Parts Breakdown
SECTION 7: PARTS

 
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 PB32M HEX BOLT M10-1.5 X 25 19-5 PT10095019-5 ON/OFF SWITCH
2 PN02M HEX NUT M10-1.5 19-6 PT10095019-6 JUNCTION BOX
3 PW04M FLAT WASHER 10MM 20 PT10095020 SPECIAL SCREW M10-1.5 X 65
4 PT10095004 UPPER DRUM 21 PT10095021 CURVED WASHER 8MM
5 PB08M HEX BOLT M6-1 X 20 22 PLN04M LOCK NUT M8-1.25
6 PWF06M FENDER WASHER 6MM 23 PT10095023 STAND SUPPORT
7 PT10095007 MIXER BLADE 24 PT10095024 STAND
8 PT10095008 DRUM GASKET 25 PB82M HEX BOLT M8-1.25 X 80
9 PT10095009 LOWER DRUM 26 PT10095026 WHEEL
10 PW03M FLAT WASHER 6MM 27 PWF10M FENDER WASHER 10MM
11 PLW03M LOCK WASHER 6MM 28 PB48M HEX BOLT M10-1.25 X 20
12 PN01M HEX NUT M6-1 29 PT10095029 AXLE
13 PT10095013 UPPER COVER 30 PT10095030 BUSHING
14 PT10095014 SPECIAL WASHER 10MM 31 PS11M PHLP HD SCR M6-1 X 16
15 PLN05M LOCK NUT M10-1.5 32 PT10095032 PIN 5 X 40MM
16 PT10095016 HANDLE 33 PWR1012 WRENCH 10/12MM
17 PT10095017 HANDLE GRIP 34 PT10095034 WRENCH 14/17MM
18 PT10095018 MOTOR COVER 35 PT10095035 MACHINE ID LABEL
19 PT10095019 MOTOR/GEARBOX ASSEMBLY 36 PLABEL-53B DISCONNECT POWER LABEL
19-1 PT10095019-1 MOTOR FAN COVER 37 PLABEL-12 READ MANUAL LABEL
19-2 PT10095019-2 MOTOR FAN 38 PLABEL-57B GLASSES RESPIRATOR LABEL
19-3 PT10095019-3 CIRCUIT BREAKER 39 PT10095039 NO WATER LABEL
19-4 PT10095019-4 S CAP 150M 150V 1-1/2" X 2-3/4" 40 PLABEL-14 ELECTRICITY LABEL
Parts List
Safety labels warn about machine hazards and ways to prevent injury. The owner of this machine
MUST maintain the original location and readability of the labels on the machine. If any label is
removed or becomes unreadable, REPLACE that label before using the machine again. Contact
Grizzly at [phone] or www.grizzly.com to order new labels.
