GreenTec RI 60 User manual

BARRIER MOWER RI 60 –80
FOX REDSKABSRAMME 2302 –2802 –3302
1. UDGAVE 2021
3. EDITION

BARRIER MOWER RI 60 –80

BARRIER MOWER RI 60 –80
A
BARRIER MOWER RI 60 –80
INSTRUCTION MANUAL
3. EDITION –SEPTEMBER 2021
ORIGINAL EDITION
! IMPORTANT !
This GreenTec RI Barrier Mower must be mounted on an approved vehicle with an approved GreenTec
multi carrier for proper operation
It is important that the operator is given a document about "technical documentation and registration
of the machine" as well as the instruction manual for the attachment tool before the machine is put
into use for the first time.
It is important that the operator fully understands the contents before using the machine.
This instruction manual must accompany the machine and must always be available to the operator.
In case of later resale of the machine, the instruction manual must go with the new owner.
The content of the instruction manual is based on information, standards and regulations, valid at the
time of publication.
As our products are under continuous development and improvement, there may be changes in the
specifications.
If there is information that differs from the current machine, updated instructions can be found on our
webpage or b contacting GreenTec - Aftersales department at: [email protected]
MANUFACTURER, NAME AND ADDRESS (a)
Merkurvej 25
DK-6000 Kolding
Danmark
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
Webadresse: www.greentec.eu

BARRIER MOWER RI 60 –80
B
PREFACE
Dear Customer!
Your new GreenTec machine is designed based on almost 30 years of experience with vehicle-mounted
machines for maintenance of green areas.
The machine is manufactured based on the latest technology as well as approved safety regulations,
standards, and regulations.
We want to make a product available in a way that does not cause damage or misunderstandings during use,
during transport or during maintenance of the machine.
The instruction manual contains information and instructions that are important and useful for maintaining
the GreenTec machine's operational safety, reliability, and value.
Therefore, read this instruction manual carefully as it will familiarize you with installation, use, care, and
maintenance. Pay special attention to safety instructions!
You are welcome to visit our website www.grentec.eu - where you can find technical documentation and
access the latest updates of instruction manuals and spare parts books on our entire product range.
We hope you enjoy your new GreenTec machine!
Kind regards
Signature: ___________________________
John Christensen
Owner, GreenTec A/S
GreenTec’s vision is to develop and sell quality machines for the maintenance of green areas, e.g., in agriculture, industry, airports and
the municipal sector. Through innovative product development, we strive to become a leader in our field.
All machines are developed in a simple, functional, and production-friendly design in close collaboration with dealers and end users. It is
our goal to identify all needs in the market segment with a minimum of 2 different solution proposals.
By in-depth analysis of requirements and serious consultancy, the customer must be offered the best possible solution, where individual
needs can also be met through modular construction of the product program.
We also strive to offer the best possible aftersales service and a fast and efficient spare parts supply.

BARRIER MOWER RI 60 –80
C
CONTENT
FABRIKANT, NAVN OG ADRESSE (a).................................................................................................................................................................... A
FORORD........................................................................................................................................................... Fejl! Bogmærke er ikke defineret.
TABLE OG FIGURELISTE ....................................................................................................................................................................................... F
OVERENSSTEMMELSESERKLÆRING (c).............................................................................................................................................................1
1. MASKINDATA OG NYTTIGE OPLYSNINGER (b)..................................................................................... Fejl! Bogmærke er ikke defineret.
1.1 REGISTRERING AF GREENTEC MASKINDATA ................................................................................................................................ 2
1.2 MÆRKEPLADE ................................................................................................................................................................................ 3
1.3 GARANTIBETINGELSER.............................................................................................................. Fejl! Bogmærke er ikke defineret.
1.4 ANVENDELSE MED ANDRE FABRIKATER END GREENTEC ...................................................... Fejl! Bogmærke er ikke defineret.
2. GENEREL INFORMATION ...........................................................................................................................................................................4
2.1 INSTRUKTIONSBOGENS ANVENDELSE.......................................................................................................................................... 4
2.2 DEFINITIONER AF INFORMATIONSKILTE........................................................................................................................................ 4
2.3 DEFINITIONER, BEGREBER OG BETEGNELSER........................................................................ Fejl! Bogmærke er ikke defineret.
3. SIKKERHED................................................................................................................................................................................................5
3.1 LOKAL LOVGIVNING I LANDET HVOR MASKINEN ANVENDES.................................................. Fejl! Bogmærke er ikke defineret.
3.2 ADVARSEL, FORBUD OG ANVISNINGER......................................................................................................................................... 5
3.3 SIKKERHEDSMÆRKNING ......................................................................................................... Fejl! Bogmærke er ikke defineret.
3.3.1 PERSONLIGT SIKKERHEDSUDSTYR –MÆRKATER............................................................ Fejl! Bogmærke er ikke defineret.
3.3.2 ADVARSELSMÆRKATER ...................................................................................................... Fejl! Bogmærke er ikke defineret.
3.4 ARBEJDE PÅ OFFENTLIGT TILGÆNGELIGE STEDER................................................................. Fejl! Bogmærke er ikke defineret.
3.4.1 ADVARSELSSKILTE PÅ OFFENTLIGE STEDER...................................................................... Fejl! Bogmærke er ikke defineret.
3.4.2 ANVENDELSE AF ADVARSELSSKILTE .................................................................................. Fejl! Bogmærke er ikke defineret.
3.4.3 FORESLÅET SKILTNING VED ARBEJDE PÅ OFFENTLIG VEJ................................................. Fejl! Bogmærke er ikke defineret.
3.5 ANBEFALINGER FOR OPTIMAL SIKKERHED OG DRIFT (l) ........................................................ Fejl! Bogmærke er ikke defineret.
3.6 NØDVENDIGE SIKKERHEDSFORANSTALTNINGER (m)............................................................. Fejl! Bogmærke er ikke defineret.
3.7 ADVARSLER OM MÅDEN MASKINEN IKKE MÅ ANVENDES PÅ (h) ........................................... Fejl! Bogmærke er ikke defineret.
3.8 SIKKERHEDSANVISNINGER FOR VEDLIGEHOLD, JUSTERING OG INSPEKTIONSARBEJDE (s)Fejl! Bogmærke er ikke defineret.
3.9 SIKKERHEDSANVISNINGER FOR DEN DRIFTSANSVARLIGE / OPERATØR .............................. Fejl! Bogmærke er ikke defineret.
4. MASKINBESKRIVELSE, KOMPONENTER OG SPECIFIKATIONER......................................................... Fejl! Bogmærke er ikke defineret.
4.1 MASKINBESKRIVELSE (d).............................................................................................................................................................13
4.2 ANVENDELSE AF MASKINEN..................................................................................................... Fejl! Bogmærke er ikke defineret.
4.2.1 MASKINENS TILSIGTEDE BRUG (g).........................................................................................................................................15

BARRIER MOWER RI 60 –80
D
4.2.2 MASKINENS ANVENDELSESOMRÅDE OG BEGRÆNSNINGER (h) ........................................................................................ 15
4.3 MASKINENS KOMPONENTER/HOVEDDELE.............................................................................. Fejl! Bogmærke er ikke defineret.
4.3.1 BASISOPHÆNG TIL PÅBYGNING INKL. 2,5 M HYDRAULIKSLANGESÆT ............................Fejl! Bogmærke er ikke defineret.
4.3.2 FJEDERPÅVIRKET TILPASNING (”BREAK-BACK”-SYSTEM).................................................................................................... 17
4.3.3 VIPPELED (”TILT-FUNKTION”) FOR TILPASNING TIL TERRÆN ............................................Fejl! Bogmærke er ikke defineret.
4.3.4 HYDRAULIKMOTOR: 25 ELLER 40 L/MIN............................................................................Fejl! Bogmærke er ikke defineret.
4.3.5 GUMMIBESKYTTELSE OMKRING KLIPPEHOVED.................................................................Fejl! Bogmærke er ikke defineret.
4.3.6 KLIPPEHOVED MED KNIVBLADE INKL. STØTTETALLERKEN UNDER KNIVE.......................Fejl! Bogmærke er ikke defineret.
4.3.6.1 TYPER AF KNIVBLADE................................................................................................Fejl! Bogmærke er ikke defineret.
4.4 GODKENDTE ARBEJDSREDSKABER (n) .......................................................................................................................................22
4.5 SPECIFIKATIONER .........................................................................................................................................................................23
4.6 STØJMÅLING AF LUFTBÅREN STØJ (u) .........................................................................................................................................24
5. INSTRUKTIONER FOR BRUG AF MASKINEN (k) ..................................................................................................................................... 25
5.1 INSTRUKTIONER VEDRØRENDE LEVERING AF MASKINEN...................................................... Fejl! Bogmærke er ikke defineret.
5.2 INSTRUKTIONER FOR MONTAGE, TILKOBLING OG FRAKOBLING (j)...........................................................................................26
5.2.1 FORBEREDELSE AF KØRETØJ ..............................................................................................Fejl! Bogmærke er ikke defineret.
5.2.2 MONTAGE OG TILKOBLING AF MASKINEN (i) ........................................................................................................................ 26
5.2.3 MONTAGE AF RI-KANTKLIPPER PÅ REDSKABSRAMME ........................................................................................................ 27
5.2.4 AFMONTERING AF RI-KANTKLIPPER PÅ KØRETØJ ..............................................................Fejl! Bogmærke er ikke defineret.
5.2.5 STABILITET (o)......................................................................................................................................................................... 34
5.2.5.1 KONTROL AF STABILITET: ..........................................................................................Fejl! Bogmærke er ikke defineret.
5.2.5.2 STABILITETEN KAN ØGES VED AT: ............................................................................Fejl! Bogmærke er ikke defineret.
5.2.5.3 FAKTORER DER HAR INDFLYDELSE PÅ STABILITETEN:............................................Fejl! Bogmærke er ikke defineret.
5.3 KLARGØRING AF MASKINEN TIL IBRUGTAGELSE..................................................................... Fejl! Bogmærke er ikke defineret.
5.3.1 FØRSTE OPSTART OG IBRUGTAGNING.................................................................................Fejl! Bogmærke er ikke defineret.
5.3.2 PROCEDURER FØR IBRUGTAGNING.....................................................................................Fejl! Bogmærke er ikke defineret.
5.4 BETJENING AF MASKINEN (e).......................................................................................................................................................36
5.4.1 OPLÆRING AF MASKINOPERATØR FØR IBRUGTAGELSE....................................................Fejl! Bogmærke er ikke defineret.
5.4.2 OPERATØRENS ARBEJDSPLADS (f)........................................................................................................................................ 37
5.4.3 TRANSPORT AF REDSKABSRAMME OG ARBEJDSREDSKAB PÅ KØRETØJ (p)...................................................................... 37
5.4.4 KØRSELSVEJLEDNING (VIST MED FOX REDSKABSRAMME)................................................................................................. 38
5.4.5 INDSTILLING OG JUSTERING AF MASKINEN (r)..................................................................................................................... 41
5.4.5.1 INDSTILLING AF PÅKØRSELSSIKRING (”BREAK-BACK”-SYSTEM).............................................................................. 41
5.4.5.2 JUSTERING AF KNIVDIAMETER..................................................................................Fejl! Bogmærke er ikke defineret.
5.4.6 START AF RI-KANTKLIPPER PÅ GREENTEC REDSKABSRAMME..........................................Fejl! Bogmærke er ikke defineret.
5.4.7 STOP AF ARBEJDSREDSKAB PÅ GREENTEC FOX REDSKABSRAMME.................................................................................. 44

BARRIER MOWER RI 60 –80
E
5.4.8 IGANGSÆTNING EFTER UTILSIGTET DRIFTSSTOP (q)............................................................................................................45
6. EFTERSYN OG VEDLIGEHOLD (e, r).........................................................................................................................................................46
6.1 INSTRUKTIONER OM SIKKERT VEDLIGEHOLD OG JUSTERING (s)..............................................................................................47
6.1.1 KORREKT FLYT AF DIN GREENTEC MASKINE ..................................................................... Fejl! Bogmærke er ikke defineret.
6.2 DAGLIGE OG RUTINEMÆSSIGE EFTERSYN (e) ............................................................................................................................48
6.3 TILSPÆNDING AF BOLTE OG HYDRAULIKFORBINDELSER ...................................................... Fejl! Bogmærke er ikke defineret.
6.3.1 TILSPÆNDING AF BOLTE...................................................................................................... Fejl! Bogmærke er ikke defineret.
6.3.2 TILSPÆNDING AF HYDRAULIKFORBINDELSER................................................................... Fejl! Bogmærke er ikke defineret.
6.4 HYDRAULISKE SLANGER ........................................................................................................... Fejl! Bogmærke er ikke defineret.
6.5 BØSNINGER, NAGLER OG LEJER............................................................................................... Fejl! Bogmærke er ikke defineret.
6.6 SMØRING AF RI-KANTKLIPPER....................................................................................................................................................52
6.7 RENGØRING/VASK AF MASKINEN ............................................................................................ Fejl! Bogmærke er ikke defineret.
6.8 OPBEVARING AF MASKINEN...................................................................................................... Fejl! Bogmærke er ikke defineret.
6.9 BORTSKAFFELSE AF MASKINE/MASKIN-DELE............................................................................................................................53
7. FEJLFINDING PÅ MASKINEN ................................................................................................................ Fejl! Bogmærke er ikke defineret.
7.1 FEJLFINDINGSPROCEDURER .................................................................................................... Fejl! Bogmærke er ikke defineret.
8. BILAG..................................................................................................................................................... Fejl! Bogmærke er ikke defineret.
8.1 HYDRAULIKDIAGRAMMER............................................................................................................................................................56

BARRIER MOWER RI 60 –80
F
TABLES AND FIGUREES
TABLES IN THIS INSTRUCTION MANUAL
TABLE 1 –MASKINER OMFATTET AF OVERENSSTEMMELSESERKLÆRING......................................................................................................1
TABLE 2 –ERKLÆREDE INTERNATIONALE STANDARDER FOR MASKINEN. ................................................Fejl! Bogmærke er ikke defineret.
TABLE 3 –FORMULAR TIL MASKINDATA.............................................................................................................................................................2
TABLE 4 –MÆRKEPLADENS INDHOLD...............................................................................................................................................................3
TABLE 5 –DEFINITIONER, BEGREBER OG BETEGNELSER I DENNE INSTRUKTIONSBOG.................................................................................4
TABLE 6 –OVERSIGT OVER STANDARDUDSTYR PÅ GREENTEC RI-KANTKLIPPER......................................................................................... 14
TABLE 7 –OVERSIGT OVER OLIEFORSYNING: RI KANTKLIPPER 60 & 80 ...................................................................................................... 19
TABLE 8 –OVERSIGT OVER TYPER AF KNIVBLADE: RI-KANTKLIPPER 60 & 80 ............................................................................................. 22
TABLE 9 –GODKENDTE ARBEJDSREDSKABER OG STANDARDUDSTYR: RI-KANTKLIPPER 60 & 80............................................................ 22
TABLE 10 –DATABLAD OVER MASKINENS SPECIFIKATIONER: RI-KANTKLIPPER 60 & 80........................................................................... 23
TABLE 11 –TILSPÆNDINGSMOMENTER VED SAMLING OG MONTERING AF MÆNGDEDELER OG HYDRAULIKFORBINDELSER............... 31
TABLE 12 –GUIDE OVER MONTAGE SAMT TILKOBLING AF HYDRAULIKFORBINDELSER TIL KØRETØJ........................................................ 32
TABLE 13 –DATABLAD FOR HYDRAULIKFORBINDELSER: MONTAGE OG TILKOBLING AF FOX REDSKABSRAMME .................................... 33
TABLE 14 –TJEKLISTE FOR DAGLIGE EFTERSYN FØR IDRIFTSÆTTELSE....................................................................................................... 48
TABLE 15 –TJEKLISTE FOR HALVÅRLIGT EFTERSYN –FOREBYGGENDE VEDLIGEHOLD.............................................................................. 49
TABLE 16 –TILSPÆNDINGSMOMENTER FOR BOLTE ..................................................................................................................................... 50
TABLE 17 –TILSPÆNDINGSMOMENTER FOR HYDRAULIKFORBINDELSER................................................................................................... 50
TABLE 18 –OVERSIGT OVER BORTSKAFFELSE/SKROTNING AF MASKINDELE............................................................................................. 54
TABLE 19 –IDENTIFICERING AF FEJLTILSTANDE ............................................................................................................................................ 55
FIGURES IN THIS INSTRUCTION MANUAL
FIGURE 1 –MÆRKEPLADE FOR GREENTEC-MASKINE ......................................................................................................................................3
FIGURE 2 –SIKKERHEDSMÆRKNING: PERSONLIGT SIKKERHEDSUDSTYR ....................................................................................................5
FIGURE 3 –SIKKERHEDSMÆRKNING: ADVARSELSMÆRKATER ......................................................................................................................6
FIGURE 4 –FORESLÅET SKILTNING VED ARBEJDE PÅ OFFENTLIG VEJ........................................................Fejl! Bogmærke er ikke defineret.

BARRIER MOWER RI 60 –80
1
DECLARATION OF CONFORMITY (c)
ACC. TO MACHINERY DIRECTIVE 2006/42/EC, ANNEX II.A
Manufacturer: GreenTec A/S
Company Address: Merkurvej 25
Zip code and city: DK-6000 Kolding
We, GreenTec, declare under all responsibility that the machine:
TYPE:
PRODUCT:
CAN BE MOUNTED ON:
Barrier Mower
RI 60
(9990060R-25, 9990060L-25, 9990060R-40,
9990060L-40)
RI 80
(9990080R-25, 9990080L-25, 9990080R-40,
9990080R-40)
FOX Multi Carrier
HXF Multi Carrier 2302
HXF Multi Carrier 2802
Table 1 –Machines covered by declaration of conformity
has been manufactured in accordance with the Machinery Directives 2006/42 / EC and 2014/68 / EU of
the European Parliament and of the Council with reference to the following standards associated with its
design, construction, and production:
NAME:
DECRIPTION:
DS/EN ISO 12100:2011
Machine safety - General principles for design - Risk assessment and risk
reduction
DS/EN 14120:2015
Safety of machinery - Guards - General requirements for the design and
construction of fixed and movable guards
DS/EN ISO 4413:2010
Hydraulic fluid power –General rules and safety requirements for systems
and their components.
Table 2 –Declared international standards: FR Flail Mower
The declaration is valid for the above equipment, up to and including the machine's connections, resp.
suspension and stabilization, power transmission and electrical connection.
When connecting the above equipment to a vehicle and/or to tools other than those mentioned above, it is
the responsibility of each owner and operator to ensure that the vehicle and the overall machine comply with
the applicable requirements of relevant directives.
Dato: 01.06.2021
Signature:___________________________
John Christensen
Co-owner GreenTec A/S

BARRIER MOWER RI 60 –80
2
Merkurvej 25
DK 6000 Kolding
Danmark
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
Webadresse: www.greentec.eu
Åbningstid: mandag-fredag 8-16
1. MACHINE DATA AND USEFUL INFORMATION
(b)
Before the machine is put into use for the first time, the importer/dealer is responsible for providing the
buyer with this document and for the machine to be registered correctly via the extranet on GreenTec's
website:
https://greentec.eu/user
If in doubt regarding login information, please contact GreenTec –Aftersales & Service:
[email protected]
The dealer/importer must also ensure that the buyer and operator fully understand the contents before the
machine is put into use.
If the machine is resold, all the supplied technical documentation must be handed over to the new owner,
and must also always accompany the machine.
The fields below are filled in, for use when ordering spare parts or other enquiries:
1.1 REGISTRATION OF MACHINE DATA
! THESE DATA MUST ALSO BE ENTERED VIA LOGIN OB THE GREENTEC EXTRANET!
Machine description:
Serial number:
Date of delivery:
Dealer:
E-mail:
Phone:
Table 3 –Machine data form
FORHANDLERSTEMPEL

BARRIER MOWER RI 60 –80
3
1.2 MANUFACTURERS PLATE
All GreenTec machines are equipped with a
manufacturer’s plate.
The manufacturer’s plate contains
important information related to the
machine, including a unique serial number
used for identification.
CONTENT OF MANUFACTURER’S PLATE:
Type:
Machine model and type number.
Serial No.:
The machines unique serial number.
Prod. year:
Production year of the machine.
Weight:
Weight without optional equipment. (kg)
Model year:
Development year of the machine.
The plate also indicates the address information of the manufacturer.
Table 4 –Contents of the manufacturer’s plate
1.3 WARRANTY
To maintain GreenTec's 2-year warranty and product liability insurance, only genuine GreenTec spare parts
may be used on GreenTec machinery and equipment.
GreenTec is not liable for damage caused by illegal or incorrect use of the machine as well as incorrect
connection or connected equipment.
See GreenTec's warranty conditions in section 5 under the Terms and Conditions of Sale and Delivery here:
https://greentec.eu/en/terms-and-conditions-sale-and-delivery/
1.4 USE WITH MANUFACTURES OTHER THAN GREENTEC
When mounting on multi carriers other than GreenTec’s, a new risk
assessment of the machine must be submitted.
If the machine is mounted on an unapproved tool carrier, the risk assessment
basis lapses, and thereby the validity and guarantee of the declaration of
conformity.
It is the responsibility of each operator to assess the risk of this
interconnection before using the machine.
Figure 1 –Manufacturer’s plate for GreenTec machines

BARRIER MOWER RI 60 –80
4
2. GENERAL INFORMATION
2.1 INSTRUKTIONSBOGENS ANVENDELSE
Read this instruction manual carefully before mounting and commissioning the machine.
If in doubt, contact your local dealer or GreenTec - Aftersales department.
The illustrations in this instruction manual are for the sole purpose of
instructing, informing, and substantiating the general procedures and
instructions.
Illustrations may appear different from the current machine, e.g., by being
fitted with accessories and / or in a different size variant.
2.2 DEFINITIONER AF INFORMATION SIGNS
The following definitions apply to this entire instruction manual:
DANGER!
Warns of a potential situation that could result in death or permanent
disabling injuries if the regulations are not followed carefully!
WARNING!
Warns of a potential situation that could result in partially disabling injuries or
serious bodily injury if the regulations are not followed carefully!
CAUTION!
Warns of a potential situation that could result in serious damage to the
machine or equipment if the instructions are not followed carefully!
NOTICE!
Specific or general information that is deemed important or useful.
2.3 DEFINITIONS, TERMS AND DESCRIPTIONS
Operator
Daily user and/or starter of the machine.
Owner:
Buyer, owner or those responsible for the operation and maintenance.
Attachment tool:
GreenTec attachment tool, machine, or working tool handled and carried by multi
carrier during operation
Multi Carrier:
GreenTec Multi Carrier, support arm, or lift that controls, handles and carries the
attachment tool during operation.
Vehicle:
Machine that transports Multi Carrier + attachment tool.
LH + RH:
Left Hand and Right Hand.
These terms are used when the machine is mounted on the vehicle, seen from
behind. These designations are also used when referring to the vehicle.
Table 5 –Definitions, terms, and descriptions in the instruction manual.

BARRIER MOWER RI 60 –80
5
3. SAFETY
3.1 LOCAL LEGISLATION IN THE COUNTRY OF USE
The use of the machine may be restricted by the laws of the countries in which it is used. It is important that
the responsible owner and operator familiarizes himself with the country's laws and regulations regarding
cutting, mowing and maintenance of fences and hedges.
3.2 WARNINGS, PROHIBITIONS, AND INSTRUCTIONS
The instructions derive from the current national accident prevention regulations, which the operator and
operator must comply with:
For all types of work on the machine, this must be disconnected from all
hydraulics!
Only authorized personnel may perform service work on the machine!
Read the instruction manual carefully before using the machine!
3.3 SAFETY LABELLING
The machine is affixed with safety labels, these are located at the identified hazards to which one is exposed,
when working with, and staying near, the machine:
3.3.1 PERSONAL SAFETY EQUIPMENT–LABELS
It is recommended that the following safety equipment is used when working on or performing maintenance
on the machine:
WORKING SUIT
SAFETY SHOES
SAFETY GLASSES
HEARING
PROTECTION
SAFETY HELMET
PROTECTIVE
GLOVES
Figure 2 –Sikkerhedsmærkning: personligt sikkerhedsudstyr
The recommended safety equipment, together with the points of attention mentioned in this and the
following sections, covers the precautions GreenTec has deemed necessary for use.
The varying circumstances that may occur while working with this machine cannot always be foreseen.
No good advice can replace "common sense", "timely care" and "paying attention", but the above
recommendations are a good start to the safe use of the GreenTec machine.

BARRIER MOWER RI 60 –80
6
3.3.2 WARNING LABELS
Warning labels that identify the dangers to which you are exposed when working and when staying near the
machine:
Warning!
Read the relevant instruction
manuals carefully before using this
machine.
Follow all instructions and safety
instructions when using the
machine.
Warning!
Danger of being hit by stones or
other objects hit by the flails.
Persons must keep a distance
from the machine when it is in
operation.
Warning!
Check for every 8 hours of use that
all bolts / nuts are tightened.
Warning!
keep your distance from the
mower blades when the machine
is running. Never remove
protective screens/caps.
Warning!
Beware of oil in case of skin contact
or inhalation of oil vapours, as well
as high pressure in case of leakage
or handling.
Switch off the engine, remove the
key and apply the parking brake
before maintenance or repair work
Figure 3 –Safety labeling: warning labels

BARRIER MOWER RI 60 –80
7
3.4 OPERATING IN PUBLIC AREAS
When operating in publicly accessible areas, such as at roadside, the residence of others in the area must be
considered.
Stop the machine immediately when e.g., pedestrians, cyclists, riders, etc. are approaching the safety zone.
Only resume work when these are at a safe distance again.
When using the machine on public areas, the applicable traffic laws must be complied with at all events.
3.4.1 WARNING SIGNS IN PUBLIC AREAS
The operating area should be marked with appropriate signage, this is a legal requirement in public
areas.
Signage must be clearly and correctly placed so that the danger is made clear.
Contact the authorities for detailed information on current legislation.
Road authorities should be advised before starting work on public roads.
3.4.2 USE OF WARNING SIGNS
On two-way roads, warning signs are posted in both directions.
The work should be within 1 km of signage.
Only perform work when visibility is good and when the risk is low - e.g., outside rush hour.
The vehicle must be equipped with a flashing orange light boom.
Vehicles should be in a striking colour.
Material debris should be removed from the road and sidewalk as soon as practicable, and at
appropriate intervals.
The work must be carried out before removing warning signs and the operator must wear visible
clothing.
Collect all road signs as soon as the work is completed.

BARRIER MOWER RI 60 –80
8
3.4.3 PROPOSED SIGNS WHEN OPERATING ON PUBLIC ROADS:
Command sign
•”Hold left”
•White and blue arrow sign
•Sign visible on the back of the machine.
Warning sign:
•”Road work”
•Apply text for work performed with appropriate
distance.
•Example: ”Verge cutting 0-1 km”
Warning sign:
•”Road chicane”
•Apply following text:
o”One lane only”
Figure 4 –Proposed signage on public roads
The above signage applies within EU mainland where traffic passes to the left
of the machine working in the direction of travel.
Signage, use of, and colors on arrow signs as well as indications depend on
the language, laws, and regulations of each country.
VERGE CUTTING
0-1 KM
HOLD LEFT
ONE LANE ONLY

BARRIER MOWER RI 60 –80
9
3.5 RECOMMENDATIONS FOR OPTIMAL SAFETY AND
OPERATION (l)
Always be aware of the following risks when using the machine!
To achieve optimal safety and operation, it is important that the operator understands how dangerous the
machine is and anticipates the danger before it occurs:
You may get stuck when the machine is engaged or disconnected and when the tool carrier is moved
out or in, up or down and forward or back!
The machine can tip over when the tool carrier is raised!
You can be caught by the rotating shaft from the PTO!
You may be hit or caught by the moving parts, e.g., flails, knives, drive shaft and wings from mounted
attachment tools.
You may be hit by flying materials or machine parts in case of machine damage!
The machine can tip over, even when not in use!
The attachment tools are powered by hydraulic oil from the hydraulic system in the machine or from
the power-providing vehicle. The operator of the vehicle should have knowledge of how the hydraulic
oil should be handled! (Read in the safety data sheet for the oil)
High pressure oil spray from damaged fittings or hydraulic hoses can penetrate the skin and cause
serious injury!
Accident in case of collision with other vehicles or lost objects on the roads.

BARRIER MOWER RI 60 –80
10
3.6 NECCESARY PROTECTIVE MEASURES (m)
The machine must be used in the following ways:
Make sure that the operator of the machine has read this instruction manual, as well as instruction
manuals for the tool carrier and used vehicle.
Make sure that the operator of the machine has been instructed in the use of the machine.
Wear hearing protection if the machine is operated from a cabin that is not soundproof or if the cabin
windows are open.
Make sure all warning labels are always visible and that none of them are missing, damaged or
illegible.
Check that all guards are fitted correctly and that there are no damaged or loose parts.
Make sure that all hydraulic pipes and hoses are positioned correctly to avoid rubbing, stretching,
squeezing, or breaking them.
Check the work area and remove any strings, poles, large stones, and other dangerous objects before
operation.
Drive at a safe speed adapted to the terrain as well as any other vehicles and obstacles.
Make sure that the vehicle is stable and meets the machine manufacturer's recommendations for
minimum weight - if necessary, use extra counterweight.
Pay attention to electric wires, if in doubt about distance contact local power plant.
It is recommended to use impact-resistant guards on the vehicle.
Check that the machine's fittings, connections, and couplings are in good condition.
Follow the manufacturer's instructions for removing and installing the machine from the vehicle.
Disconnect the hydraulics for the machine, stop the engine, apply the parking brake, and remove the
key before leaving the cab.
If necessary, remove annoying residual material from the area.
When inspecting, repairing or other work on the stationary machine, great care must be taken.
Always wear gloves, safety shoes, safety glasses and appropriate tools to carry out the work.

BARRIER MOWER RI 60 –80
11
3.7 WARNINGS ON HOW NOT TO USE THE MACHINE (h)
Do not use the machine in the following ways!
Do not operate the machine until the relevant instruction manuals have been read and understood!
The operator must also be familiar with the operating handles according to the instruction manual for
the connected tool carrier!
Do not operate the machine if there are others within machine safety distances!
Do not allow an inexperienced person to operate the machine unattended!
Do not walk within the working area / safety zone of the machine. (Risk of injury!)
Do not try to locate a leak in the hydraulics by hand, use a piece of cardboard instead!
At no time should children be allowed to play on or near the machine!
Do not perform any maintenance or adjustment without first removing the hydraulic pressure from the
machine, lowering the tool carrier to the ground, stopping the vehicle's engine, applying the parking
brake, and removing the key!
Do not use and / or mount the machine on a vehicle that does not meet the manufacturer's
specifications!
Do not use the machine if the hydraulic system shows signs of damage!
Do not stop the engine while the hydraulic pressure is activated!
Do not attempt to use the machine for any purpose other than that for which it was intended!
Do not leave the cab of the vehicle without removing the ignition key!
Do not transport the machine while the hydraulic pressure is activated!
Do not use a machine that is not maintained or if some of its guards are missing or damaged!
Do not operate the vehicle or any of the control levers from a position other than the driver's seat!
Do not drive with mounted machines where rotating parts are facing the cab of the vehicle, as this
poses a risk of stones and material being thrown at the driver!

BARRIER MOWER RI 60 –80
12
3.8 SAFETY INSTRUCTIONS FOR MAINTENANCE,
ADJUSTMENT, AND INSPECTION (s)
The machine must be maintained in the following ways:
The operator must ensure that all maintenance, inspection, and installation work is carried out by
authorized and qualified professionals who, after reading the relevant instruction manuals, are in
possession of sufficient knowledge.
Maintenance, inspection, and installation work may only be carried out with the hydraulics
disconnected.
When carrying out maintenance work under the tool carrier, secure with suitable support elements.
When replacing machines, check the hydraulic system for residual pressure.
A possible residual pressure is reduced to zero. (0 bar)
Use only suitable tools and wear heavy gloves, safety shoes and glasses.
Handle the hydraulic oil and grease properly. Always be familiar with the safety data sheets.
Immediately after completion of work, all safety and protection devices must be fitted and reactivated.
3.9 SAFETY INSTRUCTIONS FOR THE OWNER / OPERATOR
It is important to familiarize yourself with all controls and equipment as well as their function before
starting the work. If the work has only begun, it may be too late.
Check the immediate area before starting and during operation of the work the machine must
perform. (People, children, animals, or obstacles such as stones, fence posts, steel wire).
Ensure adequate visibility and illuminated work area. The safety distance specified in the machine’s
instruction manual must be strictly observed.
The operator's clothing must be tight. Avoid loose clothing.
The operator must be fresh and rested before using the machine, as well as taking breaks in case of
fatigue, to ensure their own and others' safety.
The operator should ensure varying working positions and take frequent breaks to avoid
musculoskeletal disorders.
The operator must not leave the driver 's seat while driving.
It is not permitted to “ride along” on the machine during transport and operation.
When working on high-voltage power lines, additional distance and caution are required.
