Groov-e SOUNDBAR 160 User manual

GV-SB05 SOUNDBAR160
160W All-in-One Bluetooth Soundbar
with Built-in Subwoofer

30 Day Right To Return
WWe do not envisage any problems occurring
with your groov-e GV-SB05
160W All-in-One
Bluetooth Soundbar with Built-in Subwoofer.
However, for your peace of mind, should any
fault occur, please return it within 30 days to
your retailer with proof of purchase for an
exchange or refund.
12 Mo
12 Month Guarantee
This pThis product is guaranteed for twelve
months. Please retain your receipt as this will
be required as proof of purchase in the event
that the device does not perform as
expected then please contact your original
point of purchase, should you require further
assistance then please contact us.
E
Extended Warranty
Please register your product within 30 days
from date of purchase
www.groov-e.co.uk/warranty.
Proof of purchase required.
Contact Us
Reach out to us at [e-mail]
or visit
or visit www.groov-e.co.uk
01

02
“Congratulations on your purchase and Thank You for choosing the groov-e
GV-SB05 160W All-in-One Bluetooth Soundbar with Built-in Subwoofer.
Please read the guide carefully before using”.
CAUTION
1• Keep the product and all its parts out of reach of small children.
2
2• Do NOT leave it in high temperatures as electronic devices and plastic parts may
warp in heat. No naked flame sources, such as lighted candles, should be placed on
the product.
3• Do NOT leave it in low temperatures as moisture can form inside the product,
which may damage the circuit board.
4
4• Do NOT attempt to open the product. This product does not contain any user
serviceable parts. Unauthorised handling of the device may damage it and will void
your warranty.
5• Disconnect your Soundbar from the mains power supply during thunderstorms.
6• Always check that you have completely switched off your Soundbar, before you
change or disconnect the power supply.
7
7• Never throw batteries in a fire or attempt to open the outer casing. Batteries
should not be exposed to excessive heat such as sunshine, fire or the like. Dispose
of old batteries carefully.
8• Batteries are harmful if swallowed, so keep away from young children.
Box Contents
GV-SB05 Soundbar x 1
Remote Control x 1
P
Power Adapter x 1
Optical Cable x 1
User Manual x1
OVERVIEW

03
BACK VIEW
Power
Input
AUX
Input
Optical
Input USB
Input
Power On/Off Music / Voice / Movie
Mode
Play
Pause
BT / AUX / USB
Optical Mode
Next (Short Press)
Vol+ Long Press)
Prev (Short Press)
Vol - Long Press)
Functions
TOP VIEW
1. Slide open
battery cover 2. Insert AAA batteries 3. Close battery cover
Inserting Remote Batteries

04
Remote Buttons
Using the Remote Control
The remote control sensor at the front of the soundbar is sensitive to the remote
control’s commands up to a maximum of 8 metres away and within a maximum arc
of 30 degrees. Please note that the operating distance may vary depending on the
brightness of the room.
Music
Works great for music and
podcasts,
Standard for TV programs.
Voice
Enhance human
Enhance human voices
(Clear Voice)
Movie
For an expansive theater
experience. Virtual 3D
Surround Technology,
Take your home cinema
e
experience to new heights
with sound that comes
from above and all around
you.
Power On/Off
Switch the unit between
on and Standby mode
Volume +
Press to increase the volume
Previous
Use in AUX or Bluetooth
mode to go back a track
Source
AUX / OPT / Bluetooth
Play/Pause
Press to play and pause
Movie Mode
Press for Virtual 3D
Surround
Dimmer
Press the dimmer button on
the REMOTE CONTROL to
scroll through the dimmer
options available for the
LED panel. The options are
OF
OFF, LOW, MEDIUM, HIGH
Sound Mode
Press to choose between
three different sound modes
Next
Use in AUX or Bluetooth
mode to go forward a track.
Volume -
Press to decrease the volume
AUX
Press to enter AUX mode
Bluetooth
Press to enter Bluetooth mode
OPT
Press to enter Optical mode
MUTE
Press button mute
sound

05
Instructions
Connecting to the mains supply
Ensure that the power supply voltage is in the voltage of 110V~240V.
This unit is designed This unit is designed
This unit is designed This unit is designed to use the supplied adapter only.
Connecting the unit to any other power source may cause damage to the unit.
Unwind the mains cable to its full length. Connect the mains plug to a mains
socket. Make sure the mains plug is fully inserted into the mains socket.
Connect the adapter to the unit via the DCinput Socket. (DC-20V-IN)
Using the Bluetooth
PPairing a Bluetooth Device for the First Time. Press the POWER button on the
unit or the POWER button on the remote control to switch on the unit. Press
Bluetooth button on the remote to enter Bluetooth pairing mode. Using the
controls on your Bluetooth device, select the “GV-SB05” in your Bluetooth
settings to pair. Refer to the user manual for your specific device for
instructions on pairing and connecting Bluetooth devices. When successfully
paired and connected, a beep will issue from the unit. After initial pairing, the
unit will
unit will stay paired unless unpaired manually by the user. If your device
should become unpaired or you find it is unable to connect, the use repeat the
above steps.
DC20V / 2A
110V-240V
NOTE: Ensure all audio connections
of the unit are connected before
connecting to the mains power
socket.
GV-SB05

06
Instructions
Using USB
1. Insert a USB drive into the USB port.
2.
2. Press the Source Mode button repeatedly on the remote control until USB mode
appears on the display. To Play/Pause the track or Skip Forwards/Backwards to a
selected track, use the remote control. Audio played through the connected USB
device will now be heard.
Using Optical Input
You will need: An audio source with an Optical Audio Output and an Optical cable
(included).
1.
1. Connect the Optical Audio cable to the optical output on the audio source and to
the Optical Input on the soundbar. Press the POWER button on the soundbar or
POWER button directly on the remote control to switch on the unit.
2. Press the OPT button on the remote control to switch to Optical mode or press
the MODE button on the main unit press repeatedly to select the Optical mode.
Using the
Using the controls on your connected device, make sure the audio settings are set
to PCM or Audio and are turned On. Audio from the connected audio source will now
be played through the speakers.

07
Instructions
Connecting Aux to TV or MP3 Player
Plug one end Plug one end of a 3.5mm to 3.5mm Aux In cable (not supplied) into the Aux port on
the unit. Then plug the other end of the cable into the audio output on your
TV or MP3 player or other audio source. Press the Power button on the soundbar or
Power button directly on the remote control to switch on the unit. Press the Mode
button repeatedly on the soundbar or remote or press the AUX button on the
remote control to enter AUX mode. Audio played through the TV or connected
device will now be heard through the speakers.
OOption For Wall Mounting
If you wish to wall mount the unit, please use Universal Soundbar brackets (not
included)
AUX

08
Troubleshooting
If the soundbar does not work properly as desired, please check the following.
Malfunction
No power / function
No sound
No sound from Bluetooth connection
Function disturbance
Remote control does not work
[p
[properly]
Possible Cause/Measures
Check whether the power is switched on
or off at the wall.
Check whether the power adaptor is
properly connected to power outlet or
not.
Check wh
Check whether cables are properly
installed.
If they are, please try alternative cable to
connect to your TV if possible.
Check unit is out of standby and in mode.
Disconnect the soundbar from your
device and reconnect.
Swi
Switch off and unplug the unit. Leave it
for 2 minutes and switch it on again.
If a particular mode is causing problems,
please try an alternative connection to
your TV such as Optical or Bluetooth.
Check whether the batteries have run
out or not.
R
Replace with a new ones if necessary.
Check whether there is an obstacle
blocking the remotes signal.

BATTERY REMOVAL/DISPOSAL
This product contains batteries and should not be treated as normal household
waste and should be recycled. Please take it to your nearest collection facility or
for further details contact your local council or visit www.recycle-more.co.uk
B
Batteries contain substances that may be harmful to the environment and human
health. Keep out of the reach of children and seek immediate medical help if
swallowed.
Never throw batteries into a fire or attempt to open the outer casing.
Should your product develop a fault and your battery needs replacing for further
advice on how to safely remove your battery please visit our website at
www.groov-e.co.uk
GGUARANTEE
Subject Subject to the conditions stated below, Groov-e guarantees this equipment
against defects in workmanship or materials of its mechanical and
electronic component parts (excluding styling, battery cells, magnetic
tapes, re-chargeable batteries, user removeable memory devices, with the
exception where the battery is inbuilt into the product) for a period of one
year from the date of purchase. This product will be repaired or if
necessary replaced free of charge if it has been proven to be defective
within the one
within the one year warranty period.
10
SPECIFICATIONS
Bluetooth chipset: 5.0
Bluetooth profiles: A2DP, HFP,
HSP, AVRCP, SPP
Bluetooth frequency range:
2.402-2.480 GHZ
RF output p
RF output power 4dB
Wireless range: 10M (open area)
Power supply:
AC100~240V/50~60Hz, DC
20V/2A
Speaker power: 90W (2 x 25W +
40W)
Spea
Speaker channel: 2.1
FEATURES
• Speakers: 90W RMS power & 160W peak power
• Built-in subwoofer
• 2 x medium-high frequency drivers + 1 x bass
driver
•
• Compatible with most TV’s for home theatre
sound
• Wireless Bluetooth speaker - connect to your TV,
PC, Laptop, Computer, Smartphone, Tablet
• LED display panel
• Crisp & clear sound with deep base
• 3 sound modes (Music, Movie, Voice)
• Ea
• Easy controls
• 4 Input modes: Optical, USB, AUX (3.5mm),
Bluetooth
• 1.5M Optical cable (included)
• Remote control (included) -requires 2 x AAA
batteries (included)

1) Claims under this guarantee should be made through the authorised
dealer/retailer from whom the equipment was purchased. If this is not possible,
please contact Groov-e directly.
2) This guarantee is only valid when the equipment is purchased and retained
within the United Kingdom and a valid proof of purchase has been provided.
3) This Guarantee Excludes:
(i)
(i) All damage caused through accident, misuse, wear and tear, neglect, installation
and/or use in a manner inconsistent with technical and safety standards.
(ii) Alterations or adjustments made to equipment
(iii) Loss of data resultant from malfunction of hard drive or other storage device
(iv) Damage caused to any third party device as a result of using the product.
4) No liability under this guarantee shall be incurred:
(i) In respect of damage or loss occurring during transit to or from the purchaser
(ii)
(ii) Where the serial number plate of the equipment has been removed or altered in
any way.
5) Groov-e shall not be liable for consequential damage, loss or injury arising from
or in connection with the equipment, excepting only that nothing in this condition
shall or shall be construed so as to exclude or restrict liability for negligence.
6) The cost of carriage to and from Groov-e shall be borne by the purchaser.
7) This guarantee is personal to the original purchaser and is not transferable.re
8)
8) If the equipment, in respect of which a claim hereunder is made, is found on
examination to comply with the published specifications, a test fee may be
incurred.
This gua
This guarantee is in addition to and does not in any way affect any statutory
or other right of consumer purchasers, including those rights in relation to
sections 13 to 15 of the Sale of Goods Act 1979, the Sale and Supply of
Goods to Consumer Regulations 2002, The Consumer Rights Act 2015 or the
Sale of Goods and Supply of Services Act 1980 (for ROI).
DECLARATION OF CONFORMANCE
GGroov-e hereby declares that this product is in compliance with the essential
requirements and other relevant provisions of the Radio Equipment Directive
2014/53/EU. The complete declaration of conformity can be requested from us at:
Unit J
Braintree Industrial Estate
Braintree Road
Ruislip
Middles
Middlesex
HA4 0EJ UK
www.groov-e.co.uk
Email: [e-mail]
Telephone: [phone]
Register your purchase for extended warranty
www.groov-e.co.uk/warranty MADE IN CHINA
Authorised EU Representative
Rashmian EU Ltd
Robwyn House
Suite 3E
Corrintra
Castleblayney
C
Co. Monaghan
Ireland
11
