GRIDIRON TL-01 User manual

GRIDIRONTM
Custom Tool StorageTM
Trimmer Line Spool Holder
Installation Instructions
Thank you for purchasing this Gridiron product
1 Fastening hardware is assembled at the factory but can loosen
during shipping. Assemble any loose bolts, washers, and T-nuts
as shown below (NOTE- INCORRECT ASSEMBLY WILL
RESULT IN DAMAGE.)
2 The line holder can be mounted to a post or to an enclosed trailer
wall.
3 Slide the line holder bracket down the post from the top and
tighten the bolts when you have the line holder in position.
4 To mount to an enclosed trailer wall, remove the machine bolts
and t-nuts and use the enclosed sheet metal screws to mount the
line holder to the wall.
5 Open the lid and slide your spool of line onto the spindle inside.
Feed the line through one of the slots in the rubber insert in the
lid. Close the lid and dispense line by pulling out through the lid.
6 To cut line, bend line into small loop and push into the cutter. (see
image)
Assemble all T-nuts with
pilot to inside of post.
WARNING!
DAMAGE MAY RESULT
T-nut
Pilot

The GRIDIRON Lifetime Guarantee
We want you to be a satisfied GRIDIRON customer forever so we stand
behind our GRIDIRON products with a lifetime guarantee.
Performance Guarantee
If at any time you are not completely satisfied with the performance of
your GRIDIRON product we will correct or replace it. Simply return it to
an authorized dealer.
Replacement agreement for misuse or abuse
Should you damage your GRIDIRON through misuse or abuse, we will
replace the item for ½ the current suggested list price. Send the product,
shipping prepaid, along with an explanation to Novae Customer Service.
15 Day unconditional money back guarantee
If at any time within fifteen (15) days after your purchase you are not
satisfied with your GRIDIRON product, return it to the an authorized
dealer for full refund.
Some exceptions
The springs, shock cord elements, cutting edges, vinyl and plastic protec-
tors and finish provided with your GRIDIRON products are subject to
normal wear and tear and are not covered by this guarantee.
GRIDIRONTM
Custom Tool StorageTM
Part List
Qty Description Part No.
1 Line Container 102446
1 Lid 102447
1 Spindle Bracket 102292
1 Friction disc 102454
1 Line Cutter LC-01
3 1/4-20 TH Screw 102453
3 1/4” Nut 102059
3 1/4” Lock Washer 102063
2 Single T-nut 102147
2 5/16-18 x 3/4” Bolt 102056
2 5/16” Flat Washer 102061
2 5/16” Lock Washer102064
2 #14x1 Sheet Metal 102448
1 18” SS cable 102455
Package Contents
Novae Corp.
2 Novae Parkway
Markle, IN 46770
844-240-8695
[email protected]
©2016 Novae Corp. All rights reserved
Single T-nut
