Grundig VARIXX UMS 4810 SPCD User manual

ǵ
HIFI STEREO
MICRO
SYSTEM
Varixx
UMS 4810 SPCD
DEUTSCH
ENGLISH
FRANÇAIS
ITALIANO
PORTUGUÊS
ESPAÑOL

2
4 Set-up and safety
5 Overview
The hi-fi system controls
Displays
The back of the hi-fi system
The bottom of the hi-fi system
The remote control
10 Connection and preparation
Connecting the antennas
Connecting the loudspeakers
Connecting headphones
Connecting the power cord
Inserting back-up batteries
Inserting batteries in the remote control
Switching on and off
Additional information for units sold in the UK.
13 Settings
Setting the time
Setting the alarm time
Setting the alarm type
Setting the colour of the back light of the display
15 General functions
Selecting the input source
Adjusting the volume
Muting
15 Tuner mode
Selecting the tuner input source
Selecting radio stations
Stereo/mono reception
16 CD mode
Selecting the CD input source
Inserting a CD
CD playback
Repeating the current file or track
Selecting another file or track
Searching for a passage within a file or track
Repeating a file or a title (Repeat One)
Repeating all files or tracks (Repeat All)
Playing back files or tracks in random order (Random)
Creating a track memory
CONTENTS ______________________________________________________

ENGLISH
3
CONTENTS ______________________________________________________
20 Other modes
Alarm mode
Sleep timer mode
22 Information
Cleaning the CD unit
Technical data
General instructions for laser devices
Troubleshooting

4
Please note the following information when setting up the system:
The hi-fi system is designed for the playback of audio signals. Any other use is expressly
prohibited.
If you want to set up the hi-fi system on wall shelves or in cupboards, please ensure that the
device is adequately ventilated. There must be at least 10 cm of space at the side, above and
behind the device.
Please note when setting up the hi-fi system that furniture surfaces are coated with various
types of paint and plastic, which often contain chemical additives. These additives may cause
corrosion to the feet of the unit. This may leave stains on the surface of the furniture which can
be difficult or impossible to remove.
If the hi-fi system is exposed to sudden changes in temperature, for example when taken from
the cold into a warm room, wait at least two hours before using it.
The hi-fi system is designed for use in dry rooms. If you do use it outside, please ensure that it
is protected from moisture, such as rain or water splashes.
Do not place the hi-fi system close to heating units or in direct sunlight, as this will impair
cooling.
Do not place any vessels containing liquids, such as vases, on the hi-fi system. Do not insert
any foreign bodies in the CD or tape compartment.
Do not open the hi-fi system casing under any circumstances. The manufacturer will not
accept any liability for damage resulting from improper handling.
Thunderstorms are a danger to all electrical devices. Even if the hi-fi system is switched off,
it can be damaged by a lightning strike to the mains or the antenna cable. Always remove the
mains plug during an electrical storm.
SET-UP AND SAFETY _____________________________________

The hi-fi system controls
Controls on the front
General information
ON/OFF Switches the hi-fi system to and from standby mode.
•Standby indicator. Lights up red in standby mode.
FUNCTION Switches between the TUNER and CD input sources.
–z+Adjust the volume.
OFor setting the sleep timer; switches the sleep timer off.
Auto Dimmer Sensor. Adjusts the brightness of the display in relation to the brightness
of the room.
IR Infrared sensor for remote control signals.
ȄActivates and confirms the clock time setting.
SET – For setting the hours and minutes in reverse.
SET + For setting the hours and minutes forwards.
DISPLAY MODE Switches between mode indicator, clock and alarm time.
Tuner mode
AM/FM Switches between the FM (VHF) and MW (medium wave) frequency
bands.
FM MODE Switches between stereo and mono reception.
ENGLISH
5
OVERVIEW ______________________________________________________

6
CD mode
ıII Starts and pauses playback.
7Ends playback.
5as6Press briefly to select the next or previous file or track. Press and hold
down to start a forward or reverse search.
In MP3 mode: Quickly press twice to switch the files in steps of ten
backwards or forwards.
Alarm mode
ѕActivates and confirms the clock time setting.
SET – For setting the hours and minutes in reverse.
SET + For setting the hours and minutes forwards.
ɷ/eSwitches between alarm with music (radio or CD) and signal tone,
switches the alarm function off and back on.
Controls on the top
Tuner mode
aa TUNING ss For tuning to radio stations.
CD mode
OPEN/CLOSE Sensor. Pass your hand a distance of 2 to 4 cm over the sensor to open
and close the CD compartment.
Alarm mode
SNOOZE Sensor. Pass your hand a distance of 2 to 4 cm over the sensor
SENSOR to interrupt the signal tone alarm for five minutes.
OVERVIEW ______________________________________________________

ENGLISH
7
OVERVIEW ______________________________________________________
Controls on the sides
0Headphone jack for connecting a headphone set with a jack plug (ø 3.5 mm)
on the left side of the device;
the speakers of the hi-fi system are automatically switched off.
Displays
000 In MP3 mode: shows the total number of
files or the current file.
In CD mode: shows the total number of
tracks or the current track.
00:0.0 Shows the time or the alarm time.
In tuner mode: shows the frequency.
In MP3 and CD-DA mode: shows the
elapsed playing time of the file or track.
Tuner input source is selected.
An MP3 CD is being played.
CD input source is selected.
Muting is activated.
AM In tuner mode: MW (medium wave)
frequency band indicator.
FM In tuner mode: FM (VHF) frequency band indicator.
MONO In tuner mode: mono reception is selected.
MHz In tuner mode: in combination with the FM (VHF) frequency indicator.
KHz In tuner mode: in combination with the AM (medium wave) frequency indi-
cator.
eFlashes whilst setting the alarm time.
eThe signal tone alarm is switched on.
eThe alarm function with CD is switched on.
eThe alarm function with radio is switched on.
The alarm is interrupted.
SLEEP Flashes while the sleep timer is being set. Lights up upon activation of the
sleep timer.
SNOOZE
TUNER
CD
J
ľ
CD
MP3
TUNER
000
00:0.0
TUNER
SNOOZE
CD
MP3
AM
FM MHz
KHz
SLEEP
e
J
MONO
TUNERCD
ľ
ST.

8
The back of the hi-fi system
AM ANT Socket for connecting the AM (medium wave) antenna.
FM ANT Telescopic antenna for FM (VHF) reception.
ON OFF Switches the hi-fi off and from »OFF« to standby.
The only way to fully disconnect the hi-fi from the mains supply is to pull
the plug out.
SPEAKERS Terminals for connecting loudspeaker cables.
4 OHM R = right channel, L= left channel.
+ R – – L +
AC ~ Power cord.
The bottom of the hi-fi system
Compartment For backup batteries (2 x 1.5 V R03/UM4/AAA).
OVERVIEW ______________________________________________________

ENGLISH
9
OVERVIEW ______________________________________________________
The remote control
ON/OFF Switches the hi-fi system to and from standby
mode.
FUNCTION Switches between the TUNER and CD input
sources.
əIn MP3 and CD-DA mode: opens and closes the
CD compartment.
ıII In MP3 and CD-DA mode: starts and pauses
playback.
7In MP3 and CD-DA mode: ends playback.
5as6In MP3 and CD-DA mode: select the previous or
next file, press briefly to select previous or next
track, press and hold to start a rapid reverse or
forward search.
In MP3 mode: press twice to switch the files in
steps of ten backwards or forwards.
DISPLAY Switches the back light of the display between
COLOR different colours.
COLOR If the back light of the display is in automatic
SELECT colour change mode (the default setting), press
»COLOR SELECT« to select a particular colour;
activates automatic colour change if a particular
colour had previously been chosen.
RANDOM In MP3 and CD-DA mode: plays back files or
tracks in random order.
PROGRAM Files or tracks when creating a track memory.
bIn MP3 and CD-DA mode: for repeating a file or
track or a whole CD.
pSwitches the hi-fi speakers to and from mute mode.
–z+Adjust the volume.

10
Connecting the antennas
The wire antenna provides adequate reception of local FM (VHF) regional stations. Do not
shorten the wire antenna. A frame antenna is available for the reception of MW (medium
wave) stations.
1Plug the wire frame antenna into the »AM ANT« socket on the hi-fi system. Adjust the
position of the wire frame antenna until you get the best reception.
Connecting the loudspeakers
1Plug the loudspeaker cables into the »SPEAKERS 4 OHM + R – – L +« terminals on
the hi-fi system.
Connect the cables marked in red to the red terminal.
Connecting the headphones
1Insert the headphone plug (ø 3.5 mm) into the »0« socket on the left side of the hi-fi.
– The loudspeakers of the hi-fi system are switched off.
Connecting the power cord
Note:
Check that the mains voltage on the type plate (on the bottom of the hi-fi system) corre-
sponds to your local mains supply.
The only way to disconnect the hi-fi system from the mains supply is to pull the plug.
1Plug the power cord into the wall socket.
Inserting back-up batteries
In mains operation, the back-up batteries ensure the current time is retained if there is a
power failure or the device is briefly disconnected from the mains. The alarm time and alarm
function are not saved.
1Open the backup battery compartment on the bottom of the hi-fi system by pressing the
catch and removing the lid.
2When inserting the batteries (2 x 1.5 V, type IEC R3/UM4/AAA), observe the polarity
marked on the base of the battery compartment.
Note:
After a power cut the time on the display of the hi-fi flashes. The alarm time and alarm
type must then be reset.
CONNECTION AND PREPARATION ___________
