-28- H6246 Meat Cutting Bandsaw
H6246 Parts Breakdown

H6246 Meat Cutting Bandsaw -29-
H6246 Parts Breakdown

-30- H6246 Meat Cutting Bandsaw
H6246 Parts Breakdown

H6246 Meat Cutting Bandsaw -31-
REF PART # DESCRIPTION
1 PH6246001 MEAT SAW FRAME
2 PH6246002 UPPER DOOR
3 PH6246003 LOWER DOOR
4 PH6246004 UPPER WHEEL
5 P80202 BALL BEARING 80202
6 PWN02M WING NUT M8-1.25
7 PHTEK17M TAP SCREW 5 X 20
8 PR65M EXT RETAINING RING 3MM
9 PH6246009 UPPER BALL BEARING SHAFT
10 PH6246010 WHEEL CARRIER BRACKET
11 PS09M PHLP HD SCR M5-.8 X 10
12 PN32M HEX NUT M14-2
13 PH6246013 TWO HOLE PLATE
14 PS07M PHLP HD SCR M4-.7 X 8
15 PH6246015 PARALLEL PIN
16 PCB19M CARRIAGE BOLT M8-1.25 X 50
17 PH6246017 TENSION BRACKET
18 PH6246018 BLADE TENSIONER ROD
19 PN01M HEX NUT M6-1
20 PH6246020 SLOTTED INSERT
21 PLW06M LOCK WASHER 10MM
22 PH6246022 LOCKET HOUSING
23 PH6246023 NYLON WASHER 20MM
24 PH6246024 HOUSING NUT M22-1.5
25 PH6246025 TONGUE
26 PTLW05M EXT TOOTH WASHER 6MM
27 PB02M HEX BOLT M6-1 X 12
28 PH6246028 GUIDE SNAP
29 PH6246029 TOP PLUG
30 PH6246030 BLADE TENSIONER
31 PB02M HEX BOLT M6-1 X 12
32 PW03M FLAT WASHER 6MM
33 PB119M HEX BOLT M6-1 X 60
34 PWN01M WING NUT M6-1
35 PN01M HEX NUT M6-1
36 PH6246036 HAND KNOB M6-1 X 58
37 PH6246037 BLADE GUIDE
H6246 Parts List
REF PART # DESCRIPTION
38 PH6246038 GUIDE CARRIER EXTRUSION
39 PH6246039 GUIDE CARRIER MOUNT
40 PCB01M CARRIAGE BOLT M8-1.25 X 20
41 PH6246041 SQUARE HOLE PLATE
42 PH6246042 MOUNT BLADE GUIDE
43 PW01M FLAT WASHER 8MM
44 PN03M HEX NUT M8-1.25
45 PH6246045 UPPER GUIDE BODY
46 PSB04M CAP SCREW M6-1 X 10
47 PH6246047 UPPER GUIDE SHAFT
48 PH6246048 SPECIAL SCREW
49 P626 BALL BEARING P626Z
50 PW03M FLAT WASHER 6MM
51 PH6246051 MOUNT SHAFT-1
52 PH6246052 MOUNT SHAFT-2
53 PH6246053 TENSION BRACKET FRAME
54 PH6246054 BOLT GUIDE
55 PH6246055 LOWER GUIDE SHAFT
56 PH6246056 BRACKET-BLADE GUIDE
57 PS17M PHLP HD SCR M4-.7 X 6
58 PB83M HEX BOLT M6-1 X 16
59 PFN02M FLANGE NUT M6-1
60 PH6246060 LEFT RAIL-TABLE
61 PH6246061 RIGHT RAIL-TABLE
62 PRP75M ROLL PIN 8 X 26
63 PH6246063 BUSHING
64 PH6246064 SHAFT FOR CHOPPER
65 P6203 BALL BEARING 6203Z
66 PH6246066 BRACKET FOR CHOPPER
67 PH6246067 LOWER HOUSE PLATE
68 PH6246068 BLADE COVER
69 PR05M EXT RETAINING RING 15MM
70 PR09M EXT RETAINING RING 20MM
71 PK34M KEY 5 X 5 X 20
72 PK12M KEY 5 X 5 X 30
73 PH6246073 DRIVE SHAFT

-32- H6246 Meat Cutting Bandsaw
REF PART # DESCRIPTION
74 PH6246074 DRIVE PULLEY
75 P6004 BALL BEARING 6004Z
76 PH6246076 BALL BEARING MOUNT PLATE
77 PW04M FLAT WASHER 10MM
78 PFN01M FLANGE NUT M8-1.25
79 PH6246079 LOWER WHEEL
80 PB09M HEX BOLT M8-1.25 X 20
81 PH6246081 FLANGE
82 PH6246082 ANGLE PLATE
83 PH6246083 SEPARATE PLATE
84 PH6246084 REIN SLEEVE
85 PB03M HEX BOLT M8-1.25 X 16
86 PW01M FLAT WASHER 8MM
87 PB26M HEX BOLT M8-1.25 X 30
88 PW01M FLAT WASHER 8MM
89 PN03M HEX NUT M8-1.25
90 PTLW07M EXT TOOTH WASHER 8MM
91 PVA36 V-BELT A-36 4L360
92 PH6246092 BLADE 1950
93 PSB58M CAP SCREW M8-1.25 X 12
94 PH6246094 STAND ROD (10”)
95 PH6246095 SUPPORTER
96 PH6246096 WING BOLT M8-1.25 X 20
97 PH6246097 STAND ROD (7”)
98 PH6246098 PUSHER
99 PH6246099 FENCE
100 PH6246100 TABLE
101 PRP73M ROLL PIN 4 X 30
102 PSB02M CAP SCREW M6-1 X 20
103 PB83M HEX BOLT M6-1 X 16
104 PH6246104 LOWER GUIDE MOUNT
105 PH6246105 FLAT PIECE
106 P608 BALL BEARING 6008ZZ
107 PB28M HEX BOLT M8-1.25 X 60
108 PH6246108 CHARGING HOPPER
109 PH6246109 SHAFT-THRUST
110 PH6246110 SQUARE HEAD SCREW M10
H6246 Parts List
REF PART # DESCRIPTION
111 PH6246111 REAMER
112 PH6246112 FILTER COVER
113 PH6246113 LOCK COVER
114 PH6246114 PLASTIC HOPPER COVER
115 PH6246115 MEAT PUSH ROD
116 PH6246116 RUBBER TUBE CONNECTOR
117 PH6246117 FRONT PANEL STAND
118 PH6246118 REAL PANNEL STAND
119 PH6246119 LEFT PANEL STAND
120 PH6246120 RIGHT PANEL STAND
121 PH6246121 LEG
122 PH6246122 MOUNT-MOTOR
123 PH6246123 MOTOR PULLEY
124 PH6246124 RIVET 4 X 8
125 PH6246125 MOTOR 110V, 3/4HP
126 PH6246126 CHIP CONTAINER
127 PH6246127 CHIP CONTAINER RAIL-1
128 PH6246128 CHIP CONTAINER RAIL-2
129 PH6246129 SPACER BUSH
130 PW03M FLAT WASHER 6MM
131 PB47M HEX BOLT M6-1 X 40
132 PLW03M LOCK WASHER 6MM
133 PN06M HEX NUT M5-.8
134 PN18M ACORN NUT M8-1.25
135 PS25M PHLP HD SCR M4-.7 X 35
136 PW02M FLAT WASHER 5MM
137 PH6246137 CLAMP-CORD
138 PH6246138 BOX-SWITCH
139 PHTEK1M TAP SCREW M3.5 X 12
140 PHTEK29M TAP SCREW M3.5 X 20
141 PS74M PHLP HD SCR M4-.7 X 14
142 PTLW01M EXT TOOTH WASHER 4MM
143 PH6246143 COVER-SWITCH
144 PH6246144 LOCK SWITCH
145 PH6246145 STRAIN-RELIEF
146 PH6246146 CORD W/ PLUG
147 PH6246147 RUBBER FOOT SHOE
