GreenWorks Commercial 82PH20T User manual

EN OPERATOR MANUAL
ES MANUAL DEL OPERARIO
PTB417
POLE HEDGE TRIMMER
CORTASETOS TELESCÓPICO
FR MANUEL OPÉRATEURTAILLE-HAIE SUR TIGE
www.shopgreenworksgear.com
www.greenworkstools.com
82PH20T

1 Description.................................... 2
1.1 Purpose...................................................... 2
1.2 Overview.................................................... 2
2 General power tool safety
warnings........................................ 2
2.1 Work area safety........................................ 2
2.2 Electrical safety.......................................... 2
2.3 Personal safety...........................................2
2.4 Power tool use and care.............................2
2.5 Battery tool use and care........................... 3
2.6 Service....................................................... 3
3 Proposition 65............................... 3
4 Child safety....................................3
5 Symbols on the product.................3
6 Risk levels..................................... 4
7 Environmentally safe battery
disposal......................................... 4
8 Unpack the machine......................5
8.1 Attach machine to shoulder strap...............5
8.2 Install the battery pack............................... 6
8.3 Remove the battery pack........................... 6
9 Operation.......................................6
9.1 Start the machine....................................... 6
9.2 Stop the machine....................................... 6
9.3 Adjust the trimmer head angle................... 7
9.4 Anti-jamming Function................................7
9.5 4-Step speed activation..............................7
9.6 Extend the pole.......................................... 7
9.7 Operation tips............................................. 7
10 Maintenance..................................7
10.1 Clean the machine..................................... 8
10.2 Lubricate the blade.....................................8
11 Store the machine......................... 8
12 Troubleshooting.............................8
13 Technical data............................... 8
14 Limited warranty............................ 9
1
English EN

1 DESCRIPTION
1.1 PURPOSE
This machine is intended for cutting and trimming
hedges and bushes in domestic use. It is not intended
to be used for cutting above shoulder level.
1.2 OVERVIEW
1
2
3
45
10
11
12
6
7
8
9
13
1Shoulder Strap
2Blade
3Pivoting Head
4Pivot Button
5Coupler
6On/off button
7Reverse button
8Speed control /
Safety lock button
9Trigger
10 Battery
Compartment
11 Battery Release
Button
12 Carrying Ring
13 Scabbard
2 GENERAL POWER TOOL
SAFETY WARNINGS
WARNING
Read all safety warnings and all instructions. Failure to
follow the warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your
battery-operated (cordless) power tool.
2.1 WORK AREA SAFETY
•Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
•Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust.
Power tools create sparks
which may ignite the dust or fumes.
•Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose
control.
2.2 ELECTRICAL SAFETY
•Do not expose power tools to rain or wet
conditions. Water entering a power tool will increase
the risk of electric shock.
2.3 PERSONAL SAFETY
•Stay alert, watch what you are doing and use
common sense when operating a power tool. Do not
use a power tool while you are tired or under the
influence of drugs, alcohol or medication.
A lapse of
attention while operating power tools may result in
serious personal injury.
•Use personal protection. Always wear eye
protection. Protective products such as dust mask,
non-skid safety shoes, hard hat or hearing
protection used appropriately will reduce personal
injuries.
•Prevent unintentional starting. Ensure the switch is
in the off position before connecting to power source
and/or battery pack and when picking up or carrying
the tool.
Carrying power tools with your finger on the
switch or energizing power tools that have the
switch on invites accidents.
•Do not over-reach. Keep proper footing and balance
at all times. This enables better control of the power
tool in unexpected situations.
•Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves away
from moving parts.
Loose clothes, jewellery or long
hair can be caught in moving parts.
2.4 POWER TOOL USE AND CARE
•Do not force the power tool. Use the correct power
tool for your application.
The correct power tool will
do the job better and safer at the rate for which it
was designed.
•Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be
repaired.
•Disconnect the plug from the power source and/or
the battery pack from the power tool before making
any adjustments, changing accessories, or storing
power tools.
Such preventive safety measures
reduce the risk of starting the power tool
accidentally.
•Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained
users.
2
English
EN

•Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired
before use.
Many accidents are caused by poorly
maintained power tools.
•Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
•Use the power tool, accessories and tool bits etc. in
accordance with these instructions, taking into
account the working conditions and the work to be
performed.
Use of the power tool for operations
different from those intended could result in a
hazardous situation.
2.5 BATTERY TOOL USE AND CARE
•Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used
with another battery pack.
•Use power tools only with specifically designated
battery packs.
Use of any other battery packs may
create a risk of injury and fire.
•When battery pack is not in use, keep it away from
other metal objects like paper clips, coins, keys,
nails, screws, or other small metal objects that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause
burns or fire.
•Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with plenty of soap and
water. If liquid contacts eyes, immediately seek
medical help.
Liquid ejected from the battery may
cause irritation or burns.
2.6 SERVICE
•Have your power tool serviced by a qualified repair
person using only identical replacement parts. This
will ensure that the safety of the power tool is
maintained.
3 PROPOSITION 65
WARNING
This product contains a chemical known to the state of
California to cause cancer, birth defects or other
reproductive harm. Some dust created by power
sanding, sawing, grinding, drilling, and other
construction activities contains chemicals known to
cause cancer, birth defects or other reproductive
harm. Some examples of these chemicals are:
• Lead from lead-based paints;
• Crystalline silica from bricks and cement and other
masonry products;
• Arsenic and chromium from chemically treated
lumber.
Your risk of exposure to these chemicals varies
depending on how often you do this type of work. To
reduce your exposure to these chemicals, work in a
well-ventilated area, and work with approved safety
equipment, such as dust masks that are specially
designed to filter out microscopic particles.
Save these instructions.
4 CHILD SAFETY
Tragic accidents can occur if the operator is not aware
of the presence of children.
• Keep children out of the working area and under the
watchful care of a responsible adult.
• Do not allow children under the age of 14 to operate
this machine. Children who are 14 years of age and
older must read and understand the operating
instructions and safety rules in this manual and must
be trained and supervised by a parent.
• Stay alert, and turn the machine off if a child or any
other person enters the working area.
• Use extreme care when approaching blind corners,
doorways, shrubs, trees, or other objects that may
obscure your view of a child who may run into the
path of the machine.
5 SYMBOLS ON THE PRODUCT
Some of the following symbols may be used on this
product. Please study them and learn their meaning.
Proper interpretation of these symbols will allow you to
operate the product better and safer.
Symbol Explanation
Precautions that involve your safe-
ty.
3
English EN

Symbol Explanation
Read and understand all instruc-
tions before operating the product,
and follow all warnings and safety
instructions.
Wear eye protection.
Thrown objects can ricochet and
result in personal injury or property
damage. Wear protective clothing
and boots.
Wear non-slip, heavy duty gloves.
Keep all bystanders at least 15m
away.
DANGER! Risk of electrocution!
Keep tool 50 feet away from elec-
trical lines. Keep all bystanders at
least 50 ft. away.
Do not expose the product to rain
or moist conditions.
Danger – keep hands and feet
away from blade.
Wear head protection.
Double-insulated construction
6 RISK LEVELS
The following signal words and meanings are intended
to explain the levels of risk associated with this product.
SYM-
BOL
SIGNAL MEANING
DANGER Indicates an imminently
hazardous situation,which,
if not avoided, will result in
death or serious injury.
WARNING Indicates a potentially haz-
ardous situation,which, if
not avoided, could result in
death or serious injury.
SYM-
BOL
SIGNAL MEANING
CAUTION Indicates a potentially haz-
ardous situation, which, if
not avoided, may result in
minor or moderate injury.
CAUTION (Without Safety Alert Sym-
bol) Indicates a situation
that may result in property
damage.
7 ENVIRONMENTALLY SAFE
BATTERY DISPOSAL
The toxic and corrosive materials below are in the
batteries used in this machine: Lithium-Ion, a toxic
material.
WARNING
Discard all toxic materials in a specified manner to
prevent contamination of the environment. Before
discarding damaged or worn out Li-ion battery, contact
your local waste disposal agency, or the local
Environmental Protection Agency for information and
specific instructions. Take the batteries to a local
recycling and/or disposal center, certified for lithium-
ion disposal.
4
English
EN

WARNING
If the battery pack cracks or breaks, with or without
leaks, do not recharge it and do not use. Discard it
and replace with a new battery pack. DO NOT TRY
TO REPAIR IT! To prevent injury and risk of fire,
explosion, or electric shock, and to avoid damage to
the environment:
• Cover the terminals of the battery with heavy-duty
adhesive tape.
• DO NOT try to remove or destroy any of the
battery pack components.
• DO NOT try to open the battery pack.
• If a leak develops, the released electrolytes are
corrosive and toxic. DO NOT get the solution in the
eyes or on skin, and do not swallow it.
• DO NOT put these batteries in your regular
household trash.
• DO NOT incinerate.
• DO NOT put them where they will become part of
any waste landfill or municipal solid waste stream.
• Take them to a certified recycling or disposal
center.
8 UNPACK THE MACHINE
WARNING
Make sure that you correctly assemble the machine
before use.
WARNING
• If the parts are damaged, do not use the machine.
• If you do not have all the parts, do not operate the
machine.
• If the parts are damaged or missing, speak to the
service center.
1. Open the package.
2. Read the documentation in the box.
3. Remove all the unassembled parts from the box.
4. Remove the machine from the box.
5. Discard the box and package in compliance with
local regulations.
8.1 ATTACH MACHINE TO SHOULDER
STRAP
1
2
1
2
2
1
1. Attach the carabiner to the carrying ring on the drive
tube.
2. Put on the shoulder strap.
3. Adjust the length of the strap so that the carabiner is
about a hand’s width below your right hip.
5
English EN

8.2 INSTALL THE BATTERY PACK
WARNING
• If the battery pack or charger is damaged, replace
the battery pack or the charger.
• Stop the machine and wait until the motor stops
before you install or remove the battery pack.
• Read, know, and do the instructions in the battery
and charger manual.
1. Align the lift ribs on the battery pack with the
grooves in the battery compartment.
2. Push the battery pack into the battery compartment
until the battery pack locks into place.
3. When you hear a click, the battery pack is installed.
8.3 REMOVE THE BATTERY PACK
1. Push and hold the battery release button.
2. Remove the battery pack from the machine.
9 OPERATION
• Do not put your fingers into the notches or in
position where they can get cut.
• Do not touch the blade unless you remove the
battery pack.
• Do not use the machine if the blade is damaged or
bent.
• Remove all objects such as cords, lights, wire, or
string which can become entangled in the cutting
blade and create a risk of personal injury.
WARNING
If the blade jams on an electrical cord or line, DO NOT
TOUCH THE BLADE! IT CAN BE LIVE AND
DANGEROUS. Do the steps below:
1. Hold the insulated rear handle or put the machine
down and away from you.
2. Disconnect the electrically service to the damaged
line or cord before you try to free the blade.
9.1 START THE MACHINE
68
9
For your safety, this machine is equipped with a double
switching system. This system prevents starting the
machine inadvertently.
1. Press the On / OFF button.
2. Press the safety lock button.
3. Press the trigger while you hold the safety lock
button.
4. Release the safety lock button.
WARNING
Hold the machine with two hands during operation.
9.2 STOP THE MACHINE
1. Release the trigger to stop the machine.
6
English
EN

9.3 ADJUST THE TRIMMER HEAD
ANGLE
The trimmer head can be locked into 7 positions.
1. Pull the pivot button and move the head forward or
backward to your desired position.
2. Release the pivot button.
3. Check that the trimmer head locks in place securely.
9.4 ANTI-JAMMING FUNCTION
1. If the branch is blocked in the blade, push the anti-
jamming button on the control panel, the blade will
reverse and the branch will be released.
9.5 4-STEP SPEED ACTIVATION
This machine has 4-step speed limiter. The feature is
used to optimize performance and runtime after the
different circumstances. With a higher cutting speed you
consume more energy opposed to using a lower cutting
speed and saving energy for more run time.
1. To use the 4-step speed limiter, pull speed control/
safety lock button forward to change the speed
limiter.
9.6 EXTEND THE POLE
1. Set the unit on a flat, level surface.
2. Loosen the the coupler.
3. Pull the pole out to your desired length.
4. Rotate and tighten the coupler.
9.7 OPERATION TIPS
• Start by trimming the top of the hedge. Slightly tilt
the tool (up to 15° relative to the line of cut) so that
the blade tips point slightly towards the hedge. This
will cause the blades to cut more effectively. Hold
the tool at the desired angle and move it steadily
along the line of cut. The doublesided blade allows
you to cut in either direction.
• In order to obtain a very straight cut, stretch a piece
of string along the length of the hedge at the desired
height. Use the string as a guideline, cutting just
above it.
• In order to obtain flat sides, cut upwards with the
growth. Younger stems move outwards when the
blade cuts downwards, causing shallow patches in
the hedge.
• Take care to avoid any foreign objects. Especially
avoid hard objects such as metal wire and railings,
as these could damage the blades.
• Regularly oil the blades.
WARNING
Keep hands away from blade while operating. Contact
with blade will result in serious personal injury.
10 MAINTENANCE
CAUTION
Do not let brake fluids, gasoline, petroleum-based
materials touch the plastic parts. Chemicals can cause
damage to the plastic, and make the plastic
unserviceable.
CAUTION
Do not use strong solvents or detergents on the plastic
housing or components.
7
English EN

WARNING
Remove the battery pack from the machine before
maintenance.
10.1 CLEAN THE MACHINE
WARNING
Keep the machine and the motor free of leaves,
branches or excessive oil to prevent fire risks.
• Use a moist cloth with a mild detergent to clean the
machine.
• Clean all moisture with a soft dry cloth.
• Use a small brush to clean the air vents.
10.2 LUBRICATE THE BLADE
To increase the efficiency and life of the blades,
lubricate them carefully after each work session:
• Put the machine on a flat and smooth surface.
• Use a soft cloth to clean the blades and a brush to
remove more dirt.
• Use a light layer of oil to lubricate the blades along
the top edge of the blade.
NOTE
We recommend to use the non-pollutant type oil.
11 STORE THE MACHINE
NOTE
Clean the machine before storage.
1. Remove the battery pack.
2. Let the motor cool.
3. Check that there are no loose or damaged
components. If it is necessary, replace the damaged
components, tighten screws and bolts, or speak to a
person of an approved service center.
4. Store the machine in a cool and dry location.
12 TROUBLESHOOTING
Problem Possible cause Solution
The motor shuts
down whilst
working.
The battery pack
is not installed
tightly.
Make sure that
you tighlty instal-
led the battery
pack in the ma-
chine.
The battery pack
is out of power.
Charge the bat-
tery pack.
The machine
has damage.
Do not use the
machine and
speak to service
center.
The machine
smokes during
operation.
The machine
has damage.
1. Immediately
stop the ma-
chine.
2. Remove the
battery.
3. Speak to
service cen-
ter.
The motor is on,
blades do not
move.
The machine
has damage.
Do not use the
machine and
speak to service
center.
The blades are
blocked.
Remove battery
then clear block-
age from the
blades.
Too much noise
and/or vibration
is experienced
while working.
The parts are
loosen.
1. Stop the ma-
chine.
2. Remove the
battery.
3. Inspect for
damage.
4. Check and
tighten loose
parts.
The parts have
damage.
Do not use the
machine and
speak to service
center.
13 TECHNICAL DATA
Voltage 82V
No load speed 2800/3200/3600/4000
(±10%) SPM
Blade length 20" (510 mm)
Cutting capacity 1.18” (30 mm)
8
English
EN

Weight (without battery
pack)
14.6 lbs. (6.6 kg)
14 LIMITED WARRANTY
Greenworks hereby warranties this product, to the
original purchaser with proof of purchase, 2 year
commercial power train warranty, 2 year commercial
battery warranty against defects in materials, parts or
workmanship. Greenworks, at its own discretion will
repair or replace any and all parts found to be defective,
through normal use, free of charge to the customer.
This warranty is valid only for units which have been
used for personal or commercial use and that have
been maintained in accordance with the instructions in
the owners’ manual supplied with the product from new.
2 YEAR LIMITED POWER TRAIN WARRANTY
COVERAGE:
– Motor
– PCB Boards
– Gear Box
– 2 years from the date of purchase (non transferable)
2 YEAR LIMITED BATTERY WARRANTY COVERAGE:
– Greenworks Commercial Battery Packs (GL 250, GL
400, GL 500, GL 900, GLW 300, GLW 600, GL400BT
and other series)
– 2 year from the date of purchase (non transferable)
60 DAY LIMITED WEARABLE PARTS WARRANTY
COVERAGE:
– Bars
– Blades
– Guards
– Chains
– Bump Feed Heads
– Tines
– 60 Days from date of purchase (non transferable)
WARRANTY EXCLUSIONS, LIMITATIONS AND
RIGHTS:
1. All warranties may not be transferred by the
consumer to any subsequent purchaser.
2. Parts or components not supplied by the warrantor,
or parts or components that have been modified.
3. Any failure resulting from the use of improper tools
or improper repair procedures.
4. Any failure resulting from the use of improper tools
or improper repair procedures.
5. Any failure or part that has become inoperative due
to accident, impact, abuse, misuse, neglect,
mishandling, dulling of cutting edges, or failure to
operate the product in accordance with the
information provided in the instruction manual
supplied with the product.
6. Routine maintenance items such as lubricants,
blade sharpening.
7. The unit, if it has not been operated and/or
maintained in accordance with the owner's manual.
8. The unit, if it has not been operated and/or
maintained in accordance with the owner's manual.
GREENWORKS HELPLINE:
Warranty service is available by calling our toll-free
helpline, at 1-855-470-4267.
TRANSPORTATION CHARGES:
Transportation charges for the movement of any power
equipment unit or attachment are the responsibility of
the purchaser. It is the purchaser’s responsibility to pay
transportation charges for any part submitted for
replacement under this warranty unless such return is
requested in writing by Greenworks.
Greenworks Tools
PO Box 1238
Mooresville, NC 28115
9
English EN
