GSI Group PNEG-1049 Installation and operating instructions

PNEG-1049
10"-12" Commercial Bin
Sweep Augers
Assembly and Operation Manual
PNEG-1049
Version: 4.0
Date: 03-28-18

2 PNEG-1049 10"-12" Commercial Bin Sweep Augers
Personnel operating or working around this equipment should read this manual. This manual
must be delivered with equipment to its owner. Failure to read this manual and its safety
instructions is a misuse of the equipment. Any misuse of the equipment may void the warranty.

Table of Contents
PNEG-1049 10"-12" Commercial Bin Sweep Augers 3
Contents
Chapter 1 Introduction ..........................................................................................................................................4
General Information .............................................................................................................................. 4
Chapter 2 Safety .....................................................................................................................................................5
Safety Guidelines .................................................................................................................................. 5
Cautionary Symbols Definitions ............................................................................................................ 6
Safety Cautions ..................................................................................................................................... 7
Safety Sign-Off Sheet ......................................................................................................................... 10
Chapter 3 Safety Decals ......................................................................................................................................11
Chapter 4 Assembly ............................................................................................................................................14
Chapter 5 Electrical Motor Drive Selection .......................................................................................................28
Chapter 6 Operation ............................................................................................................................................29
Chapter 7 Maintenance ........................................................................................................................................38
Storage ................................................................................................................................................ 39
Chapter 8 Parts List .............................................................................................................................................41
Motor Rods to Drive ............................................................................................................................ 42
10"-12" Drive Assembly ...................................................................................................................... 44
3:1 Aluminum Enclosed Drive ............................................................................................................. 46
Motor Mount Frame Assembly ............................................................................................................ 48
Drive to Discharge Flight and Shield ................................................................................................... 49
Discharge Flight and Shield Bundles .................................................................................................. 49
Flight and Shield Joint without Sweep Support Skid ........................................................................... 50
Intermediate Flight and Shield Bundles .............................................................................................. 51
Flight and Shield Joint with Sweep Support Skid ................................................................................ 52
Flight and Shield to Segmented Wheel ............................................................................................... 53
Chapter 9 Warranty ..............................................................................................................................................55

4 PNEG-1049 10"-12" Commercial Bin Sweep Augers
1. Introduction
General Information
1. We reserve the right to improve our product whenever possible and practical to do so. We reserve
the right to change, improve and modify products at any time without obligation to make changes,
improvements and modifications on equipment sold previously.
2. Thecommercialsweepshavebeendesigned and manufacturedtogiveyearsofdependableservice.
The care and maintenance of this machine will affect the satisfaction and service obtained. By
observing the instructions and suggestions we have recommended, the owner should receive
competent service for many years. If additional information or assistance should be required, please
contact the local dealer.
Receiving Merchandise and Filing Claims
When receiving merchandise, it is important to check both the quantity of parts and their descriptions with
the packing list enclosed within each package. All claims for freight damage or shortage must be made by
the consignee within ten (10) days from the date of the occurrence of freight damage. The consignee
should accept the shipment after noting the damage or loss.
NOTE: The only way to prevent damage to the bin sweep, bin floor and wells is to completely remove the
bin sweep from the bin.
DO NOT STORE SWEEPS IN THE BIN.
Sweeps are NOT designed to remain in a bin during filling, storage or gravity
unloading. A sweep left in a bin during these operations may be severely
damaged. The GSI Group will not be responsible for such damages.

PNEG-1049 10"-12" Commercial Bin Sweep Augers 5
2. Safety
Safety Guidelines
Safety guidelines are general-to-specific safety rules that must be followed at all times. This manual is
written to help you understand safe operating procedures and problems that can be encountered by the
operator and other personnel when using this equipment. Save these safety guidelines for future
reference.
As owner or operator, you are responsible for understanding the requirements, hazards, and precautions
that exist and to inform others as required. Unqualified persons must stay out of the work area at all times.
Alterations must not be made to the equipment. Alterations can produce dangerous situations resulting in
SERIOUS INJURY or DEATH.
This equipment must be installed in accordance with the current installation codes and applicable
regulations,which must be carefullyfollowed inall cases.Authorities havingjurisdiction must be consulted
before installations are made.
When necessary, you must consider the installation location relative to electrical, fuel and water utilities.
Personnel operating or working around equipment must read this manual. This manual must be delivered
with equipment to its owner. Failure to read this manual and its safety instructions is a misuse of the
equipment.
ST-0001-3

2. Safety
6 PNEG-1049 10"-12" Commercial Bin Sweep Augers
Cautionary Symbols Definitions
Cautionary symbols appear in this manual and on product decals. The symbols alert the user of potential
safety hazards, prohibited activities and mandatory actions. To help you recognize this information, we
use the symbols that are defined below.
DANGER
WARNING
CAUTION
NOTICE
This symbol indicates an imminently hazardous situation
which, if not avoided, will result in serious injury or death.
This symbol indicates a potentially hazardous situation
which, if not avoided, can result in serious injury or death.
This symbol indicates a potentially hazardous situation which,
if not avoided, can result in minor or moderate injury.
This symbol is used to address practices not related to
personal injury.
This symbol indicates a general hazard.
This symbol indicates a prohibited activity.
This symbol indicates a mandatory action.
ST-0005-2

2. Safety
PNEG-1049 10"-12" Commercial Bin Sweep Augers 7
Safety Cautions
Use Personal Protective Equipment
Eye
Protection
Hearing
Protection
Hand
Protection
Head
Protection
Respiratory
Protection Foot
Protection
Fall
Protection
• Use appropriate personal protective equipment:
• Wear clothing appropriate to the job.
• Remove all jewelry.
• Tie long hair up and back.
ST-0004-1
Follow Safety Instructions
• Carefully read all safety messages in this manual and
safety signs on your machine. Keep signs in good
condition. Replace missing or damaged safety signs.
Be sure new equipment components and repair parts
include the current safety signs. Replacement safety
signs are available from the manufacturer.
• Learn how to operate the machine and how to use
controls properly. Do not let anyone operate without
instruction.
• If you do not understand any part of this manual or
need assistance, contact your dealer.
ST-0002-1

2. Safety
8 PNEG-1049 10"-12" Commercial Bin Sweep Augers
Maintain Equipment and Work Area
• Understand service procedures before doing work. Keep area
clean and dry.
• Never service equipment while it is operating. Keep hands, feet,
and clothing away from moving parts
• Keep your equipment in proper working condition. Replace worn
or broken parts immediately.
ST-0003-1
Operate Motor Properly
• All electrical connections must be made in accordance with
applicable local codes (National Electrical Code for the US,
Canadian Electric Code, or EN60204 along with applicable
European Directives for Europe). Make sure equipment and
bins are properly grounded.
• Lock-out power before resetting motor overloads.
• Do not repetitively stop and start the drive in order to free a plugged
condition. Jogging the drive in this manner can damage the
equipment and drive components.
Rotating Auger Hazard
• Keep clear of rotating augers and moving parts.
• Do not remove or modify guards or covers.
• Lock-out power source before making adjustments,
cleaning, or maintaining equipment.
• Failure to follow these precautions will result in
serious injury or death.
ST-0037-1
Stay Clear of Hoisted Equipment
• Always use proper lifting or hoisting equipment when assembling
or disassembling equipment.
• Do not walk or stand under hoisted equipment.
• Always use sturdy and stable supports when needed for
installation. Not following these safety precautions creates the
risk of falling equipment, which could crush personnel and cause
serious injury or death.
ST-0047-1
ST-0009-3

2. Safety
PNEG-1049 10"-12" Commercial Bin Sweep Augers 9
Stay Clear of Rotating Parts
• Do not enter the bin while the equipment is
in operation.
• Entanglement in rotating augers will cause serious
injury or death.
• Keep all shields and covers in place at all times.
• Lock-out power source before making
adjustments, cleaning, or maintaining
equipment.
ST-0008-2
Use Unload Equipment Properly
• Do not operate this equipment alone. Make sure someone
nearby is aware of the proper shut down sequence in the event of
an emergency.
• Do not allow any person intoxicated or under the influence of
drugs to operate this equipment. All operators must be adequately
rested and prepared to perform all functions of operating
the equipment.
• Do not start equipment until all persons are clear of the work area
and safety guards are in place.
• Do not allow anyone inside a bin, truck, or wagon which is being
unloaded by an auger. Flowing grain can trap and suffocate in
seconds.
• Use ample overhead lighting after sunset to light the work area.
• Always use caution to not hit the auger when positioning the load.
• Do not leave equipment operating while unattended.
• Be aware of pinch points, which can trap or catch objects and
cause injury.
• Be sure all equipment is locked in position before operating.
• Always lock out all power sources to the equipment when
unloading is finished.
ST-0051-1

2. Safety
10 PNEG-1049 10"-12" Commercial Bin Sweep Augers
Safety Sign-Off Sheet
Below is a sign-off sheet thatcan be used to verify that all personnel have read and understood the safety
instructions. This sign-off sheet is provided for your convenience and personal record keeping.
Date Employee Name Supervisor Name
ST-0007

PNEG-1049 10"-12" Commercial Bin Sweep Augers 11
3. Safety Decals
Check components shown below to ensure that the safety decals are in place and in good condition. If a
decal cannot be easily read forany reason or has been painted over, replace it immediately. Contact your
dealer or the manufacturer to order a replacement decal free of charge.
WARNING
SHEAR POINT
Keep hands clear of moving
parts. Do not operate with
guard removed. Disconnect
and lockout power before
servicing.
DC-995GSI Group Inc. 217-226-4421
GSI Group 217-226-4421
DANGERDANGER
Keep out of bin while sweep is in operation.
RAPIDLY TRAVELLING SWEEP AUGER
Failure to heed will result in serious
injury or death. DC-1384
DC-994
Located inside belt guard
DC-1384
Located on shield
DC-995
Located outside belt guard
GSI Group 217-226-4421
DC-1760
Located on drive
3 TO 1 RATIO
DC-1760
DC-1512
Located on drive and on belt guard
DANGERDANGER
SHEAR POINT
Keep hands clear of moving
parts. Do not operate with
guard removed. Disconnect
and lockout power before
servicing.
DC-994GSI Group Inc. 217-226-4421

3. Safety Decals
12 PNEG-1049 10"-12" Commercial Bin Sweep Augers
A. DANGER Sign No. DC-1395 was supplied with your bin unloading equipment. This safety sign
should be applied to the side of the bin near the bin opening, so it will be viewed by people
entering into the bin storage building. Do not cover any safety signs or any other signs that are
already there.
B. If the safety sign location suggested is not in full view because of equipment modifications, other
equipment in the area or any reason, then locate the safety sign in a more suitable location.
C. Be certain the surface is clean, dry and free of dirt and oil. Peel paper backing from decals and stick
into place. The adhesive backing will bond on contact.
NOTE: Please remember, safety signs provide important safety information for people working near bin
unloading equipment that is in operation.
NOTE: If the Safety Sign cannot be easily read for any reason or has been painted over, replace it
immediately. Additional Safety Signs may be obtained free of charge from your dealer, distributor
or ordered from the factory.
Order SAFETY SIGN NO. DC-1395
DANGER
DANGER
ROTATING FLIGHTING
FAILURE TO DO SO WILL RESULT IN
SERIOUS INJURY OR DEATH.
This bin is equipped with grain augers
which can kill or dismember.
Keep clear of all augers and never enter
this bin unless all power is
disconnected and locked out.
DC-1395GSI Group Inc. 217-226-4421

3. Safety Decals
PNEG-1049 10"-12" Commercial Bin Sweep Augers 13
The safety decals on your equipment are safety indicators which must be carefully read and understood
by all personnel involved in the installation, operation, service and maintenance of the equipment.
To replace a damaged of missing decal, contact us to receive a free replacement.
GSI Decals
1004 E. Illinois St.
Assumption, IL. 62510
Phone: [phone]
Location Decal # Decals Description
On bin door
covers DC-GBC-1A Danger Keep Clear of Augers
Rotating flighting will
kill or dismember.
Flowing material will
trap and suffocate.
Crusted material will
collapse and suffocate.
DANGER
DANGER
Keep clear of all augers.
DO NOT ENTER this bin!
If you must enter the bin:
1. Shut off and lock out all power.
2. Use a safety harness and safety line.
3. Station another person outside the bin.
4. Avoid the center of the bin.
5. Wear proper breathing equipment or respirator.
Failure to heed these
warnings will result in
serious injury or death.
DC-GBC-1A
GSI GROUP, INC. 217-226-4421

14 PNEG-1049 10"-12" Commercial Bin Sweep Augers
4. Assembly
1. Attach the pivot yoke to the drive assembly with two (2) 5/8" x 2" grade 8 hex bolts and nylock nuts.
(See Figure 4A.)
Figure 4A Pivot to Drive Assembly
2. Remove the two (2) 3/4" x 1-1/4" grade 8 hex bolts and nuts that attach the belt guard mounting
strap to the motor mount frame assembly. These nuts will be reused in the Step 3 on Page 15.
(See Figure 4B.)
Figure 4B Remove Hardware

4. Assembly
PNEG-1049 10"-12" Commercial Bin Sweep Augers 15
3.Threadone3/4"hex nutontoeachpostof the bottommotorstraps.Next, placethefrontbottommotor
strap through the belt guard mounting strap and the front hole of the motor mount frame assembly.
Place the back bottom motor strap thought the back hole of the motor mount frame assembly. Retain
the straps by threading one 3/4" hex nut onto each post. DO NOT TIGHTEN the nuts at this time.
They will need adjustment when the motor is installed. (See Figure 4C.)
Figure 4C Attach Bottom Motor Mount Strap
4. Place the motor rods into the indentationson the bottom motorstraps. Secure themotor rods in place
by bolting the top motor straps to the bottom motor straps using eight (8) 3/8" x 1-1/2" grade 8 hex
bolts, sixteen (16) flat washers and eight (8) nylock nuts. DO NOT TIGHTEN the nuts at this time.
They will need adjustment when the motor is installed. (See Figure 4D.)
Figure 4D Attach Motor Rod and Top Motor Strap

4. Assembly
16 PNEG-1049 10"-12" Commercial Bin Sweep Augers
5. When installing the bin sweep in the bin, put two (2) 1" flat washers onto the post of the pivot yoke.
Place the drive assembly onto the center well pivot tube. (See Figure 4E.)
Figure 4E Drive Assembly to Center Pivot
6. Attach the discharge flight to the connecting shaft on the drive assembly using two (2) 1/2" x 3-1/2"
grade8 hex bolts andstovernuts. The discharge flight is distinguished by the absenceof flightribbon
at one end. This end gets attached to the drive assembly. (See Figure 4F.)
Figure 4F Discharge Flight to Drive

4. Assembly
PNEG-1049 10"-12" Commercial Bin Sweep Augers 17
7. Attach the discharge back shield to the drive assembly using two (2) 3/8" x 1-1/2" grade 8 hex bolts,
four (4) flat washers and two (2) nylock nuts. The discharge back shield does not have the full
continuous high back shield. It is cut away at the discharge to allow more grain flow around the drive
assembly. This cut back end gets attached to the drive assembly. (See Figure 4G.)
Figure 4G Discharge Shield to Drive
NOTE: Bin sweeps containing more than two (2) sections of flight and back shield can have multiple
configurations. These configurations determine where the flight and back shield joints exist in
relation to the center of the bin.
Consider all configurations for the bin diameter before continuing. On bin sweeps with
three (3) or more sections of flight and back shield, a carrier wheel assembly is used every
two (2) sections.
Choose the configuration for the bin diameter to ensure that the(se) carrier wheel assembly(s)
do not interfere with the existing well positions.
Damage to the bin sweep and unload well or well grate could result from an incorrect
configuration of flight and back shield sections.

4. Assembly
18 PNEG-1049 10"-12" Commercial Bin Sweep Augers
8. Place the 2" O.D. x 11-1/2" connecting shaft into the free end of the flight. Once the holes are aligned
properly, attach the shaft to the flight using two (2) 5/8" x 4" grade 8 hex bolts and stover nuts.
(See Figure 4H.)
Figure 4H Connecting Shaft to Flight
9. Place the bearing stand assembly onto the connecting shaft. (See Figure 4I.)
Figure 4I Bearing on Connecting Shaft

4. Assembly
PNEG-1049 10"-12" Commercial Bin Sweep Augers 19
10. Removethe7/16" x 1-1/4"HHCSbolt and 7/16"nylocknut alongwiththe7/16" flatwasherattached
to bearing stand assembly. (See Figure 4J.)
Figure 4J Remove Hardware from Bearing Stand Assembly
11. Attach the sweep support skid to the bearing stand assembly and secure it using 3/8'' x 4" HHTB
bolt, flat washer, nylock nut and flange nut as shown in Figure 4K.
NOTE: 3/8" Nylock nut and 3/8" flange nut are used for adjusting the sweep support skid with the
bearing stand assembly.
Figure 4K Sweep Support Skid to Bearing Stand Assembly

4. Assembly
20 PNEG-1049 10"-12" Commercial Bin Sweep Augers
12. Align the next section of flight making sure that the Dura-Edge on both flights are as continuous
as possible, the angle between both faces being greater than 90° and less than 180° and
without overlapping.
NOTE: Overlapping the flights or having an angle between the ribbon faces be less than 90° or
greater than 180°, will result in reduced unload capacity.
13. Attach the next flight to the connecting shaft using two (2) 5/8" x 4" grade 8 hex bolts and
stover nuts. (See Figure 4L.)
Figure 4L Flight to Flight Via Connecting Shaft
14. Attach the matching section of back shield to the bearing stand assembly and the previous section
of back shield with two (2) 3/8" x 3" carriage bolts, flat washers and nylock nuts. (See Figure 4M.)
Figure 4M Shield to Shield through Bearing
