Grohe MINTA TOUCH 31359 User manual

GROHE MINTA TOUCH
installation manual (USA)
12.06.2013

2
12.6.13
GROHE MINTA TOUCH
ARTICLE # 31359
INSTALLATION MANUAL
4 screws to attach the control unit to
back or side cabinet wall
Please use screws of appropriate length
and type for mounting surface.
Wrench 11/16” (17 mm)
Wrench 3/4” (19 mm)
Wrench 7/8” (22 mm)
Wrench 15/16” (24 mm)
Phillips screwdriver
Required Tools
(not included)
Required Materials
(not included)

3
13. Optional
Short Lever (40684)
in case of backsplash
problems
12. Optional
Gohtherm
Micro (34507) if
premixed water
is requested in
touch function
Pos. #
Prod. description
Order #
Units per
package
1
Lever
46015 000 1
2
Cap
46025 000 1
3
Cartridge
46048 000 1
4
pull out spray
46857 000 1
4.1
Non
-return valve 08565 000 1
4.2
Flow straightener
13997 000 1
5
Shank mounting kit
46345 000 1
6
Non
-return valve 08565 000 1
7
snap coupling
48220 000 1
8
solenoid valve
48213 000 1
8.1
Non
-return valve 08565 000 1
8.2
Dirt strainer
42395 000 1
9
control unit
48214 000 1
10
Battery
42886 000 1
11
Non return valve
adaptor USA
42808 000 * 1
Special Accessoires:
12
Gohtherm Micro
34507 000 1
13
Minta lever
40684 000 1
*availability on request
GROHE MINTA TOUCH
ARTICLE # 31359
INSTALLATION MANUAL
12.6.13
Spare Parts
(availaible for order)

4
GROHE MINTA TOUCH
ARTICLE # 31359
INSTALLATION MANUAL
Dimensional drawing
12.6.13

5
GROHE MINTA TOUCH
ARTICLE # 31359
INSTALLATION MANUAL
12.6.13
Operational drawings
operated with touch function (cold water only)
mixed water from
cartridge
cold water for touch
operation
operated with lever handle function (mixed water)

6
step
1
Keep a minimum distance of 3 inches (75 mm) from the
faucet hole to the back wall.
When the distance is less than 3 inches (75 mm), a shorter
lever is available (40 684)
The operating side of the lever can be fitted left, right or in
front.
Maximum thickness of worktop: 2 5/16 inches (60 mm)
< 60
Minta Short Lever Handel
(Available May 2014)
406 84 000 LP $59
406 84 DC0 LP $76
GROHE MINTA TOUCH
ARTICLE # 31359
INSTALLATION MANUAL
12.6.13

7
The flexible hoses must not be stretched,
twisted or extended!
If hoses must be extended, use nuts. The
complete hose and nuts must be insulated.
Insert the brass threaded shank through the
faucet body.
GROHE MINTA TOUCH
ARTICLE # 31359
INSTALLATION MANUAL
12.6.13
step
2
step
3

8
Guide the escutcheon, insulating sleeve and O-ring over the
flexible connection hoses and place it at the bottom of the
faucet body.
Then guide the flexible hoses and the threaded rod through
the mounting hole.
TIP: Move the white sleeves of the connection hoses one by
one in order to make it through the escutcheon, insulating
sleeve and faucet hole.
Remember to slide back the sleeves into place, make sure
the copper connections do not touch!
v
1
2
GROHE MINTA TOUCH
ARTICLE # 31359
INSTALLATION MANUAL
12.6.13
step
4
1
2

9
2
3
1
Install the mounting kit to the threaded shank
(underneath the worktop).
TIP: Slide the white sleeves (between copper pipe and
flexible hose) one by one through the mounting ring.
Remember to slide back the sleeves into place!
Place the mounting tool on top of the brass threaded
shank and turn it clockwise. At the same time keep the
faucet body in position and fixed to the worktop. In
this way, the body is mounted to the worktop.
5
Mounting the pull-out spray: Grease the rubber ring on
top of the brass rod with the included grease.
Install the nozzle on the hose.
Run the hose through the spout and then through the
brass shank. After this, press the spout carefully over
the shank and to the faucet body.
Clip at base of mounting shank must be fully pushed
down.
1
2
mounting set
3
3
GROHE MINTA TOUCH
ARTICLE # 31359
INSTALLATION MANUAL
12.6.13
step
6
step
2
step
5
1
2
1
2
3

10
7
ww
kw
1
1. Install the chrome T-connector on the cold water angle valve.
2. Connect the cold water hose (blue label) from the faucet with the top
of the chrome T-connector.
3. Connect the flexible hose (with the angled coupling) with the straight
edge on the chromed T-connector.
-
4. Connect the hot water hose (with red label) of the faucet with the hot
water angle valve.
5. Connect the mixed water supply nipple to the brass T-connector.
4
2 3
5
GROHE MINTA TOUCH
ARTICLE # 31359
INSTALLATION MANUAL
12.6.13
step
7
1
2
3
4
5

11
Connect the brass T-connector with the
control box.
Connect the brass T-connector with the mixed
water supply hose from the faucet hose.
(unlabeled)
Install the control box within 12 inch's of the faucet
mounting set so that the battery is accessible!
*4 screws not included please use screws of approprate leanth and type for
mounting surface.
1
2
GROHE MINTA TOUCH
ARTICLE # 31359
INSTALLATION MANUAL
12.6.13
step
9
step
8
1
2

12
Connect the flexible hose with the angled coupling to
the control box.
NOTE: Ensure that the hose is not in contact with
copper pipes, hoses or other parts of the faucet.
Install the red coupling on the extendable hose from
the pull out spray.
Connect red coupling to brass T-connector
1
2
GROHE MINTA TOUCH
ARTICLE # 31359
INSTALLATION MANUAL
12.6.13
step
10
step
11
1
2

13
Install the weight on the pullout hose.
Connect the cable from the control box with the faucet.
GROHE MINTA TOUCH
ARTICLE # 31359
INSTALLATION MANUAL
12.6.13
step
12
step
13

14
Is the sink basin
metal? Yes
No
Fasten balancing
cable to the
underside of the
basin
Skip to step 15
Complete
proceed to step
17
Fasten the balancing cable
14
step
14 What type is
sink do you
have ?
GROHE MINTA TOUCH
ARTICLE # 31359
INSTALLATION MANUAL
12.6.13

15
15
step
15 Fasten the balancing cable
Is there a garbage
disposal present?
Yes
No
Fasten balancing
cable to a metal
section of the
garbage disposal
Skip to step 16
Complete
proceed to step
17
GROHE MINTA TOUCH
ARTICLE # 31359
INSTALLATION MANUAL
12.6.13

16
15
step
16 Fasten the balancing cable
insert 2 images –
dishwasher near sink &
cold water supply line
Fasten the balancing
cable to a metal
section of the
dishwasher
Fasten the balancing
cable to the cold
water supply line
Is there a
dishwasher
nearby?
Yes
No
Complete
proceed to step
17
Complete
proceed to step
17
GROHE MINTA TOUCH
ARTICLE # 31359
INSTALLATION MANUAL
12.6.13

17
Turn on water first (IMPORTANT)
Insert the included battery to begin
configuration. Do not touch the faucet, sink, or
connections during this time For 1 minute!
The configuration will take one min do not
touch during this time of the system takes place.
Install the cover plate properly
15
2
3
GROHE MINTA TOUCH
ARTICLE # 31359
INSTALLATION MANUAL
12.6.13
step
17
2
3
1
End The faucet is now ready for use!

18
Touch Sensitivity function
The sensitivity of the Touch function varies depending on the ambient
temperature and humidity. The sensitivity can be set in 5 modes.
Level 3 is pre-set by the factory. Highest sensitivity level is 5.
By touching the faucet with skin or hand on the gray fields, cold water
can be tapped without operating the handle.
The touch function does not operate in the white areas
If the faucet does not respond to touch, the sensitivity needs to be
increased (to 4 or 5). When the faucet switches on spontaneously, the
sensitivity should be reduced (to 2 or 1).
Setting sensitivity of Touch function
To adjust the sensitivity, follow these steps:
•Press the AQUA STOP button until the light turns on, then release
the button.
•Then the last saved sensitivity setting will blink
(e.g. 3x flashing = Level 3).
•With each additional press of the button, the sensitivity increases 1
position. After position 5 it resets to position 1.
•When button is released, the light indicates the last set sensitivity
setting by flashing.
GROHE MINTA TOUCH
ARTICLE # 31359
INSTALLATION MANUAL
12.6.13
FAQ

19
Faucet cleaning (cleaning mode)
When touch operation should be disabled (e.g. for cleaning of
the faucet), the cleaning mode can be switched on. Then for 2
minutes, the touch operation is turned off. To enable the
cleaning mode, follow these steps:
•Briefly press the AQUA STOP button, then a small water flow
indicates the cleaning mode is activated.
•The light is blinks twice.
•For 2 minutes, the touch function is de-activated, and
afterwards it will automatically switch on again.
