Grunbeck GENO-UV User manual

Operation manual
Temperature-controlled flushing – time-controlled
for GENO-UV
Edition October 2020
Order no. 520 952-inter_065

Temperature-controlled flushing –
time-controlled for GENO-UV
Order no. 520 952-inter_065 Edited by: mal-mrie G:\BA-520952-INTER_065_TEMPERATURSPÜLUNG.DOCX
2
Table of contents

The operation manual consists of several chapters, which are listed
below.
A General
4
1 | Preface
2 | General safety information
3 | Shipping and storage
4 | Disposal
B Basic information
7
C Product description
8
1 | Intended use
2 | Technical data
3 | Scope of supply
D Installation/Commissioning/Operation
10
1 | Commissioning
2 | Set-up
Publisher's information
All rights reserved.
© Copyright by Grünbeck Wasseraufbereitung GmbH
Printed in Germany
Effective with the date of edition indicated on the cover sheet.
-Subject to modifications in line with technical advances-
Reprints, translations into foreign languages, electronic storage or copying of
this operation manual, including extracts, only with explicit written approval of
Grünbeck Wasseraufbereitung GmbH.
Any type of duplication not authorised by Grünbeck Wasseraufbereitung is a
copyright violation and subject to legal action.
Responsible for contents:
Grünbeck Wasseraufbereitung GmbH
Josef-Grünbeck-Str. 1 •89420 Hoechstaedt; Germany
Phone [phone] •Fax [phone]
www.gruenbeck.com •[e-mail]
Printing: Grünbeck Wasseraufbereitung GmbH
Josef-Grünbeck-Str. 1, 89420 Hoechstaedt; Germany

Temperature-controlled flushing –
time-controlled for GENO-UV
Order no. 520 952-inter_065 Edited by: mal-mrie G:\BA-520952-INTER_065_TEMPERATURSPÜLUNG.DOCX
3
EU Declaration of Conformity
This is to certify that the system designated below meets the safety and health requirements of
the applicable European guidelines in terms of its design, construction and execution.
This certificate will become void if the system is modified in a way not approved by us.
Manufacturer:
Grünbeck Wasseraufbereitung GmbH
Josef-Grünbeck-Str. 1
89420 Hoechstaedt
Germany
Responsible for documentation:
Markus Pöpperl
System designation:
Temperature-controlled flushing – time-controlled for
GENO-UV
Serial no.:
Refer to type plate
Applicable EC directives:
Low Voltage (2014/35/EU)
EMC (2014/30/EU)
Applied harmonised standards,
in particular:
DIN EN 60730-1:2017-05,
DIN EN 61010-1:2011-07,
DIN EN 61000-6-2:2006-03,
DIN EN 61000-6-4:2011-09
DIN EN 61326-1:2013-07
Applied national standards and
technical specifications, in particu-
lar:
Location, date and signature
Hoechstaedt, 26.02.2019 i. V.
M. Pöpperl
Dipl.-Ing. (FH)
Function of signatory:
Head of Technical Product Design

Temperature-controlled flushing –
time-controlled for GENO-UV
Order no. 520 952-inter_065 Edited by: mal-mrie G:\BA-520952-INTER_065_TEMPERATURSPÜLUNG.DOCX
4
A General
1 | Preface
Thank you for choosing a Grünbeck product. Backed by decades of experience
in the area of water treatment, we provide custom-made solutions for all kind of
processes.
Drinking water is classified as food and requires particular care. Therefore, al-
ways ensure the required hygiene in operating and maintaining systems in-
volved in the drinking water ordinance. This also applies to the treatment of wa-
ter for industrial use if repercussions for the drinking water cannot completely be
excluded.
All Grünbeck systems and devices are made of high-quality materials. This en-
sures reliable operation over many years, provided you treat your water treat-
ment system with the required care. This operation manual assists you with
crucial information. Please read the entire operation manual carefully before
installing, operating or servicing the system.
Customer satisfaction is our primary aim, and providing customers with qualified
advice is crucial. If you have any questions concerning this system, possible
extensions or general water and waste water treatment, our field service staff,
as well as the experts at our headquarters in Hoechstaedt, are available to help
you.
Advice and
assis-
tance
For advice and assistance, please contact your local representative (refer to
www.gruenbeck.com). In case of emergency, please get in touch with our ser-
vice hotline at [phone]. We can connect you with the appropriate ex-
pert more quickly if you provide the required system data. To ensure that this
information is to hand at all times, please keep the precise equipment data to
hand (refer to the type plate in chapter C-1).

Temperature-controlled flushing –
time-controlled for GENO-UV
Order no. 520 952-inter_065 Edited by: mal-mrie G:\BA-520952-INTER_065_TEMPERATURSPÜLUNG.DOCX
5
2 | General safety information
2.1 Symbols and notes
Important information in this operation manual is emphasised by
symbols. Please pay particular attention to this information to ensure
the hazard-free, safe and efficient handling of the system.
Danger! Failure to adhere to this information will cause serious or
life-threatening injuries, major damage to property or inadmissible
impurities in the drinking water.
Warning! Failure to adhere to this information may cause injuries,
damage to property or contamination of the drinking water.
Caution! Failure to adhere to this information can result in damage
to the system or other objects.

Note: This symbol characterises information and tips that make your
work easier.
Tasks with this symbol may only be performed by Grünbeck's tech-
nical service/authorised service company or by persons expressly
authorised by Grünbeck.
Tasks with this symbol may only be performed by trained and quali-
fied electrical experts according to the VDE guidelines or according
to the guidelines of a similar local institution.
Tasks with this symbol may only be performed by water suppliers or
approved installation companies. In Germany, the installation com-
pany must be registered in the installation directory of a water suppli-
er according to Section 12(2) AVBWasserV (German Ordinance on
General Conditions for the Supply of Water).
2.2 Operating
personnel
Only allow persons who have read and understood this operation
manual to work with the system. Strictly observe the safety infor-
mation.

Note: By concluding a maintenance contract, you ensure that all of
the required tasks are performed on time. You may perform the inter-
im inspections yourself.

Temperature-controlled flushing –
time-controlled for GENO-UV
Order no. 520 952-inter_065 Edited by: mal-mrie G:\BA-520952-INTER_065_TEMPERATURSPÜLUNG.DOCX
6
3 | Shipping and storage
Caution! The system may be damaged by frost or high temperatures.
In order to avoid damage of this kind:
Protect from frost during transportation and storage!
Do not install or store the system next to objects which radiate a lot of
heat.
4 | Disposal
Comply with the applicable national regulations.
4.1 Packaging
Dispose of the packaging in an environmentally sound manner.
4.2 Product
If this symbol (crossed out waste bin) is on the product, European
Directive 2012/19/EU applies to this product. This means that this
product or the electric and electronic components are not allowed to
be disposed of in the household waste.
Dispose of electrical and electronic products or components in an
environmentally sound manner.

For information on collection points for your product, contact your
municipality, the public waste disposal authority, an authorised body
for the disposal of electrical and electronic products or your waste
collection service.

Temperature-controlled flushing –
time-controlled for GENO-UV
Order no. 520 952-inter_065 Edited by: mal-mrie G:\BA-520952-INTER_065_TEMPERATURSPÜLUNG.DOCX
7
B Basic information

Note: Prior to installation, please check the temperature-controlled
flushing for possible transportation damage.
The control unit must be protected against frost and may not be in-
stalled next to heat sources which radiate a lot of heat. The device
itself is approved for an ambient temperature of max. 40 °C.
Warning: The electrical installation may only be carried out by an au-
thorised electrician in accordance with the regulations of the electrical
utility and the applicable VDE regulations. The client must provide an
AC/DC sensitive ground fault circuit interrupter (trip current 30 mA).
The electrical connection is made via a 230V/50Hz AC power system.
Caution! The electrical power supply to the control unit must be dis-
connected before each installation/removal or intervention in the con-
trol.
Do not disconnect the unit from the mains prior to a holiday!

Note: Like the corresponding GENO-UV disinfection devices, the
temperature-controlled flushing must be connected to a permanently
live socket outlet.
Caution! Danger of burns! During continuous operation, the coil of
the 2/2-way solenoid valve can become very hot.

Temperature-controlled flushing –
time-controlled for GENO-UV
Order no. 520 952-inter_065 Edited by: mal-mrie G:\BA-520952-INTER_065_TEMPERATURSPÜLUNG.DOCX
8
C Product description
1 | Intended use
The temperature-controlled flushing – time-controlled for GENO-UV
serves for the periodic renewal of water in the GENO-UV disinfection
unit. During longer idle times (e.g. holiday, seasonal operation), the
lamp energy can raise the temperature of the water to above the ad-
missible temperature range. This can be effectively prevented by
means of temperature-controlled flushing that is time-controlled.
The temperature-controlled flushing – time-controlled for GENO-UV is
designed exclusively for use in industrial and commercial applica-
tions.
1.1 Mounting of the temperature-controlled flushing – time-controlled for GENO-UV
Plug the electronic part onto the solenoid valve coil as shown in Fig.
D-1. It must be ensured that the drain tap (no. 7) can be
opened/closed correctly. If necessary, the connector part in the elec-
tronics can be turned by ±90°.

Note: Do not damage the cable connections on the plug or the elec-
tronics!

Temperature-controlled flushing –
time-controlled for GENO-UV
Order no. 520 952-inter_065 Edited by: mal-mrie G:\BA-520952-INTER_065_TEMPERATURSPÜLUNG.DOCX
9
2 | Technical data
Table C-1: Technical data
Temperature-controlled flushing – time-controlled
for GENO-UV
Connection data
2/2-way valve
Protective system
IP 65 (with connector socket)
Power supply
[V/Hz]
230/50 – 60
Connection data
Digital time control
Protection/Protection class
IP 65/ (with valve)
Power supply
[V/Hz]
230/50 – 60
Nominal capacity
1.5 W
Switching voltage
like operating voltage
Switching times
0.5 s … 10 h
Performance data
Digital time control
Nominal pressure (PN)
10
Operating range
2-10 bar
Dimensions and weights
Temperature rinsing
Width approx. (with drain connection)
170 mm
Height approx.
100 mm
Depth, approx.
90 mm
Ambient data
Ambient temperature
5 – 40 °C
Max. relative air humidity
70 %
Order no.
523 820
3 | Scope of supply
Temperature-controlled flushing – time-controlled for GENO-UV con-
sisting of 2/2-way solenoid valve, digital time control and mains cable.
Reducing nipple for connection to the GENO-UV disinfection unit, as
well as a hose for draining the water.

Temperature-controlled flushing –
time-controlled for GENO-UV
Order no. 520 952-inter_065 Edited by: mal-mrie G:\BA-520952-INTER_065_TEMPERATURSPÜLUNG.DOCX
10
D Installation/Commissioning/Operation
1 | Commissioning
The temperature-controlled flushing is connected to the GENO-UV
disinfection unit as shown in Fig. 1, System design.
1
Vent tap
5
2/2-way solenoid valve
2
Inflow into GENO-UV
6
Drain connection acc. to DIN EN 1717
3
UV lamp
7
Digital time control
4
Discharge valve
8
Outflow from GENO-UV
Fig. 1: System design
The hose is led to the drain. There must be a free outflow to the drain.
Depending on the GENO-UV disinfection unit, a different volume of
water must be exchanged. The system volumes are listed in the rele-
vant technical data or an extract can be found in the table below.
Table D-1: GENO-UV disinfection unit water volume
Disinfection unit
Water volume
GENO-UV 40 S 8 litres
GENO-UV 60 S; GENO-UV 60 I 10 litres
GENO-UV 120 S, GENO-UV 120 I 16 litres
GENO-UV 200 S, GENO-UV 200 I 21 litres

Temperature-controlled flushing –
time-controlled for GENO-UV
Order no. 520 952-inter_065 Edited by: mal-mrie G:\BA-520952-INTER_065_TEMPERATURSPÜLUNG.DOCX
11
Deviations from the proposed basic settings may be necessary de-
pending on the local pressure level, temperature conditions and other
conditions.
A = t
on
= open state (basic setting = 10 s)
B = function setting (basic setting = t
off
+ t
on
)
C = t
off
= closed state (basic setting = 5 h)
Proposal for basic setting
1
Cursor
5
Min. value of the time range +50% of
the time range
2
Position 1 of the potentiometer =
minimum value of the selected time
range (default position)
6
Min. value of the time range +80% of
the time range
3
Min. value of the time range +10%
of the time range
7
Position 3 of the potentiometer = full
scale of the selected time range
4
Min. value of the time range +40%
of the time range

Temperature-controlled flushing –
time-controlled for GENO-UV
Order no. 520 952-inter_065 Edited by: mal-mrie G:\BA-520952-INTER_065_TEMPERATURSPÜLUNG.DOCX
12
The time is set as a percentage. For ex-
ample, a setting of 8 s in the time range
0.5 ... 10 s achieves by changing over to
the time range 0.5 ... 10 h, a value of 8
hours.
Example: In the time range 0.5 ... 10 s,
the percentages correspond to the fol-
lowing times:
17 % ≈1,6 s
34 % ≈3,2 s
51 % ≈4,8 s
68 % ≈6,3 s
85 % ≈7,9 s
Fig. D-3 Legend for time setting

Note: After finishing the installation, open the GENO-UV vent tap on
the temperature-controlled flushing.
2 | Design
1
Switches 4 and 5: To choose the operating mode of the solenoid valve
Switches 1, 2 and 3: To adjust the range ton
Switches 6, 7 and 8: To adjust the range toff
2
Potentiometer t
off
3
Potentiometer t
on

Temperature-controlled flushing –
time-controlled for GENO-UV
Order no. 520 952-inter_065 Edited by: mal-mrie G:\BA-520952-INTER_065_TEMPERATURSPÜLUNG.DOCX
13
Switches 4
and 5
Operation mode of the solenoid valve
ON (ton)/OFF (toff) cycle of the valve: Set the
time ton and the time toff
OFF (toff)/ON (ton) cycle of the valve: Set the
time ton and the time toff
Timed-out activation of the valve: Only set
the time ton
Delayed activation of the valve: Only set the
time delay toff
Switches 1, 2, 3 (t
on
) and 6, 7, 8 (t
off
)
Time range
0,5-10 seconds
1,5-30 seconds
5-100 seconds
0,5-10 minutes

Temperature-controlled flushing –
time-controlled for GENO-UV
Order no. 520 952-inter_065 Edited by: mal-mrie G:\BA-520952-INTER_065_TEMPERATURSPÜLUNG.DOCX
14
1,5-30 minutes
5-100 minutes
12-240 minutes
0,5-10 hours
