-56- G1023SL Series Table Saw
























 






























G1023SL (All) Main Parts

G1023SL Series Table Saw -57-
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P1023SL001 CABINET 87B PN07 HEX NUT 10-24
1A P1023SL001A LOWER PANEL 87C P1023SL087C MOTOR CORD (G1023SL/X/W)
2A P1023SL002A SCALE 87C P1023SLWX087C MOTOR CORD (G1023SLWX)
3 PHTEK4 TAP SCREW #10 X 3/8 87C P1023SLWX3087C MOTOR CORD (G1023SLWX3)
4 P1023SL004 MOTOR COVER 87D P1023SL087D POWER CORD (G1023SL/X/W)
5 P1023SL005 CORD CLAMP 87D P1023SLWX087D POWER CORD (G1023SLWX)
6A PS24 PHLP HD SCR #8-32 X 3/8 87D P1023SLWX3087D POWER CORD (G1023SLWX3)
6B PN14 HEX NUT #8-32 87G P1023SL087G GROMMET
58 P1023SL058 CORD CLAMP 87H P1023SL087H WIRE NUT
58A P1023SL058A CORD CLAMP PLATE 88 P1023SL088 SWITCH PLATE
58B P1023SL058B CORD CLAMP PLATE 88A PFH25 FLAT HD SCR 5/16-18 X 1"
79 PSS07 SET SCREW 1/4-20 X 1/2 88B PW07 FLAT WASHER 5/16
80 P1023SL080 STANDARD TABLE INSERT 88C PN02 HEX NUT 5/16-18
80A P1023SL080A DADO TABLE INSERT 90A P1023SL090A G1023SL MACHINE ID LABEL
81 P1023SL081 TABLE 90A P1023SLX090A G1023SLX MACHINE ID LABEL
82 PLW04 LOCK WASHER 3/8 90A P1023SLW090A G1023SLW MACHINE ID LABEL
83 PB24 HEX BOLT 3/8-16 X 1-1/4 90A P1023SLWX090A G1023SLWX MACHINE ID LABEL
83-1 PB18 HEX BOLT 3/8-16 X 1" 90A P1023SLWX3090A G1023SLWX3 MACHINE ID LABEL
84L P1023SL084L LEFT EXTENSION WING 91 P1023SL091 DUST HOSE ADAPTER
84R P1023SL084R RIGHT EXTENSION WING 104 PW03 FLAT WASHER #10
85 PW02 FLAT WASHER 3/8 154 P1023SL154 SWITCH PLATE BRACE
86 PSB16 CAP SCREW 3/8-16 X 3/4 155 P1023SL155 MOTOR BRACE
87 P1023SL087 MAG SWITCH (3HP, 1-PH) 211 G8588 LOGO PLATE
87 P1023SLWX087 MAG SWITCH (5HP, 1-PH) 212 PLABEL-12A READ MANUAL LABEL
87 P1023SLWX3087 MAG SWITCH (5HP, 220V, 3-PH) 213 PLABEL-11 SAFETY GLASSES LABEL
87S P1023SLWX3087S MAG SWITCH (5HP, 440V, 3-PH) 218 PLABEL-14 ELECTRICITY LABEL
87A PS31 PHLP HD SCR 10-24 X 1-3/4 219 PLABEL-33 UNPLUG TABLE SAW LABEL
