GSi GrainVue User manual

Cable Monitoring System
Installation Manual
PNEG-2347
Version 1.0
Date: 11-01-21
PNEG-2347

All information, illustrations, photos, and specifications in this manual are based on the latest
information available at the time of publication. The right is reserved to make changes at any
time without notice.
2PNEG-2347 Cable Monitoring System

Contents
Chapter 1 Safety Precautions ....................................................................................................................5
Safety Guidelines........................................................................................................................5
Cautionary Symbol Definitions......................................................................................................6
Safety Cautions...........................................................................................................................7
Safety Decals ........................................................................................................................... 11
Operating Conditions.................................................................................................................13
Maintenance and Service...........................................................................................................13
Safety Sign-off Sheet.................................................................................................................14
Chapter 2 Gateway Installation................................................................................................................15
Gateway Installation — Overview ...............................................................................................15
Installing the Power Supply Unit (PSU) .......................................................................................15
Installing the Gateway ...............................................................................................................18
Chapter 3 Cable Monitoring Overview .....................................................................................................23
Installation Overview .................................................................................................................23
System Overview ......................................................................................................................24
Chapter 4 Installing the Cable Monitoring Hub ........................................................................................25
Chapter 5 Installing the Power Supply.....................................................................................................29
NOTE.......................................................................................................................................29
OPTION 1: Solar Powered.........................................................................................................29
OPTION 2: Installing the Power Supply Unit ................................................................................29
OPTION 3: Installing the Fan Control Module ..............................................................................32
Chapter 6 Connecting the T/RH Cables ...................................................................................................43
Cable Installations.....................................................................................................................43
Cable Positions.........................................................................................................................43
OPTION 1: Single Cable Connection ..........................................................................................44
OPTION 2: Installing and Connecting the Mux Whip ....................................................................45
OPTION 3: Installing and Connecting the Mux Box ......................................................................46
Chapter 7 Activating the Cable Monitoring Hub.......................................................................................49
Chapter 8 Appendix.................................................................................................................................51
Appendix-A: Fan Control Wiring Diagram ....................................................................................51
Appendix-B: Firmware Upgrade Procedure .................................................................................52
Appendix-C: Cable Connection Ports..........................................................................................53
Appendix-D: Cable Reference Details.........................................................................................54
Appendix-E: Risk Analysis .........................................................................................................55
Limited Warranty — N.A. Grain Products ................................................................................57
PNEG-2347 Cable Monitoring System 3

NOTES
4PNEG-2347 Cable Monitoring System

1Safety Precautions
Topics Covered in this Chapter
▪ Safety Guidelines
▪ Cautionary Symbol Definitions
▪ Safety Cautions
▪ Safety Decals
▪ Operating Conditions
▪ Maintenance and Service
▪ Safety Sign-off Sheet
Safety Guidelines
Safety guidelines are general-to-specific safety rules that must be followed at all times. This manual is
written to help you understand safe operating procedures and problems that can be encountered by the
operator and other personnel when using this equipment. Read and save these instructions.
As owner or operator, you are responsible for understanding the requirements, hazards, and precautions
that exist and to inform others as required. Unqualified persons must stay out of the work area at all
times.
Alterations must not be made to the equipment. Alterations can produce dangerous situations resulting in
SERIOUS INJURY or DEATH.
This equipment must be installed in accordance with the current installation codes and applicable regula-
tions, which must be carefully followed in all cases. Authorities having jurisdiction must be consulted
before installations are made.
When necessary, you must consider the installation location relative to electrical, fuel and water utilities.
Personnel operating or working around equipment must read this manual. This manual must be delivered
with equipment to its owner. Failure to read this manual and its safety instructions is a misuse of the
equipment.
ST-0001–4
PNEG-2347 Cable Monitoring System 5

Chapter 1: Safety Precautions
Cautionary Symbol Definitions
Cautionary symbols appear in this manual and on product decals. The symbols alert the user of potential
safety hazards, prohibited activities and mandatory actions. To help you recognize this information, we
use the symbols that are defined below.
Table 1-1 Description of the different cautionary symbols
Symbol Description
This symbol indicates an imminently hazardous situation which, if
not avoided, will result in serious injury or death.
This symbol indicates a potentially hazardous situation which, if not
avoided, can result in serious injury or death.
This symbol indicates a potentially hazardous situation which, if not
avoided, can result in minor or moderate injury.
This symbol is used to address practices not related to personal
injury.
This symbol indicates a general hazard.
This symbol indicates a prohibited activity.
This symbol indicates a mandatory action.
ST-0005–2
6PNEG-2347 Cable Monitoring System

Chapter 1: Safety Precautions
Safety Cautions
Use Personal Protective Equipment
• Use appropriate personal protective equipment:
Eye
Protection
Respiratory
Protection
Foot
Protection
Hearing
Protection
Head
Protection
Fall
Protection
Hand
Protection
• Wear clothing appropriate to the job.
• Remove all jewelry.
• Tie long hair up and back.
ST-0004–1
Follow Safety Instructions
• Carefully read all safety messages in this manual and safety
signs on your machine. Keep signs in good condition.
Replace missing or damaged safety signs. Be sure new
equipment components and repair parts include the current
safety signs. Replacement safety signs are available from
the manufacturer.
• Learn how to operate the machine and how to use controls
properly. Do not let anyone operate without instruction.
• If you do not understand any part of this manual or need
assistance, contact your dealer.
ST-0002–1
PNEG-2347 Cable Monitoring System 7

Chapter 1: Safety Precautions
Maintain Equipment and Work Area
• Understand service procedures before doing work. Keep
area clean and dry.
• Never service equipment while it is operating. Keep hands,
feet, and clothing away from moving parts.
• Keep your equipment in proper working condition. Replace
worn or broken parts immediately.
ST-0003–1
Install and Operate Electrical Equipment Properly
• Electrical controls must be installed by a qualified electrician
and must meet the standards set by applicable local codes
(National Electrical Code for the US, Canadian Electric
Code, or EN60204 along with applicable European Direc-
tives for Europe).
• Lock-out power source before making adjustments, cleaning,
or maintaining equipment.
• Make sure all equipment and bins are properly grounded.
ST-0075–1
Fall Hazard
• Ladders, stairways and platforms are for use by competent
and trained personnel only. Do not allow children or other
unauthorized persons to have access to the equipment.
• Access to the equipment must be restricted by the use of
security fencing and lockable gates.
• Lower sections of ladders must be fitted with a lockable
safety gate to prevent unauthorized access.
• Make sure that hot surfaces have had adequate time to cool
before working on or in the equipment.
• Lock out and tag out power supplies and fuel supplies to all
equipment.
• Do not attach lifting equipment to ladders or platforms.
• Do not go outside of the safety rails provided on elevated
platforms.
• Do not work at heights during high winds, rain, snow, or ice
storms.
ST-0056–1
8PNEG-2347 Cable Monitoring System

Chapter 1: Safety Precautions
Confined Space Hazards and Entry Procedures
• Note that the interior of this equipment is considered a con-
fined space. Maintenance of this equipment can require
access to the confined space.
• Access doors must be shut and locked except when access
is required.
• Doors giving access to dangerous equipment must be safety
interlocked.
• The following entry procedures must be followed:
— Be aware of all possible hazards present inside the con-
fined space and wear personal protective equipment
(PPE) as needed.
— Complete a permit to work and follow all permit required
confined space entry procedures defined by the site
manager.
— Make sure that the area has been purged of any hazard-
ous products or gases. Check the atmosphere for harm-
ful gases or vapors with a suitable gas analyzer and
make sure levels are safe before entering.
— Do not smoke or use naked flames.
— Lock out and tag out power supplies and fuel supplies to
all equipment.
— Do not work alone. Work in teams of at least three so
that help is immediately available in the event of an
emergency.
— Confirm that all personnel have safely exited the equip-
ment and tools have been recovered once work is
complete.
ST-0055–1
PNEG-2347 Cable Monitoring System 9

Chapter 1: Safety Precautions
Do Not Enter Bin
• Rotating flighting will kill or dismember.
• Flowing material will trap and suffocate.
• Crusted material will collapse and suffocate.
— If you must enter the bin:
1. Shut off and lock out all power sources.
2. Use a safety harness and safety line.
3. Station another person outside the bin.
4. Avoid the center of the bin.
5. Wear proper breathing equipment or respirator.
ST-0061–1
10 PNEG-2347 Cable Monitoring System

Chapter 1: Safety Precautions
Safety Decals
The safety decals on your equipment are safety indicators which must be carefully read and understood
by all personnel involved in the installation, operation, service and maintenance of the equipment.
To replace a damaged of missing decal, contact us to receive a free replacement.
GSI Decals
1004 E. Illinois Street
Assumption, IL 62510
Phone: [phone]
Location Decal No. Decal Description
Located next to
aeration system. DC-969 Caution Vacuum Pressure
On bin doors
and roof hatch
covers
DC-2483 Warning Entrapment Hazard
PNEG-2347 Cable Monitoring System 11

Chapter 1: Safety Precautions
Location Decal No. Decal Description
On bin door
covers DC-GBC-1A Warning Keep Clear of
Augers
On bin door
covers DC-GBC-2A Warning Unload Instructions
GrainVue fan
control 530-00147 Danger GrainViz Fan Safety
Text
12 PNEG-2347 Cable Monitoring System

Chapter 1: Safety Precautions
Operating Conditions
The GrainVue Cable Monitoring system has been designed to operate within the conditions outlined in
Table 1-2, page 13. Do not install or operate the GrainVue Cable Monitoring system in conditions that are
beyond what is listed below.
Table 1-2 System operating conditions
Operating Condition Designed for outdoor use
Operating Temperature -30°C to +50°C (-22°F to 122°F)
Storage Temperature -30°C to +50°C (-22°F to 122°F)
Operating Relative Humidity 0% to 95% non-condensing humidity
Altitude (Maximum) 2000 m (6561 ft.)
Minimum IP Rating IP54
Maintenance and Service
There are no user serviceable parts in the GrainVue Cable Monitoring system. Please contact the
manufacturer for all service inquiries.
Manufacturer
GSI Électronique Inc.
5200 Armand Frappier
St-Hubert, Quebec J3Z 1G5
Phone Number: 1-450-926-2777
Toll Free: 1-877-926-2777
PNEG-2347 Cable Monitoring System 13

Chapter 1: Safety Precautions
Safety Sign-off Sheet
Below is a sign-off sheet that can be used to verify that all personnel have read and understood the safety
instructions. This sign-off sheet is provided for your convenience and personal record keeping.
Date Employee Name Supervisor Name
ST-0007
14 PNEG-2347 Cable Monitoring System

2Gateway Installation
Topics Covered in this Chapter
▪ Gateway Installation — Overview
▪ Installing the Power Supply Unit (PSU)
▪ Installing the Gateway
Gateway Installation — Overview
The GrainVue outdoor communications gateway system comes with a pre-built and mounted MikroTik
LtAP unit. Throughout this section, various antennas will need to be installed and connected to this base
unit. A Gateway Power Supply Unit (PSU) is also provided to supply power remotely to the gateway over
standard, shielded category 5e data cable.
The maximum distance for gateway communications in a typical environment, with a clear line of sight,
should be no more than 2,000 m or 6,565 ft. Recommended installation locations for PSU(s) and
Gateway(s) are provided on a custom site map.
Installing the Power Supply Unit (PSU)
Before You Begin
Before installing the Gateway PSU, refer to all safety rating information below.
INPUTS:
SUPPLY INPUT: 100-240 VAC ±10%, 50-60 Hz, 1 phase, 40W
OUTPUTS: 24V DC/AC, 1.5A Max.
Operating Temperature -40°C to 40°C (-40°F to 104°F)
Storage Temperature -20°C to 50°C (-4°F to 122°F)
Environment Type Indoor and outdoor use
Pollution Degree 2
Installation Category 2
Altitude 2000 Meters Max. (6561 Ft. Max)
Operating Relative Humidity (Maximum)
• -40°C to 10°C (-40°F to 50°F) Non condensing
• 10°C to 30°C (50°F to 86°F) 95% (± 3%) Non
condensing
• 30°C to 40°C (86°F to 104°F) 95% (± 3%) Non
condensing
IP rating (IEC 60529) 66
Nema Rating (NEMA 250) 4X
IK rating (degree of mechanical protection - impact,
IEC 62262) 08
PNEG-2347 Cable Monitoring System 15

Chapter 2: Gateway Installation
What You Should Know
The Gateway PSU must be installed in a location that has sufficient air circulation around the box.
Minimum clearance is 22" W x 27" H to ensure protection against electrical conducted noise.
NOTE: Refer to the custom site map for the recommended PSU installation location.
1. Fasten two cable glands (31) into the pre-drilled holes in the Gateway PSU (2) enclosure.
NOTE: These cable glands (31) can be found packaged inside of the enclosure.
Figure 2-1 Installing the cable glands to the Gateway PSU enclosure
2Gateway PSU 31 Cable gland
2. Insert the provided ethernet cable (14) and power cable (15) through the cable glands (31) and
terminate them into the Gateway PSU PCBA terminal blocks. Refer to the Figure 2-2, page 16 and
Table 2-1, page 16 for proper cable mapping.
Figure 2-2 Gateway PSU PCBA terminal blocks
Table 2-1 Ethernet cable and power cable mapping details
Ethernet Cable (14) Blue/White + Blue +
Brown/White + Brown -
Power Cable (15)
Black L1
White N
Green Ground
16 PNEG-2347 Cable Monitoring System

Chapter 2: Gateway Installation
3. Using four self-tapping screws (1), mount the Gateway PSU (2) onto an appropriate structure in the
location designated on your custom site map.
Figure 2-3 Installing the Gateway PSU
1Self-tapping screws 14 Ethernet Cable
2Gateway PSU 15 Power Cable
4. Plug the Power Cable (15) connected to the Gateway PSU (2), into an available power outlet
on-site.
NOTE: The Ethernet Cable (14) will be connected in a later step.
Installing the Permanent Power Cable
WARNING
Only a certified electrician can complete the power supply installation. Make sure all
power sources are disconnected before performing any maintenance or service.
Always follow all national and local electrical and safety regulation for your area.
1. Disconnect and remove the temporary Power Cable (15) from the Gateway PSU (2) as shown in
Figure 2-2, page 16.
2. Remove the installed cable gland (31) from the Gateway PSU (2) as shown in Figure 2-1, page 16.
3. Replace the removed cable gland (31) with an outdoor rated conduit fitting.
4. Run outdoor rated #14-12 AWG cable through the conduit fitting to the terminal block connections
as shown in Figure 2-2, page 16.
5. Connect the outdoor rated cable to a circuit protected by a 15 Amp circuit breaker.
PNEG-2347 Cable Monitoring System 17

Chapter 2: Gateway Installation
Installing the Gateway
The Gateway assembly can be mounted multiple ways, choose an option that is best for your site
location. There are two gateway assembly variants that can be provided with GrainVue systems. Option 1
(KIT - Gateway Mounted Assembly, WiFi) is used for connection to a pre-established local WiFi network.
Option 2 (KIT - Gateway Mounted Assembly, Cell) is used for connection to a cellular network. The
appropriate kit(s) will be provided on a per-site basis. Step 4 is the only step in this portion of the
installation that will vary between the two kits.
1. Install the WiFi omni Antenna (4) onto the gateway top bracket (5) using the two pre-installed bolt
and nut sets (6).
Figure 2-4 Installing the WiFi antenna
4 WiFi omni antenna 6 Bolt and nut set
5Gateway top bracket
2. Install the LoRa antenna kit (7) onto the gateway top bracket (5) using the four pre-installed bolt,
washer and nut sets (6).
Figure 2-5 Installing the LoRa antenna kit
5Gateway top bracket 7LoRa antenna
6 Bolt, washer and nut set
18 PNEG-2347 Cable Monitoring System

Chapter 2: Gateway Installation
3. Install the ubiquiti pole (8) onto the gateway top bracket (5) using the three pre-installed U-bolt sets
(9).
Figure 2-6 Installing the ubiquiti pole
5Gateway top bracket 9 U-bolt set
8 Ubiquiti pole
4. Install the WiFi and cell gateway kits.
a. For cell gateway kits: Install the LTE omnidirectional antenna (10) onto the ubiquiti pole (8) using
the pre-installed gear clamp (11).
Figure 2-7 Installing the LTE antenna
8 Ubiquiti pole 11 Gear clamp
10 LTE omnidirectional antenna
PNEG-2347 Cable Monitoring System 19

Chapter 2: Gateway Installation
b. For Wifi gateway kits: Install the LPDA directional antenna (12) onto the ubiquiti pole (8) using
the pre-installed U-bolt set (9).
Figure 2-8 Installing the LPDA antenna
8 Ubiquiti pole 12 LPDA directional antenna
9 U-bolt set
5. Remove the bottom access door of the gateway and connect all installed antennas according to the
key below.
• PORT A <—> LoRa Antenna : Use the provided blue LoRa transmission line for connection
• PORT B <—> PoE (This connection will be done later)
• PORT C <—> Active GPS Antenna: Connected prior to shipping
• PORT D <—> LTE Omnidirectional Antenna OR LPDA Directional Antenna
— For LTE: Use the provided SMA Male to SMA Male cable for connection
— For LPDA: Use the provided N-Male to RP-SMA Male cable for connection
• PORT E <—> WiFi Omni Antenna: Use the SMA cable pre-connected to the WiFi Omni
Antenna for connection
Figure 2-9 Gateway port layout
