G0444/G0444Z 10" Table Saw -57-















 

































 



 
  

 











-58- G0444/G0444Z 10" Table Saw
128 126 125
81
82
124
123
73
72
66
68
67
70
69
59
60 57
56
53
52
51
48
47
49
62
64
63
61 58 54
48 47
49
51
60
54
55
121 71 74
75
76 77 79
78
122
80
85
87
86
88
89
84 87
90 91 93
99
121
94 121
100
95
96
97
98
127
92
111 110
103
104
101
102
115
117
116-1
116
106
105
104
107
108
114
118
119
120
109
160

G0444/G0444Z 10" Table Saw -59-
136
137
134
131
133
141
139
142
139
129
130
144
145
146
147
132
138
139
141
143
156
135

-60- G0444/G0444Z 10" Table Saw
1A P0444001A DADO TABLE INSERT
1 P0444001 TABLE INSERT
2 P0444002 BUMPER
3 PSS04 SETSCREW 1⁄4-20 X 5⁄16"
4 P0444004 TABLE
5 P0444005 CABINET
6 PW07 FLAT WASHER 5⁄16"
7 PB32 HEX BOLT 5⁄16-18 X 5⁄8"
8 P0444008 SCALE
9 P0444009 EXTENSION WING - SHEET
9 P0444Z009 EXTENSION WING - CAST IRON
10 PLW05 LOCK WASHER 7⁄16"
11 PB90 HEX BOLT 7⁄16-14 X 11⁄4"
12 P0444012 BEARING BRACKET
13 PS35 PHLP HD SCR 5⁄16-18 X 3⁄4"
14 PW07 FLAT WASHER 5⁄16"
15 PN02 HEX NUT 5⁄16-18
16 P0444016 BLADE GUARD
17 PRP68M ROLL PIN 6 X 48
18 P0444018 SPEED NUT
19 P0444019 SUPPORTING ARM
21 P0444021 PIN 6 X 30
22 P0444022 SPLITTER
22A P0444022A MOUNT
23 P0444023 ANTI-KICKBACK
24 P0444024 ANTI-KICKBACK SPRING
25 P0444025 ROLL PIN 8 X 20
26 P0444026 BRACKET
27 P0444027 BRACKET
28 PB12 HEX BOLT 5⁄16-18 X 11⁄4"
29 PLW01 LOCK WASHER 5⁄16"
30 P0444030 GUARD SUPPORT SHAFT
31 PW07 FLAT WASHER 5⁄16"
32 P0444032 HAND KNOB
33 PN14 HEX NUT 8-32
34 PS21 PHLP HD SCR 8-32 X 3⁄4"
35 P0444035 MITER GAUGE BODY
36 PFH09 FLAT HD SCR 1⁄4-20 X 5⁄16"
37 P0444037 SLIDING BLOCK
38 P0444038 MITER BAR
38A PSS34 SETSCREW 10-24 X 5⁄8"
39 P0444039 STOP LINK
40 P0444040 POINTER
41 PRP14M ROLL PIN 3 X 6
41A PSS11 SETSCREW 1⁄4-20 X 1⁄4"
42 P0444042 SWITCH BOX WITH 2 BUTTONS
42-1 P044042-1 SWITCH
43 PS10 PHLP HD SCR 10-24 X 11⁄2"
44 P0444044 SWITCH BOX
45 P0444045 SWITCH FIXING PLATE
46 PN07 HEX NUT 10-24
47 PSW03-1 KNOB
REF PART # DESCRIPTION
48 P0444048 HANDWHEEL
49 P0444049 HANDWHEEL HANDLE
51 PW02 FLAT WASHER 3⁄8"
52 P0444052 POINTER
53 PSS11 SETSCREW 1⁄4-20 X 1⁄4"
54 P0444054 SET COLLAR
55 PSS11 SETSCREW 1⁄4-20 X 1⁄4"
56 P0444056 TILT SHAFT
57 P0444057 ECCENTRIC
58 P0444058 HEX NUT 9⁄16-20
59 P0444059 ROLL PIN 3.5 X 20
60 P0444060 FIBER WASHER
61 P0444061 FRONT BRACKET
62 PB12 HEX BOLT 5⁄16-18 X 11⁄4"
63 PW07 FLAT WASHER 5⁄16"
64 PLW01 LOCK WASHER 5⁄16"
66 P0444066 STOP BLOCK
67 PB05 HEX BOLT 1⁄4-20 X 3⁄4"
68 PW06 FLAT WASHER 1⁄4"
69 PSS16 SETSCREW 1⁄4-20 X 11⁄2"
70 PN05 HEX NUT 1⁄4-20
71 P0444071 FRONT TRUNNION
72 PRP49M ROLL PIN 5 X 25
73 PB32 HEX BOLT 5⁄16-18 X 5⁄8"
74 P0444074 WAVE WASHER
75 P0444075 ECCENTRIC
76 P0444076 ELEVATING SHAFT
77 P0444077 ROLL PIN 3.5 X 20
78 P0444078 FIBER WASHER
79 P0444079 SPACER
80 P0444080 ARBOR BRACKET SHAFT
81 P0444081 ARBOR NUT
82 P0444082 FLANGE
83 P0444083 BLADE OPTIONAL
84 P0444084 ARBOR BRACKET
85 PRP49M ROLL PIN 5 X 25
86 P0444086 ARBOR
87 P6203 BALL BEARING 6203ZZ
88 PK23M KEY 5 X 5 X 25
89 P0444089 LOADING SPRING
90 PR23M INT RETAINING RING 40MM
91 P0444091 JAM NUT 5⁄8-24
92 P0444092 ARBOR PULLEY
93 PSS05 SETSCREW 5⁄16-18 X 1⁄4"
94 P0444094 REAR TRUNNION
95 P0444095 REAR TRUNNION BRACKET
96 PW07 FLAT WASHER 5⁄16"
97 PLW01 LOCK WASHER 5⁄16"
98 PB03 HEX BOLT 5⁄16-18 X 1
99 P0444099 MOTOR BRACKET
100 PSS17 SETSCREW 5⁄16-18 X 5⁄16"
101 P0444101 MOTOR PLATE ROD
REF PART # DESCRIPTION

G0444/G0444Z 10" Table Saw -61-
102 P0444102 MOTOR PLATE
103 PB03 HEX BOLT 5⁄16-18 X 1
104 PW07 FLAT WASHER 5⁄16"
105 PLW01 LOCK WASHER 5⁄16"
106 PN02 HEX NUT 5⁄16-18
107 P0444107 MOTOR PULLEY
108 PSS11 SETSCREW 1⁄4-20 X 1⁄4"
109 P0444109 V-BELT 3VX-470
110 PK23M KEY 5 X 5 X 25
111 P0444111 MOTOR 1.5 HP (G0444)
111 P0444Z111 MOTOR 2 HP (G0444Z)
112 PWRCRD110L CORD 110V, LONG W/PLUG
112 PWRCRD220L CORD 220V, LONG W/PLUG
113 P0444113 NYLON CLAMP
114 PWRCRD110S POWER CORD 110V, SHORT
114 PWRCRD220S POWER CORD 220V, SHORT
115 PCB09 CARRIAGE BOLT 5⁄16-18 X 13⁄4"
116 PEC07M E-CLIP 7MM
116-1 P0444116-1 SPACER
117 P0444117 GUARD PLATE
118 P0444118 GUARD COVER
119 P0444119 FIBER WASHER 5⁄16"
120 PWN03 WING NUT 5⁄16-18
121 PN09 HEX NUT 5⁄8-18
122 P0444122 TIE-ROD
123 PN08 HEX NUT 3⁄8-16
124 P0444124 ADJUSTABLE STOP 3⁄8-16 X 2
125 PWR23 23MM WRENCH
126 PWR1213 12MM X 13MM WRENCH
127 PB05 HEX BOLT 1⁄4-20 X 3⁄4"
128 PAW02M ALLEN WRENCH 2MM
128B PAW04M ALLEN WRENCH 4MM
REF PART # DESCRIPTION
128A PAW03M ALLEN WRENCH 3MM
129 P0444129 FOOT STAND
130 P0444130 TOP SHORT BRACKET
131 P0444131 BOTTOM SHORT BRACKET
132 P0444132 TOP LONG BRACKET
133 P0444133 BOTTOM LONG BRACKET
134 P0444134 RUBBER FEET
135 PS19 PHLP HD SCR 1⁄4-20 X 1
136 PN05 HEX NUT 1⁄4-20
137 PW06 FLAT WASHER 1⁄4"
138 PCB01 CARRIAGE BOLT 5⁄16-18 X 5⁄8"
139 PW07 FLAT WASHER 5⁄16"
141 PN02 HEX NUT 5⁄16-18
142 PB03 HEX BOLT 5⁄16-18 X 1
143 P0444143 DUST HOOD
144 P0444144 PLATE
145 PTLW01 EXT TOOTH WASHER #10
146 PS22 PHLP HD SCR 10-24 X 5⁄8"
147 PN07 HEX NUT 10-24
148 P0444148 CORD CLIP
149 PB05 HEX BOLT 1⁄4-20 X 3⁄4"
150 PW06 FLAT WASHER 1⁄4"
151 PW01 FLAT WASHER 1⁄2"
152 PN06 HEX NUT 1⁄2-12
153 P0444153 SAFETY GLASSES LABEL
154 P0444154 UNPLUG WARNING LABEL
155 P0444155 WARNING LABEL
156 P0444156 GRIZZLY CAST LOGO
157 P0444157 READ MANUAL LABEL
160 P0444160 ELECTRICITY LABEL
161 P0444161 BLADE GUARD LABEL
162 P0444162 MACHINE ID LABEL (G0444)
162 P0444Z162 MACHINE ID LABEL (G0444Z)
163 PB96 HEX BOLT 10-24 X 5/8
REF PART # DESCRIPTION
