Grizzly H3272 User manual

COPYRIGHT © AUGUST, 2003 BY GRIZZLY INDUSTRIAL, INC.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
PRINTED IN USA
MINI AIR COMPRESSOR
MODEL H3272
INSTRUCTION MANUAL
Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence, accidents, repairs or alterations or lack of main- tenance. This is Grizzly’s sole written warranty and any and all warranties that may be implied by law, including any merchantability or fitness, for any particular purpose, are here- by limited to the duration of this written warranty. We do not warrant or represent that the merchandise complies with the provisions of any law or acts unless the manufacturer so warrants. In no event shall Grizzly’s liability under this warranty exceed the purchase price paid for the product and any legal actions brought against Grizzly shall be tried in the State of Washington, County of Whatcom. We shall in no event be liable for death, injuries to persons or property or for incidental, con- tingent, special, or consequential damages arising from the use of our products. To take advantage of this warranty, contact us by mail or phone and give us all the details. We will then issue you a “Return Authorization Number,” which must be clearly posted on the outside as well as the inside of the carton. We will not accept any item back without this number. Proof of purchase must accompany the merchandise. The manufacturers reserve the right to change specifications at any time because they con- stantly strive to achieve better quality equipment. We make every effort to ensure that our products meet high quality and durability standards and we hope you never need to use this warranty. Please feel free to write or call us if you have any questions about the machine or the man- ual.
Grizzly Industrial, Inc.
1203 Lycoming Mall Circle
Muncy, PA 17756
Phone: [phone]
Fax: [phone]
E-Mail:
[email protected]
Web Site: http://www.grizzly.com
Thank you again for your business and continued support. We hope to serve you again soon!
WARRANTY AND RETURNS

1. READ THIS ENTIRE MANUAL
BEFORE OPERATING THE COMPRESSOR.
2. OPERATE THE COMPRESSOR IN A
WELL VENTILATED AREA.
3. NEVER AIM THE AIR NOZZLE
DIRECTLY AT YOURSELF OR OTH- ERS.
4. DO NOT USE THE COMPRESSOR
FOR FILLING BREATHING OR DIV- ING APPARATUS.
5. ALWAYS WEAR SAFETY GLASS-
ES WHEN OPERATING THIS MACHINE.
6. DO NOT USE A TOOL THAT
REQUIRES MORE THAN THE COM- PRESSORS CFM AND PSI RATING.
Safety
This 1⁄8HP Mini Air Compressor is ideal for most air brush sets. Portable design fea- tures automatic shut-off at 38 PSI, a mois- ture trap, an air brush holder and a coiled air hose. CFM at maximum PSI is 0.48 and the total weight is 7 lbs.
Introduction
The Model H3272 Mini Air Compressor is wired for 110V, single-phase operation only. To operate the mini air compressor: 1. Make sure the compressor is discon-
nected from the power source.
2. Connect your coiled air hose to the 1⁄4"
NPT connector on the air filter. Note— Use teflon tape on the treads of the fit- tings.
3. Connect the air brush or other air tools
to the compressor.
4. Plug the compressor in and press the
switch to start it.
5. Disconnect the air tool and unplug the
compressor when not in use.
Operations
Regular periodic maintenance on your air compressor will ensure its optimum performance. Make a habit of inspect- ing your compressor each time you use it. Check the following items: •Clean off the cylinder head. •Check for worn or damaged cords and
plugs.
•Check for any other condition that could
hamper the safe operation of this machine.
•Check for loose bolts or fittings. •Check air lines and connectors to make
sure they are in good condition.
•Drain the moisture trap periodically.
Maintenance
Set Up
The Model H3272 was shipped in a care- fully packed box. Inspect the machine for damages due to shipping. If you have con- cerns please contact us. Contact informa- tion is on the back page. Place the Model H3272 on a flat surface in a well ventilated, dry area where tempera- tures will not exceed 90˚F. The Model H3272 is an oilless compres- sor. DO NOT ADD OIL.
Always wear safety glasses and use
extreme caution when working around compressed air.
Always unplug compressor when
performing maintenance or chang- ing air tools.
Model H3272 Mini Air Compressor
Ref# Part# Description 101 PH3272101 Motor 102 PH3272102 Front Case 103 PH3272103 Front Cover 104 PH3272104 Capacitor/On/Off Switch 105 PH3272105 Piston Rod 106 PH3272106 Ball Bearing 107 PH3272107 Crankshaft 108 PSB10M Cap Screw M5-.8 x 15 109 PH3272109 Inlet & Exhaust Plate 110 PSB57M Cap Screw M3-.5 X 6 111 PH3272111 Cylinder 112 PH3272112 Compression Ring 113 PH3272113 Collar 114 PH3272114 Cylinder Base 115 PH3272115 O-Ring 116 PH3272116 Valve Plate Set 117 PH3272117 O-Ring
Ref# Part # Description
118 PH3272118 Cylinder Head 119 PH3272119 Release Valve 121 PN02M Hex Nut M10-1.5. 122 PH3272122 Handle 123 PH3272123 Handle Screw 124 PH3272124 Connector 125 PH3272125 Water Filter 126 PH3272126 Connector 127 PH3272127 Air Hose Nut 128 PH3272128 Air Hose 129 PH3272129 Air Hose Nut 130 PH3272130 Connector 1⁄4NPT
131 PH3272131 Elbow 132 PH3272132 Pressure Switch 133 PS09M Phlp Hd Scr M5-.8 X 10 134 PS77M Php Hd Scr M5-.8 x 140 135 PS78M Phl Hd Scr M4-.7 x 45
