
left open.
● Make sure all doors and
windows and other opening to
the outside have been
closed.
● Room temperature is too
low.
●Warm temperature is good for
ature will reduce unit's working
effect. This unit should be wor-
king in a place where temper-
ature is above 5°C.
Problem Possible Causes Solution
Power indicator is
not lit when power
is connected.
● Power is not supplied for
power plug is not well
inserted.
● Check if power is lost. If yes,
wait for the power to restore.
● If not, check whether the
power circuit or power socket
has been damaged.
● Check whether power plug is
loosen.
● Check whether power cord is
damaged.
● Fuse is blown. ● Replace the main board.
Bucket full indicator
is lit up.
● Bucket is not properly
placed.
●Water is full in the bucket.
●Bucket hasbeen removed.
●
Empty the bucket and replace
it.
Unit can function
normally but it can
not start up.
● Humidity is set too high.
● If you want the air drier,
press humidity button to
to dehumidify continuously.
lower the figure for unit
13

Compressor
and fan
motor stop.
This button
is invalid.
2
Tube
Temperature
Sensor
Malfunction
F2
●Temperature sensor on the
evaporator is loosen or is poorly
connected with the terminal of
display board.
● Some element of display board
may have been put upside down
and cause short circuit.
●Temperature sensor on the eva-
porator is damaged
● Display board is damaged.
3Humidity Sensor
Malfunction L1 ●
Humidity sensor is short-circuited.
● Humidity sensor is damaged.
● Display board is damaged.
No. Malfunction
Name
Display
Code Unit's
Condition Possible Causes
Display
Window
1
Ambient
Temperature
Sensor
Malfunction
F1
Compressor
and fan
motor stop.
●Ambient temperature sensor is
loosen or is poorly connected
with the terminal of display board.
● Some element of display board
may have been put upside down
and cause short circuit.
●Ambient temperature sensor is
damaged
● Display board is damaged.
Malfunction Codes
● Unit's Malfunction Codes
14

Electric schematic diagram
The Electric schematic diagram are subject to change without notice.
Please refer to which one on the unit.
15
4Freon-lacking
protection F0 ● Refrigerant is leaking. ● System is blocked
5
High-tempe-
rature over
load
protection
H3
● Ambient operation condition is
bad.
● The evaporator and condenser
are blocked with filth.
● The system is abnormal.
No. Malfunction
Name
Display
Code Unit's
Condition Possible Causes
Display
Window
Compressor
stops opera-
tion. 30s lat-
er , the fan
will also stop
operation.
PE
AP1
DISP
AP2 DISP BN(BK)
BU(WH)
TUBE TEMP.
BU
POWER
L
N
RD
AC-L
N
FAN
COMP
TEMP/HUM CN5
YEGN(GN)
MAIN BOARD
DISPLAY
BOARD
HUMIDITY
SENSOR
ST
COMP
PE
YEGN
C
2
COMP.
TUBE
RT1
θ
WIFI
SENSOR WIFI
HEALTH
UV LIGHT
MODULE
OPTIONAL
SWITCH
PROXIMITY
C1
M1 MOTOR
FAN
BN
RD
AP3

16
No ignition sources
Safety preparation work
Work procedure
General work area
Checking for presence of refrigerant
Presence of fire extinguisher
a) Any person who is involved with working on or breaking into a refrigerant circuit
should hold a current valid certificate from an industry-accredited assessment authori-
ty, which authorises their competence to handle refrigerants safely in accordance with
an industry recognised assessment specification.
b) Servicing shall only be performed as recommended by the equipment manufac-
turer. Maintenance and repair requiring the assistance of other skilled personnel shall
be carried out under the supervision of the person competent in the use of flammable
refrigerants.
Aptitude requirement for maintenance man(repairs should be done only be
specialists).
The maximum refrigerant charge amount is shown on the following table a
(Note:Please refer to the nameplate for the charging quantity of R290).
Prior to beginning work on systems containing flammable refrigerants, safety checks
are necessary to ensure that the risk of ignition is minimised. For repair to the refriger-
ating system, the following precautions shall be complied with prior to conducting work
on the system.
Work shall be undertaken under a controlled procedure so as to minimise the risk of
a flammable gas or vapour being present while the work is being performed.
All maintenance staff and others working in the local area shall be instructed on the
nature of work being carried out. Work in confined spaces shall be avoided. The area
around the workspace shall be sectioned off. Ensure that the conditions within the area
have been made safe by control of flammable material.
The area shall be checked with an appropriate refrigerant detector prior to and
during work, to ensure the technician is aware of potentially toxic or flammable atmo-
spheres. Ensure that the leak detection equipment being used is suitable for use with
all applicable refrigerants, i.e. non-sparking, adequately sealed or intrinsically safe.
If any hot work is to be conducted on the refrigeration equipment or any associated
parts, appropriate fire extinguishing equipment shall be available to hand. Have a dry
powder or CO2 fire extinguisher adjacent to the charging area.
No person carrying out work in relation to a refrigeration system which involves
exposing any pipe work shall use any sources of ignition in such a manner that it may
11 154
Room area (m2)
<0.152 0.225 0.304
Maximum charge (kg)
table a - Maximum charge (kg)
Specialist's Manual
