Groz LED 150 User manual

INSTRUCTION MANUAL
S2890, REV A
1
LED 150
2W COB Rechargeable
Pocket Flash Light
Ideal for maintaince
professionals,
mechanics, drivers,
supervisors etc
2W COB light produces
200 lumens for a
flooding beam of
focussed light
Outstandingly bright
light COB ( chip on
board)technology for
high lumen output per
square inch, giving
super brightness &
illumination
COB light have an
advantage of thermal
resistance & larger
cooling area
Swivelling Magnetic
Base: The Base can
swivel upto 180° to
adjust to the required
angle
Hands free use: Super
strong Magnetic base
makes it easy to mount
onto any metallic
surface for hands free
use
CAT NR. ORD NR.
LED/150 55049
IK07
RoHs
Pocket/ Belt Clip: Can
be hooked onto a
pocket/Belt for easy
mobility and hands
free operation
Rotating hook:
Rotating Hook adjusts
to dierent angles
Light weight &
Durable: light weight
heavy duty ABS body
with rubber coating
is water resistant and
impact resistant
Complete with 3.7V
1800 mAh Litium-ion
battery for longer life
Micro USB charging
port protected by
rubberized bezel
5V 1 Amp USB output
port for use as power
bank
Supplied with USB
cable
LUMEN
200
RUN TIME
3 H
CHARGING
TIME
3H
BATTERY
Li-ion

www.groz-tools.com
2
SAFETY INFORMATION
• Check for damaged parts and any other
conditions that may aect the operation
of this product. Replace damaged parts
immediately.
• Do not use the lamp in the immediate vicinity
of inflammable materials or gases.
• Only use the accessories included with the
product .
• Keep the lamp out of reach of unauthorised
persons, especially children.
• Do not point the light directly in your own or
any other person’s or animal’s eyes.
PACKAGING CONTENT
NOMENCLATURE
OPERATING INSTRUCTIONS (REFER
“NOMENCLATURE”)
Charging
1. Fully charge the battery before the first use.
2. Turn o the light and connect to the supplied
micro USB charger cable.
3. Plug in the Micro USB cable
4. The red LED will light up during the charge.
5. Once the batteries are completely charged
the red indicator LED turns OFF and the
green LED will turn on.
6. Full charge takes 3hrs.
7. Power Bank- Insert a USB cable in the USB
slot and the device connected with the
battery will start charging
OPERATION
To switch ON the light press the button at the
top of the unit. Press the same button to switch
OFF the light
MAINTENANCE
• Before cleaning the LED worklight,
disconnect the USB cable (if being charged)
• Clean with a dry or slightly moist, clean, lint-
free cloth and a mild detergent if required.
• Do not use cleaners that contain abrasives
or solvents.
• Check the LED worklight for damage before
each use. If the lens is damaged it must be
replaced immediately.
• Clean any dirt from the housing or the
lens immediately, since it could cause
overheating.
DISPOSAL
Remove the battery from the light by opening
both the locks on the top and bottom of the
battery.
DESCRIPTION QUANTITY
Light 1
USB cable 1
AON/OFF button
B5V DC micro USB charging port
CUSB output port for use as Power Bank
A
B
C

3
