Grip G-SWS User instructions

G-SWS
Assembly and Operating Manual
Dear customer,
Congratulations!
You have chosen the best product we know how to make with our
30 years of experience and passion for precision.
Please follow the instructions in this manual to
avoid mistakes and save time.
In case you need further information or you have
further requests we will be glad to be at your disposal.
With best regards
Your GRIP GmbH
GRIP GmbH Handhabungstechnik
Alter Hellweg 70 Tel. [phone] [e-mail]
44379 Dortmund, Germany Fax [phone] www.grip-gmbh.com
SWS Connector
1
3
4
5
8
9
10
8.1
Spare and wear parts
Assembly
Maintenance and care
7.1 Disassembly
6
Exploded view
EC-Declaration of incorporation 8
7
7.2 Torque specifications
1
2
Contents
2.2 Intended use
Operation
Safety
2.1 Symbol
Page
2
2
2
2
2
2.4 Safety indication
Scope of delivery
Technical data 3
2
2.3 Environmental and operating conditions
3
3
Warranty
6
7
4
5
5
5
6Parts list

G-SWS
Assembly and Operating Manual
1 Operation
2 Safety
2.1 Symbol
2.2 Intended purpose
2.3 Environmental and operating conditions
2.4 Safety indication
Dangers may arise from the unit, if:
•the product is not installed or inserted properly,
•the system is not used for its intended purpose,
•the safety and installation notes are not observed.
CAUTION! Never operate the semi-cylindrical bolt when the load is suspended!
2
NOTICE!
The unit may only be operated if the machine in which the unit is installed complies with
the relevant provisions of the machinery directive 2006-42-EC.
NOTICE!
A semi-cylindrical bolt safety device must be used for dynamic applications.
Otherwise boundary conditions supplied by the customer, e.g. vibrations can lead to
automatic lock-out release.
Everyone who is responsible for assembly, commissioning and maintenance must read and
understand the complete operating instructions. Improper use, which affects the function und
operational safety of the SWS Connector, is prohibited.
In order to prevent damage to the connector as well as injuries to the operator, the
lower assembly or the tool must be secured by hand or other devices before opening
the change system. Otherwise there is a risk that irreparable damages to the tool or
injury to the operator are caused by the unit falling down.
This symbol indicates possible hazards to persons or the SWS
Connector.
The SWS Connector has been designed as an interface between special solutions and automation
(e.g. gripper). Furthermore, the SWS can also be used as an interface between handling device and
tool . In dynamic applications, it can only be used with the locking piston. The unit may only be used in
the context of its technical specifications. The system is intended for the installation in a machine. The
requirements of the applicable instructions must be considered and adhered to.
Use this unit only in dry and splash-proof environments at room temperature as well as within the
application parameters defined in the technical specifications. If this is not the case, warranty
cannot be accepted. Exceptions are units designed especially for the respective conditions.
To open the change system, insert the square socket key on the square of the semi-cylindrical bolt and turn
counter-clockwise (“to the left") by 180 ° to the stop. The upper and lower assembly can now be pulled apart.
When joining the parts, the hand lever must be set to open position. Now, upper and lower assembly can be
pushed into each other.
By turning the semi-cylindrical bolt clockwise (“to the right”) 180° up to the stop, the system is locked. Afterwards
the hand lever is folded and latched.

G-SWS
Assembly and Operating Manual
3 Warranty
4 Scope of Delivery
•
5 Technical Data
3
The semi-cylindrical bolt safety device (VS2) is available as an option for sizes SWS050,
SWS063, SWS080, SWS100 and SWS125. The sizes SWS160, SWS200 and SWS250 are
always equipped with a semi-cylindrical bolt safety device.
If the product is used as intended in 1-shift operation the warranty is valid for 24 months from the
ex-works delivery date under observance the mandatory maintenance and lubrication intervals and
the given operating conditions. Generally parts touching the work piece and wear parts are not
part of the warranty. Wear parts are listed in chapter 8.1. The unit is considered to be defective if
its basic function "Lock" is no longer functioning.
•SWS as painted in Image 6 depending on the order number of the upper or lower assembly.
Behold technical data sheets: TD-SWS050-EN, TD-SWS063-EN, TD-SWS080-EN, TD-SWS100-
EN, TD-SWS100-B02-EN, TD-SWS125-EN, TD-SWS160-EN, TD-SWS200-EN, TD-SWS250-EN

G-SWS
Assembly and Operating Manual
6 Assembly
4
Depending on the size one (SWS050 to 080) or two (SWS100 to 250) fitting bores according to
ISO 9409 are available on the robots or grippers side.
CAUTION! Risk of pinching the fingers when closing the SWS
When assembling, the upper and lower assemblies do not have to be inserted
into each other as far as they will go. By turning the semi-cylindrical bolt, the
lower assembly is pulled around the locking stroke (see technical description
„VH“).
The upper assembly of the SWS Connector is mounted on the robot flange, the manipulator or
similar actuators. It can be centered with the help of a centering disc. The angular orientation is
determined by means of a fitting bore. The lower assembly is mounted on grippers, measuring
instruments or other tools. If the SWS Connector can not be installed directly, adapter flanges
must be used. Use screws according to DIN 912. For the sizes 50, 63 and 80, screws according to
DIN 7984 are to be used on the gripper side. The screw-in depth of the screws must be observed.
We recommend the use of a "medium-tight" screw lock.
Optionally, the SWS can be provided with a MEK Energy Coupling. To mount the MEK the "E"
option must be specified when ordering the SWS. The MEK is available in different versions. The
MEK enables the simultaneous coupling of electrical and pneumatic lines when opening or closing
the SWS. The MEK is mounted with two cylinder screws to the upper and lower assemblies. For
further installation instructions, please refer to the assembly and operating instructions of the MEK.
CAUTION!
Perform assembly work only when the power supply is switched off!
Image 1
Image 2
Robot flange
Upper assembly
ISO 4762
DIN 7984/ ISO 4762
Lower assembly
(MGW050-125 and SWS160-250)

G-SWS
Assembly and Operating Manual
Centering disc
7 Maintenance and care
7.1 Disassembly of the SWS
(Behold Image 5)
1. Disassemble the SWS.
2. Loosen the Setscrew (Pos. 3).
3.
4. Clean all parts thoroughly. Inspect for wear and defects.
5. Lubricate all mating surfaces.
For assembly, reverse the order.
7.2 Torque specifications
M6 – 8,5 Nm; M8 – 20,6 Nm; M10 – 41 Nm; M12 – 71 Nm
5
In order to archieve a precise fit, centering discs in every size are offered (as shown in image 3).
The use of a centering disc ensures that the upper assembly and/or lower assembly of the
Connector are properly centered. Installation on both the upper assembly and lower assembly is
possible (as shown in image 4).
Image 3 Image 4
The SWS is virtually maintenance-free. Check the semi-cylindrical bolt in regular intervals for
correct function. Keep the mating surface and the moving parts clean and lubricate them slightly.
Spare parts and component parts of the SWS can be found on our homepage:
www.grip-gmbh.com
To disassemble the semi-cylindrical bolt (Pos. 2) from the other component parts (Pos. 5,
6, 7 and 8), remove the cylinder bolt (Pos. 8).

G-SWS
Assembly and Operating Manual
8 Parts list
8.1 Spare and wear parts, depending on size
6
2
1
3 1
Pos. Quantity
1 1
1
5 1
Index pin
Housing VS2 (optional)
1
Flap VS2 (optional)
4
9 1
Cylinder bolt VS2 (optional)
Lower assembly MGW
6
2
7 1
Screw VS2 (optional)
11 Anti-rotation-protection EG-SWS…-VS2 1
Pos.
Description
Order-No.
Quantity
2
Semi-cylindrical bolt
Quantity
1
10 Square Socket Key ZG-VKS...-SW… 1
EG-SWS…-HB
1
8
size 050-125
size 125-250
Description
Upper assembly
Semi-cylindrical bolt
Setscrew
Pos. Description
1Upper assembly
2
Semi-cylindrical bolt
1
3Setscrew 1
7Flap VS2 1
4Index pin 1
5Housing VS2 1
8Cylinder bolt VS2 1
9Lower assembly SWS 1
6
Screw VS2
2

G-SWS
Assembly and Operating Manual
9 Exploded view
7
Image 5
Image 6
Upper assembly
Lower assembly

G-SWS
Assembly and Operating Manual
10 EC - Declaration of incorporation
according to the Machinery Directive 2006/42/EC, annex II B
The producer / distributor GRIP GmbH Handhabungstechnik
Alter Hellweg 70
D-44379 Dortmund, Germany
hereby declares that the following products
Product designation: Quick change system (SWS)
Functional description:
Type designation: G-SWS050 to 250
EN ISO 12100:2010
Authorized representative Dipl.-Ing. (FH) Hasan Canti
Location: Dortmund
Date:
Dipl.-Ing. (FH) Hasan Canti
Executive Director
8
Systems for the manual and form-closed exchange of components
such as grippers and tools on robots or receptacles
The provisions of the above-mentioned directives -including their effective amendments- comply
with the time of the declaration.
He further states that the following essential requirements of the Machinery Directive 2006/42/EC
were applied and observed:
annex I, numerics: 1.1.2; 1.1.3; 1.1.5; 1.3.2; 1.7.4
He further states that the specific technical documentation has been drawn up in accordance with
annex VII, Part B.
The following harmonized standard has been applied:
Safety of Machinery- Basic concepts, general principles for
design- Part 1:
Basic terminology and methodology
13.09.2020
Safety of Machinery- Basic concepts, general principles for
design- Part 2:
Technical principles
In the case of reasoned requests, the specific documents shall be sent to the national authorities
as follows: Post
The product mentioned above may only be put into operation if it has been established applicable
that the unit, into which the above-mentioned product is to be incorporated, complies with the
provisions of the Machinery Directive 2006/42/EC.
