AEG ALP18 User manual

ALP18

2
2
Important!
It is essential that you read the instructions in this manual before
assembling, operating, and maintaining the product.
Subject to technical modifications.
ALP18
x 1x 1x 1
x 1
x 1

33
ALP18
x 1x 1x 1
x 1
x 1

4
4
LED INDICATOR
HANDLE
TRIGGER
SWITCH
BATTERY
PORT
CUTTING BLADE
FIXED BLADE
LOCKING NUT
LOCKING SCREW
LED INDICATOR DESCRIPTION
LED indicator Sound Description
Off The product is off.
Solid green The product is on and ready to
begin cutting.
Flashing red
(2 times) 2 beeps
The product has reached its
overload limit. The material is
too large to be cut. The cutting
blades open.
Flashing red
(5 times) 5 beeps
The product has made 5,000
cuts. Check the quality of the
blades
Flashing red
(3 times) 3 beeps
Over-temperature protection
is activated. Wait for 30
minutes or until the product
has cooled down before
resuming operation.

55
LED INDICATOR
HANDLE
TRIGGER
SWITCH
BATTERY
PORT
CUTTING BLADE
FIXED BLADE
LOCKING NUT
LOCKING SCREW

6
6
8
15
10
14
OPERATING THE PRODUCT
REPLACING THE BLADE

77
8
15
10
14
CLEANING THE PRODUCT
STORING THE PRODUCT

8
8
click
3s
3
2
1
4
OPERATING THE PRODUCT
NOTE: Hold the trigger for 3 seconds to
turn on the product. The product beeps
and the blades open if they were initally
closed.
NOTE: Never leave the product
unattended while the battery is inserted.
NOTE: Always keep your non-cutting
hand away from the blades while using
the product.

99
click
3s
3
2
1
4
30s
zz
3s
5
NOTE: The product will automatically
turn off after 30 seconds of inactivity,
leaving the blades open. To turn on
again, hold the trigger for 3 seconds
until the product beeps.
NOTE: Never transport the product
with the blades open.
NOTE: Hold the trigger for 3 seconds
to turn off the product. The blades will
immediately close, followed by 2 beeps
after 3 seconds. The blades will be
locked close.

10
10
12
2
1
3
2
1
4
2
1
REPLACING THE BLADE
NOTE: Turn off the product using the
trigger to ensure that the blades are
locked close. Remove the battery pack
before performing any maintenance on
the product.
1
2
6
7
8
5
2
1
1
2
NOTE: Make sure that the replacement
blade (ALP1) is placed in the same
position as the old one. Ensure that the
teeth are seated correctly between each
other.

11 11
12
2
1
3
2
1
4
2
1
1
2
6
7
8
5
2
1
1
2
NOTE: Make sure that the replacement
blade (ALP1) is placed in the same
position as the old one. Ensure that the
teeth are seated correctly between each
other.

12
12
12
2
1
10
11
12
9
NOTE: Do not overtighten the nut. The
torque setting is 0.2 Nm.
NOTE: Do not overtighten the bolt. The
torque setting is 3.0 Nm.
3
2
13
NOTE: Do not overtighten the housing
cover. The torque setting is 0.4 Nm.
NOTE: Ensure to align the U washer with
the teeth of the bolt before tightening it.

13 13
12
2
1
10
11
12
9
3
2
13
NOTE: Do not overtighten the housing
cover. The torque setting is 0.4 Nm.

14
14
2
1
3
2
1
CLEANING THE PRODUCT
NOTE: Turn off the product using the
trigger to ensure that the blades are
locked close. Remove the battery pack
before performing any maintenance on
the product.
NOTE: Put the nozzle of the oil tank
against the steel ball, and pour light
lubricant oil, such as sewing machine oil,
to lubricate the blades.
2
1
2
1
STORING THE PRODUCT
NOTE: Never store the product with the
blades open.

15 15
2
1
3
2
1
2
1
2
1
STORING THE PRODUCT
NOTE: Never store the product with the
blades open.

16
16
BATTERY AND CHARGER
Model ALP18
Compatible
battery packs
L1815G, L1820S, L1820R, L1825R, L1840R, L1850R, L1860R,
L1830RHD, L1830R-X5, L1860R-X5, L1890RHD, L1890R,
L1840SHD, A18FB4, L1850SHD, A18FB5
Compatible
chargers
BL1218, BLK1218, BL18DP-LE, BL18DP-X5, BL18DP2-X5,
BL18DPS, AL1218G, AL18G, BL18S
NOTE: Buy the compatible battery packs and chargers from an authorised
service centre.
REPLACEMENT PARTS
Blade set ALP1
INTENDED USE
The cordless secateurs are only designed for cutting and pruning small wood
limbs and branches with a diameter of up to 30 mm (softwood) and 25 mm
(hardwood). Do not cut branches with diameters that are greater than these
values. Do not use the product for any other purpose.
GENERAL PRODUCT SAFETY WARNINGS
WARNING! Read all safety warnings, instructions, illustrations and
specifications provided with this power tool. Failure to follow all instructions
listed below may result in electric shock, fire, and/or serious injury.
Save all warnings and instruction for future reference.
The term “power tool” in the warnings refers to your mains-operated (corded)
product or battery-operated (cordless) product.
WORK AREA SAFETY
Keep work area clean and well lit. Cluttered or dark areas invite accidents.
Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
ELECTRICAL SAFETY
Power tool plugs must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk of electric shock.
Avoid body contact with earthed or grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
Do not expose power tools to rain or wet conditions. Water entering a
power tool will increase the risk of electric shock.
Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase the risk of electric shock.
When operating a power tool outdoors, use an extension cord suitable
for outdoor use. Use of a cord suitable for outdoor use reduces the risk of
electric shock.
If operating a power tool in a damp location is unavoidable, use a residual
current device (RCD) protected supply. Use of an RCD reduces the risk of
electric shock.
PERSONAL SAFETY
Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired
or under the influence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in serious personal injury.
Use personal protective equipment. Always wear eye protection.
Protective equipment such as a dust mask, non-skid safety shoes, hard hat
or hearing protection used for appropriate conditions will reduce personal
injuries.
Prevent unintentional starting. Ensure the switch is in the o-position
before connecting to power source and/or battery pack, picking up or
carrying the tool. Carrying power tools with your finger on the switch or
energising power tools that have the switch on invites accidents.
Remove any adjusting key or wrench before turning the power tool on. A
wrench or a key left attached to a rotating part of the power tool may result
in personal injury.
Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
Dress properly. Do not wear loose clothing or jewellery. Keep your hair
and clothing away from moving parts. Loose clothes, jewellery or long hair
can be caught in moving parts.
TECHNICAL DATA CORDLESS SECATEURS ALP18
Rated voltage 18 V d.c.
Cutting capacity
Softwood 30 mm
Hardwood 25 mm
Product length 0.29 m
Noise emission values determined according to IEC 62841-1:
Sound Pressure Level at Operator Position LpA = 71.8 dB(A)
Uncertainty K= 3.0 dB
A-weighted sound power level LWA = 82.8 dB(A)
Uncertainty K= 3.0 dB
Vibration total values determined according to EN IEC 62841-1:
Vibration emission value (front/rear) ah= 1.4 m/s²
Uncertainty K= 1.5 m/s²
Weight (without battery) 0.96 kg
Weight with the heaviest battery pack 2.1 kg
Cutting cycle time ≤ 1 second
Recommended use: Allow 1 second between each cut.
If devices are provided for the connection of dust extraction and collection
facilities, ensure these are connected and properly used. Use of dust
collection can reduce dust-related hazards.
Do not let familiarity gained from frequent use of tools allow you to
become complacent and ignore tool safety principles. A careless action can
cause severe injury within a fraction of a second.
POWER TOOL USE AND CARE
Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at the rate
for which it was designed.
Do not use the power tool if the switch does not turn it on and o. Any
power tool that cannot be controlled with switch is dangerous and must be
repaired.
Disconnect the plug from the power source and/or remove the battery
pack, if detachable, from the power tool before making any adjustments,
changing accessories, or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool accidentally.
Store idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to operate
the power tool. Power tools are dangerous in the hands of untrained users.
Maintain power tools and accessories. Check for misalignment or binding
of moving parts, breakage of parts and any other condition that may
aect the power tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by poorly maintained power
tools.
Keep cutting tools sharp and clean. Properly maintained cutting tools with
sharp cutting edges are less likely to bind and are easier to control.
Use the power tool, accessories and tool bits etc. in accordance with these
instructions, taking into account the working conditions and the work
to be performed. Use of the power tool for operations dierent from those
intended could result in a hazardous situation.
Keep handles and grasping surfaces dry, clean and free from oil and
grease. Slippery handles and grasping surfaces do not allow for safe handling
and control of the tool in unexpected situations.
BATTERY TOOL USE AND CARE
Recharge only with the charger specified by the manufacturer. A charger
that is suitable for one type of battery pack may create a risk of fire when used
with another battery pack.
Use power tools only with specifically designated battery packs. Use of
any other battery packs may create a risk of injury and fire.
When battery pack is not in use, keep it away from other metal objects,
like paper clips, coins, keys, nails, screws or other small metal objects, that
can make a connection from one terminal to another. Shorting the battery
terminals together may cause burns or a fire.
Under abusive conditions, liquid may be ejected from the battery; avoid
contact. If contact accidentally occurs, flush with water. If liquid contacts
eyes, additionally seek medical help. Liquid ejected from the battery may
cause irritation or burns.
Do not use a battery pack or tool that is damaged or modified. Damaged
or modified batteries may exhibit unpredictable behaviour resulting in fire,
explosion or risk of injury.
Do not expose a battery pack or tool to fire or excessive temperature.
Exposure to fire or temperature above 130°C may cause explosion.
Follow all charging instructions and do not charge the battery pack or
tool outside the temperature range specified in the instructions. Charging
improperly or at temperatures outside the specified range may damage the
battery and increase the risk of fire.
SERVICE
Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power
tool is maintained.
Never service damaged battery packs. Service of battery packs should only
be performed by the manufacturer or authorized service providers.

17 17
Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
ELECTRICAL SAFETY
Power tool plugs must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk of electric shock.
Avoid body contact with earthed or grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
Do not expose power tools to rain or wet conditions. Water entering a
power tool will increase the risk of electric shock.
Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase the risk of electric shock.
When operating a power tool outdoors, use an extension cord suitable
for outdoor use. Use of a cord suitable for outdoor use reduces the risk of
electric shock.
If operating a power tool in a damp location is unavoidable, use a residual
current device (RCD) protected supply. Use of an RCD reduces the risk of
electric shock.
PERSONAL SAFETY
Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired
or under the influence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in serious personal injury.
Use personal protective equipment. Always wear eye protection.
Protective equipment such as a dust mask, non-skid safety shoes, hard hat
or hearing protection used for appropriate conditions will reduce personal
injuries.
Prevent unintentional starting. Ensure the switch is in the o-position
before connecting to power source and/or battery pack, picking up or
carrying the tool. Carrying power tools with your finger on the switch or
energising power tools that have the switch on invites accidents.
Remove any adjusting key or wrench before turning the power tool on. A
wrench or a key left attached to a rotating part of the power tool may result
in personal injury.
Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
Dress properly. Do not wear loose clothing or jewellery. Keep your hair
and clothing away from moving parts. Loose clothes, jewellery or long hair
can be caught in moving parts.
TECHNICAL DATA CORDLESS SECATEURS ALP18
Rated voltage 18 V d.c.
Cutting capacity
Softwood 30 mm
Hardwood 25 mm
Product length 0.29 m
Noise emission values determined according to IEC 62841-1:
Sound Pressure Level at Operator Position LpA = 71.8 dB(A)
Uncertainty K= 3.0 dB
A-weighted sound power level LWA = 82.8 dB(A)
Uncertainty K= 3.0 dB
Vibration total values determined according to EN IEC 62841-1:
Vibration emission value (front/rear) ah= 1.4 m/s²
Uncertainty K= 1.5 m/s²
Weight (without battery) 0.96 kg
Weight with the heaviest battery pack 2.1 kg
Cutting cycle time ≤ 1 second
Recommended use: Allow 1 second between each cut.
If devices are provided for the connection of dust extraction and collection
facilities, ensure these are connected and properly used. Use of dust
collection can reduce dust-related hazards.
Do not let familiarity gained from frequent use of tools allow you to
become complacent and ignore tool safety principles. A careless action can
cause severe injury within a fraction of a second.
POWER TOOL USE AND CARE
Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at the rate
for which it was designed.
Do not use the power tool if the switch does not turn it on and o. Any
power tool that cannot be controlled with switch is dangerous and must be
repaired.
Disconnect the plug from the power source and/or remove the battery
pack, if detachable, from the power tool before making any adjustments,
changing accessories, or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool accidentally.
Store idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to operate
the power tool. Power tools are dangerous in the hands of untrained users.
Maintain power tools and accessories. Check for misalignment or binding
of moving parts, breakage of parts and any other condition that may
aect the power tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by poorly maintained power
tools.
Keep cutting tools sharp and clean. Properly maintained cutting tools with
sharp cutting edges are less likely to bind and are easier to control.
Use the power tool, accessories and tool bits etc. in accordance with these
instructions, taking into account the working conditions and the work
to be performed. Use of the power tool for operations dierent from those
intended could result in a hazardous situation.
Keep handles and grasping surfaces dry, clean and free from oil and
grease. Slippery handles and grasping surfaces do not allow for safe handling
and control of the tool in unexpected situations.
BATTERY TOOL USE AND CARE
Recharge only with the charger specified by the manufacturer. A charger
that is suitable for one type of battery pack may create a risk of fire when used
with another battery pack.
Use power tools only with specifically designated battery packs. Use of
any other battery packs may create a risk of injury and fire.
When battery pack is not in use, keep it away from other metal objects,
like paper clips, coins, keys, nails, screws or other small metal objects, that
can make a connection from one terminal to another. Shorting the battery
terminals together may cause burns or a fire.
Under abusive conditions, liquid may be ejected from the battery; avoid
contact. If contact accidentally occurs, flush with water. If liquid contacts
eyes, additionally seek medical help. Liquid ejected from the battery may
cause irritation or burns.
Do not use a battery pack or tool that is damaged or modified. Damaged
or modified batteries may exhibit unpredictable behaviour resulting in fire,
explosion or risk of injury.
Do not expose a battery pack or tool to fire or excessive temperature.
Exposure to fire or temperature above 130°C may cause explosion.
Follow all charging instructions and do not charge the battery pack or
tool outside the temperature range specified in the instructions. Charging
improperly or at temperatures outside the specified range may damage the
battery and increase the risk of fire.
SERVICE
Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power
tool is maintained.
Never service damaged battery packs. Service of battery packs should only
be performed by the manufacturer or authorized service providers.
CORDLESS SECATEURS SAFETY WARNINGS
DANGER! Keep hands away from the blade. Contact with the blade will
result in serious personal injury.
WARNING! Do not leave the product unattended before the LED and
sound indicate that it is off.
Save these instructions. Refer to them frequently, and use them to instruct
others who may use the product. If you loan someone the product, loan them
these instructions also to prevent misuse of the product and possible injury.
Never allow children, persons with reduced physical, sensory, or mental
capabilities or lack of experience and knowledge, or people who are unfamiliar
with these instructions to use the product. Local restrictions may limit the age
of operator.
Do not operate the product in poor lighting. Use the product only in daylight
or good artificial light.
Do not use the product to cut wires.
Do not use the product where there is a risk of hidden wiring.
To reduce the risk of injury associated with contacting moving parts, always
turn o the product, remove the battery pack, and make sure that all moving
parts have come to a stop:
■before clearing a blockage
■before checking, cleaning, or working on the product
■before changing accessories
■before leaving the product unattended
■before performing maintenance
Keep the product clean of clippings and other materials. They may
become lodged between the jaw and blade.
Keep the area clear of all bystanders, children, and pets while operating
the product.
When cutting a limb under tension, be alert for springback so that you
will not be struck when the tension in the wood fibres is released.
Maintain the product with care. Keep the cutting blades sharp and
clean for best performance and to reduce the risk of injury. Follow the
instructions for lubricating and changing accessories.
Before using the product, check for damaged parts and press the trigger
to ensure that the cutting blades open and close correctly. Check the
product regularly to make sure that it will operate properly and perform
the intended function. Keep hands away from the blade.
Keep your body warm in cold weather. When operating the product,
wear gloves to keep the hands and wrists warm. It is reported that cold
weather is a major factor contributing to Raynaud’s Syndrome.
Injuries may be caused, or aggravated, by prolonged use of the product.
When using any product for prolonged periods, ensure to take regular
breaks.
Operate the product only in temperatures between 0°C and 40°C.
Store the product in a location where the ambient temperature is
between 0°C and 40°C.
ADDITIONAL BATTERY SAFETY WARNINGS
To reduce the risk of fire, personal injury, and product damage due to a
short circuit, never immerse the tool, battery pack, or charger in fluid or
allow fluid to flow inside them. Corrosive or conductive fluids, such as
seawater, certain industrial chemicals, and bleach or bleach-containing
products, etc., can cause a short circuit.
Charge the battery pack in a location where the ambient temperature is
between 10°C and 38°C.
Store the battery pack in a location where the ambient temperature is
between 0°C and 40°C.
Use the battery pack in a location where the ambient temperature is
between 0°C and 40°C.
TRANSPORTATION AND STORAGE
Turn o the product, remove the battery pack, and allow both to cool before
storing or transporting.
Remove all foreign materials from the product. Install the blade cover.

18
18
For transportation in a vehicle, secure the product against movement or falling
to prevent injury to persons or damage to the product.
Store the product in a cool, dry, and well-ventilated place that is inaccessible
to children. Keep the product away from corrosive agents such as garden
chemicals and de-icing salts. Do not store the product outdoors.
TRANSPORTING LITHIUM BATTERIES
Transport the battery in accordance with local and national provisions and
regulations. Follow all special requirements on packaging and labelling when
transporting batteries by a third party.
Ensure that no batteries can come in contact with other batteries or conductive
materials while in transport by protecting exposed connectors with insulating,
nonconductive caps or tape. Do not transport batteries that are cracked or
leaking. Check with the forwarding company for further advice.
MAINTENANCE
To avoid serious personal injury, always remove the battery pack from the
product when cleaning or performing any maintenance. Ensure that the
cutting mechanism has stopped before setting down the product and storing
the product.
Use only original manufacturer’s replacement parts, accessories, and
attachments. Failure to do so can cause possible injury, can contribute to poor
performance, and may void your warranty.
Servicing requires extreme care and knowledge and should be performed only
by a qualified service technician. Have the product serviced by an authorised
service centre only.
After each use, clean the body and handles of the product with a soft, dry
cloth. Any part that is damaged should be properly repaired or replaced by an
authorised service centre.
After each use, clean the debris from the blades with a sti brush, and then
use a disinfectant wipe to clean the blades. Carefully apply a rust-preventative
lubricant. Use a recommended rust-preventative lubricant spray to apply an
even distribution and reduce the risk of personal injury from contact with the
blades. For information about suitable spray products, check with your local
authorised service centre.
You may make adjustments and repairs described in this manual. For other
repairs, contact an authorised service centre.
Check all nuts, bolts, and screws at frequent intervals for proper tightness to
ensure that the product is in safe working condition.
Avoid using solvents when cleaning plastic parts. Most plastics are susceptible
to damage from various types of commercial solvents and may be damaged
by their use. Use clean cloths to remove dirt, dust, oil, or grease. Do not at any
time let brake fluids, gasoline, petroleum-based products, or penetrating oils
come in contact with plastic parts. Chemicals can damage, weaken, or destroy
plastic, resulting in serious personal injury.
NOTE: To ensure long and reliable service, carry out the following maintenance
regularly:
Check for obvious defects, such as loose, dislodged, or damaged blades;
loose fixings; and worn or damaged components.
Visually check the condition of the cutting edges of the cutting blade.
Replace the blade when worn or damaged.
SYMBOLS
Safety alert
Read the instructions carefully before starting the product.
Wear head and eye protection.
Do not expose to rain or damp condition
Regulatory Compliance Mark (RCM). Product meets
applicable regulatory requirements.
Visible radiation, instructional safeguard
To prevent serious injury, do not touch cutting blades.
Beware of thrown or flying objects. Keep all bystanders,
especially children and pets, at least 15 m away from the
operating area.
Do not dispose of electric tools together with household
waste material. Electric tools and electronic equipment
that have reached the end of their life must be collected
separately and returned to an environmentally compatible
recycling facility. Check with your local authority or retailer
for recycling advice and collection point.

Wear head and eye protection.
Do not expose to rain or damp condition
Regulatory Compliance Mark (RCM). Product meets
applicable regulatory requirements.
Visible radiation, instructional safeguard
To prevent serious injury, do not touch cutting blades.
Beware of thrown or flying objects. Keep all bystanders,
especially children and pets, at least 15 m away from the
operating area.
Do not dispose of electric tools together with household
waste material. Electric tools and electronic equipment
that have reached the end of their life must be collected
separately and returned to an environmentally compatible
recycling facility. Check with your local authority or retailer
for recycling advice and collection point.
