Greyline Instruments TTFM 1.0 User manual

www.greyline.com
USER'S GUIDE
Installation & Operation
Instructions
Transit Time Flow Meter
Model TTFM 1.0
Manual Series A.2

Note: This page has been left blank intentionally.

Page 3
TTFM 1.0 Transit Time Flow Meter
INDEX
TRANSDUCER INSTALLATION.........................................................................4
CONNECTIONS.....................................................................................................5
KEYPAD SYSTEM ................................................................................................8
CALIBRATION MENU .........................................................................................9
MESSAGE.............................................................................................................10
STATUS................................................................................................................10
PASSWORD..........................................................................................................11
UNITS/MODE.......................................................................................................12
CALIBRATION....................................................................................................13
RELAY PARAMETERS.......................................................................................15
SPECIAL FUNCTIONS........................................................................................16
TRANSDUCER MOUNTING..............................................................................18
ENCLOSURE INSTALLATION..........................................................................23
FIELD TROUBLESHOOTING............................................................................24
COMMON QUESTIONS AND ANSWERS........................................................27
APPLICATIONS HOTLINE.................................................................................29
PRODUCT RETURN PROCEDURE...................................................................30
APPENDIX A – OPTIONS...................................................................................32
DATA LOGGING.................................................................................................36
SPECIFICATIONS................................................................................................38
APPENDIX B - CONVERSION TABLE.............................................................39
PIPE CHARTS ......................................................................................................40
APPENDIX C – LIQUID SPEED OF SOUND....................................................43
IMPORTANT NOTE: This instrument is manufactured and calibrated to meet product specifications.
Please read this manual carefully before installation and operation. Any unauthorized repairs or
modifications may result in a suspension of the warranty.
If this product is not used as specified by the manufacturer, protection may be impaired.
Available in Adobe Acrobat pdf format

Page 4
TTFM 1.0 Transit Time Flow Meter
TRANSDUCER INSTALLATION
TRANSDUCER
TRANSDUCER
*SEPARATION
DISTANCE
TTJB
JUNCTION
BOX
BNC1
BNC2
* Shown in display after pipe dimensions are entered. ‘’Message

Page 5
TTFM 1.0 Transit Time Flow Meter
CONNECTIONS:
POWER INPUT: The standard model requires AC power input between 100 to 240 VAC 50/60Hz . No
adjustments are necessary for voltages within this range. Connect L (Live) N (Neutral) and AC Ground.
Optional DC input model requires 9-32 VDC/9 Watts. Connect to + and - terminals.
Optional Thermostat and Heater modules are available rated for 115 VAC or 230 VAC.
IMPORTANT NOTE: To comply with CSA/UL electrical safety standards, AC power input and relay
connection wires must have conduit entry to the instrument enclosure. Installation requires a switch,
overcurrent fuse or circuit breaker in the building (in close proximity to the equipment) that is marked as
the disconnect switch.
Risk of electric shock. Loosen cover screw to access connections. Only qualified personnel
should access connections.
Note: Use of instrumentation over 40°C ambient requires special field wiring.
Note: User replaceable fuse is 2 Amp 250V (T2AL250V), located on the power supply.
!

Page 6
TTFM 1.0 Transit Time Flow Meter
CONNECTIONS
DATA LOGGER
SENSOR
AC
LN
TDR 1
GND
TDR 2
GND
NO
C
NC
NO
C
NC
–
+
4-20mA
RLY2
RLY1
AC
GROUND USB HARNESS
CONNECTOR
NC
C
NO
NC
C
NO
NC
C
NO
NC
C
NO
RLY3 RLY4 RLY5 RLY6
EXTRA RELAYS OPTION
POWER
INPUT
HEATER OPTION
TRANSDUCER
GND
DOWNSTREAM
UPSTREAM

Page 7
TTFM 1.0 Transit Time Flow Meter
QUICK BENCH TEST:
In the TTFM Calibration menu set parameters to perform a bench test:
-Set Pipe OD = 1.000 inch
-Set Pipe wall = 0.25 inch
-Set Pipe material to ABS
-Press twice to exit Calibration and return to main display.
From main display press to view Status menu. Apply coupling compound to the face of transducers
and press together as indicated in the illustration below.
The Status menu should indicate Echo Confidence of 100% and a high Signal Strength (75-100% for
TTFM with standard options).
COUPLING
COMPOUND
~0.8”
20 mm

Page 8
TTFM 1.0 Transit Time Flow Meter
KEYPAD SYSTEM
The diagram on page 8 shows the TTFM 1.0 menu system. Arrows show the four directions to leave a
menu box. Pressing a corresponding keypad arrow will move to the next item in the direction shown.
Move the cursor (underline) under numerals and increase or decrease numerals with the and keys.
To store calibration values permanently (even through power interruptions), press the .

Page 9
TTFM 1.0 Transit Time Flow Meter
CALIBRATION MENU
--Password----------
Password 0000
USG/m
Tot 20130.8 USG
Relays 1 2 3 4 5 6
0.000
--Message-----------
Data log Logging
Log Used 0%
Sens Space 8.4in
Sensor Good
Signal
Strength
--24 hr log----------
Date Feb. 12/2010
Total 50138 USG
Average 34.82 USG/m
Maximum 52.20 USG/m
Max Time 11:08:00
Minimum 0.000 USG/m
Min Time 9:15:00
}
--Status------------
Velocity 4.21ft/s
Tot 1260.15USG
Signal Strength 80%
EC 100%
Relays 1 2 3 4 5 6
20mA at 176USG/s
}
--Data Logging-------
Log Site ID 0
Mode Flow
Set Date Feb 18/2010
Set Time 11:27:40
Interval 10sec
Log Logging
}
--Units/Mode--------
Mode Flow
Linear in
Volume USG
Time min
Temperature C
}
--Simulation--------
Test Actual
Flow 250USG/m
4-20mA Flow 5.60mA
Relays 1 2 3 4 5 6
}
--Relay Parameters--
Relay 1
Function Flow
Mode Pump
On 1000 USG
Off 0.000 USG
}
--Configuration-----
Transit Time 1.14
Logger 1.16T
Relays 2
Analog Out 1
}Utility 1.20.02
--Menu Selections----
Units / Mode
Calibration
Relay Parameters
Data Logging
Special Functions
Simulation
Configuration
}
OPTIONAL FEATURES
--Special Functions-
Language English
Analog Out 4-20mA
Backlight High
Reset Totalizer NO
Negative Totals NO
Cal Constant 1.000
Restore Defaults NO
New Password 0000
}
--Calibration-------
20mA at 2500.0 USG/m
4mA at 0.000 USG/m
Min Flow 2.262 USG/m
Damping 20%
Sensor Select SE16B
Fluid Water
Crossings 2
Pipe OD 12.0000in
Pipe Wall 0.2300 in
Pipe ABS
Lining None
Fluid Temp 10.0C
Zero Tare No
LOE Time 30sec
}
0
%

Page 10
TTFM 1.0 Transit Time Flow Meter
RUN
The main display shows the units selected from the Units/Mode menu, Flow or
Velocity rate being measured, TOTALIZER and RELAY states. The TTFM 1.0
will start-up with this display and will return to this screen after a timeout if keys
are not pressed in other menus.
MESSAGE
Press from the RUN display to view status of the data logger and error/warning
messages provided by the instrument. The word Message will appear on the RUN
display if error messages are being generated by the instrument. Refer to the
manual section Error/Warning Messages for a description. Press to return to the
main display.
STATUS
Press from the RUN display to view instrument status. Velocity will be
displayed in ft/sec or m/sec.
Tot Displays the current totalizer reading.
Signal Strength Displays magnitude of signal being received by the
ultrasonic transducer.
EC Echo Confidence - displays percentage of good echoes
received.
Relays Energized relays will display as a white character on a
black background.
20mA at Displays the flow value entered in Calibration
menu for 20mA output.
USG/min
Tot 20130.8 USG
Relays 123456
0.000
--Message-----------
Data log Logging
Log Used 0%
Sens Space 8.4in
Sensor Good
Signal
Strength 0%
--Status------------
Velocity 4.21ft/s
Tot 1260.15USG
Signal Strength 80%
EC 100%
Relays 1 2 3 4 5 6
20mA at 176USG/s
}
