Grundfos PS.R Series User manual

Pumping station systems
PS.R.05 - 17
Installation and operating instructions
GRUNDFOS INSTRUCTIONS

English (GB)
2
English (GB) Installation and operating instructions
Original installation and operating instructions
These installation and operating instructions describe Grundfos
pumping station systems PS.R.05-17.
Sections 1-7 give the information necessary to be able to handle,
install and start using the product in a safe way.
Sections 8-10 give important information about the product, as
well as information on maintenance, service and disposal of the
product.
CONTENTS
Page
1. Symbols used in this document
The text accompanying the three hazard symbols DANGER,
WARNING and CAUTION is structured in the following way:
1. Symbols used in this document 2
2. Safety instructions 3
3. Receiving the product 4
3.1 Transporting the product 4
3.2 Inspecting the product 4
4. Installing the product 5
4.1 Preparing the foundation 5
4.2 Installing the pit 5
4.3 Installing the valve chamber 7
4.4 Connecting the pipes 8
4.5 Fitting the sleeve 9
4.6 Pipes with flange connection 9
5. Installing the pump(s) 9
5.1 Fitting the chain 9
6. Installing the level switches 10
6.1 Start and stop levels 10
6.2 Installing the pump controller 10
6.3 Float switches 10
6.4 Electrodes 11
6.5 Air bells 11
6.6 Pressure transducer 11
6.7 Other types of level control equipment 11
7. Electrical connection 11
7.1 Installing the cables 11
8. Product introduction 12
8.1 Product description 12
8.2 Applications 12
8.3 Pumped liquids 12
8.4 Pumping station system (PS.S) 12
8.5 Pumping station modular (PS.M) 12
8.6 Identification 13
9. Maintaining and servicing the product 15
9.1 Repairing a non-return valve 16
9.2 Contaminated pumps 16
9.3 Service contract 16
10. Disposal 16
Prior to installation, read this document. Installation
and operation must comply with local regulations and
accepted codes of good practice.
DANGER
Indicates a hazardous situation which, if not avoided,
will result in death or serious personal injury.
WARNING
Indicates a hazardous situation which, if not avoided,
could result in death or serious personal injury.
CAUTION
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate personal injury.
SIGNAL WORD
Description of hazard
Consequence of ignoring the warning.
- Action to avoid the hazard.
A blue or grey circle with a white graphical symbol
indicates that an action must be taken.
A red or grey circle with a diagonal bar, possibly with
a black graphical symbol, indicates that an action
must not be taken or must be stopped.
If these instructions are not observed, it may result in
malfunction or damage to the equipment.
Tips and advice that make the work easier.

English (GB)
3
2. Safety instructions
Receiving the product
Installing the product
Electrical connection
Maintaining and servicing the product
DANGER
Crushing hazard
Death or serious personal injury
- Place the pit on even ground to prevent the pit in
overturning.
- Make sure the lifting bracket or strap is tightened
before attempting to lift the pit. Tighten if
necessary. Carelessness during lifting or
transportation may cause injury to persons or
damage to the pit.
CAUTION
Collapsing hazard
Minor or moderate personal injury
- Support for the crane must be placed at a suitable
distance from the pit to avoid collapse of pit hole.
Work according to local regulations.
WARNING
Crushing hazard
Death or serious personal injury
- The lifting equipment used for lifting the pump
must be rated for the weight of the pump,
approved and maintained according to local
regulations.
WARNING
Electric shock
Death or serious personal injury
- The pump or pump controller must be connected
to an external emergency stop.
If the main switch is used as emergency stop, it
must fulfil EN 60204-1, 10.8.4.
DANGER
Electric shock
Death or serious personal injury
- Before starting any work on the product, make
sure that the power supply has been switched off
and that it cannot be accidentally switched on.
DANGER
Crushing and suffocation hazard
Death or serious personal injury
- Before entering PS.R.17, make sure that the cover
and safety grid are locked in open position and
that the pit is ventilated according to local
regulations. If not, do not enter the pit.
DANGER
Falling hazard
Death or serious personal injury
- When entering the pit, wear a safety harness and
use approved equipment for lifting persons up from
the pit according to local regulation.
CAUTION
Pressurised system
Minor or moderate personal injury
- Relieve the pressure by draining the system before
dismantling the non-return valve.
CAUTION
Biological hazard
Minor or moderate personal injury
- Remove the fuses or switch off the main switch
before dismantling the non-return valve.
Make sure that the power supply cannot be
accidentally switched on.
- Use gloves and other suitable personal protection
equipment in accordance with local regulations.
Observe local regulations on exposure to
wastewater.
- Rinse the non-return valve thoroughly with clean
water before carrying out maintenance and
service.
- Flush the pump thoroughly with clean water and
rinse the pump parts in water after dismantling.

English (GB)
4
3. Receiving the product
3.1 Transporting the product
The pit must be transported in a horizontal position and anchored
to the transport vehicle. Accessories, if any, must be secured
inside the pit.
The customer must provide appropriate lifting equipment at the
place of unloading. The weight of the pit is stated on the
nameplate.
Precautions during transport and handling
• Do not dump the pit from the lorry.
• Use approved straps of textile or similar materials when lifting
the pit on to or down from a lorry or moving it on the
construction site.
• Handle and lift the pit according to local regulations.
• Do not drag the pit over the ground.
• Point loads must not occur.
• The pit must not be exposed to sharp edges.
• Fix the pit securely during transport.
• When the pit is placed on the ground, make sure the ground is
even.
Fig. 1 Lifting the pit
3.2 Inspecting the product
After transportation and before installation, the pumping station
must be inspected by the customer.
The inspection must include the following:
• Check the pumping station for transport damage. Contact the
transporter immediately if you detect any damage.
• Check that the products delivered correspond to the order.
• Check the positions and sizes of fittings.
• Retighten various connections, as they may have become
loose during the transport.
• Check that all valves, except the draining valve in the valve
chamber, are open.
• Check other equipment such as vent pipes.
When transporting and handling the pit at low
temperatures, take into consideration that the pit
impact resistance is reduced.
Before raising the pit into vertical position, remove
transport supports and accessories from the inside of
the pit.
DANGER
Crushing hazard
Death or serious personal injury
- Place the pit on even ground to prevent the pit in
overturning.
If the pit is equipped with a lifting point, use it during
handling.
TM06 0063 4713
DANGER
Crushing hazard
Death or serious personal injury
- Make sure the lifting bracket or strap is tightened
before attempting to lift the pit. Tighten if
necessary. Carelessness during lifting or
transportation may cause injury to persons or
damage to the pit.

English (GB)
5
4. Installing the product
4.1 Preparing the foundation
With reference to DS/EN 1997-1: Eurocode 7: Geotechnical
Category 2:
We recommend that you complete a geotechnical investigation of
the site conditions before you install the pit.
With reference to DS/EN 1997-1: Eurocode 7: Geotechnical
Category 1:
The geotechnical investigation can be judged to be unnecessary,
if the conditions below are fulfilled:
• There is a negligible risk of overall instability, ground
movements or adverse ground conditions.
• Comparable local experience shows that the ground
conditions are sufficiently uncomplicated.
• There is no excavation below the water table.
• Comparable local experience indicates that the proposed
excavation below the water table will be uncomplicated.
In case of doubt, consult a geotechnical specialist.
Fig. 2 Schematic installation drawing
4.1.1 Foundation layer
• The pit must be placed on a foundation layer if soil analyses
and information about the pit load indicate that the soil is not
capable of bearing the weight. The bedding layer on which the
pit is placed is not regarded as a foundation layer.
• The foundation layer can be made after the excavation by
laying a stable layer of suitable gravel or similar material and
compacting it in layers of maximum 30 cm (corresponding to
approximately 20 cm after compaction). Such a foundation
layer is also required if the excavation has become too deep
by mistake.
4.1.2 Bedding layer
• The material for the bedding layer must be compactable and
composed so that neither its properties nor the compaction will
cause damage to the pit.
• Grains larger than 16 mm must not be present.
• The content of grains between 8 and 16 mm must not exceed
10 %.
• The material must not be frozen.
• Sharp flint etc. must not be present.
• The bedding layer must have a thickness of 10 cm.
4.2 Installing the pit
Place the pit on the bedding layer.
Check that the pit is vertical.
Groundwater must not rise above the bedding layer until
backfilling has been completed.
CAUTION
Collapsing hazard
Minor or moderate personal injury
- Support for the crane must be placed at a suitable
distance from the pit to avoid collapse of pit hole.
Work according to local regulations.
Installation of pits must be carried out by an
authorised person in accordance with local
regulations.
Work in or near wastewater pits must be carried out
according to local regulations.
TM02 9362 2404
Pos. Description
1 Foundation layer
2 Bedding layer
3 Backfill, compacted in layers of maximum 30 cm
4Distance of 50 cm from cover where heavy loads must
not occur
Select the location of the pit so that its installation
does not damage other equipment. And the other
equipment must not damage the buried pit.
44
3
2
1
Check the pit for external damage before lowering it
into position. When the pit has been installed,
Grundfos cannot be held responsible for possible
damage.
CAUTION
Collapsing hazard
Minor or moderate personal injury
- Support for the crane must be placed at a suitable
distance from the pit to avoid collapse of pit hole.
Work according to local regulations.
Before lowering the pit into position, retighten various
connections, as they may have become loose during
the transport.

English (GB)
6
4.2.1 Backfill
Fig. 3 Compactors
• The backfill must provide sufficient support of the pit on all
sides and ensure that the load can be transferred without
detrimental point impacts or similar impacts. See fig. 4.
Fig. 4 Even pressure on all sides of the pit
• The backfill must meet the same requirements as those for the
bedding layer.
• The backfilling must be carried out so that the pit is not
damaged or deformed.
Fig. 5 Oval pit after compaction
• The backfill must be compacted in layers of maximum 30 cm
(corresponding to approx. 20 cm after compaction).
Fig. 6 Insufficient compaction under pipes
Do not use plate compactors at a distance of less
than 30 cm from the pit wall.
TM06 3602 0615TM06 3603 0615
During backfilling, the cover must be fitted on the pit
to ensure that the pit is not deformed (becomes
oval).
TM02 9361 2404
1
Max.
25 kN
Max.
150 kg
1a
2
Compact the backfill under the inlet and outlet pipes
properly so that they are not exposed to downward
loads when the backfill settles. See fig. 6.
TM02 9360 2404
If the hole for the pit is drilled, pay special attention to
the compaction of the backfill to prevent uplift.
Use mechanical compacting equipment and compact
the backfill to minimum 97 % proctor density.

English (GB)
7
4.2.2 Uplift prevention
• The pit design ensures that the pit is protected against uplift if
installed correctly (excluded D 800 x 1000 and D 1200 x
1500). Requirements for uplift prevention depend on the
geotechnical conditions. They must be determined by the
engineer or contractor and are outside Grundfos' area of
responsibility.
The safety against uplift is determined according to Eurocode EN
1997-1 including national annex, DS/EN 1997-1 DK NA:2015.
The most unfavourable ground water conditions for the pit is
when the ground water table is located at terrain level. This
situation creates the highest hydrostatic water pressure at the
bottom of the pit, and causes the highest reduction in soil weight
for the stabilising soil volume.
The sand volume resting on the pit’s shoulder is a stabilising
force. The sand volume is determined as a cone with hollow core
as illustrated in fig. 7.
The inclination of the cone is illustrated 1:n. The inclination n can
be determined based on the friction angle for the design. The
characteristic friction angle for sand with a unit weight of 19 kN/
m3, compacted to 97 % standard proctor, is estimated to 37
degrees. The design friction angle is 32 degrees which
corresponds to an inclination of n = 1.6.
Fig. 7 Stabilising sand volume
4.3 Installing the valve chamber
When installing the valve chamber, follow the same instructions
as for installation of the pit. See section 4. Installing the product.
Fig. 8 Valve chamber
The requirements below are the minimum
requirements. Observe local regulations.
TM06 7269 2316
The valve chamber is only to be installed for PS.R.17
pits.
TM06 1754 2614
Isolating valves
Non-return valves

English (GB)
8
4.4 Connecting the pipes
Compact the backfill around the pit up to the lower part of a pipe
connection, before connecting the pipe.
Before connecting the pipes, check the following:
• The pipes and the gaskets must be clean.
• The inlet pipe must be properly aligned with the pipe
connection.
Holes for inlet pipe, electrical connection and venting are to be
drilled on site.
Mark the pit where the inlet is to be. Drill the marked spot with a
hole saw. Remove all burrs from the hole. The hole saw is
available as an accessory. See the table below.
4.4.1 PS.R.05 - PS.R.10
Fig. 9 Drilling the inlet hole, ∅500-1200
4.4.2 PS.R.17
Drilling from the outside
If the hole diameter is bigger than 150 mm or the hole is to be
drilled into a rib, drill in the centre of a rib. See fig. 10.
Fig. 10 Drilling from the outside
Drilling from the inside
Due to the circular pit shape, the pilot drill must extend beyond
the cutting edge of the hole saw by at least 23 mm. The position
of the hole is not an issue. See fig. 11.
Fig. 11 Drilling from the inside
We recommend that you provide the pit with a vent
pipe (accessory).
Place inlet and outlet pipe connections in accordance
with local regulations.
Sleeve Pipe diameter Product number Hole saw [mm] Borehole tolerance [mm] Product number
LM50/40 40 96230763 51 - 2/+ 1 96571532
LM50/50 50 96230753 60 - 2/+ 1 96571533
LM50/63 63 96571523 75 - 2/+ 1 96571534
LM50/75 75 96571527 86 - 2/+ 1 96571535
LM50/90 90 96571528 102 - 2/+ 1 96571536
L965/110 110 91716040 127 - 0/+ 2 91713756
L965/160 160 91713754 177 - 0/+ 2 91713755
LM100/
200 200 91712032 212 - 2/+ 1 91712025
Pilot drill 91712026
TM02 9342 2404
We recommend that
you drill the inlet
hole in the
cylindrical, smooth
part.
The hole saw must have a cup depth of minimum 90
mm.
The inlet hole must not be drilled in the pit close to
pipes, float switches or other parts of the pit
installation.
TM04 9441 4210TM04 9573 4610

English (GB)
9
4.5 Fitting the sleeve
1. Fold the sleeve and insert it into the hole (from the outside of
the pit).
2. Unfold the sleeve so that it lies evenly in the hole.
3. LM50/100 sleeves: Pull the sleeve outwards until its collar
touches the inside of the pit all around the hole.
L965 sleeves: Pull the sleeve outwards until its collar touches
the inside of the pit at the positions 3 and 9 o'clock.
See fig. 14.
4. Lubricate the inside of the sleeve with a water-based
lubricant.
5. Chamfer the pipe and press it home.
LM50/100 sleeves: Push the inlet pipe through the sleeve. See
fig. 12.
Fig. 12 Pipe with LM50/100 sleeve, seen from side
L965 sleeves: Push the inlet pipe into the sleeve and against the
stop. See fig. 13.
Fig. 13 Pipe with L965 sleeve, seen from side
Fig. 14 Pipe with L965 sleeve, seen from top
4.6 Pipes with flange connection
5. Installing the pump(s)
Some versions come without the pump(s) installed. For
installation and startup of the pump, see the installation and
operating instructions for the pump.
5.1 Fitting the chain
For pumps on auto coupling, we recommend that you fit the chain
in the foremost lifting eye of the lifting bracket. The number of
lifting eyes depends on the pump.
Fig. 15 Chain fitted to the pump
As it must be possible to pull the pump up through
the pit, the inlet pipe must not project beyond the
sleeve by more than 50 mm.
TM03 3709 0806TM03 3708 0806TM03 3768 1006
Pit side
Max. 50 mm
Pit side
Pit side
If the pit is to be installed at a temperature below 0
°C, loosen all bolts of the flanges and retighten them
when the pit has been installed.
This will prevent stress in the pipes.
Lower the pump(s) carefully into the pit in order to
avoid damage to pump(s) and pit.
TM02 9341 2404
WARNING
Crushing hazard
Death or serious personal injury
- The lifting equipment used for lifting the pump
must be rated for the weight of the pump,
approved and maintained according to local
regulations.
Chains supplied by Grundfos are marked with
maximum load and production date.
Do not exceed the maximum load.
Maintain the chain according to local regulations. We
recommend that you check chains and shackles
supplied by Grundfos at least once a year for cracks,
corrosion or other irregularities. If you find any
defects, replace the chain or shackles.

English (GB)
10
6. Installing the level switches
See the installation and operating instructions for the level control
system.
When installing the level switches, observe the following points:
• To prevent air intake and vibrations in the pump, the stop level
switch must be fitted in such a way that the pump is stopped
before air is sucked into the pump.
• In the case of one-pump operation, the start level switch
should be installed in such a way that the pump is started at
the required level; however, the pump must always be started
before the liquid level reaches the lower edge of the bottom
inlet pipe.
• In the case of two-pump operation, the start level switches
should be installed in such a way that pump two is started
before the liquid level reaches the lower edge of the bottom
inlet pipe, and so that pump one is started correspondingly
earlier.
• The high-level alarm switch must always be installed about
100 mm above the start level switch; however, the alarm must
always be given before the liquid level reaches the inlet pipe.
For further settings, see the installation and operating instructions
for the level switch selected.
6.1 Start and stop levels
The effective volume of the pit must be so large that the number
of starts does not exceed the maximum permissible number. See
the installation and operating instructions for the pump.
6.2 Installing the pump controller
See the installation and operating instructions for the pump
controller.
6.3 Float switches
If float switches have been selected, they can be fitted on a tube
which can be lifted out of the pit. This ensures easy adjustment of
the float switches.
Fig. 16 Adjustment of float switches
The pit inlet must not be located within the area shown in fig. 17,
as it will disturb the function of float switches.
Fig. 17 Location of inlet
If the pit is equipped with an AutoADAPT-controlled
pump, an external level controller is not needed.
Note that the bottom float switch (the stop switch)
must stop the pump before the liquid level in the pit
falls below the minimum level of the pump. See the
installation and operating instructions for the pump.
TM02 8960 1204
A Minimum 300 mm
B 50 to 100 mm
C Operating range 110 mm
Distance B must not be too big as otherwise the float
switch may get stuck in other parts of the installation.
TM02 8961 1204
A
BC
200 200

English (GB)
11
6.4 Electrodes
If electrodes are used for level control, note that the electrodes
come in a standard lengths of 1 m. When they are installed, their
lengths must therefore be adjusted so that they are activated at
the correct levels.
If possible, bend the electrodes away from each other so that
paper and similar items cannot get stuck between the electrodes
and disturb the signal.
When they have been shortened to the desired length, strip 10 to
15 mm of the lower end of the electrodes.
The electrodes come with a 10 m cable.
Fig. 18 Electrodes in a pit with one pump
Fig. 19 Electrodes in a pit with two pumps
6.5 Air bells
Air bells are pulse generators for the pressure switches of the
pump controller and function by means of pneumatic pressure
changes. The pressure changes when the liquid level changes in
the air bell. The air bells are connected to the pressure switches
of the controller by means of pressure hoses.
Fig. 20 Air bells in a pit with one pump
6.6 Pressure transducer
If a pressure transducer is used, install it a protective pipe in
order to prevent contamination and deposits.
6.7 Other types of level control equipment
See the installation and operating instructions for the equipment.
7. Electrical connection
See the installation and operating instructions for the pump and
the pump controller.
7.1 Installing the cables
The cables for the level switches and the pump(s) can be led into
the pit in different ways. Often the cables are led into the pit
through a cable entry in the side of the pit. If the pit is equipped
with a vent pipe, the vent pipe can be used as cable entry.
TM02 8962 1204TM02 8963 1204TM01 9345 2404
Alarm: 32
Start: 22
The stop level
depends on the
pump type
Common: 11
Alarm: 42
Start2: 32
The stop level
depends on the
pump type
Common: 11
Start1: 22
CU211
CU 211
The electrical installation must be carried out by an
authorised person in accordance with local
regulations.
WARNING
Electric shock
Death or serious personal injury
- The pump or pump controller must be connected
to an external emergency stop.
If the main switch is used as emergency stop, it
must fulfil EN 60204-1, 10.8.4.
DANGER
Electric shock
Death or serious personal injury
- Before starting any work on the product, make
sure that the power supply has been switched off
and that it cannot be accidentally switched on.
Do not install Grundfos control boxes and the free
end of the supply cable inside the pumping station.
When installing or removing the pump, make sure
not to pinch or damage the cables.
When the pump and cables have been installed,
suspend the cables in such a way that any stress is
relieved from the cables.

English (GB)
12
8. Product introduction
8.1 Product description
Grundfos pumping stations are pre-fabricated pumping stations
for collection and pumping of wastewater.
The pit is made of PE-HD (polyethylene) and comes with outlet
pipes and valves fitted.
The pipes are made of PE or stainless steel depending on the
location of the pit and the pumped liquid, and thus the pump
selected.
Wastewater is led into the pit. When the liquid in the pit reaches
the maximum liquid level, the pump will start and pump the liquid
further on into the sewer system.
Fig. 21 Example of pumping station
8.2 Applications
Grundfos pumping stations are used for collection and pumping
of drainage water, grey wastewater and sewage. The pump type
depends on the pumped liquid.
8.3 Pumped liquids
8.3.1 Liquid temperature
Maximum 40 °C. For higher temperatures, contact Grundfos.
8.3.2 Acids and alkalis
The pumping station is resistant to strong acids and alkalis as
well as solvents.
The pumps are supplied with the pump pit and normally capable
of withstanding pH values between 4 and 10. In case of doubt,
please contact Grundfos.
8.3.3 Viscosity
Very thick wastewater must not be led into the pit. See also the
installation and operating instructions for the pump.
8.3.4 Density
Maximum 1100 kg/m3.
8.4 Pumping station system (PS.S)
This section applies only to pumping station systems consisting
of Grundfos-approved components mentioned on the nameplate
of PS.S.
The pumping station system contains all the elements making the
pumping station function as one unit, and can contain the
following five elements:
•pit
•pump
• pump controller
• level controller
• accessories.
The pumping station system may not always have all five
elements. However, it will always have a pit and a pump, but the
pump controller or the level controller may be incorporated in the
pump, and/or accessories may be omitted.
8.4.1 CE approval of PS.S
PS.S is CE approved in accordance with these directives and
standards:
• EN 2006/42/EC, EU Machinery Directive
• EN/ISO 12100, Safety of machinery - General principles for
design - Risk assessment and risk reduction.
In order to ensure safe transport and to fulfil customer requests,
the PS.S elements can be assembled on site. But the CE
approval of PS.S is only valid if the following conditions have
been fulfilled:
• PS.S has been assembled correctly in accordance with the
installation and operating instructions for PS.S and the pit,
pump and control systems.
• PS.S contains the Grundfos specified elements stated on the
PS.S nameplate. The PS.S nameplate is fitted inside the pit.
8.5 Pumping station modular (PS.M)
PS.M is used instead of PS.S when the CE approval for the
complete system is not needed or some of the components in the
pumping station, e.g. the controllers, are not supplied by
Grundfos.
A risk assessment for the complete system must be performed by
the customer, if necessary.
TM02 9363 2404
Pos. Description
1Pump
2 Chain
3 Guide rails
4Floatswitch
5 Non-return valve
6 Isolating valve
7 Flange/coupling
8 Connection, 1/2" internal thread
9 Cover
9
7
6
4
2
1
8
5
3
Select the pump on the basis of knowledge of the
liquid temperature. See the installation and operating
instructions for the individual pumps.

English (GB)
13
8.6 Identification
8.6.1 Nameplate, PS.S
Fig. 22 Nameplate, PS.S
8.6.2 Nameplate, PS.M
Fig. 23 Nameplate, PS.M
8.6.3 Type key, PS.S
TM06 1743 2714TM06 7590 3616
Pos. Description
1 Product number
2 Production site
3 Type designation
4 Country of origin
5 Weight
6 Production code and date of production (YYWW)
7Installation and operating instructions, publication
number
8 Product number, pit
9 Product number, pump
10 Product number, pump controller
11 Product number, level controller
12 Product number(s), accessories
13 Not filled in
12
3
4
9
10
11
12
5
67
81313
DK-8850 Bjerringbro, Denmark
99153401
Model
Type PS.M.R.17.25.SEG.LCD.10.FS2
Pumping Station Modular
Made in Weight
P.c.
Well cpl. Pump cpl.
Control System
Accessories
Level System
12
5
7
9
13
11
8
6
34
10
12
Example PS. S. R. 17. 25. SEG. LCD110. FS2
Grundfos pumping station
S: CE-marked system
M: Modular system
Pit material
R: Rotation-moulded PE
G: Glass fibre-reinforced plastic
Pit sump diameter [mm] x 100
05: 500 mm
08: 800 mm
10: 1000 mm
12: 1200 mm
17: 1700 mm
Pit depth [mm] x 100
25: 2500 mm
Pump type
CC: Unilift CC
KP: Unilift KP
AP12: Unilift AP12.50
AP35: Unilift AP35, Unilift AP12.40
AP50: Unilift AP50
APB: Unilift AP35B, Unilift AP50B
SEG: SEG
DP/EF: DP (0.6 - 1.5 kW), EF
DP/SL: DP (2.6 kW), SL1.50.65 and SLV.65.65
DPK: DPK, DPK.V
SE/SL: SE/SL
Pump controller
X: No Grundfos controller
CU100: Control unit
LC107: Level controller
LC108: Level controller
LC110: Level controller
LC115: Level controller
LCD107: Level controller - two pumps
LCD108: Level controller - two pumps
LCD110: Level controller - two pumps
LCD115: Level controller - two pumps
DC318: Dedicated Controls
DC319: Dedicated Controls
DCD318: Dedicated Controls - two pumps
DCD319: Dedicated Controls - two pumps
Level controller
AB2: Two air bells
AB3: Three air bells
FS2: Two float switches
FS3: Three float switches
FS4: Four float switches
EL3: Three electrodes
EL4: Four electrodes
EL5: Five electrodes
PT: Pressure transducer

English (GB)
14
8.6.4 Nameplate, PS.R.05 - PS.R.17
Fig. 24 Nameplate, PS.R.05 - PS.R.17
8.6.5 Type key, PS.R.17
* Maximum 3 m pit depth
TM06 3908 1215
Pos. Description
1 Product number
2 Production site
3 Type designation
4 Country of origin
5 Weight
6 Production code and date of production (YYWW)
7Installation and operating instructions, publication
number
8 Not filled in
132
75
Type
Standards used:EN 12050-1 or EN 12050-2
Model
Weight
P.c.
Made in
EU declaration of performance
96835168
PS.R.17.45.D.DC.SS65.A65.DP/SL
Denmark
P10
96235218
636 kg
1325
Notified body:0197
4
6
8
Example PS. R. 17. 25. D. GC. SS50. A50. SEG
Pumping station
Rotation moulded pit
Pit sump diameter [mm] x 100
05: 500
08: 800
10: 1000
12: 1200
17: 1700
Pit depth [mm] x 100
25: 2500
S: One pump
D: Two pumps
Pipe design
DC: Direct outlet, common
GC: Goose neck, common
VC: Valve chamber
Pipe material and pipe diameter
Stainless steel:
SS40: DN 40 (1 1/2")
SS50: DN 50 (2")
SS65: DN 65 (2 1/2")
SS80: DN 80 (3")
SS100: DN 100 (4")
Polyethylene:
PE40: D40 mm (1 1/4")
PE50: D50 mm (1 1/2")
PE63:* D63 mm (2")
PE75: D75 mm (2 1/2")
PE90: D90 mm (3")
PE110: D110 mm (4")
Installation type
Auto coupling:
A40: DN 40 pump connection
A50: DN 50 pump connection
A65: DN 65 pump connection
A80: DN 80 pump connection
A100: DN 100 pump connection
Free-standing pump:
S: Free-standing pump
Pump type
KP: Unilift KP, Unilift CC
AP35: Unilift AP12.40, Unilift AP35
AP50: Unilift AP12.50, Unilift AP50
APB: Unilift AP35B, Unilift AP50B
SEG: SEG
DP/EF: DP (0.6 - 1.5 kW) / EF
DP/SL: DP (2.6 kW) / SL1.50.65 / SLV.65.65
DPK: DPK, DPK.V
SE/SL: SE/SL

English (GB)
15
9. Maintaining and servicing the product
See the installation and operating instructions for the pump and
the pump controller.
Fig. 25 Opening PS.R.17
Fig. 26 Lifting a free-standing pump for service
Fig. 27 Lifting a pump on auto coupling for service
We advise you to make all maintenance and service
work when the pump is placed outside the pit.
Do not enter and work inside PS.R.05 - PS.R.12.
DANGER
Crushing and suffocation hazard
Death or serious personal injury
- Before entering PS.R.17, make sure that the cover
and safety grid are locked in open position and
that the pit is ventilated according to local
regulations. If not, do not enter the pit.
TM06 0535 0414
DANGER
Falling hazard
Death or serious personal injury
- When entering the pit, wear a safety harness and
use approved equipment for lifting persons up from
the pit according to local regulation.
All work in pits must be carried out according to local
regulations and supervised by at least one person
outside the pumping station.
When work is going on in or in the proximity of an
open pumping station or valve chamber, place proper
warning signs and correct safety barriers around the
pit in order to avoid that persons fall into the pit. The
warning signs must be visible from all directions.
90°
1
90°
2
34
If the top opening is up to ∅1000, normal precaution
will be sufficient. Openings larger than ∅1000 must
be equipped with safety barriers or other safety
measures.
Pumps can be lifted by means of a crane, using the
lifting points.
Use proper slings or chains approved for lifting.
CAUTION
Biological hazard
Minor or moderate personal injury
- Use gloves and other suitable personal protection
equipment in accordance with local regulations.
Observe local regulations on exposure to
wastewater.
If natural light is insufficient, the maintenance staff
must use lamps.
TM06 0545 0414TM06 0546 0414

English (GB)
16
9.1 Repairing a non-return valve
1. Open the valve chamber drain valve by means of the valve
handle in the pit in order to empty the sump of the valve
chamber. See fig. 28.
2. Close the isolating valves. See fig. 8.
3. Loosen and remove the two screws on the non-return valve
cover. See fig. 29.
4. Replace worn-out valve balls and clean valves inside.
5. Close the valve cover and tighten the screws.
6. Open the isolating valves. See fig. 8.
7. Close the drain valve inside the pit. See fig. 28.
Fig. 28 Drain valve
Fig. 29 Non-return valve
9.2 Contaminated pumps
For further information, see the installation and operating
instructions for the pump.
9.3 Service contract
It is possible to make a service contract with Grundfos.
10. Disposal
This product or parts of it must be disposed of in an
environmentally sound way:
1. Use the public or private waste collection service.
2. If this is not possible, contact the nearest Grundfos company
or service workshop.
3. If it is not possible to dispose of the product as a complete
unit, the pump and installation equipment can be removed
from the pit, and the pit can be filled and covered.
See also end-of-life information on www.grundfos.com.
Subject to alterations.
CAUTION
Pressurised system
Minor or moderate personal injury
- Relieve the pressure by draining the system before
dismantling the non-return valve.
CAUTION
Biological hazard
Minor or moderate personal injury
- Remove the fuses or switch off the main switch
before dismantling the non-return valve.
Make sure that the power supply cannot be
accidentally switched on.
CAUTION
Biological hazard
Minor or moderate personal injury
- Rinse the non-return valve thoroughly with clean
water before carrying out maintenance and
service.
Make sure the isolating valves cannot be accidentally
opened.
When entering the valve chamber, do not step on
pipes or valves
TM06 1755 2714
Valve handle
Drain valve
TM06 1756 2714
CAUTION
Biological hazard
Minor or moderate personal injury
- Flush the pump thoroughly with clean water and
rinse the pump parts in water after dismantling.
Non-return valve Non-return valve,
exploded view

Declaration of conformity
17
Declaration of conformity 1
GB: EC declaration of conformity for Grundfos
pumping station system, type PS.S
This EC declaration of conformity applies only to Grundfos pumping
station system, type PS.S, marked with the CE mark on the nameplate.
It is a condition for the validity of the declaration that the pumping station
system at any time consists of the correct and Grundfos-approved
components and products mentioned in the nameplate of the pumping
station system.
We, Grundfos, declare under our sole responsibility that the pumping
station system, type PS.S, to which this declaration relates, is in
conformity with the Council directive on the approximation of the laws of
the EC member states listed below:
The pumping station system, type PS.S, always consists of a pit,
minimum one pump and, depending on the pump type, also a pump
controller and a level controller, and possibly accessories, all selected
from the list below:
Please find the EC declaration of conformity and/or EU declaration of
performance of components and products in the installation and
operating instructions delivered with these components and products.
CZ: Prohlášení o shoděES pro systém čerpací
stanice Grundfos, typ PS.S
Toto prohlášení o shoděES se vztahuje pouze na systém čerpací stanice
Grundfos, typ PS.S, který je na typovém štítku označen značkou CE.
Podmínkou platnosti prohlášení je, že systém čerpací stanice musí vždy
zahrnovat správné komponenty a produkty schválené společností
Grundfos uvedené na typovém štítku systému čerpací stanice.
My, firma Grundfos, prohlašujeme na svou plnou odpovědnost, že
systém čerpací stanice, typ PS.S, na který se toto prohlášení vztahuje, je
v souladu s ustanoveními směrnice Rady o sblížení právních předpisů
členských státůEvropského společenství uvedených níže:
Systém čerpací stanice, typ PS.S, vždy zahrnuje čerpací jímku,
minimálnějedno čerpadlo a, v závislosti na typu čerpadla, také regulátor
čerpadla a regulátor hladiny, případnědalší příslušenství podle seznamu
níže:
Prohlášení o shoděES nebo prohlášení ES o výkonu komponent
a produktůnaleznete v montážním a provozním návodu dodaném
stěmito komponentami a produkty.
DK: EF-overensstemmelseserklæring for
pumpestationssystem, type PS.S, fra Grundfos
Denne EF-overensstemmelseserklæring gælder kun for pumpestations-
system, type PS.S, fra Grundfos som er mærket med CE-mærke på type-
skiltet. Det er en betingelse for erklæringens gyldighed, at
pumpestationssystemet til enhver tid består af de korrekte komponenter
og produkter, som er godkendt af Grundfos, og som er anført på pumpe-
stationssystemets typeskilt.
Vi, Grundfos, erklærer under ansvar at pumpestationssystemet, type
PS.S, som denne erklæring omhandler, er i overensstemmelse med
disse af Rådets direktiver om indbyrdes tilnærmelse til EF-medlemssta-
ternes lovgivning:
Pumpestationssystemet, type PS.S, består altid af en brønd, mindst én
pumpe og, afhængig af pumpetypen, også en pumpestyring og en
niveaustyring, og evt. tilbehør fra listen nedenfor:
EF-overensstemmelseserklæring og/eller EF-ydeevnedeklaration for
komponenter og produkter fremgår af monterings- og driftsinstruktion
som leveres sammen med disse komponenter og produkter.
DE: EG-Konformitätserklärung für die
Grundfos-Pumpstationenanlage Typ PS.S
Die EG-Konformitätserklärung gilt nur für die Grundfos Pumpstationen-
anlage vom Typ PS.S. Diese ist mit der CE-Kennzeichnung auf dem
Typenschild gekennzeichnet. Voraussetzung für die Gültigkeit der Erklä-
rung ist, dass die Pumpstationenanlage zu jeder Zeit aus den richtigen
und von Grundfos genehmigten Bauteilen und Produkten besteht, die auf
dem Typenschild der Anlage vermerkt sind.
Wir, Grundfos, erklären in alleiniger Verantwortung, dass die Pumpstatio-
nenanlage vom Typ PS.S, auf die sich diese Erklärung bezieht, mit den
folgenden Richtlinien des Rates zur Angleichung der Rechtsvorschriften
der EU-Mitgliedsstaaten übereinstimmt:
Die Pumpstationenanlage vom Typ PS.S besteht immer aus einem
Schacht, mindestens einer Pumpe und, abhängig vom Pumpentyp, auch
aus einer Pumpensteuerung und einem Niveauschalter und enthält mög-
licherweise Zubehör aus der nachfolgenden Liste:
Sie finden die EG-Konformitätserklärung und/oder die EG-Leistungser-
klärung für Bauteile und Produkte in der mitgelieferten Montage- und
Betriebsanleitung.
ES: Declaración de conformidad de la CE para el
sistema de estación de bombeo Grundfos de
tipo PS.S
Esta declaración de conformidad de la CE sólo es válida para sistemas
de estación de bombeo Grundfos de tipo PS.S que ostenten la marca CE
en la placa de características. La validez de la declaración queda supedi-
tada a que el sistema de estación de bombeo incorpore en todo
momento los componentes y accesorios correctos y homologados por
Grundfos, indicados en la placa de características del sistema de esta-
ción de bombeo.
Grundfos declara, bajo su exclusiva responsabilidad, que el sistema de
estación de bombeo de tipo PS.S al que hace referencia esta declara-
ción cumple lo establecido por la Directiva del Consejo sobre la aproxi-
mación de las legislaciones de los Estados miembros de la CE indicados
a continuación:
El sistema de estación de bombeo de tipo PS.S debe incorporar siempre
un pozo, un mínimo de una bomba y, según el tipo de bomba, también un
controlador de bomba y un controlador de nivel, así como, posiblemente,
accesorios, todos los cuales deben formar parte de la siguiente lista:
Encontrará las declaraciones de conformidad de la CE y/o las declara-
ciones de rendimiento de la CE relativas a los componentes y accesorios
en las instrucciones de instalación y funcionamiento suministradas con
tales componentes y accesorios.
FR: Déclaration CE de conformité pour la station de
pompage Grundfos, type PS.S
Cette déclaration CE de conformité s'applique uniquement à la station de
pompage Grundfos de type PS.S qui est marqué du logo CE. Pour la
validité de la déclaration il faut que les composants et produits conformes
et approuvés par Grundfos mentionnés sur la station de pompage corres-
pondent à ceux utilisés par la station de pompage.
Nous, Grundfos, déclarons sous notre entière responsabilité que la sta-
tion de pompage de type PS.S, à laquelle la présente déclaration fait
référence, est conforme aux directives du Conseil concernant le rappro-
chement des législations des États membres de la Communauté euro-
péenne répertoriés ci-dessous :
La station de pompage de type PS.S se compose toujours d'une fosse, et
selon le type de pompe, d'un coffret de commande et d'un régulateur de
niveau, et éventuellement d'accessoires, tous sélectionnés dans la liste
ci-dessous :
Veuillez trouver la déclaration CE de conformité et/ou la déclaration CE
de performance des composants et produits dans la notice d'installation
et de fonctionnement livrée avec lesdits produits et composants.

Declaration of conformity
18
IT: Dichiarazione CE di conformità per l'impianto
della stazione di pompaggio Grundfos, tipo
PS.S
La presente dichiarazione di conformità CE è applicabile esclusivamente
all'impianto della stazione di pompaggio Grundfos, tipo PS.S, contrasse-
gnato con il marchio CE sulla targhetta di identificazione. È una condi-
zione per la validità della dichiarazione in base alla quale l'impianto della
stazione di pompaggio è sempre costituito dai componenti e prodotti cor-
retti e approvati da Grundfos, menzionati nella targhetta di identificazione
dell'impianto della stazione di pompaggio.
Grundfos dichiara sotto la sua esclusiva responsabilità che l'impianto
della stazione di pompaggio, tipo PS.S, ai quali si riferisce questa dichia-
razione, è conforme alle seguenti direttive del Consiglio riguardanti il
riavvicinamento delle legislazioni degli Stati membri CE:
L'impianto della stazione di pompaggio, tipo PS.S, è sempre costituito da
un pozzetto, almeno una pompa e, a seconda del tipo di pompa, anche
un regolatore della pompa e un regolatore di livello, oltre ad eventuali
accessori selezionati dal seguente elenco:
La dichiarazione di conformità CE e/o la dichiarazione CE relativa alle
prestazioni dei componenti e ai prodotti si trovano nelle istruzioni di
installazione e funzionamento fornite con i componenti e i prodotti stessi.
NL: EG-conformiteitsverklaring voor Grundfos
pompput systeem, type PS.S
Deze EG-conformiteitsverklaring geldt uitsluitend voor het Grundfos
pompput systeem, type PS.S, dat is voorzien van een CE-merkteken op
het typeplaatje. Het is een voorwaarde voor de geldigheid van de verkla-
ring dat het pompput systeem te allen tijde is uitgerust met de correcte
en door Grundfos goedgekeurde componenten en producten die op het
typeplaatje van het pompput systeem staan vermeld.
Wij Grundfos verklaren geheel onder eigen verantwoordelijkheid dat het
pompput systeem, type PS.S, waarop deze verklaring betrekking heeft,
in overeenstemming is met de Richtlijnen van de Raad in zake de onder-
linge aanpassing van de hieronder genoemde wetgeving van de EG-lid-
staten:
Het pompput systeem, type PS.S, bestaat altijd uit een put, minimaal één
pomp en, afhankelijk van het pomptype, een pompregelaar en een
niveauregelaar, en mogelijk accessoires, die allemaal uit de onder-
staande lijst zijn geselecteerd:
Raadpleeg de EG-conformiteitsverklaring en/of EG-prestatieverklaring
van componenten en producten in de installatie- en bedieningsinstructies
die zijn meegeleverd met deze componenten en producten.
PL: Deklaracja zgodności WE dla przepompowni
Grundfos typu PS.S
Niniejsza deklaracja zgodności WE dotyczy wyłącznie przepompowni
Grundfos typu PS.S oznaczonej znakiem CE na tabliczce znamionowej.
Deklaracja zgodności jest ważna pod warunkiem, że przepompownia
składa sięz odpowiednich i zatwierdzonych przez Grundfos elementów
i produktów wymienionych na tabliczce znamionowej.
My, Grundfos, oświadczamy z pełnąodpowiedzialnością, że nasza
przepompownia typu PS.S, której deklaracja niniejsza dotyczy, jest
zgodna z następującymi dyrektywami Rady w sprawie zbliżenia
przepisów prawnych państw członkowskich:
Przepompownia typu PS.S zawsze składa sięze zbiornika, co najmniej
jednej pompy oraz, w zależności od typu pompy, z regulatora pompy
i sterownika poziomu, a także z ewentualnych akcesoriów
wyszczególnionych na liście poniżej:
Deklaracje zgodności WE i/lub deklaracje właściwości użytkowych
elementów i produktów znajdująsięw dołączonych do nich instrukcjach
montażu i eksploatacji.
PT: Declaração de conformidade CE para o sistema
de estação elevatória Grundfos, tipo PS.S
Esta declaração de conformidade CE aplica-se apenas ao sistema de
estação elevatória da Grundfos, tipo PS.S, com a marca CE na chapa de
características. É condição para a validade da declaração que o sistema
de estação elevatória seja sempre composto pelos componentes e pro-
dutos correctos e aprovados pela Grundfos, mencionados na chapa de
características do sistema de estação elevatória.
A Grundfos declara sob sua única responsabilidade que o sistema de
estação elevatória, tipo PS.S, ao qual diz respeito esta declaração, está
em conformidade com a Directiva do Conselho sobre a aproximação das
legislações dos Estados Membros da CE listados abaixo:
O sistema de estação elevatória, tipo PS.S, é sempre composto por um
poço, pelo menos uma bomba e, dependendo do tipo de bomba, também
por um controlador da bomba e um sensor de nível, bem como possíveis
acessórios, todos seleccionados a partir da lista abaixo:
A Declaração de Conformidade CE e/ou a declaração CE de desempe-
nho dos componentes e produtos podem ser encontradas nas instruções
de instalação e funcionamento entregues com esses componentes e pro-
dutos.
RU: Декларация осоответствии нормам ЕС на
систему насосной станции Grundfos, тип
PS.S
Настоящая декларация осоответствии нормам ЕС применяется
только ксистеме насосной станции Grundfos, тип PS.S, имеющей на
фирменной табличке маркировку CE. Для действительности
декларации обязательным условием является то, чтобы система
насосной станции состояла из правильных иодобренных компанией
Grundfos компонентов иизделий, указанных на фирменной табличке
системы насосной станции.
Мы, компания Grundfos, со всей ответственностью заявляем, что
система насосной станции, тип PS.S, ккоторой относится настоящая
декларация, соответствует Директиве Совета ЕС об унификации
законодательных предписаний стран-членов ЕС, перечисленных
ниже:
Система насосной станции, тип PS.S, всегда состоит из колодца,
минимум одного насоса ивзависимости от типа насоса регулятора
насоса ирегулятора уровня, атакже, возможно, вспомогательных
принадлежностей, все из которых выбраны из нижеприведенного
перечня:
Декларация осоответствии нормам ЕС и/или декларация
качественных характеристик компонентов иизделий приведены в
руководстве по монтажу иэксплуатации, поставляемом сданными
компонентами иизделиями.
SK: ES vyhlásenie o zhode k sústavám čerpacích
staníc Grundfos, typ PS.S
Toto ES vyhlásenie o zhode sa vzťahuje len na sústavy čerpacích staníc
Grundfos typu PS.S, označené značkou CE na štítku.
Podmienkou platnosti vyhlásenia je, že sústava čerpacej stanice
pozostáva zo správnych komponentov a produktov schválených
spoločnosťou Grundfos tak, ako sú uvedené na štítku čerpacej stanice.
My, spoločnosťGrundfos, vyhlasujeme na svoju plnú zodpovednosť, že
sústava čerpacej stanice typu PS.S, na ktorú sa toto vyhlásenie
vzťahuje, je v súlade s ustanoveniami smernice Rady pre zblíženie
právnych predpisov členských štátov Európskeho spoločenstva
v oblastiach:
Sústava čerpacej stanice typu PS.S vždy pozostáva z nádrže, minimálne
jedného čerpadla a v závislosti od typu čerpadla, tiež z riadiacej jednotky
čerpadla a hladinovej riadiacej jednotky a ďalších prípadných doplnkov,
z ktorých sú všetky vybrané z nižšie uvedeného zoznamu:
ES vyhlásenie o zhode a/alebo ES vyhlásenie o parametroch
komponentov a produktov nájdete v montážnom a prevádzkovom návode
dodávanom s týmito komponentmi a produktmi.

Declaration of conformity
19
FI: Grundfosin tyypin PS.S pumppaamon
EY-vaatimustenmukaisuusvakuutus
Tämä EY-vaatimustenmukaisuusvakuutus koskee vain Grundfosin tyypin
PS.S pumppaamoa, jonka tyyppikilvessä on CE-merkintä.
Vaatimustenmukaisuusvakuutus on voimassa vain, kun
pumppaamojärjestelmässä käytetään alkuperäisiä Grundfosin
hyväksymiä komponentteja ja tuotteita, jotka on merkitty
pumppaamojärjestelmän tyyppikilpeen.
Grundfos vakuuttaa omalla vastuullaan, että tyypin PS.S pumppaamojär-
jestelmä, jota tämä vakuutus koskee, on EY:n jäsenvaltioiden lainsää-
dännön yhdenmukaistamiseen tähtäävien Euroopan neuvoston
direktiivien vaatimusten mukainen seuraavasti:
Tyypin PS.S pumppaamojärjestelmä sisältää aina kaivon, vähintään
yhden pumpun ja pumpputyypistä riippuen myös pumppusäätimen ja pin-
nankorkeuden säätimen sekä mahdollisesti lisäosia alla olevasta luette-
losta:
EY-vaatimustenmukaisuusvakuutus ja/tai komponenttien ja tuotteiden
EY-suoritustasoilmoitus toimitetaan kyseisten komponenttien ja tuottei-
den asennus- ja käyttöohjeiden mukana.
SE: EG-försäkran om överensstämmelse för
Grundfos pumpstationssystem av typ PS.S
Denna EG-försäkran om överensstämmelse gäller endast för Grundfos
pumpstationssystem av typ PS.S med CE-märkning på typskylten. För att
försäkran ska vara giltig måste pumpstationssystemet alltid bestå av kor-
rekta och av Grundfos godkända komponenter och produkter som anges
på pumpstationssystemets typskylt.
Vi, Grundfos, försäkrar under eget ansvar att pumpstationssystemet av
typ PS.S, som denna försäkran avser, överensstämmer med Rådets
direktiv om tillnärmning av lagstiftningen i de EU-medlemsstater som lis-
tas nedan:
Pumpstationssystemet av typ PS.S består alltid av en brunn, minst en
pump och, beroende på typen av pump, även en pumpstyrenhet och en
nivåstyrenhet och eventuella tillbehör, som alla är valda i nedanstående
lista:
EG-försäkran om överensstämmelse och/eller EG-försäkran om kompo-
nenters och produkters prestanda finns i monterings- och driftsinstruktio-
nen som medföljer dessa komponenter och produkter.
TR: PS.S tipi Grundfos pompa istasyonu sistemi için
AB uygunluk beyanı
Bu AB uygunluk beyanısadece etiketinde CE işaretine sahip PS.S tipi
Grundfos pompa istasyonu sistemi için geçerlidir. Beyanın geçerliliğinin
bir koşulu, pompa istasyonu sisteminin her zaman etikette belirtilen
doğru ve Grundfos onaylıbileşen ve ürünlerden oluşmasıdır.
Grundfos olarak bu bildirimin konusu olan PS.S tipi pompa istasyonu
sisteminin, aşağıda belirtilen AB üye ülkelerinin yasalarının uyumlu hale
getirilmesiyle ilgili Konsey direktifine uygun olduğunu ve bununla ilgili
olarak tüm sorumluluğun bize ait olduğunu beyan ederiz:
PS.S tipi pompa istasyonu sistemi daima bir pitten, minimum bir
pompadan ve pompa türüne bağlıolarak tamamıaşağıdaki listeden
seçilen bir pompa kontrolörü ve seviye kontrolöründen ve muhtemelen
aksesuarlardan oluşur:
Bileşen ve ürünlerin AB uygunluk beyanınıve/veya AB performans
beyanını, bu bileşen ve ürünlerle birlikte teslim edilen montaj ve
çalıştırma talimatlarında bulabilirsiniz.
Directive:
— Machinery Directive (2006/42/EC).
Standard used: EN ISO 12100:2010.
Components and products:
Pit: PS.R.05, PS.R.08, PS.R.10, PS.R.12, PS.R.17
Pump: CC, KP, AP12, AP35, AP50, APB, SEG, DP/EF,
DP/SL, DPK, DPK.V, SE/SL, CC-A, KP-A, AP12-A,
AP35-A, AP50-A, APB-A, SEG AUTOADAPT, DP/EF
AUTOADAPT, DP/SL AUTOADAPT, SE/SL AUTOADAPT
Pump controller: CU, DC/DCD, LC/LCD
Level controller: Air bells, float switches, electrodes, pressure
transducer.
Accessories: Ventilation package, vaccum breaker, pressure
gauge, sleeves, chains.
This EC declaration of conformity is only valid when published as part of
the Grundfos installation and operating instructions (publication number
96235218).
Bjerringbro, 29th June 2016
Svend Aage Kaae
Director of product engineering, Western Europe
Grundfos Holding A/S
Poul Due Jensens Vej 7
8850 Bjerringbro, Denmark
Person authorised to compile the technical file and
empowered to sign the EC declaration of conformity.

Operating manual EAC
20
Operating manual EAC 2
RUS
PUST
Руководство по эксплуатации
Руководство по эксплуатации на данное изделие является составным и включает в себя несколько частей:
Часть 1: настоящее «Руководство по эксплуатации».
Часть 2: электронная часть «Паспорт. Руководство по монтажу и эксплуатации» размещенная на сайте
компании Грундфос. Перейдите по ссылке, указанной в конце документа.
Часть 3: информация о сроке изготовления, размещенная на фирменной табличке изделия.
Сведения о сертификации:
Насосы типа PUST сертифицированы на соответствие требованиям Технических регламентов Таможенного
союза: ТР ТС 004/2011 «О безопасности низковольтного оборудования»; ТР ТС 010/2011 «О безопасности
машин и оборудования»; ТР ТС 020/2011 «Электромагнитная совместимость технических средств».
Сертификаты соответствия:
№ TC RU C-DK.АИ30.В.01435, срок действия до 13.03.2020 г.
№ TC RU C-RU.АИ30.В.01416, срок действия до 09.03.2020 г.
Выдан:
Органом по сертификации продукции «ИВАНОВО-СЕРТИФИКАТ» ООО «Ивановский Фонд Сертификации».
Адрес: 153032, Российская Федерация, г. Иваново, ул. Станкостроителей, д.1.
Изделия, произведенные в России, изготавливаются в соответствии с ТУ 4859-016-59379130-2011.
KAZ
PUST
Пайдалану бойынша нұсқаулық
Атаулы өнімге арналған пайдалану бойынша нұсқаулық құрамалы болып келеді және келесі бөлімдерден
тұрады:
1 бөлім: атаулы «Пайдалану бойынша нұсқаулық»
2 бөлім: Грундфос компаниясының сайтында орналасқан электронды бөлім «Төлқұжат, Құрастыру жəне
пайдалану бойынша нұсқаулық». Құжат соңында көрсетілген сілтеме арқылы өтіңіз.
3 бөлім: өнімнің фирмалық тақташасында орналасқан шығарылған уақыты жөніндегі мәлімет
Сертификаттау туралы ақпарат:
PUST типті сорғылары «Төмен вольтты жабдықтардың қауіпсіздігі туралы» (ТР ТС 004/2011), «Машиналар
және жабдықтар қауіпсіздігі туралы» (ТР ТС 010/2011) «Техникалық заттардың электрлі магниттік сәйкестілігі»
(ТР ТС 020/2011) Кеден Одағының техникалық регламенттерінің талаптарына сәйкес сертификатталды.
Сәйкестік сертификат:
№ TC RU C-DK.АИ30.В.01435, жарамдылық мерзімі 13.03.2020 жылға дейін
№ TC RU C-RU.АИ30.В.01416, жарамдылық мерзімі 09.03.2020 жылға дейін
«Иваново Сертификаттау Қоры» ЖШҚ «ИВАНОВО-СЕРТИФИКАТ» өнімді сертификациялау бойынша
органымен берілген.
Мекен-жайы: 153032, Ресей Федерациясы, Иванов облысы, Иваново қ., Станкостроителей көш., 1 үй.
Ресейде өндірілген өнімдер ТШ 4859-016-59379130-2011 сәйкес өндіріледі.
