Green Power Kempo GPT-E1303 User manual
3
KEMPO JuiceExtractor
GreenPower
Special features
Easy to clean and convenient to use
With the simplified design, the size became smaller and the operation is relatively
easy. Most importantly, extractor is easy to clean.
Extraction of ion-vitalizing fresh juice
The far infrared irradiating materials and magnetic wire installed in the fresh juice
cup and clean gear (Twin gear) help in the ion-vitalization of the fresh juice, while
presenting a delightful flavor and removing the unpleasant grass odor.
Separation of agrichemicals and heavy metal
Based on the scientific logic proposed by Norman Walker (American biochemist)
that the heavy metal and fiber (Pulp) separated after mashing and crushing
vegetables are combined with affinity, the Green Power Juice Extractor is specially
designed and created to extract pure fresh juice by discharging the combined
agrichemicals and heavy metal with the vegetable pulp through the utilization of a
complete mashing, crushing, and squeezing method.
Automatic pulp discharge
With the use of Pulp Discharging Knob that is applied depending on the
characteristics of the materials to be extracted, the juice can be extracted more
efficiently.
Multi-functional cooking aid
It is a perfect aid for home-made dishes as various screens can be applied for
vegetable juice extraction as well as for grinding of various ingredients.
High quality juice extraction with low noise
With the application of the super-precise motor and speed reducer, it generates
noise less than 60while realizing high quality juice extraction and other various
functions.
Automatic overheating thermostat
An automatic overheating thermostat is installed to automatically intercept the
power in case of overheating due to excessive use and to restart the machine when
the temperature goes down. Such feature prevents the occurrence of overheating
and suppresses the danger of potential fire.
5
KEMPO JuiceExtractor
GreenPower
4
GreenPower
KEMPO JuiceExtractor
Important safety instructions
The wooden pusher is made out of birch tree,
which is safe to human body, and any part
separated by the Clean Gear (Twin gear) is
discharged together with the pulp, thus, there is no
detrimental effect on the quality and freshness of
the juice.
Do not allow water to seep into the product
when cleaning (It may result to
performance degradation and electric
shock).
Do not boil the parts when cleaning (It
may result to product deformation and
discoloration).
When using the product at home, use it
away from children. After using the
product, store it in a safe place that is out
of reach of children.
Do not unplug the power cord with wet
hands (It may result to electric shock).
Do not insert any hard object (Knife,
chopsticks, etc.) into the feeding chute (It
may result into the damage of the speed
reducer).
Slice the ingredients to be inserted through
the feeding chute in their proper sizes
(Excessive insertion of ingredients
shortens the life of the juice extractor).
When using hard grains, soak them first in
water (For about 6 hours) and then grind
them a little at a time with small amount of
water.
Never put ice into the extractor.
It may damage the parts.
When using the Crush Screen for
fruit ice cream, fruit ice sorbet,
red pepper mincing, etc., remove
the vegetable and fruit knobs
before use.
Clean Gear (Twin gear)
Pulp Discharging part and Vegetable (Fruit) knob
Important safety instructions
1st gear point
2nd gear point
Make sure indicated parts are
properly aligned when combining
the Clean Gear (Twin gear).
Non-alignment may result into
product malfunction and noise
generation.
When assembling the Vegetable (Fruit) knob, properly align the
dented part of the Pulp Discharging Part and the projected part of
the Vegetable (Fruit) knob. Non-alignment may result into product
malfunction.
Since the Vegetable (Fruit) knob has different spring strengths,
adjust the knob depending on the ingredients to ensure a convenient
use of the product (Loosen the knob slightly when having trouble in
discharging the pulp)
Vegetable knob (White)
Fruit knob (Red)
Pulp Discharging Part
Green Power Juice Extractor pursues perfection for the consumers. Owing to misuse
or inappropriate storage, however, it may encounter a technical problem. Please keep
in mind that the life cycle of the product is commensurate to the appropriateness of
product use. Please pay attention to the following basic warnings to ensure the safe
and effective use of the product.
This product is for 110V or 220V use.
(In case of 110 voltages, convert
the voltage to 220 using a transformer.)
Plug for 220V must be used.
6
GreenPower
KEMPO JuiceExtractor
Name and function of each part
Feeding chute
Inlet for ingredients
Lock lever
Clockwise for assembly
Counterclockwise for disassembly
On
:
For operation
Off
:
For operation stop
Reverse
:
Switch down for 1~2 sec. when
the product is stopped by
overload
For a more convenient disassembly, set the switch on
reverse position for 5~10 sec. after using the product
Feeding chute cover
The part covering the feeding chute and
Pulp Discharging Part (Remove any juice
remnants after assembly.)
Fresh juice cup
Use when extracting and storing
fresh juice (Place the cup closely
toward the body.)
Feeding chute handle
Pulp outlet adjusting knob
Power switch
Stainless-steel pulp container
Use when
controlling the
amount of pulp for
extraction of fresh
vegetables and
fruits
7
KEMPO JuiceExtractor
GreenPower
Parts organization and usage
1. Parts organization and usage for GPT-E1303 Standard type
2. Common parts for GPT-E1303 and GPT-E1305
Parts organization and usage for GPT-E1305 Multi-purpose Extractor and GPT-E1303 Standard + Exclusive Pro type
When fix the feeding chute cover
( forward direction ) & Dissemble
it ( backward direction)
Handle
Body
(Installed motor and speed reducer)
8
Assembly for GPT-E1303 Standard type
Assembly for
GPT-E1303 Standard
type
GreenPower
KEMPO JuiceExtractor
9
KEMPO JuiceExtractor
GreenPower
It is very important to make sure that the
Clean Gears are completely aligned.
Ensure the correct placement of the 1st
gear point between the 2nd gear points
as shown in the figure to assemble the
part into the main body.
Align the projected part of the knob and
the dented rail of the Pulp Discharging Part
for their application to the body. Turn those
parts to the right for locking up.
The failure of assembly affects the pulp
discharge as the operation of the knob
spring would be obstructed. Also, it may
result into the damage of the Pulp
Discharging Part (Use the knob properly
depending on the ingredients to be used).
It is very important to make sure that
the Clean Gears are completely
aligned. Ensure the correct placement
of the 1st gear point between the 2nd
gear points as shown in the figure to
assemble the part into the main body.
There should not be any gap between the
body and gears after the gear application,
and the gears should
be placed horizontally.
Place the screen closely towards the body
and then apply.
Completely attach the Pulp Discharging
Part to the screen and place it.
Place the stainless-steel container and fresh juice
cup as shown in the figure and press the power
switch upward to operate the extractor. Insert
ingredients through the inlet and press them using
the wooden pusher.
There should be a gap as shown in the
figure after the screen application is
completed.
Press the inlet lid downward and turn the
lever clockwise to fasten.
Lift up handle pin and push it forward
direction
R L
How to clean
11
KEMPO JuiceExtractor
GreenPower
10
Disassembly for GPT-E1303 Standard type
GreenPower
KEMPO JuiceExtractor
Push the handle pin backward and
down direction
Remove the Pulp Discharging Part from
the Body.
Remove the Clean Gear (Twin gear)
from the Body.
Remove the Screen from the
Body.
Slowly turn the Feeding Chute Handle by
180 degrees in the counterclockwise
direction.
Separate the Feeding Chute Cover from
the Body by lifting it upward.
After use, remove the adjusting knob and clean the
interior of the product by pouring a glass of water
slowly into the extractor in its normal operation
state.
After disassembly, soak the parts and clean them
completely using the cleaning brush.
Unplug and disassemble the extractor.
After cleaning, dry the parts in a well-ventilated
place.
1. Remove the water
completely, being careful not to
introduce any water content in
the body and display part.
(Never soak in or spray water to
the Body ? Electric/Electronics
device protection)
2.When cleaning the parts, do
not boil the parts nor use
chemical products like chlorine
bleach, thinner, and benzene (It
causes deterioration and
discoloration of the product)
Do the reverse rotation when disassembling (For 5~10 sec.)
Disassemble the parts according to the instruction shown in Pg. 10
How to use GPT-E1303 standard type
13
KEMPO JuiceExtractor
GreenPower
12
How to use GPT-E1303 standard type
GreenPower
KEMPO JuiceExtractor
Clean Gear(Twin gear) + Vegetable Screen + Pulp Discharging Part + Vegetable Knob+ Feeding Chute Cover + Wooden Pusher
Fiber texture varies depending on the season so properly adjust the knob when using the extractor.
It is possible to extract vegetable juice more than 3kg consecutively.
The pine needles contain less amount of moisture, thus, it is hard to extract pure juice from it. In such case, perform extraction together with
vegetables with high moisture content to get a perfectly extracted pine needle juice.
Ingredient :
Angelica, kale, and carrot
How to make
Roll the kale leaf in the size
appropriate for juice extraction and
cut the angelica in the size of 5cm.
Quadrisect the carrot.
Assemble the Vegetable Screen and
Vegetable Knob to the Green Power Juice Extractor
and extract juice using the wooden pusher.
Since the taste of angelica and kale is bitter, add a
carrot to make the taste milder for those who have not
tasted it yet.
It is also good to add natural honey instead of a carrot.
Angelica: It is convenient to extract the juice by inserting
the stem and leaf alternately.
Ingredient :
Carrot and beet
How to make
Wash the carrot or beet and slice it
into 4 ~ 6 parts in the size suitable
for insertion into the Feeding Chute
as shown in the figure.
Assemble the Vegetable Screen and
Vegetable Knob to the Green Power Juice Extractor
and extract juice using the wooden pusher.
Pour the fresh juice into a glass.
Carrot: It is the king of fresh juice extraction. The root
and leaves are used, and it is advised to use carrot
without peeling off its skin.
Beet: The root and leaves are used, and it is advised to
drink the juice together with other vegetable juice.
Insert the pointed part of vegetables for each extraction.
Clean Gear (Twin gear) + Vegetable Screen + Pulp Discharging Part + Fruit Knob + Feeding Chute Cover + Wooden Pusher (Fruit Pusher for beans)
Use the Feeding Chute Cover for fruit for the soft vegetables like cucumber, spinach, and lettuce.
Fiber texture varies depending on the season so properly adjust the knob when using the extractor.
In case of extracting juice of all fruits, vegetables, and mixed fruits or making soymilk or bean curd, use the Feeding Chute Cover for fruit for
convenient use.
Ingredient :
Potatoes
How to make
Wash the potatoes
and slice them in the
size suitable for
insertion into the
Feeding Chute.
Assemble the Vegetable Screen and
Fruit Knob to the Green Power Juice
Extractor and extract juice using the
wooden pusher.
Add an apple to get a more flavorful
juice.
It is possible to make pan-fried potato
dish by adding starch with the pulp.
The potato with sprout or green potato is
poisonous so it is not suitable for juice
extraction.
Ingredient :
Soybeans, salt,
bittern water, and
mugwort juice (Carrot, beet, and celery)
How to make
Soak the soybeans in water for about 6 hours.
Assemble the Vegetable Screen and Fruit Knob to the Green Power
Juice Extractor and extract juice by adding some water with the Fruit
Pusher.
Boil the juice while stirring so as not to be scorched. (Add salt to
make soymilk and cool it down, and serve it with boiled noodle for
soybean noodle.)
Mix the mugwort extract to the boiled bean juice (Carrot and beet
juice) and stir after adding a little salt. Leave it for awhile to make
soft bean curd.
Place a cotton cloth in the bean curd frame and pour the soft bean
into the frame. Drain the water from the bean to make bean curd
(Bean curd with mugwort).
The residue of the bean curd is used for Korean stew made with
bean-curd dregs.
Extract the once ground soybean for perfect bean juice extraction.
15
KEMPO JuiceExtractor
GreenPower
14
How to use GPT-E1303 standard type
How to use GPT-E1303 standard type
GreenPower
KEMPO JuiceExtractor
Clean Gear (Twin gear) + Fruit Screen + Pulp Discharging Part + Fruit Knob + Feeding Chute Cover + Fruit Pusher
(The juice from the fruits with high viscosity is hardly extracted so take the pulp-added juice or use the Multi-purpose Extractor.)
Fiber texture varies depending on the season so properly adjust the knob when using the extractor.
It is possible to make fruit juice, fruit ice bar, and salad dressings.
Fruit juice: Fibrous fruits like apples, pears, watermelons, and grapes (Seedless Kyoho grapes)
Ingredient :
Apples
How to make
Wash the apples and slice them
without peeling off the skin.
Assemble the Vegetable Screen and
Fruit Knob to the Green Power Juice
Extractor and extract juice using the
Fruit Pusher.
Pour the juice in a glass. Unlike the commercially
available apple juice, it presents the true taste of an
apple with flesh in it.
Apple: If you want to have a clear juice, extract an apple
after assembling the Fruit Knob to the Vegetable
Screen or use the special part.
Add an orange when extracting apple juice for a fresher
taste.
Extract the non-fresh apples with vegetables or through
the Multi-purpose Extractor.
Ingredient :
Watermelon
How to make
Wash a watermelon and slice it after
peeling off the skin.
Assemble the Fruit Screen and Fruit
Knob to the Green Power Juice
Extractor and extract juice using the
Fruit Pusher.
Savor the fresh taste of watermelon.
Watermelon: Since 99% of the nutrients is contained in
the inner skin, it is advised to use the inner
skin when extracting juice from a
watermelon. Make watermelon juice and
store it in the refrigerator as an excellent
beverage for summer.
Clean Gear (Twin gear) + Crush Screen + Pulp Discharging Part (Knob removed) + Feeding Chute Cover + Fruit Pusher
Fruit ice cream and fruit sorbet Crush for dried red pepper and coffee beans
Various rice cakes (With the use of a steamer after soaking the brown rice in water)
Peanut butter
For meat grinding (Refrigerated and frozen meat) ? Beef, pork, and fish
Ingredient :
Frozen fruits, milk, condensed
milk, jelly, and fruit yogurt
How to make
Assemble the Crush Screen and Pulp
Discharging Part to the Green Power Juice
Extractor and insert the frozen fruits. Extract
using the Fruit Pusher.
Add milk, condensed milk, and fruit yogurt
and decorate with jelly to make a tasty fruit
ice sorbet.
Add sweet red-bean porridge for fruit red-
bean ice sorbet.
Ingredient :
Various fruits (Banana, strawberry, melon, steamed
sweet potato, etc.)
How to make
Wash various fruits and slice them in proper sizes. Remove all
the parts that are not consumed when eating fresh fruits.
Freeze the fruits.
Assemble the Crush Screen and Pulp Discharging Part to the
Green Power Juice Extractor and extract the frozen fruits using
the Fruit Pusher to make a tasty and fresh fruit ice cream.
For those who prefer other flavors, add frozen milk or chocolate
syrup to the fruit ice cream. You may also add walnuts and
almonds to get crunchy texture in your ice cream. It is also
good to mix differently flavored ice creams together.
17
KEMPO JuiceExtractor
GreenPower
16
How to use GPT-E1303 standard type
How to use GPT-E1303 standard type
GreenPower
KEMPO JuiceExtractor
Mincing seasonings for Kimch
Crushes dried red pepper, fresh pepper, garlic, ginger, onion, salted anchovy, salted shrimp, etc.
Possible to store ingredients for a longer period of time without damaging the nutritional value based on the principles
of millstone and mortar
Displays seasoning effect even by inserting half of the required ingredients as the nutrients are perfectly extracted
Good to be used in a restaurant as it presents strong flavor and taste
When making a patty for hamburger, fish cake, sausage, and meatballs (Able to grind refrigerated and frozen beef and
pork, and able to mince fish with bones)
When juicing the root of Dioscorea batatas, tomatoes, aloe, etc.
When making porridge with sesame, pine nut, and pumpkin (Porridge can be easily made with the rice soaked in
water.)
When making pan-fried mung beans and potatoes
With the Green Power Juice Extractor, it is possible to make a delicious jam by
grinding seasonal fruits. It is the joy of the mothers to be able to effectively
present the flavorful taste and nutritional benefits to the family by making a jam.
Easily make jams out of strawberries, apricots, tomatoes, and apples.
Ingredient :
Brown rice, sesame oil, salt, and bean flour
How to make
Wash the brown rice and soak it in water for a night. Place a cloth
in a steamer and make rice.
Season the rice with a little bit of sesame oil and salt.
Assemble the Crush Screen and Pulp Discharging Part to the Green Power Juice Extractor and grind the rice using
the Fruit Pusher.
Injeolmi is ready by covering the rice paste with bean flour.
In case of making sweet rice ball cake, steam the brown rice together with Chinese jujube without the seeds. Extract
the rice paste using the Green Power Juice Extractor. Make the paste into bite-size pieces and cover it with various
types of grain powder.
Ingredient :
Mung bean and salt
How to make
Wash the peeled mung bean and soak it in water.
Assemble the Crush Screen and Pulp Discharging Part to the Green
Power Juice Extractor and grind it using the Fruit Pusher.
Add salt to the ground paste.
Fry the paste on a hot pan. It is also good to add Kimchi, bean sprout, bracken, pork, balloon flower root, onion, etc.
depending on ones taste preference.
It is good to use only mung beans, but brown rice powder or flour seasoned for pan-fried dishes can be mixed in as
well. Also, it is good to fry by adding water-soaked rice to the paste.
Ingredient :
Beef, pork, bean curd, green onion, garlic, salt, sesame, sesame oil, pepper, flour, and eggs
How to make
After assembling the Crush Screen and Pulp Discharging Part to the Green Power Juice Extractor, grind the meat,
green onion, and garlic using the Fruit Pusher.
Make paste by adding bean curd, pepper, salt, sesame, and
sesame oil to the ground ingredients.
Take proper amount from the paste and make it into a ball shape.
Cover the meatball with flour and salt-flavored egg. Pan-fry the
meatball.
Ingredient :
Beef, pork, onion, celery, salt, pepper, bread crumbs,
and eggs
How to make
Assemble the Crush Screen and Pulp Discharging Part to the Green Power Juice Extractor and grind the meat using
the Fruit Pusher.
Chop the onion and celery and fry them on a hot pan.
Mix the pan-fried ingredients with the ground ingredients and make them into paste by adding salt, pepper, bread
crumbs, and eggs.
Shape the paste and fry it on a hot pan.
19
KEMPO JuiceExtractor
GreenPower
18
Parts organization and use for GPT-E1303 (standard+exclusive pro)
and GPT-E1305 (Multi-purpose extractor)
Assembly for GPT-E1303 (Standard + Exclusive Pro type) /
GPT-E1305 (Multi-purpose extractor)
GreenPower
KEMPO JuiceExtractor
1) Since fiber nature varies depending on
the seasons and regions, please change to
a nozzle with a bigger hole in case of
having a problem of extraction.
2) In case of having difficulty for juice
extraction, add other fruits to facilitate a
more convenient extraction.
Strength of GPT-E1305 (Multi-purpose extractor)
1. It makes clear and pure wheatgrass and fruit juices.
2. It displays excellent economic efficiency by enabling high level of juice extraction.
3. It is easy to clean, and extraction is done in a short period of time.
4. The extracted juice tastes good and remains nutrition filled, and it is possible to store the juice for a longer period
of time.
5. It realizes perfect hygiene through the installedClean Systemthat does not generate iron and plastic powder.
6. The assembly and disassembly are easily done, and the price is reasonable.
Things to note for the use of GPT-E1305 (Multi-purpose extractor)
1. It is hard to extract juice when using only strawberry and kiwi. Please add other fruits or vegetables to facilitate a
better extraction.
2. UseClean Gear (Twin gear)for the vegetables with thick stems and large leaves, such as angelica and kale, or
rooted vegetables such as carrots, beets, and potatoes. - Extra purchase
3. The extraction is higher and faster as the ingredients are gently pressed.
4. Since the characteristics of fruits and vegetables vary depending on various aspects such as seasons, regions,
countries, level of freshness, etc., it is advised to change a nozzle in case of having difficulty in extracting juice. (It
is necessary to use the nozzle with big hole when extracting the juice from old fruits or vegetables. - Be sure to
wash the screen as well.)
Warning! When extracting pomegranate, grapes, or vegetables with seeds, the Wheatgrass Screen must be used
(Stainless-steel). The use of the Fruit Screen (Acetal) in the extraction of seeded fruits or vegetables may result
into damaging the screen.
[1] W (Wheatgrass) [3] G-S (Grape with seed) [5] P-S (Small pomegranate) [8] O (Orange)
(Failure to do so may result
into an extraction problem
and part damage when using
the Vegetable/Fruit Screen.)
Apply the gear to be used and the
screen to the Multi-Purpose Gear.
Press the Feeding Chute Cover down
and life up the handle lock pin and push
it forward direction.
Closely press the Crush Screen into
the Body to place it (The Crush Screen
must be used).
Place the knob for the Multi-purpose
Gear to the Pulp Discharging Part
(Letter should be seen).
There should be a 4mm gap as shown
in the figure after assembling the Pulp
Discharging Part.
Lock Lever
How to use GPT-E1303 (Advanced type) /
GPT-E1305 (Multi-purpose extractor)
21
KEMPO JuiceExtractor
GreenPower
20
Disassembly for GPT-E1303 (Standard + Exclusive Pro type) /
GPT-E1305 (Multi-purpose extractor)
GreenPower
KEMPO JuiceExtractor
Push the handle pin backward and
down direction.
Remove the Pulp Discharging Part
from the Body.
Remove the Stainless-steel Screen
using the longer side of the Multi-
purpose Gear.
Remove the Screen from the Body.
Slowly turn the Feeding Chute Handle by
180 degrees in the clockwise direction.
(The handle may run idle and may be
damaged if it is turned fast.)
Separate the Feeding Chute Cover
from the Body by lifting it upward.
Turn the Nozzle to the left to remove.
ppeecciiaalliieeddnnoolleesseelleeccttaannoolleeddeeppeennddiinnggoonniinnggrreeddiieennttssttoobbeeeexxttrraacctteedd..
W (Wheatgrass)
1. Wheatgrass 2. Melon 3. Oriental
melon 4. Pear (Hard) 5. Houttuynia
cordata Thunberg
T-L (Big-sized tomato)
1. Tomato (Big) 2. Wild grape
G-S (Grape with seeds,
small-sized grapes)
1. Grape (With seeds)
G-L (Seedless grapes,
big-sized grapes)
1. Grape (Seedless) 2. Apple (Hard) 3.
Melon (With seeds) 4. Celery 5. Soymilk
P-S (Small-sized pomegranate)
1. Pomegranate (Small seeds)
2. Apple (Hard)
P-L (Big-sized pomegranate)
1. Pomegranate (Big seeds)
W.M (Watermelon)
1. Watermelon 2. Water parsley 3. Pear
(Hard) 4. Mugwort
5. Paprika 6. Chives
O (Orange)
1. Orange 2. Pear (Soft) 3. Apple (Soft)
4. Cherry tomato
5. Grapefruit 6. Tangerine
7. Celery 8. Spinach
Multi-purpose Gear + Fruit Screen + Wheatgrass Screen Crush Screen Pulp Discharging Part + Nozzle (Select a type) +
Feeding Chute Cover + Fruit Pusher
(The juice from fruits with high viscosity like strawberry and tomato are not solely extracted. In that case, take the minced fruit as porridge type
or insert other fruits alternately in the middle of its extraction.)
Since fiber nature varies depending on the season, please change the nozzle for the effective use of extractor.
The Stainless-steel Screen must be used for seeded fruits like pomegranate and grapes < Stainless-steel Screen> (The use of the Fruit
Screen in the extraction of seeded fruits or vegetables may result into damaging the screen.)
The Fruit Screen may be used instead of the Stainless-steel Screen when extracting seedless fruits. (The Fruit Screen is easy to clean.)
23
KEMPO JuiceExtractor
GreenPower
22
How to make pasta / noodle with GPT-E1303 (Standard +
Exclusive Pro type) / GPT-E1305 (Multi-purpose extractor)
Information on parts purchase for multi-purpose extractor and
Standard
extractor
GreenPower
KEMPO JuiceExtractor
How to make pasta / noodle with GPT-E1303 (Standard + Exclusive Pro type) /
GPT-E1305 (Multi-purpose extractor)
[How to make dough for pasta/noodle]
- Mix 500g of flour + 150cc of Vegetable juice (Water) + a little bit of salt + 3T of vegetable oil together.
- The dough should be neither watery nor thick so that it can be broken into small pieces.
Udong noodle (For 5 persons)
Ingredients :
500g of flour, 150cc of water, a little bit of salt,
and 3T of vegetable oil
How to make
Mix flour and vegetable oil well so as not to be lumpy,
and then add salt.
Assemble Pasta Screen and Pasta Outlet to the Green
Power Juice Extractor.
Insert the dough little by little using a spoon.
Cut the noodle discharged from the outlet into the
proper length.
Hot noodle soup
Ingredients :
500g of flour, 150cc of water, a little bit of salt,
and 3T of vegetable oil
How to make
Mix flour and vegetable oil well so as not to be lumpy,
and then add salt.
Assemble Pasta Screen and Pasta Outlet to Green
Power Juice Extractor.
Insert the dough little by little using a spoon.
Cut the noodle discharged from the outlet into the
proper length.
Information on parts purchase for multi-purpose
extractor and general extractor
1. Those who have purchased GPT-E1303 Standard type can purchase the extra set of
Multi-purpose Extractor.
2. Those who have purchased GPT-E1303 Multi-purpose Extractor can purchase the
extra standard set.
3. How to purchase: Contact the main office or the store where you purchas the product.
4. GPT-E1306 Silver type (Simple type) is designed for the convenience of the elderly or
those people who only need the function of vegetable extraction. The user s manual for
this product is provided separately.
25
KEMPO JuiceExtractor
GreenPower
24
Trouble shooting
GreenPower
KEMPO JuiceExtractor
How to replace the fuse and product specification
Having noise from the
Clean Gear (Twin gear)
during the product
operation
Operation failure
1) Make sure if the power supply is a reasonable power.
2) Is the power cord properly plugged to the socket?
3) Is the fuse ok?
4) Have you used the extractor excessively?
(An automatic overheating thermostat is installed in the machine to
automatically intercept the power in case of overheating generated by
excessive use and to restart it when the temperature goes down. Please wait
for about 30 minutes in such case.)
When Clean Gear is
stopped during the
product operation
1) Have you inserted too much ingredients into the Feeding Chute?
(Perform reversed rotation for 2~3 sec. when the machine is stopped owing
to the excessive insertion of ingredients.)
2) Is there any foreign substance in the Feeding Chute?
(Stop operation when a foreign substance is introduced and unplug the
machine. Disassemble it as shown in Pg.8 to remove the foreign substance.)
1) Are the Clean Gears (Twin gear) assembled as shown in the figure below?
(2 parts on the left, 1 part on the right)
2) Are the assembled Clean Gears (Twin gear) completely attached on the
fixing axis on the body?
3) Is there any foreign substance at the dented part where axis A is placed?
Check-up point
Problem
1. Slightly press the fuse holding knob
counterclockwise as shown in the figure.
By turning it 1/3 in the counterclockwise
direction, it can be disassembled.
2. Remove the damaged fuse and replace it
with a new one.
3. Press the knob slightly and turn it
clockwise for assembly. By turning it 1/3
in the clockwise direction, it can be
assembled.
The fuse of the product is located on the bottom of the body. For
performing fuse replacement, please follow the following
instructions.
odel lectricitycertification
roductame reenpoweruiceExtractor
ower W
perationtime min.
Dimensions .mer
etweight (W)(D)()
Electricitycertification .g
GreenPower
KEMPO JuiceExtractor
26
Theproductwarrantyisavailableasfollows
Informationonconsumer’scompensationfortheloss
Product name Electric juice extractor
Product No.
Date of purchase
Address
Name TEL
Address
Name TEL
Customer
Sales store
odelname Warrantyperiod
GPT-1303GPT-1305GPT-1306
ear
1. It is a product that is manufactured through the strict quality management and testing
process.
2. In case of having a technical problem under normal operating condition, the Service Center
of the main office offers free repair service for the below stated warranty period.
3. In case of requiring service charge during the warranty period, the repair service is to be
offered as well.
4. Please present the Certificate of Warranty when requesting for a repair service.
5. This Certificate of Warranty is effective only in Korea.
6. Consumable supplies (Wooden pusher, cleaning brush, etc.) are not covered by the warranty
period.
7. In case the product is used for business purposes (Sales activity, use under abnormal
situation, etc.), the warranty period shall not be applied.
8. If a product is taken to the Service Center and is judged as not to have a technical problem,
the service charge shall be asked.
9. The quality warranty of motors and speed reducers are 5 years but Twin gear and screen are
just only 1 year.
Type of consumer’s loss
Detail of compensation
During warranty period
After warranty
period
In case of
naturally
generated
functional and
performance
malfunction under
the normal
product use
In case of
functional and
performance
malfunction
In case of repair request for the important parts
within the 1 month after the product purchase
Repair available
Repair unavailable (Except for the case that has an
exterior problem, away from functional or
performance failure)
Repair
available
(Period of parts
availability)
Free repair
Free repair
Free part replacement
Free part replacement
Repair with charge
Product replacement
after charging the
amount applicable to the
charged repair service
Repair with charge
Repair with charge
Repair with charge
Repair unavailable
Repair with charge
Replacement after
depreciating
Refund after adding 10%
to the depreciated amount
Based on the standard
stipulated by our
company
Mechanical problem generated by
the same defect up to 3 times
Mechanical problem generated by
the same defect up to 4 times
Repair unavailable regardless of
parts availability
Repair unavailable due to the
unavailability of required parts
This manual suits for next models
2
Table of contents
Other Green Power Kitchen Appliance manuals
Popular Kitchen Appliance manuals by other brands
Agu
Agu PMBF2 user manual
Ves Electric
Ves Electric V-TO-3 instruction manual
Char-Broil
Char-Broil MULTI PURPOSE COOKER 11101706 Product guide
U-Line
U-Line 2224ZWCS-15B User guide & service manual
Cuisinart
Cuisinart Smart Stick CSB-77 INSTRUCTION AND RECIPE BOOKLET
Zephyr
Zephyr UWN24C02BG Use, care and installation guide
