Gryphon Dynamics GD-8 Installation guide

ASSEMBLY INSTRUCTIONS
GRYPHON DYNAMICS GD-8
Designed for Professional Frames
www.gryphondynamics.co.kr
Rev. Nov 2013

SPECIFICATIONS
2
A
B
F
E
C
D
A B C D E F
OT1400F 1,400 5351,329 1555085921,950
OT1200F 1,200 4591,144 1555085921,820
OT1100F 1,100 4201,052 1555085921,690
OT1200S 1,200 4591,140 1555085921,740
OT1100S 1,100 4201,052 1555085921,680
OT1000S 1,000 3829601555085921,620
- Landing Gear : LG-5039TW
- Weight : Exlc. Landing Gear
Model
Weight(g)
Dimension(mm)

1. MOTOR MOUNT ASSEMBLY
3
CASE 1
MM-0401(Motor Mount)
M3x8mm Soket Button Head Cap Screw
CASE 2 : ESC MOUNT
CASE 3 : MOTOR MOUNT REINFORCEMENT
CN-0002M(Motor Mount Boom Connector)
MB-0501(Motor Connector Clamping Block)
M3x10mm Soket Countersunk Head Screw
EM-0601(ESC Mount)
MS-0402(Motor Mount Surpport)
M2.5x6mm Soket Head Cap Screw
0° ~ -6°
0° ~ +6°
Circle Hole
Oval Hole
INSTALL MOTOR ONTO THE MOTOR MOUNT
M3x8mm(or 6mm) Soket Countersunk Head Screw
THRUST VECTORING ANGLE ADJUSTMENT

2. OUTER BOOM ASSEMBLY 1
4
NOTE : Please repeat these
steps until you have 8 units.
3. OUTER BOOM ASSEMBLY 2
M3x8mm Soket Button Head Cap Screw : 4pcs
M3x8mm Torx Countersunk Head Screw : 8pcs
HC-0135D(Hub Connector 135D : 2pcs)
NOTE : Please repeat these
steps until you have 4 units.

4. INNER BOOM ASSEMBLY
5
M3x8mm Torx Countersunk Head Screw : 16pcs
HC-0090D(Hub Connector 90D : 2pcs)
5. INNER & OUTER BOOM ASSEMBLY
M3x8mm Torx Countersunk Head Screw : 4pcs
NOTE : Please repeat these
steps until you have 4 units.

6. FOLDING BOOM GUIDE RAIL ASSEMBLY
6
M3x6mm Soket Button Head Cap Screw : 2pcs GR-0101(Folding Boom Guide Rail & Collar)
M3x6mm Soket Button Head Cap Screw : 2pcs
FOLDING BOOM CONNECTOR DETAILED DRAWING
M3x4mm Hexagon Soket Set Screw LN-0204(Lock Knob)
RL-0203(Rolling Locker)
Neodymium Magnet(Φ4x2mm)
LP-0202(Guide Pin)
RL-0203(Rolling Locker)
M3x4mm Hexagon Soket Set Screw
Neodymium Magnet(Φ4x2mm)
LN-0204(Lock Knob)
ONLY CLOCKWISE DIRECTION
ONLY CLOCKWISE DIRECTION
PW-0205(Shim Washer)

7. CENTER PLATE / TOP
7
Top View
M3x6mm Soket Button Head Cap Screw : 24pcs
Bottom View
M3x6mm Soket Button Head Cap Screw : 12pcs
CM-0820 (8x20mm Cross Member) : 8pcs
CM-0846 (8x46mm Cross Member) : 4pcs
CP-2416OT
CP-0100BT
CP-0101GP
CL-0100V : 4pcs

8. CENTER PLATE / BOTTOM
8
Top View
Bottom View
CL-0100V(Boom Clamp : 4pcs)
CM-0846(8x46mm Cross Member : 4pcs)
M3x12mm Soket Button Head Cap Screw : 4pcs
CL-0100V(Boom Clamp : 4pcs)
CB-4012GR(Gear Rail : 2pcs)
EC-1012(PVC End Cap : 4pcs)
Direction Mark
M3x6mm Soket Button Head Cap Screw : 8pcs
CL-108(Gear Rail Boom Clamp) : 4pcs
M3x6mm Soket Button Head Cap Screw : 12pcs
Direction Mark
NOTE : If you mount the T-type
Landing Gear(LG-3039), please
follow the steps below.
M3x6mm Soket Button Head Cap Screw : 8pcs

9. CENTER PLATE & INNER BOOM ASSEMBLY(T-TYPE)
9
M3x6mm Soket Button Head Cap Screw : 18pcs

10. CENTER PLATE & INNER BOOM ASSEMBLY(I-TYPE)
10
M3x6mm Soket Button Head Cap Screw : 12pcs

CB-4012SK(Landing Gear Skid)
APPENDIX 1 : LANDING GEAR(T-TYPE) ASSEMBLY
11
M3x20mm Soket Button Head Cap Screw
EC-1012(PVC End Cap)
M3 Nylon Lock Nut
CB-3920(Landing Gear Boom)
M3x8mm Soket Button Head Cap Screw(2pcs)
M3x6mm Soket Button Head Cap Screw(2pcs)
CP-0102LG(Landing Gear Guide Plate & Spacer)
M3x6mm Soket Button Head Cap Screw(4pcs)
CL-0100H(Boom Clamp : 2pcs)
M3x8mm Soket Button Head Cap Screw(2pcs)
M3x6mm Soket Button Head Cap Screw(2pcs)
The length of cabon boom
CB-4012SK : 400mm
CB-5012SK : 500mm
The length of cabon boom
LG-3420 : 340mm
LG-3920 : 390mm
LG-4420 : 440mm
A-Type : M3x12mm Soket Button Head Cap Screw
B-Type : M3x20mm Soket Button Head Cap Screw + M3 Nylon Lock Nut

APPENDIX 2 : LANDING GEAR(I-TYPE ) ASSEMBLY
12
EC-1012(PVC End Cap)
CB-3920(Landing Gear Boom)
M3x8mm Soket Button Head Cap Screw
M3x6mm Soket Button Head Cap Screw
CP-0102LG(Landing Gear Guide Plate & Spacer)
M3x6mm Soket Button Head Cap Screw
CL-0100H(Boom Clamp)
A-Type : M3x12mm Soket Button Head Cap Screw
B-Type : M3x20mm Soket Button Head Cap Screw + M3 Nylon Lock Nut
The length of cabon boom
LG-3420 : 340mm
LG-3920 : 390mm
LG-4420 : 440mm
