GreenIQ GIQ-SYS-EU-8C1 User manual
EN
EN
1. Your GreenIQ Smart Garden Hub
Thank you for purchasing the GreenIQ
Smart Garden Hub. GreenIQ allows
you to easily control your garden's
irrigation and lighting, and save money
on your water and electricity bills. Your
GreenIQ:
•Automatically adjusts irrigation
scheduling based on current and
forecasted weather.
•Controls your landscape lighting
based on sunrise and sunset
schedule.
•Connects to the Internet wirelessly
or via an Ethernet cable.
•Connects to weather, soil moisture,
fertilizer-content and flow sensors.
2. GreenIQ’s Mobile Apps
Please use one of the following mobile
apps to setup and control your Hub:
iOS: http://apple.co/1s9clEw
Android: http://bit.ly/1VhOvSs
Web: https://greeniq.net
EN
You can download GreenIQ’s mobile
app by scanning one of the following
QR codes:
iOS
Android
Web app
EN
3. Setting up your GreenIQ Smart
Garden Hub
Please read the latest setup
instructions in the following link:
http://support.greeniq.co
GreenIQ Support
In this link you’ll find useful resources
for setting up your GreenIQ,
connecting to sensors, connecting to
your landscape lighting and integrating
with popular home automation
platforms such as IFTTT, Amazon
Echo and many more.
EN
4. Your GreenIQ Smart Garden Hub
1. Front Cover
2. Status Indicator
3. Optical Sensor
4. Power Adapter Port
5. Terminals (x3)
6. Back Cover
7. Mounting Holes (x2)
EN
5. Installation Instructions
Warnings
•Incorrect installation might damage
the device, and even cause serious
injuries or death from electrical
shock.
•Do not plug or apply power to the
unit until you have compiled and
checked all wiring connections.
•Before connecting or disconnecting
wires to the unit, disconnect the the
power adapter from the mains inlet.
•When completing installation, make
sure that there are no exposed wire
ends.
•Always use the provided GreenIQ
power adapter.
•Never open the device’s enclosure.
•Do not attempt to link two or more
units using a single power adapter.
•To prevent damage to the unit,
connect only one valve to each
open zone wire.
•Always use water-tight connectors
for all wires splice connections.
EN
Selecting a Location
The unit’s location should meet the
following criteria:
1. The unit is not waterproof, and
therefore should be installed in a
dry location, either indoor or inside
a protective enclosure outdoors.
2. The unit’s operating temperature
range is 0°C to 40°C (32°F to
104°F). Please avoid exposing the
unit to direct sunlight or other heat
sources.
3. If you plan to use the unit in Wi-Fi
or 3G Mode, you have to make
sure that there is a good wireless
signal reception at the unit’s
location.
4. Make sure that electrical outlet and
the irrigation valve wires are
available at the unit’s location.
5. The electrical outlet shall be
located near the GreenIQ Hub and
shall be easily accessible.
EN
Mounting
1. Use the unit’s mounting holes on
the back to mount it on a wall.
2. The distance between the two
mounting holes is 76mm / 3 inch.
EN
Connecting the unit to the irrigation
valves
There are several types of irrigation
valves in the market. The GreenIQ
Smart Garden Hub supports only
24VAC valves.
Warning: Never shortcut a GreenIQ
wire with other GreenIQ wire.
Wiring example
EN
GreenIQ Terminals
Left Terminal:
V-1: Valve 1
V-2: Valve 2
V-3: Valve 3
V-4: Valve 4
V-5: Valve 5
V-6: Valve 6
V-7: Valve 7
V-8: Valve 8*
COM: Common
* V-8 Can be configured to control a master
valve for V-1 to V-7.
Right Terminal (valid only on 16-
zones products):
V-9: Valve 9
V-10: Valve 10
V-11: Valve 11
V-12: Valve 12
V-13: Valve 13
V-14: Valve 14
V-15: Valve 15
V-16: Valve 16**
COM: Common
** V-16 Can be configured to control a master
valve for V-9 to V-15.
EN
Top Terminal:
ACI: Unused
COM: Common
ACO: 24VAC Output
L1: Lighting 1 Output***
L2: Lighting 2 Output***
P: Fertilizer Pump Output***
5V: 5VDC Output for sensors
GND: DC Ground for sensors
S1: Sensor 1 Input
S2: Sensor 2 Input
S3: Sensor 3 Input
F: Flow Meter Input
*** An external relay is required. The relay is
sold separately on our website and selected
stores.
EN
6. Technical Specifications
Size and Weight:
• Smart Garden Hub:
◦Diameter: 16.0 cm (6.3 inches)
◦Depth: 2.7 cm (1.06 inches)
◦Weight: 260 grams (9.17 oz.)
• Package
◦Height: 10.0 cm (3.94 inches)
◦Width: 19.0 cm (7.48 inches)
◦Depth: 19.0 cm (7.48 inches)
◦Total Weight: 1.3Kg (2.87 lb.)
Irrigation zones:
• 8 or 16 irrigation valves.
• Voltage rating: 24VAC
• Valve maximum current rating:
250mA
Power Adapter:
• Output: 24VAC, 1A (included)
Communication:
• Wi-Fi Model: Supports 802.11 b/g/n
• Cellular Model: HSDPA
Operating Requirements:
• Operating Temperature: -20° to
55°C (-4° to 131°F)
• Relative humidity: up to 95% non-
condensing
EN
Part Numbers:
GIQ-SYS-EU-8C1\XX - Wi-Fi, 220VAC, 8 zones
GIQ-SYS-US-8C1\XX - Wi-Fi, 120VAC, 8 zones
GIQ-SYS-EU-8C2\XX - Cell, 220VAC, 8 zones
GIQ-SYS-US-8C2\XX - Cell, 120VAC, 8 zones
GIQ-SYS-EU-8C3\XX - Wi-Fi+CELL, 220VAC, 8 zones
GIQ-SYS-US-8C3\XX - Wi-Fi+CELL, 120VAC, 8 zones
GIQ-SYS-EU-16C1\XX - Wi-Fi, 220VAC, 16 zones
GIQ-SYS-US-16C1\XX - Wi-Fi, 120VAC, 16 zones
GIQ-SYS-EU-16C2\XX - Cell, 220VAC,16 zones
GIQ-SYS-US-16C2\XX - Cell, 120VAC, 16 zones
GIQ-SYS-EU-16C3\XX - Wi-Fi+CELL, 220VAC, 16 zones
GIQ-SYS-US-16C3\XX - Wi-Fi+CELL, 120VAC, 16 zones
EN
EN
FR
1. Votre Terminal intelligent pour jardin
GreenIQ
Nous vous remercions d’avoir acheté le
Terminal intelligent pour jardin
GreenIQ. Le terminal GreenIQ vous
permet de contrôler facilement
l’irrigation et l’éclairage de votre jardin
tout en vous faisant économiser de
l’argent en ce qui concerne les factures
d’eau et d’électricité. Votre terminal
GreenIQ :
•Règle de manière automatique la
programmation de l’irrigation en
fonction des conditions
météorologiques actuelles et
prévues.
•Contrôle l’éclairage de votre
paysage en fonction du lever du jour
et de la tombée de la nuit.
•Se connecte à l’Internet via le Wi-Fi
ou un câble Ethernet.
•Se connecte aux capteurs
météorologiques, de l’humidité du
sol, de contenu du fertilisant et de
débit.
FR
2. Les Applications mobiles de
GreenIQ
Veuillez utiliser l’une des applications
mobiles suivantes pour configurer et
contrôler votre terminal :
iOS : http://apple.co/1s9clEw
Androïde : http://bit.ly/1VhOvSs
Web : https://greeniq.net
Vous pouvez télécharger l’application
mobile de GreenIQ en faisant un scan
de l’un des codes QR suivants :
iOS
Androïde
App Web
FR
3. Configuration de votre Terminal
intelligent pour jardin GreenIQ
Veuillez lire les dernières instructions
relatives à la configuration dans le lien
suivant :
http://support.greeniq.co
L’assistance GreenIQ
Dans ce lien, vous trouverez des
ressources utiles relatives à la
configuration de votre terminal
GreenIQ, à sa connexion aux capteurs,
à l’éclairage de votre paysage et à son
intégration à des plateformes
domotiques populaires telles que
IFTTT, Amazon Echo et plus encore.
