GreenTec HXF 2802 User manual

6th Edition 2015

HXF 2800 / 2802 AHS
2

HXF 2800 / 2802 AHS
3
HXF 2800/2802 AHS
Handbook
6. Edition – June 2015
The information contained in this manual is correct at the time of publication.
However, in the course of constant development, changes in specifications are
inevitable. Should you find the information given in this book different to the
machine it relates to please contact the “After Sales Department” for advice
© Greentec Machinery Limited 2015
Please ensure that this manual is handed to the operator before using the
machine for the first time. The operator must fully understand the contents
of this manual before using this machine.
(If the machine is resold the Manual must be given to the new owner!)
Merkurvej 25
DK 6000 Kolding
Danmark
Tlf: [phone]
Email: [e-mail]
http: www.greentec.eu

HXF 2800 / 2802 AHS
4

HXF 2800 / 2802 AHS
5
Contents
Contents .......................................................................................................................5
Introduction..................................................................................................................7
Useful information .......................................................................................................8
General Information.....................................................................................................9
EU Declaration of Conformity...................................................................................10
Vehicle / Tractor Preparation....................................................................................11
Vehicle Ballast..........................................................................................................11
Front weights............................................................................................................11
Rear weights ............................................................................................................11
Factors that affect stability........................................................................................12
Suggestions to increase stability..............................................................................12
Safety..........................................................................................................................13
Safety Recommendations ........................................................................................14
Additional Safety Advice...........................................................................................16
Specifications.............................................................................................................17
Before starting work..................................................................................................17
Setting to work position ............................................................................................17
Tool start ..................................................................................................................18
Tool stop...................................................................................................................18
Overhead power lines...............................................................................................19
Assembly / Disassembly...........................................................................................19
Transport position.....................................................................................................20
Working position.......................................................................................................20
Storage.....................................................................................................................21
Extra equipment.........................................................................................................22
Hydraulic angle adjustment......................................................................................22
Control panel............................................................................................................22
Diagrams.....................................................................................................................23
Splitter Valve............................................................................................................23
Electric diagram........................................................................................................24
Hydraulic diagrams...................................................................................................25
Maintenance...............................................................................................................26
Lubrication................................................................................................................26
Hydraulic Hoses.......................................................................................................26
Oil Supply.................................................................................................................27
Maintenance chart....................................................................................................27
Pins and Bushes ......................................................................................................28
Storage.....................................................................................................................28
Problem solving.........................................................................................................29
GreenTec Warranty....................................................................................................30

HXF 2800 / 2802 AHS
6

HXF 2800 / 2802 AHS
7
Introduction
Dear customer!
Your new Greentec machine is constructed with background in more than 20 years experience with tractor
mounted machines to maintenance of green areas. This machine is produced by the latest technology and
recognized safety regulations, standards and regulations.
We want to make a product available in such a way, that neither the use of the machine during transportation or
maintenance of the machine causes any damage or misunderstandings.
This manual contains information and instructions that are important and useful for maintaining your Greentec
machine's reliability, dependability and value. Please read this manual carefully as it will familiarize you with the
installation, use, care and maintenance. Pay particular attention to the instructions regarding safety.
You are welcome to visit our website www.greentec.eu - where the login via the dealer's access gives you the
latest updates on instructional and part books on our entire product range. The password for dealer log-in:
PUBLISHER
We hope, you will be pleased with your new Greentec machine.
Best regards,
John Christensen
Sales Director Greentec A/S
Greentec’s vision is to develop and sell quality machines for the maintenance of green areas, including in
agriculture, in industry, at airports and in the local sector. Through innovative product development, we will
strive to become a leader in our field.
All machines are developed in a simple and functional design in close cooperation with dealers and end users. It
is our goal to cover every need in the market segment with preferably 2 different solutions. In-depth analysis of
requirements and serious advice to the customer is offered the best solution, where individual needs can be met
through the modularity of the product program.
Our goal is also to offer the best possible after sales service, and a quick and efficient spare parts supply.

HXF 2800 / 2802 AHS
8
Useful information
Before using the machine for the first time, it’s the seller’s responsibility that the buyer is
given this manual, and the seller is sure, that the buyer fully understands the manual’s
contents. If the machine is resold, the manual must be transferred to the new owner.
Please fill out the list below to ensure that the necessary information is at hand when
ordering spare parts etc.
Serial No
Delivery date
Dealer
Tlf./ fax
Merkurvej 25
DK 6000 Kolding
Danmark
Tlf: [phone]
Email: [e-mail]
http: www.greentec.eu
Opening hours: Mon-Fri 8-16

HXF 2800 / 2802 AHS
9
General Information
Read this manual before fitting or operating the machine or accessory. Whenever any doubt
exists contact your local dealer or the GreenTec Service Department for assistance.
Only use ‘Genuine GreenTec Parts’ on GreenTec machinery and
equipment.
DEFINITIONS: The following definitions apply throughout this manual;
DANGER: Alerts to a hazardous situation which will result in death or serious injury if not
observed carefully.
WARNING: Alerts to a hazardous situation which could result in death or serious injury if not
observed carefully.
CAUTION: Alerts to a hazardous situation which could result in damage to the machine
and/or equipment if not observed carefully.
NOTICE: Specific or general information considered important or useful to emphasise.
LEFT HAND (LH) & RIGHT HAND (RH): These terms are applicable to the machine when
fitted to the tractor and viewed from the rear; these terms also apply to tractor references.
SERIAL PLATE
All machines are equipped with a serial number plate containing important information
relating to the machine including a unique serial number used for identification purposes.
Note: Images in this manual are provided for instruction and informational purposes only and
may not show components in their entirety. In certain instances images may appear different
to the actual
machine; where this occurs the general procedure will be basically the same.

HXF 2800 / 2802 AHS
10
Merkurvej 25, DK-6000 Kolding, Denmark
EU Declaration of Conformity
Adapted EEC directive
EG Guideline 2006/42/EF, 89/392/EEC & 98/37/EC
We, GreenTec A/S, Merkurvej 25, 6000 Kolding, hereby declare that in terms of its design,
method of construction and our execution thereof, the item of machinery described below
complies with the basic health and safety regulations of the respective EU Directives.
Product: GreenTec HXF 2802 AHS
Product code: 9992800
Serial no: 58392
Type: Arm System
The EC Declaration only applies if the machine stated above is used in accordance with the
operating instructions.
on behalf of GreenTec A/S
Date: 22.01.2015 Signature:________ _________________________
John Christensen Sales Director
