Green Brook GX-SL04N Assembly instructions

Operating & Safety Instructions
GX-SL04N. GX-SL05N, GX-SL06N, GX-SL08N & GX-SL 0N
Warning
Read the instructions
Maximum total
load
Correct erection angle
(65°
-
75°)
Do not use the ladder on an
uneven or unfirm ground
Do not overreach
e aware of electrical hazards
when
transporting ladder
Do not use the
ladder as a bridge
not erect ladder on
contaminated ground
Maximum number of
users on a ladder
Do not step off the side
of the ladder
Ladders used for access to
a higher level shall be
extended at least 1m
above the landing point
and secured, if necessary
Do not lean the ladder
against unsuitable surfaces
Use the ladder with
restraint devices engaged
only
Ensure standing ladder is
opened before use
Face ladder when
ascending or descending
ladder

Introduction
Type GX-SL04N
Steps 4
Weight 6.2 kg
Max. Load 150 kg
L
1
(mm) 1200
L
2
(mm) 881
Max. Standing height: approx.
0.27m
Type GX-SL05N
Steps 5
Weight 7.6 kg
Max. Load 150 kg
L
1
(mm) 1500
L
2
(mm) 1078
Max. Standing height: approx.
0.55m
Type GX-SL08N
Steps 8
Weight 11.7 kg
Max. Load 150 kg
L
1
(mm) 2400
L
2
(mm) 1669
Max. Standing height: approx.
1.38m
Type GX-SL06N
Steps 6
Weight 8.8 kg
Max. Load 150 kg
L
1
(mm) 1800
L
2
(mm) 1275
Max. Standing height: approx.
0.83m
Type GX-SL10N
Steps 10
Weight 15.0 kg
Max. Load 150 kg
L
1
(mm) 3000
L
2
(mm) 2063
Max. Standing height: approx.
1.9 m

Professional Use
. Check before using the ladder
a. Ensure that you are fit enough to use a ladder. Certain medical conditions or
medication, alcohol or drug abuse could make ladder use unsafe
b. Prevent damage of the ladder when transporting e.g. by fastening and, ensure they are
suitably placed to prevent damage
c. Inspect the ladder after delivery. efore every use visually check the ladder is
not damaged and is safe to use. Do not use a damaged ladder.
d. Visually check the ladder at the start of each working day when the ladder is to be used
e. For professional users regular periodic inspection is required
f. Ensure the ladder is suitable for the task
g. Do not use a damaged ladder.
h. Do not use the ladder if contaminated, e.g. with wet paint, mud, oil or snow
i. For professional use a risk assessment shall be carried out respecting the legislation in the
country of use
j. Do not modify the ladder design
2. Positioning and erecting the ladder
a. The ladder shall be erected at the correct position, such as the correct angle
for a leaning ladder (65-75º angle of inclination, approximately 1:4) with the rungs or treads
level and complete opening of a standing ladder
b. Leaning ladders with steps shall be used that the steps are in a horizontal position
c. Locking devices, if fitted, shall be fully secured before use;
d. The ladder shall be on an even, level and unmovable base
e. A leaning ladder should lean against a flat non-fragile surface and should be secured before
use, e.g. tied or use of a suitable stability device
f. The ladder shall never be repositioned from above

g. When positioning the ladder take into account risk of collision with the ladder e.g. from
pedestrians, vehicles or doors; Secure doors (not fire exits) and windows where possible in
the work area
h. Identify any electrical risks in the work area, such as
overhead lines or other exposed electrical equipment
i. The ladder shall be stood on its feet, not the rungs or treads
j. Ladders shall not be positioned on slippery surfaces (such as ice, shiny surfaces or
significantly contaminated solid surfaces) unless additional effective measures are taken to
prevent the ladder slipping or ensuring contaminated surfaces are sufficiently clean.
k. Ladder shall never be moved from the top
3. Using the ladder
a. Do not exceed the maximum permissible load for the type of ladder
b. Do not overreach; users should keep their belt buckle (navel) inside the stiles and both feet
on the same step/rung throughout the task
c. Do not step off a leaning ladder at a higher level without additional security, such as tying off
or use of a suitable stability device
d. Do not use standing ladders for access to another level
e. Do not stand on the top three rungs of a leaning ladder
f. Do not stand on the top two steps/rungs of a standing ladder without a
platform and hand/knee rail.
g. Do not stand on the top four steps/rungs of a standing ladder with an
extending ladder at the top
h. Ladders should only be used for light work of short duration
i. Use non-conductive ladders for unavoidable live electrical work;
j. Do not use the ladder outside in adverse weather conditions, such as strong wind;
k. Take precautions against children playing on the ladder
l. Secure doors (not fire exits) and windows where possible in the work area

m. Do not ascend or descend unless you are facing the ladder
n. Keep a secure grip on the ladder when ascending and descending;
Maintain a handhold whilst working from a ladder or take additional safety precautions if
you cannot
o. Do not use the ladder as a bridge
p. Do not wear unsuitable footwear when climbing a ladder
q. Avoid excessive side loadings e.g. drilling brick and concrete
r. Do not spend long periods on a ladder without regular breaks (tiredness is a risk);
s. Leaning ladders used for access to a higher level should be extended at least 1 m above the
landing point
t. Do not carry equipment which is heavy or difficult to handle while using a
ladder
u. Avoid work that imposes a sideways load on ladders, such as side-on drilling
through solid materials (e.g. brick or concrete)
v. Maintain a handhold whilst working from a ladder or take additional safety precaution if you
cannot
w. Standing ladders shall not be used as leaning ladders unless they are
designed for that purpose
x. Do not move a ladder while standing on it.
y. For outdoor use caution to the wind

z. Only use the ladder in the direction as indicated, only if necessary due to
design of ladder
aa. horizontal surface which looks like a platform on a standing ladder that is
not designed for standing on (e.g. a plastic work tray) shall be clearly indicated on that
surface, only if necessary due to design of ladder. The rated load of plastic work tray is 10kg
4. Repair, maintenance and storage
Repairs and maintenance shall be carried out by a competent person and be in accordance with the
producer’s instruction.
For repair and replacement of parts, e.g. feet, if necessary contact the producer or distributor.
Ladders should be stored in accordance with the producer’s instructions.
Ladders made of or using thermoplastic, thermosetting plastic and reinforced plastic materials
should be stored out of direct sunlight.
Ladders made of wood should be stored in a dry place and shall not be coated with opaque and
vapour-tight paints.
Ladders made of wood should be stored in a dry place and shall not be coated with opaque and
vapour-tight paints.
-Is the ladder stored away from areas where its condition could deteriorate more rapidly (e.g.
dampness, excessive heat, or exposed to the elements)?
-Is the ladder stored in a position which helps it to remain straight (e.g. hung by the stiles on
proper ladder brackets or laid on a flat clutter free surface)?
-Is the ladder stored where it cannot be damaged by vehicles, heavy objects, or
contaminants?
-
-Is the ladder stored where it cannot cause a trip hazard or an obstruction
-Is the ladder stored securely where it cannot be easily used for criminal purposes?
-If the ladder is permanently positioned (e.g. on scaffolding), is it secured against
unauthorized climbing (e.g. by children)?

MAINTENANCE AND STORING YOUR LADDER:
•Keep the ladder in a clean, dry place.
•Hold the ladder firmly when carrying it.
•Never store materials on your ladder
•Keep your ladder clean and free from any foreign matter.
•Clean the ladder after each use
•Regularly check the parts and hinges of the ladder. Oil the hinges regularly, but do so carefully to
ensure no oil drips on the rungs or side rails.
For regular inspection, the following items shall be taken into account:
— check that the stiles/legs (uprights) are not bent, bowed, twisted, dented, cracked, corroded or
rotten;
— check that the stiles/legs around the fixing points for other components are in good condition;
— check that fixings (usually rivets, screws or bolts) are not missing, loose, or corroded;
— check that rungs/steps are not missing, loose, excessively worn, corroded or damaged;
— check that the hinges between front and rear sections are not damaged, loose or corroded;
— check that the locking stays horizontal, back rails and corner braces are not missing, bent, loose,
corroded or damaged;
— check that the rung hooks are not missing, damaged, loose or corroded and engage properly on
the rungs;
— check that guide brackets are not missing, damaged, loose or corroded and engage properly on
the mating stile;
— check that ladder feet / end caps are not missing, loose, excessively worn, corroded or damaged;
— check that the entire ladder is free from contaminants (e.g. dirt, mud, paint, oil or grease);
— check that locking catches (if fitted) are not damaged or corroded and function correctly;
— check that the platform (if fitted) has no missing parts or fixings and is not damaged or corroded.
If any of the above checks cannot be fully satisfied, you should NOT use the ladder.
For special ladder types, further items identified by the manufacturer shall be taken into account.

Reasons for accidents
The following list of hazards and examples of their causes, which is not exhaustive, are common
reasons for accidents encountered when using ladders and are the basis on which the information in
this manual has been developed:
a) Loss of stability:
1. Incorrect positioning of the ladder (such as incorrect angle for leaning ladder or not fully
opening a standing ladder);
2. slide outwards at the bottom (such as bottom of leaning ladders sliding away from the wall)
3. side slip, falling sideways and top flip (such as overreaching or fragile top contact surface);
4. falling sideways
5. condition of the ladder (such as missing anti-slip feet);
6. stepping off an unsecured ladder at height;
7. ground conditions (such as unstable soft ground, sloping ground, slippery surfaces or
contaminated solid surfaces);
8. Adverse weather conditions (such as windy conditions);
9. collision with the ladder (such as vehicle or door
10. incorrect choice of ladder (such as too short, unsuitable task).
b) From handling:
1. Transferring the ladder to the work position;
2. erecting and dismantling the ladder;
3. carrying items up the ladder
c) Slip trip and fall of user:
1. Inappropriate footwear;
2. contaminated rungs or Steps;
3. unsafe user practices (such as climbing 2 rungs at a time, sliding down stiles).
4. ground conditions (such as unstable soft ground, sloping ground, slippery surfaces or
contaminated solid surfaces).
d) Structural failure of ladder:
1. condition of the ladder (such as damaged stiles);
2. overloading the ladder.
3. unintended use.
e) Electrical hazards:
1. Unavoidable live working (e. g. fault finding);
2. positioning ladders too close to live electrical equipment (such as overhead power lines);
3. ladders damaging electrical equipment (such as covers or protective insulation);
4. incorrect selection of type of ladder for electrical work.

ENGEX FIBREGLASS LADDERS REPAIR, STORAGE & MAINTENANCE
IMPORTANT MAINTENANCE NOTES
• Ladders must not be used without ladder foot and end caps
• If discovered on the daily inspection that the ladders has a broken rail, rung or
any other defect, the ladder must be labelled UNFIT FOR USE and quarantined or
alternatively follow your company’s health and safety procedure. If the ladder
cannot be repaired it must be discarded immediately.
• Do not make any temporary repairs. Any repair should be performed by a ladder
repair specialist.
• Store the ladders upright, indoors, in a dry ventilated area out of direct sunlight.
• The ladders should be stored in area free from accidental damage.
• Do not leave ladders for a prolonged time exposed in direct sunlight.
• There should be nothing placed on the ladders when in storage.
• The ladders should not be exposed to high temperature or high humidity.
• Do not cover any surface cracks or damage.
• Lubricant should be used on the hinged joint frequently to maintain free
movement.
We advise any service or repair work must always be carried out by an authorized service
workshop.
The ladder should be operated in accordance with local health and safety guidelines to
avoid injuring others.
Distributed by: ENGEX
0 Sandersons Way
Blackpool
FY4 4NB
Tel No: 0 253 830900
